2009 HONDA ODYSSEY service indicator

2009 Odyssey Online Reference Owner's Manual
Contents

Owner's Identification Form

Introduction .......................................................................................................................................................... i A Few Words About Safety .............................................................................................................................. iii
Your Vehicle at a Glance (main controls) ...................................................................................................... 3
Driver and Passenger Safety (seat belts, SRS, and child protection) .......................................................... 5
Instruments and Controls (indicators, gauges, dashboard, and steering column) ......................................... 63
Features (climate control, audio, steering wheel, rear entertainment, security, cruise control and HomeLink® )....... 209
Before Driving (fuel, vehicle break- in, and cargo loading) ............................................................................ 367
Driving (engine and transmission operation) ...................................................................................................... 383
Maintenance (minder, fluid checking, minor services, and vehicle storage)...................................................... 413
Taking Care of the Unexpected (flat tire, dead battery, overheating, and fuses) ..................................... 461
Technical Information (vehicle specifications, tires, and emissions controls) ................................................ 491
Warranty and Customer Relations (U. S. and Canada only) (warranty and contact information) ......... 509
Authorized Manuals (U. S. only) (how to order) ........................................................................................... 513
Index ............................................................................................................................... ...................................... I

Service Information Summary ( fluid capacities and tire pressures)

1
00X31-SHJ-6400

A convenient ref erence to the
sections in this manual.
A quick ref erence to the main
controls in your vehicle.
Explains the purpose of each
instrument panel indicator and gauge,
and how to use the controls on the
dashboard and steering column.ID numbers, dimensions, capacities,
and technical information.
How to order manuals and other
technical literature.
A summary of the inf ormation you
need when you pull up to the f uel
pump.
Important inf ormation about the
proper use and care of your vehicle’s
seat belts, an overview of the
supplemental restraint system, and
valuable inf ormation on how to
protect children with child restraints.
How to operate the heating and
cooling system/climate control
system, the audio system, rear
entertainment and other convenience f eatures.
This section covers several problems
motorists sometimes experience,
and details how to handle them.
The maintenance minder shows you
when you need to take your vehicle
to the dealer for maintenance service.
There is also a list of things to check
and instructions on how to check
them.
The proper way to start the engine,
shif t the transmission, and park; plus
what you need to know if you’re
planning to tow a trailer.
What gasoline to use, how to break-
in your new vehicle, and how to load
luggage and other cargo.
A summary of the warranties
covering your new vehicle, and how
to contact us for any reason. Refer to
your warranty manual f or detailed
inf ormation.
Contents
Your Vehicle at a Glance
Driver and Passenger Saf ety
Instruments and Controls
Features T echnical Inf ormation
Warranty and Customer
Relations
(U.S. and Canada only)
Authorized Manuals
(U.S. only)
Index
Service Inf ormation Summary
T aking Care of the Unexpected
Maintenance
Driving
Bef ore Driving
Overview of Contents
2
\f—\f—
y


y
(\fy\f\f\fy
2009 Odyssey

µ
This section gives you important
inf ormation about how to protect
yourself and your passengers. It
shows you how to use seat belts. It
explains how your airbags work. And
it tells you how to properly restrain
inf ants and children in your vehicle.
.........
Important Safety Precautions .6
.......
Your Vehicle’s Saf ety Features .7
.......................................
Seat Belts .8
...........................................
Airbags .9
.........
Protecting Adults and Teens .11
.....
1. Close and Lock the Doors .11
...........
2. Adjust the Front Seats .12
............
3. Adjust the Seat-Backs .13
...
4. Adjust the Head Restraints .14
5. Fasten and Position the Seat
.....................................
Belts .15
6. Maintain a Proper Sitting ................................
Position .18
.....
Advice f or Pregnant Women .19
...
Additional Safety Precautions .19 Additional Inf ormation About Your
.................................
Seat Belts .21
..
Seat Belt System Components .21
......................
Lap/Shoulder Belt .22
Automatic Seat Belt .............................
Tensionners .23
...............
Seat Belt Maintenance .24
Additional Inf ormation About Your .....................................
Airbags .25
......
Airbag System Components .25
How Your Front Airbags
.........................................
Work .27
...
How Your Side Airbags Work .31
How Your Side Curtain Airbags
.........................................
Work .33
..
How the SRS Indicator Works .34
How the Side Airbag Of f
......................
Indicator Works .35
How the Passenger Airbag ...............
Of f Indicator Works .35
.............................
Airbag Service .36
...
Additional Safety Precautions .37
Protecting Children General ................................
Guidelines .38
All Children Must Be ...............................
Restrained .38All Children Should Sit in a Back
...........................................
Seat .39
The Passenger’s Front Airbag .........
Can Pose Serious Risks .39
If You Must Drive with .....................
Several Children .41
If a Child Requires Close ..................................
Attention .41
...
Additional Safety Precautions .41
Protecting Inf ants and Small ...................................
Children .43
.......................
Protecting Inf ants .43
.........
Protecting Small Children .44
.....................
Selecting a Child Seat .46
....................
Installing a Child Seat .47
...............................
With LATCH .48
.........
With a Lap/Shoulder Belt .51
..............................
With a Tether .53
...........
Protecting Larger Children .56
...............
Checking Seat Belt Fit .56
..................
Using a Booster Seat .57
When Can a Larger Child Sit in
.........................................
Front .58
...
Additional Safety Precautions .59
.............
Carbon Monoxide Hazard .60
...................................
Saf ety Labels .61
Driver and Passenger Saf ety
Driver and Passenger Saf ety
5
——
y


y
(y
y
2009 Odyssey

Do not try to remove or replace
anyairbagbyyourself.Thismust
be done by an authorized dealer or
a knowledgeable body shop.
Your airbag systems are virtually
maintenance f ree, and there are no
parts you can saf ely service.
However, you must have your
vehicle serviced if:
If the indicator comes on with no
f ront seat passenger and no objects
on the seat, or with an adult riding
there, something may be interf ering
with the weight sensors. Look f or
and remove:
Any items under the f ront
passenger’s seat.
Any object(s) hanging on the seat
or in the seat-back pocket.
Any object(s) touching the rear of
the seat-back. Any airbag
that has deployed must be
replaced along with the control
unit and other related parts. Any
seat belt tensioner that activates
must also be replaced. Take your vehicle to an
authorized dealer as soon as
possible. If you ignore this
indication, your airbags may not
operate properly.
Even if your
airbags do not inflate, your dealer
should inspect the driver’s seat
position sensor, the f ront
passenger’s weight sensors, the
f ront seat belt tensioners, and all
seat belts and their anchors worn
during a crash to make sure they
are operating properly.
If no obstructions are f ound, have
your vehicle checked by a dealer as
soon as possible.
Additional Inf ormation About Your Airbags
Airbag Service
An airbag ever inf lates. T he SRS indicat or alert s you t o a
problem.
If your vehicle has a moderat e t osevere impact .
36
\f—\f—
y



y
(\fy\f\f
y
2009 Odyssey

This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position. If it comes on while driving,
it indicates that one or more of your
vehicle’s tires are signif icantly low
on pressure.
If this happens, pull to the side of the
road when it is saf e, check which tire
has lost the pressure, and determine
the cause. If it is because of a flat tire,
replace the flat tire with the compact
spare (see page ), and have the
f lat tire repaired as soon as possible.
If two or more tires are underinf lated,
call a prof essional towing service
(see page ). For more
inf ormation, see page .If this happens, pull to the side of the
road when it is saf e, check which tire
has lost pressure on the multi-
inf ormation display, and determine
the cause. If it is because of a flat tire,
have the flat tire repaired as soon as
possible. If two or more tires are
underinf lated, call a prof essional
towing service. For more
inf ormation, see page .
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position.
This indicator has two f unctions:
If it comes on while driving, it
indicates that one or more of your
vehicle’s tires are signif icantly low
on pressure.
You will also see a ‘‘CHECK TIRE
PRESSURE’’ message on the multi-
inf ormation display (see page ).
Check the tire pressure monitor on
the multi-inf ormation display and
determinethecause(seepage ). Your vehicle has Michelin PAX tires.
Repair or replacement of PAX tires
must be done by a Honda dealer or
an authorized Michelin PAX system
dealer. For more inf ormation, see
page .
1.
88
465
488 396 401488
457
CONT INUED
On LX, EX, EX-L and Canadian DX models On Touring models
U.S. models with the Michelin
PAX
system
Instrument Panel Indicators
Low Tire Pressure
IndicatorLow Tire Pressure/
TPMS Indicator
Inst rument s and Cont rols
71
——
y

y
(yy
2009 Odyssey

This indicator comes on f or a f ew
seconds when you turn the ignition
switch to the ON (II) position. It
remindsyouthatitistimetotake
your vehicle in f or scheduled
maintenance. The maintenance main
items and sub items will be displayed
in the inf ormation display. See pagef or more inf ormation on the
maintenance minder.
This indicator goes of f when your
dealer resets it after completing the
required maintenance service. This indicator comes on when there
is a system message on the multi-
inf ormation display. Press the INFO
button on the steering wheel (see
page ) to see the message (see
page ).
Most of the time, this indicator
comes on along with other indicators
in the instrument panel such as the
seat belt reminder indicator, SRS
indicator, VSA system indicator, etc.
This indicator comes on when the
security system is set. For more
inf ormation, see page .318
82
87
415
On LX, EX, EX-L and Canadian DX models On Touring modelsOn EX, EX-L and Touring models
Instrument Panel Indicators
Maintenance Minder
Indicator
System Message
IndicatorSecurity System Indicator
76
SECURITY SYSTEM INDICATOR
\f—\f—
y


y
(\fy\f\f
y
2009 Odyssey

The inf ormation display in the
instrument panel shows you the
engine oil lif e and maintenance
service items when the ignition
switch is in the ON (II) position. This
inf ormation helps to keep you aware
of the periodic maintenance your
vehicle needs f or continued trouble-
f ree driving. Ref er to page f or
more inf ormation.Your vehicle’s onboard diagnostic
system will detect a loose or missing
f uel f ill cap as an evaporative system
leak. The f irst time a leak is detected
a ‘‘CHECK FUEL CAP’’ message
appears on the information display.
Turn the engine of f , and conf irm the
f uel f ill cap is installed. If it is, loosen
it, then retighten it until it clicks at
least once. The message should go
off after several days of normal
driving once you tighten or replace
the f uel f ill cap. To scroll to another
display, press the select/reset knob.
The ‘‘CHECK FUEL CAP’’ message
will appear each time you restart the
engine until the system turns the
message of f .If the system still detects a leak in
your vehicle’s evaporative emissions
system, the malf unction indicator
lamp (MIL) comes on. If the f uel f ill
cap was not already tightened, turn
the engine of f , and check or
retighten the f uel f ill cap until it
clicks at least once. The MIL should
go off after several days of normal
driving once the cap is tightened or
replaced. If the MIL does not go of f ,
have your vehicle inspected by a
dealer. For more inf ormation, see
page .
415
480
Gauges
Maintenance MinderCheck Fuel Cap Message
80
\f—\f—
y

y
(\fy\f\fy
2009 Odyssey

Help assure your vehicle’s f uture
reliability and perf ormance by paying
extra attention to how you drive
during the f irst 600 miles (1,000 km).
During this period:Avoid full-throttle starts and rapid
acceleration.
Avoidhardbrakingforthefirst
200 miles (300 km).
Do not change the oil until the
scheduled maintenance time.
You should also f ollow these
recommendations with an
overhauled or exchanged engine, or
when the brakes are replaced. Do not tow a trailer.
In addition, in order to maintain good
perf ormance, f uel economy, and
emissions control, we strongly
recommend, in areas where it is
available, the use of gasoline that
does NOT contain manganese-based
f uel additives such as MMT.
Your vehicle is designed to operate
on unleaded gasoline with a pump
octane number of 87 or higher. Use
of a lower octane gasoline can cause
a persistent, heavy, metallic rapping
noise that can lead to engine damage.
Some gasoline today is blended with
oxygenates such as ethanol or
MTBE. Your vehicle is designed to
operate on oxygenated gasoline
containing up to 10% ethanol by
volume and up to 15% MTBE by
volume. Do not use gasoline
containing methanol.
If you notice any undesirable
operating symptoms, try another
service station or switch to another
brand of gasoline.
For f urther important f uel-related
inf ormation, please ref er to your.
Use of gasoline with these additives
may adversely af f ect perf ormance,
and cause the Malfunction Indicator
Lamp on your instrument panel to
come on. If this happens, contact
your dealer f or service.
We recommend using quality
gasolines containing detergent
additives that help prevent fuel
system and engine deposits.
Break-in Period
Fuel Recommendation
Quick Start Guide
Break-in Period, Fuel Recommendation
368
\f—\f—
y
\f\fy
(\fy\fy
2009 Odyssey
