2009 HONDA ACCORD SEDAN brake light

This section gives inf ormation about
the controls and displays that
contribute to the daily operation of
your vehicle. All the essential
controls are within easy reach............................
Control Locations .54
............................
Instrument Panel .55
..........
Instrument Panel Indicators .56
.............................................
Gauges .63
....................
Inf ormation Display .64 .....................................
Odometer .64
Outside Temperature ...................................
Indicator .65
...................................
Trip Meter .65
..........
Check Fuel Cap Message .66
..................
Maintenance Minder .66
...................
Temperature Gauge .66
..................................
Fuel Gauge .66
Controls Near the Steering ...........................................
Wheel .67
.
Windshield Wipers and Washers .68
.........
Turn Signals and Headlights .69
........................................
Fog Lights .72
........
Instrument Panel Brightness .72
.................
Hazard Warning Button .73
.................
Rear Window Def ogger .74
........
Steering Wheel Adjustments .75
...............................
Keys and Locks .76
........................
Immobilizer System .77
................................
Ignition Switch .78
......................................
Door Locks .79
.
Auto Door Locking/Unlocking .80
..............
Childproof Door Locks .86
.......................
Remote Transmitter .86
................................................
Trunk .90
........
Emergency Trunk Opener .91 .................................................
Seats .92
.
Front Seat Power Adjustments .92
FrontSeatManual
............................
Adjustments .93
Driver’s Seat Manual Height ..............................
Adjustment .94
..........................
Head Restraints .94
.......................
Folding Rear Seat .97
......................................
Armrests .98
..................................
Seat Heaters .100
...........................................
Mirrors .101
............................
Power Windows .103
.......................................
Moonroof .107
...............................
Parking Brake .109
.........
Interior Convenience Items .110
.....................
Beverage Holders .111
........
Accessory Power Sockets .111
.............
Console Compartment .112
..................................
Glove Box .113
....................
Sunglasses Holder .113
..................................
Sun Visors .114
............................
Vanity Mirror .115
..................................
Coat Hook .115
..........................
Center Pockets .115
...............................
Interior Lights .116
Instruments and Controls
Inst rument s and Cont rols
53
\f—\f—\fy
\f\fy
)\f
\fy\f\fy
2009 Accord Sedan

Î
ÎÎ
Î
The U.S. instrument panel is shown. Dif f erences f or the Canadian models are noted in the text.
Instrument Panel
Inst rument s and Cont rols
55
(P.57) (P.62)
: If equipped LOW FUEL INDICATOR
ANTI-LOCK BRAKE SYSTEM
(ABS) INDICATOR
HIGH BEAM INDICATOR DAYTIME RUNNING LIGHTS INDICATOR
SEAT BELT REMINDER
INDICATOR LIGHTS ON INDICATOR
CRUISE CONTROL
INDICATOR
SUPPLEMENTAL RESTRAINT
SYSTEM INDICATOR
SIDE AIRBAG OFF
INDICATOR
IMMOBILIZER SYSTEM
INDICATOR
MALFUNCTION INDICATOR LAMP LOW OIL PRESSURE INDICATOR (P.62)
(P.62) (P.61)
(P.61)
(P.61)
SECURITY SYSTEM INDICATOR
(P.57)(P.57)(P.58)
(P.62)
PARKING BRAKE AND BRAKE SYSTEM INDICATOR
CRUISE CONTROL
MAIN INDICATOR
(P.62)
MAINTENANCE MINDER INDICATOR
CHARGING SYSTEM INDICATOR (P.61)
(P.56)(P.60)
FOG LIGHT INDICATOR
VSA ACTIVATION INDICATOR
VEHICLE STABILITY ASSIST (VSA)
SYSTEM INDICATOR (P.58)(P.58)
(P.56,370)(P.56,369) (P.56,369)
(P.59)
FUEL ECONOMY INDICATOR
LOW TIRE
PRESSURE
INDICATOR
(P.59)
TIRE PRESSURE MONITORING
SYSTEM (TPMS) INDICATOR (P.59)DOOR AND TRUNK OPEN INDICATOR (P.60)
——y

y
)
yy
2009 Accord Sedan

This indicator comes on with the
high beam headlights. For more
inf ormation, see page .
This indicator also comes on with
reduced brightness when the
daytime running lights (DRL) are on
(see page ).
If this indicator comes on when you
turn the ignition switch to the ON
(II) position and release the parking
brake, it means there is a problem
with the DRL. There may also be a
problem with the high beam
headlights. Have your vehicle
checked by your dealer.
This indicator comes on when the
security system is set. See page
f or more inf ormation on the
security system.
This indicator comes on as a
reminder that you must ref uel soon.
When the indicator comes on, there
are about 2.8 U.S. gal (10.5
)of fuel
remaining in the tank.
When the needle reaches E, there is
a very small amount of f uel in the
tank. 69
71
217
If equipped
High Beam Indicator
Daytime Running L ights
Indicator
Security System Indicator
Low Fuel Indicator
Instrument Panel Indicators
Inst rument s and Cont rols
61
SECURITY SYSTEM INDICATOR
\f—\f—\fy

y
)\f
\fy\f\fy
2009 Accord Sedan

This f eature turns of f the headlights,
all other exterior lights, and the
instrument panel lights within 15
seconds after you remove the key
and close the driver’s door.
The automatic lighting of f f eature
activates if you leave the headlight
switch in the ‘‘ ’’ or ‘‘ ’’
position or if the lights are turned on
by setting the switch in the ‘‘AUTO’’
position (if equipped), and you
remove the key, then open and close
the driver’s door.If you turn the ignition switch to the
LOCK (0) position with the
headlight switch on, but do not open
the door and get out, the lights turn
of f af ter 10 minutes (3 minutes, if
the switch is in the ‘‘AUTO’’
position).
If you unlock the door, but do not
open it within 15 seconds, the lights
will go off. With the driver’s door
open, you will hear a lights-on
reminder chime.
The lights will turn on again when
you unlock or open the driver’s door.
The headlights revert to normal
operation when you turn them on
with the switch.
With the headlight switch of f or in
the position, the high beam
headlights and the high beam
indicator come on with reduced
brightness when you turn the
ignition switch to the ON (II)
position and release the parking
brake. They remain on until you turn
the ignition switch of f , even if you
set the parking brake.
Automatic Lighting Of f Feature
Daytime Running Lights
Turn Signals and Headlights
Inst rument s and Cont rols
71
\f—\f—\fy

\fy
)\f
\fy\f\fy
2009 Accord Sedan

To apply the parking brake, pull the
lever up f ully. To release it, pull up
slightly, push the button, and lower
the lever. The parking brake
indicator on the instrument panel
should go out when the parking
brake is f ully released (see page ).57
Parking Brake
Inst rument s and Cont rols
109
PARKING BRAKE LEVER
Driving the vehicle with the parking
brake applied can damage the rear
brakes and hubs. A beeper will sound if
the vehicle is driven with the parking
brake on.
\f—\f—\fy
\fy
)\f
\fy\f

y
2009 Accord Sedan

You can decrease the set cruising
speed in any of these ways:If you need to decrease your
speed quickly, use the brakes as you
normally would.
Press and hold the SET/DECEL
button. Release the button when
you reach the desired speed.
To slow down in very small
amounts, tap the SET/DECEL
button repeatedly. Each time you
do this, your vehicle will slow
down about 1 mph (1.6 km/h).
Tap the brake or clutch pedal
lightly with your f oot. The
CRUISE CONTROL indicator on
the instrument panel will go out.
When the vehicle slows to the
desired speed, press the SET/
DECEL button.
You can increase the set cruising
speed in any of these ways:
Press and hold the RES/ACCEL
button. When you reach the
desired cruising speed, release the
button.
Push on the accelerator pedal.
Accelerate to the desired cruising
speed, then press the SET/
DECEL button.
To increase the speed in very
small amounts, tap the RES/
ACCEL button. Each time you do
this, your vehicle will speed up
about 1 mph (1.6 km/h).
Cruise control may not hold the set
speed when you are going up and
down hills. If your speed increases
going down a hill, use the brakes to
slow down to the desired speed. This
will cancel cruise control. To resume
the set speed, press the RES/
ACCEL button. The CRUISE
CONTROL indicator on the
instrument panel comes on.
When climbing a steep hill, the
automatic transmission may
downshif t to hold the set speed.
Cruise Control
Changing the Set Speed
224
NOTE:
\f—\f—\fy

y
)\f
\fy\fy
2009 Accord Sedan

Park the vehicle, and set the
parking brake. Pull the hood
release handle located under the
lower lef t corner of the dashboard.
The hood will pop up slightly.Reach in between the hood and
the f ront grille with your f ingers.
The hood latch handle is above
the ‘‘H’’ logo. Push this handle up
until it releases the hood. Lif t the
hood.If the hood latch handle moves stif f ly,
or if you can open the hood without
lifting the handle, the mechanism
should be cleaned and lubricated.
1. 2.
Opening and Closing the Hood
Service Station Procedures
264
LATCH
HOOD RELEASE HANDLE
\f—\f—\fy
y
)\f
\fy\fy
2009 Accord Sedan

Bef ore installing any accessory:Make sure the accessory does not
obscure any lights, or interf ere
with proper vehicle operation or
perf ormance.
Modif ying your vehicle, or installing
some non-Honda accessories, can
make your vehicle unsaf e. Bef ore
you make any modif ications or add
anyaccessories,besuretoreadthe
f ollowing inf ormation.
Your dealer has Honda accessories
that allow you to personalize your
vehicle. These accessories have
been designed and approved f or your
vehicle, and are covered by warranty.
Although non-Honda accessories
may f it on your vehicle, they may not
meet f actory specif ications, and
could adversely af f ect your vehicle’s
handling and stability.
When properly installed, cellular
phones, alarms, two-way radios, and
low-powered audio systems should
not interf ere with your vehicle’s
computer controlled systems, such
as your airbags, anti-lock brakes, and
tire pressure monitoring system. Be sure electronic accessories do
not overload electrical circuits
(see page ) or interf ere with
the proper operation of your
vehicle.
Bef ore installing any electronic
accessory, have the installer
contact your dealer for assistance.
If possible, have your dealer
inspect the f inal installation.
Do not install accessories on the
side pillars or across the rear
windows. Accessories installed in
theseareasmayinterferewith
proper operation of the side
curtain airbags.372
A ccessories
A ccessories and Modif ications
Bef ore Driving
271
Improper accessories or
modifications can affect your
vehicle’s handling, stability, and
performance, and cause a
crash in which you can be hurt
or killed.
Follow all instructions in this
owner’s manual regarding
accessories and modifications.
\f—\f—\fy
\fy
)\f
\fy\fy
2009 Accord Sedan
