2009 INFINITI QX56 height

FRONT FINAL DRIVEDLN-227
< DISASSEMBLY AND ASSEMBLY > [FRONT FINAL DRIVE: M205]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
2. Using feeler gauges, measure the clearance between the side gear back and differential case at three different points, while
rotating the side gear. Average the three readings to calculate
the clearance. (Measure the clearanc e of the other side as well.)
 If the side gear back clearance is outside of the specification, use a thicker or thinner side gear thrust washer to adjust.
Refer to DLN-234, "Inspection and Adjustment"
.
CAUTION:
 Insert feeler gauges with the same thickness on both
sides to prevent side gear from tilting.
 Each gear should rotate smoothly without excessive
resistance during differential motion.
 Select a side gear thrust washer for right and left individually.
NOTE:
Side gear back clearance is clearance between side gear and differential case for adjusting side gear
backlash.
Drive Pinion Height
 Drive gear and drive pinion are supplied in matched sets only.
Matching numbers on both drive pinion and drive gear are etched
for verification. If a new gear set is being used, verify the numbers
of each drive pinion and drive gear before proceeding with assem-
bly.
 The mounting distance from the centerline of the drive gear to the back face of the drive pinion for the M205
final drive assembly is 103.5 mm (4.0748 inches).
On the button end of each drive pinion, there is etched a plus (+) number, a minus (-) number, or a zero (0),
which indicates the best running position for each partic ular gear set. This dimension is controlled by a
selective drive pinion height adjusting washer between t he drive pinion rear bearing inner race and drive pin-
ion.
For example: If a drive pinion is etched m+8 (+3), it would require 0.08 mm (0.003 inch) less drive pinion
height adjusting washer than a drive pinion etched “0”. This means decreasing drive pinion height adjusting
washer thickness; increases the m ounting distance of the drive pinion to 103.6 mm (4.0778 inches). If a
drive pinion is etched m-8 (-3), it would require adding 0.08 mm (0.003 inch) more to the drive pinion height
adjusting washer than would be required if the drive pinion were etched “0”. By adding 0.08 mm (0.003 inch),
the mounting distance of the drive pinion was decreased to 103.4 mm (4.0718 inches) which is just what a
m-8 (-3) etching indicated.
 To change the drive pinion height, use different drive pinion height adjusting washers which come in different thickness.
 Use the following tables as a guide for selecting the correct drive pinion height adjusting washer thickness to
add or subtract from the old drive pinion height adjusting washer. Side gear back
clearance
: Refer to
DLN-234, "Inspection
and Adjustment"
If the side gear back clearance is greater than
specification:
Use a thicker side gear thrust washer.
If the side gear back clearance is less than spec-
ification: Use a thinner side gear thrust washer.
PDIA0576E
SDIA2241E
Revision: December 20092009 QX56

DLN-228
< DISASSEMBLY AND ASSEMBLY >[FRONT FINAL DRIVE: M205]
FRONT FINAL DRIVE
ASSEMBLY
Drive Pinion Assembly
1. Install drive pinion rear bearing outer race using Tools.
2. Install drive pinion front bearing outer race using Tools.
3. Select drive pinion height adjusting washer.
OLD DRIVE
PINION
MARKING NEW DRIVE PINION MARKING mm (in)
-10 (-4) -8 (-3) -5 (-2) -3 (-1) 0 (0) + 3 (+1) +5 (+2) +8 (+3) +10 (+4)
+10 (+4) +0.20
(+0.008) +0.18
(+0.007) +0.15
(+0.006) +0.13
(+0.005) +0.10
(+0.004) +0.08
(+0.003) +0.05
(+0.002) +0.02
(+0.001) 0
(0)
+8 (+3) +0.18
(+0.007) +0.15
(+0.006) +0.13
(+0.005) +0.10
(+0.004) +0.08
(+0.003) +0.05
(+0.002) +0.02
(+0.001) 0
(0) -0.02
(-0.001)
+5 (+2) +0.15
(+0.006) +0.13
(+0.005) +0.10
(+0.004) +0.08
(+0.003) +0.05
(+0.002) +0.02
(+0.001) 0
(0) -0.02
(-0.001) -0.05
(-0.002)
+3 (+1) +0.13
(+0.005) +0.10
(+0.004) +0.08
(+0.003) +0.05
(+0.002) +0.02
(+0.001) 0
(0) -0.02
(-0.001) -0.05
(-0.002) -0.08
(-0.003)
0 (0) +0.10
(+0.004) +0.08
(+0.003) +0.05
(+0.002) +0.02
(+0.001) 0
(0) -0.02
(-0.001) -0.05
(-0.002) -0.08
(-0.003) -0.10
(-0.004)
-3 (-1) +0.08
(+0.003) +0.05
(+0.002) +0.02
(+0.001) 0
(0) -0.02
(-0.001) -0.05
(-0.002) -0.08
(-0.003) -0.10
(-0.004) -0.13
(-0.005)
-5 (-2) +0.05
(+0.002) +0.02
(+0.001) 0
(0) -0.02
(-0.001) -0.05
(-0.002) -0.08
(-0.003) -0.10
(-0.004) -0.13
(-0.005) -0.15
(-0.006)
-8 (-3) +0.02
(+0.001) 0
(0) -0.02
(-0.001) -0.05
(-0.002) -0.08
(-0.003) -0.10
(-0.004) -0.13
(-0.005) -0.15
(-0.006) -0.18
(-0.007)
-10 (-4) 0
(0) -0.02
(-0.001) -0.05
(-0.002) -0.08
(-0.003) -0.10
(-0.004) -0.13
(-0.005) -0.15
(-0.006) -0.18
(-0.007) -0.20
(-0.008)
Tool number A: ST30901000 ( — )
B: KV40105230 ( — )
SDIA2251E
Tool number A: ST35271000 ( — )B: KV40104810 ( — )
SDIA2252E
Revision: December 20092009 QX56

FRONT FINAL DRIVEDLN-229
< DISASSEMBLY AND ASSEMBLY > [FRONT FINAL DRIVE: M205]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
4. Install the selected drive pinion height adjusting washer to the drive pinion. Press the drive pinion rear bearing inner race to it
using Tool.
CAUTION:
Do not reuse drive pinion rear bearing inner race.
5. Install the collapsible spacer to the drive pinion. CAUTION:
Do not reuse collapsible spacer.
6. Apply differential gear oil to the drive pinion rear bearing, and install the drive pinion assembly to the gear carrier.
7. Apply differential gear oil to the drive pinion front bearing, and install the drive pinion front bearing inner race to the drive pinion
assembly.
CAUTION:
Do not reuse drive pinion front bearing inner race.
8. Apply multi-purpose grease to the lips of the new front oil seal.
Then drive the new front oil seal in evenly using Tools.
CAUTION:
 Do not reuse front oil seal.
 Do not incline the new fron t oil seal when installing.
 Apply multi-purpose grease to th e lips of the new front oil
seal.
9. Install the companion flange to the drive pinion while aligning the matching marks. Tap the companion flange until fully seated
using suitable tool.Tool number : — (C-4040)
SDIA2253E
PDIA0708E
Tool number A: KV38100500 (J-25273)
B: KV38102200 ( — )
PDIA0717E
SDIA2266E
Revision: December 20092009 QX56

DLN-234
< SERVICE DATA AND SPECIFICATIONS (SDS) [FRONT FINAL DRIVE: M205]
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
General SpecificationINFOID:0000000004193547
Inspection and AdjustmentINFOID:0000000004193548
DRIVE GEAR RUNOUT
Unit: mm (in)
SIDE GEAR CLEARANCE
Unit: mm (in)
PRELOAD TORQUE
Unit: N·m (kg-m, in-lb)
BACKLASH
Unit: mm (in)
COMPANION FLANGE RUNOUT
Unit: mm (in)
SELECTIVE PARTS
Drive Pinion Height Adjusting Washer
Applied model4WD
VK56DE
A/T
Final drive model M205
Gear ratio 3.357
Number of teeth (Drive gear/Drive pinion) 47/14
Differential gear oil capacity (Approx.) 1.6 (3 3/8 US pt, 2 7/8 Imp pt)
Number of pinion gears 2
Drive pinion adjustment spacer type Collapsible
Item Limit
Drive gear back face 0.08 (0.0031) or less
Item Standard
Side gear back clearance (Clearance between side gear and dif-
ferential case for adjusting side gear backlash) 0.20 (0.0079) or less
(Each gear should rotate smoothly without excessive resistance during differential motion.)
Item Standard
Drive pinion bearing preload torque 2.3 - 3.4 (0.24 - 0.34, 21 - 30)
Total preload torque
(Total preload torque = drive pinion bearing preload torque + side
bearing preload torque). 2.98 - 4.76 (0.31 - 0.48, 27 - 42)
Item Standard
Drive gear to drive pinion backlash 0.12 - 0.20 (0.0050 - 0.0078)
Item Limit
Companion flange face 0.10 (0.0039) or less
Companion flange inner side 0.13 (0.0051) or less
Revision: December 20092009 QX56

DLN-254
< DISASSEMBLY AND ASSEMBLY >[REAR FINAL DRIVE: R230]
REAR FINAL DRIVE
ASSEMBLY INSPECTION AND ADJUSTMENT
 Drain the differential gear oil before inspection and adjustment. Refer to
DLN-244, "Changing Differential
Gear Oil".
 Remove and install the carrier cover as neces sary for inspection and adjustment. Refer to DLN-249,
"Removal and Installation".
Total Preload Torque
1. Remove the side flanges if necessary. Refer to DLN-247, "Removal and Installation".
CAUTION:
The side flanges must removed in or der to measure total preload torque.
2. Rotate the drive pinion back and forth 2 to 3 times to check for unusual noise and rotation malfunction.
3. Rotate the drive pinion at least 20 times to check for smooth operation of the bearings.
4. Measure the total preload torque using Tool.
NOTE:
Total preload torque = Drive pinion bearing preload torque +
Side bearing preload torque
 If the measured value is out of the specification, check and adjust each part. Adjust the drive pinion
bearing preload torque first, then adjust the side bearing preload torque.
CAUTION:
Select a side bearing adjusting wash er for right and left individually.
Drive Gear Runout
1. Drive pinion lock nut 2. Companion flange 3. Front oil seal
4. Drive pinion front bearing 5. Collapsible spacer 6. Drive pinion rear bearing
7. Drive pinion height adjusting washer 8. Drive pinion 9. Gear carrier
10. Drive gear 11. Pinion mate shaft 12. Lock pin
13. Pinion mate gear 14. Pinion mate thrust washer 15. Side gear
16. Side gear thrust washer 17. Differential case 18. Side bearing
19. Side bearing adjusting washer 20. Bearing cap 21. Carrier cover
22. Filler plug 23. Drain plug 24. Side oil seal
Tool number : ST3127S000 (J-25765-A)
Total preload torque
: Refer to DLN-270, "Inspection and Adjustment"
SPD884
If the total preload torque is greater than specification
On drive pinion bearings: R eplace the collapsible spacer.
On side bearings: Use thinner side b earing adjusting washers by the same
amount on each side. Refer to DLN-270, "Inspection and Adjust-
ment".
If the total preload torque is less than specification On drive pinion bearings: Tighten the drive pinion lock nut.
On side bearings: Use thicker side b earing adjusting washers by the same
amount on each side. Refer to DLN-270, "Inspection and Ad-
justment".
Revision: December 20092009 QX56

REAR FINAL DRIVEDLN-255
< DISASSEMBLY AND ASSEMBLY > [REAR FINAL DRIVE: R230]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
1. Fit a dial indicator to the drive gear back face.
2. Rotate the drive gear to measure runout.
 If the runout is outside of the limit , check the condition of the drive
gear assembly. Foreign material may be caught between the drive
gear and differential case, or the differential case or drive gear may
be deformed.
CAUTION:
Replace drive gear and drive pinion as a set.
Tooth Contact
1. Apply red lead to the drive gear. NOTE:
Apply red lead to both faces of thr ee to four gears, at four loca-
tions evenly spaced on the drive gear.
2. Rotate the drive gear back and forth several times. Then check for correct drive pinion to drive gear tooth contact as shown.
CAUTION:
Check tooth contact on dri ve side and reverse side.
3. If the tooth contact is improper ly adjusted, follow the procedure
below to adjust the pinion height (dimension X). Runout limit : Refer to
DLN-270, "Inspection
and Adjustment"
SPD886
SPD357
SDIA0570E
SDIA0517E
Revision: December 20092009 QX56

DLN-256
< DISASSEMBLY AND ASSEMBLY >[REAR FINAL DRIVE: R230]
REAR FINAL DRIVE
 If the tooth contact is near the face (face contact), or near the heel
(heel contact), use a thicker drive pinion height adjusting washers
to move the drive pinion closer to the drive gear.
Refer to DLN-270, "Inspection and Adjustment"
.
 If the tooth contact is near the flank (flank contact), or near the toe (toe contact), use a thinner drive pinion height adjusting washers to
move the drive pinion farther from the drive gear.
Refer to DLN-270, "Inspection and Adjustment"
.
Backlash
1. Fit a dial indicator to the drive gear face to measure the back-
lash.
 If the backlash is outside of the specification, change the thickness of the side bearing adjusting washers.
CAUTION:
Do not change the total thickness of side bearing adjusting washers as it will change the side bearing
preload torque.
Companion Flange Runout
PDIA0440E
PDIA0441E
Backlash : Refer to DLN-270, "Inspection and
Adjustment"
If the backlash is greater than specification:
Make side bearing adjusting washer thicker on drive
gear back side, and side bearing adjusting washer
thinner on drive gear toot h side by the same amount.
Refer to DLN-270, "Inspection and Adjustment"
.
If the backlash is less than specification: Make side bearing adjusting washer thinner on drive
gear back side, and side bearing adjusting washer
thicker on drive gear tooth side by the same amount.
Refer to DLN-270, "Inspection and Adjustment"
.
SPD513
Revision: December 20092009 QX56

REAR FINAL DRIVEDLN-261
< DISASSEMBLY AND ASSEMBLY > [REAR FINAL DRIVE: R230]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
5. Press the drive pinion assembly (with rear inner bearing race and collapsible spacer) out of the gear carrier.
CAUTION:
Do not drop drive pinion assembly.
6. Remove the front oil seal. CAUTION:
Do not damage gear carrier.
7. Remove the drive pinion front bearing inner race.
8. Remove the drive pinion rear bearing inner race and drive pinion height adjusting washer using Tool.
9. Remove the drive pinion front and rear bearing outer races by tapping them uniformly using suitable tool.
CAUTION:
Do not damage gear carrier.
INSPECTION AFTER DISASSEMBLY
Clean the disassembled parts. Then inspect the parts fo r wear or damage. If wear or damage are found, follow
the measures below.
Drive Pinion and Drive Gear
 If the drive pinion and drive gear teeth do not mesh or line-up correctly, determine the cause and adjust, repair, or replace as necessary.
 If the drive pinion or drive gear are worn, crack ed, damaged, pitted or chipped (by friction) noticeably,
replace with new drive pinion and drive gear.
 Drive pinion and drive gear are supplied in matched sets only. Matching numbers on both drive pinion and
drive gear are etched for verification. If a new drive pinion and drive gear set are being used, verify the num-
bers of each drive pinion and drive gear before proceeding with assembly.
Bearing
 If bearings are chipped (by friction), pitted, worn, rust ed, scratched, or unusual noise is coming from bearing,
replace with new bearing assembly (as a new set).
 Bearing must be replaced with a new one whenever disassembled.
Side Gear and Pinion Mate Gear
 If any cracks or damage are found on the surf ace of the teeth, replace with new one.
 If any worn or chipped marks are found on the side of the side gear and pinion mate gear which contact the
thrust washer, replace with new one.
 Replace both side gear and pinion mate gear as a set when replacing side gear or pinion mate gear.
Side Gear Thrust Washer and Pinion Mate Thrust Washer
 If any chips (by friction), damage, or unus ual wear are found, replace with new one.
SPD892
Tool number: : ST30031000 (J-22912-01)
S-PD179
SDIA0817E
Revision: December 20092009 QX56
