2009 GMC ENVOY set clock

Brake System Warning Light..........................3-35
Antilock Brake System (ABS) Warning Light.....3-36
StabiliTrak
®Service Light...............................3-36
StabiliTrak®Indicator Light.............................3-37
Engine Coolant Temperature Gage..................3-37
Tire Pressure Light.......................................3-38
Malfunction Indicator Lamp.............................3-38
Oil Pressure Gage........................................3-42
Change Engine Oil Light................................3-43
Security Light...............................................3-43
Cruise Control Light......................................3-43
Reduced Engine Power Light.........................3-44
Highbeam On Light.......................................3-44
Service Four-Wheel Drive Warning Light..........3-44
Check Gages Warning Light...........................3-45
Gate Ajar Light.............................................3-45
Fuel Gage...................................................3-46
Low Fuel Warning Light.................................3-47
Check Gas Cap Light....................................3-47Driver Information Center (DIC).......................3-47
DIC Operation and Displays...........................3-48
DIC Warnings and Messages.........................3-51
DIC Vehicle Customization.............................3-56
Audio System(s).............................................3-62
Setting the Clock..........................................3-63
Radio(s)......................................................3-64
Using an MP3..............................................3-80
XM Radio Messages.....................................3-84
Navigation/Radio System...............................3-86
Bluetooth
®...................................................3-86
Rear Seat Entertainment (RSE) System...........3-96
Rear Seat Audio (RSA)................................3-109
Theft-Deterrent Feature................................3-110
Audio Steering Wheel Controls......................3-110
Radio Reception.........................................3-111
Fixed Mast Antenna....................................3-112
XM™ Satellite Radio Antenna System............3-112
Chime Level Adjustment...............................3-112
Section 3 Instrument Panel
3-2

2. Set the driver’s and passenger’s temperature.
To nd your comfort setting, start with a 72°F (22°C)
temperature setting and allow about 20 minutes
for the system to adjust. Turn the driver or
passenger side temperature knob to adjust the
temperature setting as necessary. If a temperature
setting of 60°F (15°C) is chosen, the system will
remain at the maximum cooling setting. If a
temperature setting of 90°F (32°C) is chosen, the
system remains at the maximum heat setting.
Choosing either maximum setting may not cause
the vehicle to heat or cool any faster.
Manual Operation
9(Off):Press to turn off the entire climate control
system. Outside air still enters the vehicle, and will be
directed to the oor. The system turns on by pressing
either AUTO, air delivery mode, fan control, or by
adjusting either temperature knob.
Driver’s Side Temperature Knob:Turn clockwise
or counterclockwise to increase or decrease the
temperature on the driver side of the vehicle.
The display will show the temperature setting decreasing
or increasing and an arrow pointing toward the driver.
This knob can also adjust the passenger side
temperature setting if the two are linked.Passenger Side Temperature Knob:Turn clockwise
or counterclockwise to increase or decrease the
temperature on the passenger side of the vehicle.
The display will show the temperature setting
decreasing or increasing and an arrow pointing toward
the passenger. The passenger temperature setting
can be set to match and link to the driver’s temperature
setting by pressing and holding the AUTO button
for three seconds. When adjusting the driver side
temperature setting, the passenger side temperature
setting will follow and both arrows will appear on
the display. The passenger side temperature setting
also resets and re-links to the driver side temperature
setting if the vehicle has been off for more than
three hours.
w9x(Fan Control):Press the arrows to increase
or decrease the fan speed. The display shows the
selected fan speed and the driver side temperature
setting for ve seconds.
C(Air Delivery Mode Control):Press to change the
direction of the airow in the vehicle. The air delivery
modes will appear on the display as it is being adjusted.
The display shows the selected air delivery mode and
the driver temperature setting for ve seconds.
3-23

Outlet Adjustment
Use the air outlets located in the center and on the side
of the instrument panel to direct the airow. Use the
thumbwheels near the air outlets to open or close off the
airow.
Operation Tips

Clear away any ice, snow, or leaves from air inlets
at the base of the windshield that could block the
ow of air into the vehicle.
Keep the path under the front seats clear of objects
to help circulate the air inside of the vehicle more
effectively.
Use of non-GM approved hood deectors can
adversely affect the performance of the system.
Check with your dealer/retailer before adding
equipment to the outside of the vehicle.
Rear Climate Control System
The vehicle has one of the following rear climate control
systems. With either of these systems, the rear
climate controls will be disabled when the front climate
control system is in defrost. This occurs to provide
maximum airow to clear the windshield.A. Power Button
B. Air Delivery Mode Control
The temperature of the air coming through the rear outlets
is determined by the front passenger temperature setting.
PWR (Power):Press to turn the rear climate controls
on or off.
Air Delivery Mode Control:Turn clockwise or
counterclockwise to change the direction of the airow
to the rear seat area.
H(Panel):Air is directed to the rear console outlets.
)(Bi-level):Air is directed to the second seat
side oor outlets and the rear console outlets.
6(Floor):Air is directed to the second seat side oor
outlets.
3-26

Notice:Contact your dealer/retailer before adding
any equipment.
Adding audio or communication equipment could
interfere with the operation of the vehicle’s engine,
radio, or other systems, and could damage them.
Follow federal rules covering mobile radio and
telephone equipment.
Notice:The chime signals related to safety belts,
parking brake, and other functions of your vehicle
operate through the radio/entertainment system.
If that equipment is replaced or additional equipment
is added to your vehicle, the chimes may not
work. Make sure that replacement or additional
equipment is compatible with your vehicle before
installing it. SeeAccessories and Modifications
on page 5-3.
The vehicle has Retained Accessory Power (RAP).
With RAP, the audio system can be played even after
the ignition is turned off. SeeRetained Accessory Power
(RAP) on page 2-22for more information.Setting the Clock
The clock can be set with the ignition on or off.
The radio may have a button marked with an H or HR to
represent hours and an M or MN to represent minutes.
Press and hold the hour button until the correct hour
displays. AM or PM displays for morning or evening
hours. Press and hold the minute button until the correct
minute displays.
To synchronize the time with an FM station broadcasting
Radio Data System (RDS) information, press and hold
the hour and minute buttons at the same time until
UPDATED and the clock symbol appear on the
display. If the time is not available from the station,
NO UPDATE or NO UPDAT will appear on the display.
RDS time is broadcast once a minute. After tuning
to an RDS broadcast station, it could take a few minutes
for the time to update.
3-63

Audio System (cont.)
Setting the Clock.........................................3-63
Theft-Deterrent Feature...............................3-110
XM™ Satellite Radio Antenna System...........3-112
Audio System(s).............................................3-64
Automatic Headlamp System............................3-14
Automatic Transmission
Fluid..........................................................5-21
Operation...................................................2-25
B
Battery..........................................................5-38
Electric Power Management..........................3-17
Run-Down Protection...................................3-18
Bluetooth
®.....................................................3-86
Brake
Emergencies................................................ 4-6
Brake Fluid....................................................5-35
Brakes..........................................................5-35
System Warning Light..................................3-35
Braking........................................................... 4-4
Braking in Emergencies..................................... 4-6
Break-In, New Vehicle.....................................2-20
Bulb Replacement...........................................5-46
Back-Up Lamps...........................................5-48
Front Turn Signal, Sidemarker and
Parking Lamps.........................................5-47
Halogen Bulbs............................................5-46Bulb Replacement (cont.)
Headlamp Aiming........................................5-45
Headlamps.................................................5-46
License Plate Lamps....................................5-49
Replacement Bulbs......................................5-49
Taillamps, Turn Signal, and Stoplamps............5-47
Buying New Tires...........................................5-70
C
Calibration.....................................................2-40
California Fuel.................................................. 5-6
California Perchlorate Materials Requirements....... 5-4
California Proposition 65 Warning....................... 5-4
Canadian Owners................................................ ii
Capacities and Specications..........................5-120
Carbon Monoxide...........................2-12, 2-37, 4-28
Care of
Safety Belts..............................................5-106
Cargo Cover..................................................2-54
Cargo Tie Downs............................................2-55
CD, MP3 .......................................................3-80
Center Console Storage Area...........................2-52
Chains, Tire...................................................5-76
Charging System Light....................................3-33
Check
Engine Lamp..............................................3-38
Gages Warning Light...................................3-45
Check Gas Cap Light......................................3-47
2

Checking Things Under the Hood......................5-10
Chemical Paint Spotting.................................5-110
Child Restraints
Child Restraint Systems...............................1-39
Infants and Young Children...........................1-35
Lower Anchors and Tethers for Children..........1-43
Older Children.............................................1-32
Securing a Child Restraint in a
Rear Outside Seat Position........................1-49
Securing a Child Restraint in the
Center Rear Seat Position.........................1-51
Securing a Child Restraint in the
Right Front Seat Position..........................1-52
Where to Put the Restraint...........................1-42
Chime Level Adjustment.................................3-112
Cigarette Lighter.............................................3-19
Cleaning
Aluminum Wheels......................................5-109
Exterior Lamps/Lenses................................5-107
Fabric/Carpet............................................5-104
Finish Care...............................................5-108
Instrument Panel, Vinyl, and Other
Plastic Surfaces.....................................5-106
Interior.....................................................5-103
Leather....................................................5-105
Tires........................................................5-109
Underbody Maintenance.............................5-110
Washing Your Vehicle.................................5-107
Weatherstrips............................................5-106
Windshield, Backglass, and Wiper Blades......5-108Climate Control System
Dual ..........................................................3-19
Dual Automatic............................................3-22
Outlet Adjustment........................................3-26
Rear ..........................................................3-26
Clock, Setting.................................................3-63
Collision Damage Repair..................................7-11
Compass.......................................................2-40
Compressor Kit
Storing.......................................................
5-87
Compressor Kit, Tire Sealant............................5-77
Content Theft-Deterrent....................................2-16
Control of a Vehicle.......................................... 4-3
Convenience Net............................................2-54
Coolant
Engine.......................................................5-25
Engine Temperature Gage............................3-37
Cooling System..............................................5-24
Cruise Control................................................3-10
Cruise Control Light........................................3-43
Customer Assistance Information
Courtesy Transportation................................7-10
Customer Assistance for Text
Telephone (TTY) Users............................... 7-6
Customer Assistance Offices........................... 7-6
Customer Satisfaction Procedure..................... 7-2
GM Mobility Reimbursement Program............... 7-7
Reporting Safety Defects to General Motors.......7-15
3

Perchlorate Materials Requirements,
California..................................................... 5-4
Phone
Bluetooth
®..................................................3-86
Power
Door Locks.................................................. 2-8
Electrical System.......................................5-112
Lumbar Controls........................................... 1-4
Reduced Engine Light..................................3-44
Retained Accessory.....................................2-22
Seat ............................................................ 1-3
Steering Fluid.............................................5-33
Windows....................................................2-14
Privacy..........................................................7-16
Event Data Recorders..................................7-17
Navigation System.......................................7-18
OnStar .......................................................7-18
Radio Frequency Identication.......................7-18
Programmable Automatic Door Locks.................. 2-9
R
Radio Frequency Identication (RFID),
Privacy......................................................7-18
Radio(s)........................................................3-64
Radios
Navigation/Radio System,
see Navigation Manual..............................3-86
Rear Seat Audio........................................3-109Radios (cont.)
Reception.................................................3-111
Setting the Clock.........................................3-63
Theft-Deterrent..........................................3-110
Reading Lamps..............................................3-17
Rear Axle......................................................5-43
Locking......................................................4-10
Rear Climate Control System............................3-26
Rear Door Security Locks................................2-11
Rear Floor Storage Cover................................2-53
Rear Seat Audio (RSA)..................................3-109
Rear Seat Entertainment System.......................3-96
Rear Seat Operation.......................................1-11
Rear Windshield Washer/Wiper........................... 3-9
Rearview Mirror, Automatic Dimming..................2-39
Rearview Mirrors.............................................2-39
Reclining Seatbacks.......................................... 1-7
Recommended Fluids and Lubricants.................6-12
Recreational Vehicle Towing.............................4-38
Reduced Engine Power Light............................3-44
Remote Keyless Entry (RKE) System.................. 2-4
Remote Keyless Entry (RKE) System,
Operation..................................................... 2-5
Removing the Flat Tire and Installing the
Spare Tire..................................................5-92
Removing the Spare Tire and Tools...................5-89
Replacement Bulbs.........................................5-49
Replacement Parts, Maintenance......................6-14
10

Reporting Safety Defects
Canadian Government..................................7-15
General Motors...........................................7-15
United States Government............................7-14
Restraint System Check
Checking the Restraint Systems....................1-70
Replacing Restraint System Parts
After a Crash..........................................1-71
Retained Accessory Power...............................2-22
Roadside
Assistance Program....................................... 7-7
Rocking Your Vehicle to Get it Out....................4-31
Routing, Engine Drive Belt...............................6-15
Running the Vehicle While Parked.....................2-38
S
Safety Belt Reminders.....................................3-30
Safety Belts
Care of ....................................................5-106
How to Wear Safety Belts Properly................1-18
Lap-Shoulder Belt........................................1-27
Safety Belt Extender....................................1-32
Safety Belt Use During Pregnancy.................1-31
Safety Belts Are for Everyone.......................1-13
Safety Warnings and Symbols.............................. iii
Scheduled Maintenance..................................... 6-4Seats
Head Restraints..........................................1-10
Heated Seats............................................... 1-4
Manual Lumbar............................................. 1-3
Memory ....................................................... 1-5
Power Lumbar .............................................. 1-4
Power Seats................................................. 1-3
Rear Seat Operation....................................1-11
Reclining Seatbacks...................................... 1-7
Secondary Latch System.................................5-97
Securing a Child Restraint
Center Rear Seat Position............................1-51
Rear Outside Seat Position...........................1-49
Right Front Seat Position..............................1-52
Security Light.................................................3-43
Service........................................................... 5-3
Accessories and Modications......................... 5-3
Adding Equipment to the Outside of the
Vehicle..................................................... 5-5
California Perchlorate Materials Requirements..... 5-4
California Proposition 65 Warning.................... 5-4
Doing Your Own Work................................... 5-4
Engine Soon Lamp......................................3-38
Four-Wheel-Drive Warning Light.....................3-44
Publications Ordering Information...................7-15
Service, Scheduling Appointments.....................7-10
Servicing Your Airbag-Equipped Vehicle..............1-68
Setting the Clock............................................3-63
11
