INSTRUMENT PANEL
F0Z0250mF0Z0251m
Actual-Active VERSIONS
A Fuel gauge with reserve warning
light
B Speedometer (speed indicator)
C Engine coolant temperature gauge
with excess temperature warning
light
D Digital display.
Warning lights
m
and
c
are only
provided on Diesel versions.
fig. 11 – Left-hand drive versions
fig. 12 – Right-hand drive versions
001-030 PANDA EN 7-10-2009 13:39 Pagina 11

12
KNOW YOUR
VEHICLE
SAFETY
CORRECT USE
OF THE CAR
WARNING LIGHTS
AND MESSAGES
IN
AN EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
F0Z0252mF0Z0253m
Dynamic VERSIONS
A Speedometer (speed indicator)
B Fuel gauge with reserve warning
light
C Engine coolant temperature gauge
with excess temperature warning
light
D Rev counter
E Multifunction display.
Warning lights
m
and
c
are only
provided on Diesel versions.
fig. 13 – Left-hand drive versions
fig. 14 – Right-hand drive versions
001-030 PANDA EN 7-10-2009 13:39 Pagina 12

13KNOW YOUR
VEHICLESAFETY
CORRECT USE
OF THE CAR
WARNING LIGHTS
AND MESSAGES
IN
AN EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
F0Z0635mF0Z0636m
Emotion VERSIONS
A Speedometer (speed indicator)
B Fuel gauge with reserve warning
light
C Engine coolant temperature gauge
with excess temperature warning
light
D Rev counter
E Reconfigurable multifunction
display.
Warning light
m
is only provided on
Diesel versions.
Warning light
t
is only provided on
versions fitted with Dualogic gearbox
(see “Dualogic” Supplement attached
to this Owner Handbook).
fig. 15 – Left-hand drive versions
fig. 16 – Right-hand drive versions
001-030 PANDA EN 7-10-2009 13:39 Pagina 13

14
KNOW YOUR
VEHICLE
SAFETY
CORRECT USE
OF THE CAR
WARNING LIGHTS
AND MESSAGES
IN
AN EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
F0Z0146m
fig. 17
F0Z0256m
fig. 18
REV. COUNTER fig. 18
The indicator B shows the engine revolution number.
IMPORTANT The electronic injection control system grad-
ually shuts off the flow of fuel when the engine is “over-
revving” resulting in a gradual loss of engine power.
When the engine is idling, the rev counter may indicate
a gradual or sudden increase of the speed.
This behaviour is standard as it takes place during the ac-
tivation of the climate control system or the fan. It should
not be considered as a fault. In these cases, a slow change
in engine speed preserves the battery charge.
INSTRUMENTSThe instrument background colour and type may vary
according to the versions.
SPEEDOMETER (SPEED INDICATOR) fig. 17
The indicator A shows the car speed (speedometer).
001-030 PANDA EN 7-10-2009 13:39 Pagina 14

15KNOW YOUR
VEHICLESAFETY
CORRECT USE
OF THE CAR
WARNING LIGHTS
AND MESSAGES
IN
AN EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
F0Z0148m
fig. 19
ENGINE COOLANT TEMPERATURE
GAUGE fig. 19
This shows the temperature of the engine coolant fluid and
starts working when the fluid temperature exceeds
approx. 50 °C.
Under normal conditions, the needle should hover
around the middle of the scale depending on the working
conditions.
C Low engine coolant temperature
H High engine coolant temperature.
The warning light B may light up (with a message on
the reconfigurable multifunction display for some versions)
to indicate that the coolant temperature is too high; in this
case, stop the engine and contact a Fiat Dealership. FUEL LEVEL GAUGE fig. 19
The needle shows the amount of fuel left in the fuel tank.
E tank empty.
F tank full (see the instructions provided in paragraph
“At the filling station”).
The reserve warning light A turns on to indicate that
approximately 5 litres of fuel are left in the tank.
Do not travel with the fuel tank almost empty: the gaps
in fuel delivery could damage the catalytic converter.
IMPORTANT The needle sets to E with the warning light
A flashing to indicate that the system is failing. If this is
the case, contact a Fiat Dealership to have the system
checked.
If the needle reaches the red area, stop the
engine immediately and contact a Fiat
Dealership.
001-030 PANDA EN 7-10-2009 13:39 Pagina 15

16
KNOW YOUR
VEHICLE
SAFETY
CORRECT USE
OF THE CAR
WARNING LIGHTS
AND MESSAGES
IN
AN EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
F0Z0015m
fig. 20
F0Z0027m
fig. 21
CONTROL BUTTONS fig. 21
A Brief pressing to switch from total to trip km/miles.
Long pressing (over 2 seconds) to reset trip km/miles.
B Clock setting.SETTING THE CLOCK fig. 21To set the clock, press the button B. Every pressing on the
button moves the clock forward by one unit. Keeping the
button pressed for some seconds obtains auto-
matic fast increase. When you are close to the required
time, release the button and complete the adjustment
by single presses.
DIGITAL DISPLAY“STANDARD” SCREEN fig. 20
The standard screen shows the following information:
A Headlight aiming position (only with dipped beam
headlights on).
B Clock (always displayed, even with ignition key
removed and front doors closed).
C Odometer (display of covered kilometres or miles).
NOTE With key removed (when opening at least one of
the front doors) the display turns on and shows the
covered kilometres or miles for a few seconds.
001-030 PANDA EN 7-10-2009 13:39 Pagina 16

17KNOW YOUR
VEHICLESAFETY
CORRECT USE
OF THE CAR
WARNING LIGHTS
AND MESSAGES
IN
AN EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
F0Z0185m
fig. 22
F0Z0016m
fig. 23
MULTIFUNCTION DISPLAY STANDARD SCREEN fig. 23
The standard screen shows the following information:
A Headlight aiming position (only with dipped beam head-
lights on).
B Clock.
C Odometer (display of covered km or miles).
NOTE With key removed (when opening at least one of
the front doors) the display turns on and shows the time
and covered km or miles, for a few seconds. WARNING LIGHT TEST fig. 22
The following warning lights are tested:
❒
engaged handbrake/low brake fluid level;
❒
ABS and EBD system (where provided);
❒
ESP system (where provided);
❒
“Dualdrive” electrical power steering failure (where
provided).
The diagnosis is automatically run when the ignition key
is turned to MAR and during standard operation when
a fault is signalled. At the end of the initial warning light
check, the message “LEd Error” will flash on the display
for about 10 seconds if a faulty warning light is found.
001-030 PANDA EN 7-10-2009 13:39 Pagina 17

18
KNOW YOUR
VEHICLE
SAFETY
CORRECT USE
OF THE CAR
WARNING LIGHTS
AND MESSAGES
IN
AN EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
F0I0142m
fig. 24
F0Z0152m
fig. 25
WARNING LIGHT TEST fig. 25
The following warning lights are tested:❒
engaged handbrake/low brake fluid level;
❒
ABS and EBD system (for versions/markets where
provided);
❒
ESP system (for versions/markets where provided);
❒
“Dualdrive” electrical power steering failure.
The diagnosis is automatically run when the key is turned
to MAR and during standard operation when a fault is sig-
nalled. At the end of the initial warning light check, the
message “LEd Error” will flash on the display for about
10 seconds if a faulty warning light is found. SETTING THE CLOCK fig. 24
To adjust the time, press button A to increase minutes, but-
ton B to decrease minutes. Every pressing on the button
moves the clock forward by one unit. Keeping the button
pressed for some seconds obtains automatic fast increase.
When you are close to the required time, release the but-
ton and complete the adjustment by single presses.
