2009 HONDA ACCORD SEDAN wiper blades

This section explains why it is
important to keep your vehicle well
maintained and how to f ollow basic
maintenance saf ety precautions.
This section also includes
instructions on how to read the
maintenance minder messages on
the information display, and
instructions f or simple maintenance
tasks you may want to take care of
yourself .
If you have the skills and tools to
perf orm more complex maintenance
tasks on your vehicle, you may want
to purchase the service manual. See
page f or inf ormation on how to
obtain a copy, or see your dealer.......................
Maintenance Saf ety .306
....................
Maintenance Minder .307
..............................
Fluid Locations .314
........................
Adding Engine Oil .316
Changing the Engine Oil and ...........................................
Filter .318
..............................
Engine Coolant .320
....................
Windshield Washers .322
.......................
Transmission Fluid .323
..........
Automatic Transmission .323
..............
Manual Transmission .325
................
Brake and Clutch Fluid .326
................................
Brake Fluid .326
...............................
Clutch Fluid .327
....................
Power Steering Fluid .327
....................................
Timing Belt .328
.............................................
Lights .329
................
Cleaning the Seat Belts .338
.....................................
Floor Mats .338
..................
Dust and Pollen Filter .339
.................................
Wiper Blades .340
...............................................
Tires .343
...................
Checking the Battery .351
.............................
Vehicle Storage .352
403
Maintenance
Maint enance
305
\f—\f—\fy
\fy
)\f
\fy\f
\fy
2009 Accord Sedan

Fill the reservoir with a good-quality
windshield washer f luid. This
increases the cleaning capability and
prevents f reezing in cold weather.
When you ref ill the reservoir, clean
the edges of the windshield wiper
blades with windshield washer f luid
on a clean cloth. This will help to
condition the blade edges.
Check the level in the windshield
washer reservoir at least monthly
during normal use.
Check the f luid level by removing
the cap and looking at the level
gauge.
The washer level indicator will come
on when the level is low (see page
).
62
Canadian models only
Windshield Washers
322
LEVEL GAUGE
V6 models LEVEL GAUGE
2.4
engine models
Do not use engine antif reeze or a
vinegar/water solution in the
windshield washer reservoir. Antif reeze
can damage your vehicle’s paint, while
a vinegar/water solution can damage
the windshield washer pump. Use only
commercially-available windshield
washer f luid.
\f—\f—\fy
\fy
)\f
\fy\fy
2009 Accord Sedan

To replace a wiper blade:Raise the wiper arm of f the
windshield. Raise the driver’s side
first, then the passenger’s side.
Check the condition of the wiper
blades at least every six months.
Replace them if you f ind signs of
cracking in the rubber, areas that are
getting hard, or if they leave streaks
and unwiped areas when used.
Disconnect the blade assembly
from the wiper arm:
Put a cloth on the edge of the lock
tab, then push up on the lock tab
caref ully with a f lat-tip screwdriver.
2.
1.
Wiper Blades
340
WIPER ARMS
LOCK TAB
Do not open the hood when the wiper
arms are raised, or you will damage the
hood and wiper arms.
\f—\f—\fy
y
)\f
\fy\fy
2009 Accord Sedan

Pivot the blade assembly toward
the wiper arm until it releases
from the wiper arm.
When replacing a wiper blade,
make sure not to drop the wiper
blade or wiper arm down on the
windshield.Examine the new wiper blades. If
they have no plastic or metal
reinf orcement along the back
edge, remove the metal
reinf orcement strips f rom the old
wiper blade, and install them in
the slots along the edge of the new
blade.
Make sure the three rubber tabs
inside the blade f it to each notch of
the reinf orcement, as shown.
Remove the blade f rom its holder
by grabbing the tabbed end of the
blade. Pull f irmly until the tabs
come out of the holder.
3. 4.
CONT INUED
Wiper Blades
Maint enance
341
BLADE
BLADE
REINFORCEMENT
WIPER ARM
TOP
\f—\f—\fy
y
)\f
\fy\fy
2009 Accord Sedan

Place the top of the wiper blade on
the end of the blade assembly, and
slide the blade onto the assembly
in the direction pointed to by the
arrow.Slide the wiper blade assembly
onto the wiper arm. Push down
thelocktab.Makesurethewiper
blade assembly locks in place.
Lower the wiper arm down against
the windshield, the passenger’s
side first, then the driver’s side.
Make sure the tab on the blade
assembly fits in the indent of the
wiper blade and the blade is
completely installed.
5. 6.
7.
Wiper Blades
342
INDENT
TAB
