2009 INFINITI QX56 ECU

DLN-174
< DISASSEMBLY AND ASSEMBLY >[ATX14B]
TRANSFER ASSEMBLY
10. Install the new front oil seal until it is seated flush with the end
face of the front case using Tool.
CAUTION:
 Do not reuse oil seal.
 Apply petroleum jelly to oi l seal lip before installing.
11. Install the planetary carrier assembly and sun gear assembly to the front case using Tool.
12. Install the new snap ring to the sun gear. CAUTION:
Do not reuse snap ring.
13. Apply petroleum jelly to the circumference of the new oil seal, and install it to the front case using Tools.
CAUTION:
 Do not reuse oil seal.
 Apply petroleum jelly to oil seal.
14. Install the fork guide, shift fork spring, 2-4 fork, and L-H fork to the shift rod, and secure them with new retaining pins.
CAUTION:
Do not reuse retaining pins.Tool number : KV38100500 ( — )
SDIA3383E
Tool number : ST33200000 (J-26082)
SDIA2791E
SDIA2144E
Tool number A: ST30720000 (J-25405)
B: ST33200000 (J-26082)
Dimension : 4.0 - 4.6 mm (0.157 - 0.181 mm)
SDIA3191E
SDIA2142E
Revision: December 20092009 QX56

DLN-232
< DISASSEMBLY AND ASSEMBLY >[FRONT FINAL DRIVE: M205]
FRONT FINAL DRIVE
10. Install side bearing adjusters into gear carrier.
11. Apply differential gear oil to the side bearings, and install the dif-
ferential case assembly with the side bearing outer races into
the gear carrier.
CAUTION:
Do not reuse side bearing ou ter race when replacing side
bearing inner race (replace as a set).
12. Install the side bearing caps with the matching marks aligned. NOTE:
Do not tighten at this step. This allows further tightening of side
bearing adjusters.
13. Tighten each side bearing adjuster alternately turning drive gear.
14. Check and adjust tooth contact, backlash, drive gear runout and total preload torque.
Recheck above items.
 After adjusting tooth contact and backlash secure side bearing
adjuster with screws and tighten side bearing cap bolt to the
specified torque. Refer to DLN-217, "Disassembly and Assem-
bly".
15. Apply multi-purpose grease to the lips of the new side oil seal. Then drive the new side oil seal in evenly to
the gear carrier using suitable tool.
CAUTION:
 Do not reuse side oil seal.
 Do not incline the new side oil seal when installing.
 Apply multi-purpose grease to the lips of the new side oil seal.
SPD527
PDIA0700E
SDIA2265E
SDIA2263E
Revision: December 20092009 QX56

DLN-238
< PREPARATION >[REAR FINAL DRIVE: R230]
PREPARATION
PREPARATION
PREPARATION
Special Service ToolINFOID:0000000005877759
The actual shapes of Kent-Moore tool
s may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.)
Tool name Description
HT72400000
(—)
Slide hammer Removing differential case assembly
K V 1 0 1111 0 0
(J-37228)
Seal cutter Removing carrier cover
KV10112100
(BT-8653-A)
Angle wrench Tightening bolts for drive gear
KV38100200
(J-26233)
Drift Installing side oil seal
a: 65 mm (2.56 in) dia.
b: 49 mm (1.93 in) dia.
KV38100800
(J-25604-01)
Attachment Securing unit assembly
a: 541 mm (21.30 in)
b: 200 mm (7.87 in)
KV381054S0
(J-34286)
Puller Removing front oil seal
S-NT125
S-NT046
NT014
ZZA1143D
SDIA0267E
ZZA0601D
Revision: December 20092009 QX56

REAR FINAL DRIVEDLN-251
< REMOVAL AND INSTALLATION > [REAR FINAL DRIVE: R230]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
7. Place a suitable jack under the rear final drive assembly. CAUTION:
Do not place the jack on the carrier cover.
8. Remove the nuts and bolts and remove the rear final drive assembly.
CAUTION:
Secure rear final drive assembl y to the jack while removing
it.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
 When installing the breather hose make sure the pa inted marking on the metal end of breather hose
is to the front of the vehicle and there are no pinched or restricted areas on the breather hose
caused by folding or bend ing when installing it.
 When installing the breather hose insert the plastic end of the breather hose into the hole in the sus-
pension member.
WDIA0117E
Revision: December 20092009 QX56
