2009 INFINITI QX56 window

PWC-100
< SYMPTOM DIAGNOSIS >
REAR LH SIDE POWER WINDOW ALONE DOES NOT OPERATE
REAR LH SIDE POWER WINDOW ALONE DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000003776041
1. CHECK REAR POWER WINDOW SWITCH LH
Check rear power window switch LH.
Refer to PWC-15, "REAR POWER WINDOW SW ITCH : Component Function Check"
.
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair or replace the malfunctioning parts.
2. CHECK REAR POWER WINDOW MOTOR LH
Check rear power window motor LH.
Refer to PWC-20, "REAR LH : Component Function Check"
.
Is the inspection result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-38, "Intermittent Incident"
.
Revision: December 20092009 QX56

REAR RH SIDE POWER WINDOW ALONE DOES NOT OPERATE
PWC-101
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
REAR RH SIDE POWER WINDOW ALONE DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000003776042
1. CHECK REAR POWER WINDOW SWITCH RH
Check rear power winodw switch RH.
Refer to PWC-15, "REAR POWER WINDOW SWITCH : Component Function Check"
.
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair or replace the malfunctioning parts.
2. CHECK REAR POWER WINDOW MOTOR RH
Check rear power window motor RH.
Refer to PWC-21, "REAR RH : Component Function Check"
.
Is the inspection result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-38, "Intermittent Incident"
.
Revision: December 20092009 QX56

PWC-102
< SYMPTOM DIAGNOSIS >
ANTI-PINCH SYSTEM DOES NOT OPERATE NORMALLY (DRIVER SIDE)
ANTI-PINCH SYSTEM DOES NOT OPERATE NORMALLY (DRIVER SIDE)
Diagnosis ProcedureINFOID:0000000003776043
1. CHECK DOOR WINDOW SLIDING PART
 A foreign material adheres to window glass or glass run rubber.
 Glass run rubber wear or deformation.
 Sash is tilted too much or not enough.
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair or replace the malfunctioning parts.
2. CHECK ENCODER CIRCUIT
Check encoder circuit.
Refer to PWC-23, "DRIVER SIDE : Component Function Check"
.
Is the inspection result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-38, "Intermittent Incident"
.
Revision: December 20092009 QX56

ANTI-PINCH SYSTEM DOES NOT OPERATE NORMALLY (PASSENGER SIDE)
PWC-103
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
ANTI-PINCH SYSTEM DOES NOT OPERATE NORMALLY (PASSENGER
SIDE)
Diagnosis ProcedureINFOID:0000000003776044
1. CHECK DOOR WINDOW SLIDING PART
 A foreign material adheres to window glass or glass run rubber.
 Glass run rubber wear or deformation.
 Sash is tilted too much or not enough.
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair or replace the malfunctioning parts.
2. CHECK ENCODER CIRCUIT
Check encoder circuit.
Refer to PWC-25, "PASSENGER SIDE : Component Function Check"
.
Is the inspection result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-38, "Intermittent Incident"
.
Revision: December 20092009 QX56

PWC-104
< SYMPTOM DIAGNOSIS >
ANTI-PINCH SYSTEM DOES NOT OPERATE NORMALLY (REAR LH SIDE)
ANTI-PINCH SYSTEM DOES NOT OPER ATE NORMALLY (REAR LH SIDE)
Diagnosis ProcedureINFOID:0000000003776045
1. CHECK DOOR WINDOW SLIDING PART
 A foreign material adheres to window glass or glass run rubber.
 Glass run rubber wear or deformation.
 Sash is tilted too much or not enough.
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair or replace the malfunctioning parts.
2. CHECK ENCODER CIRCUIT
Check encoder circuit.
Refer to PWC-23, "DRIVER SIDE : Component Function Check"
.
Is the inspection result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-38, "Intermittent Incident"
.
Revision: December 20092009 QX56

ANTI-PINCH SYSTEM DOES NOT OPERATE NORMALLY (REAR RH SIDE)
PWC-105
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
ANTI-PINCH SYSTEM DOES NOT OPER ATE NORMALLY (REAR RH SIDE)
Diagnosis ProcedureINFOID:0000000003776046
1. CHECK DOOR WINDOW SLIDING PART
 A foreign material adheres to window glass or glass run rubber.
 Glass run rubber wear or deformation.
 Sash is tilted too much or not enough.
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair or replace the malfunctioning parts.
2. CHECK ENCODER CIRCUIT
Check encoder circuit.
Refer to PWC-23, "DRIVER SIDE : Component Function Check"
.
Is the inspection result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-38, "Intermittent Incident"
.
Revision: December 20092009 QX56

PWC-110
< SYMPTOM DIAGNOSIS >
POWER WINDOW RETAINED POWER OPERATION DOES NOT OPERATE
PROPERLY
POWER WINDOW RETAINED POWE R OPERATION DOES NOT OPER-
ATE PROPERLY
Diagnosis ProcedureINFOID:0000000003776051
1. CHECK FRONT DOOR SWITCH
Check front door switch.
Refer to PWC-34, "Component Function Check"
.
Is the inspection result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-38, "Intermittent Incident"
.
Revision: December 20092009 QX56

PWC-112
< SYMPTOM DIAGNOSIS >
KEYLESS POWER WINDOW DOWN DOES NOT OPERATE
KEYLESS POWER WINDOW DOWN DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000003776053
1. CHECK INTELLIGENT KEY FUNCTION
Check Intelligent Key function.
Refer to DLK-56, "CONSULT-III Func tion (INTELLIGENT KEY)"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-38, "Intermittent Incident".
NO >> Replace BCM. Refer to BCS-56, "Removal and Installation"
.
Revision: December 20092009 QX56
