2009 INFINITI QX56 key

DLK-174
< ECU DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY UNIT
Reference Value - Steering Lock Solenoid
INFOID:0000000003775827
TERMINAL LAYOUT
PHYSICAL VALUES
WIIA1169E
Te r m i n a l Wire
Color Signal Designation Condition
Voltage (V)Approx.
Ignition
Switch Posi- tion Operation or Conditions
1 G/Y Power source (fuse) LOCK —Battery voltage
2L/Y Steering lock solenoid
power supply LOCK
— 5
3L/O Steering lock solenoid
communication signal
LOCKWhen Intelligent Key is inside ve-
hicle, press ignition knob switch.
Other than the above
5
4B Steering lock solenoid
ground —— 0
SIIA1911J
Revision: December 20092009 QX56

INTELLIGENT KEY UNITDLK-175
< ECU DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Wiring Diagram — INTELLIGENT KEY SYSTEM —INFOID:0000000003775828
ABKWA0023GB
Revision: December 20092009 QX56

DLK-176
< ECU DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY UNIT
AAKWA0240GB
Revision: December 20092009 QX56

INTELLIGENT KEY UNITDLK-177
< ECU DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
ABKWA0025GB
Revision: December 20092009 QX56

DLK-178
< ECU DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY UNIT
ABKWA0026GB
Revision: December 20092009 QX56

INTELLIGENT KEY UNITDLK-179
< ECU DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
ABKWA0027GB
Revision: December 20092009 QX56

DLK-180
< ECU DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY UNIT
ABKIA0067GB
Revision: December 20092009 QX56

INTELLIGENT KEY UNITDLK-181
< ECU DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
AAKIA0059GB
Revision: December 20092009 QX56
