The engine of your car is factory filled with Selenia.
Oil change? The experts recommend Selenia
This is an engine oil range which satisfies the most advanced
international specifications. Its superior technical characteristics
allowSelenia to guarantee the highest performance
and protection of your engine.
The Selenia range includes a number of technologically advanced products:
SELENIA K PURE ENERGY
Synthetic lubricant designed for latest generation, low
emission, petrol engines. Its specific formulation warrants
the utmost protection also for high performance
turbocharged engines with high thermal stress.
Its low ash content helps to maintain the total cleanliness
of modern catalysts.
SELENIA WR PURE ENERGY
Fully synthetic lubricant that can meet the requirements of
the latest diesel engines. Low ash content to protect the
particulate filter from the residual products of combustion.
High Fuel Economy System that allows
considerable fuel saving.
It reduces the danger of dirtying the turbine to ensure the
protection of increasingly high performance diesel
enginesSELENIA MULTIPOWER
Particularly ideal for the protection of new generation petrol
engines, very effective even in the most severe weather
conditions. It guarantees a reduction in fuel consumption
(Energy conserving) and it is also ideal for alternative
engines.
SELENIA SPORT
Fully synthetic lubricant capable of meeting the needs of
high performance engines.
Studied to protect the engine also in high thermal stress
conditions, it prevents deposits on the turbine to achieve
the utmost performance in total safety.
The range also includes Selenia StAR Pure Energy, Selenia
Racing, Selenia K, Selenia WR, Selenia 20K, Selenia 20K AR.
For further information on Selenia products visit the web site
www.flselenia.com.
238-244 BRAVO GB.qxd 11-11-2009 10:57 Pagina 243

ENGINE OIL CHANGE
1.4 16V- 1.4 T-JET - 1.6 Multijet
- 1.9 Multijet 8V - 1.9 Multijet 16V - 2.0 Multijet
Tank capacity 57
Reserve8-10
Refuel petrol engines with unleaded petrol with octane rating (RON) no lower than 95 only (EN 228 Specifications)
Refuel diesel engines with diesel fuel for motor vehicles only (EN 590 Specifications)
FUEL CAPACITIES (litres)
Fiat Group Automobiles S.p.A. - Customer Services - Technical Services - Service Engineering - Largo Senatore G. Agnelli, 5 - 10040 Volvera - Torino (Italia) - Print N. 603.81.442 - 11/2009 - 4 Edition
Add +0.3 bar to the prescribed inflation pressure when the tyres are warm. Recheck pressure value with cold tyres.
With snow tyres, add +0.2 bar to the inflation pressure value prescribed for standard tyres.
When running at speed higher than 160 km/h, inflate tyres at full load inflation values.
T.P.M.S. system not available for tyre 195/65 R15 91H.
COLD TYRE INFLATION PRESSURE (bar)
195/65 R15 91H 2.3 2.3 2.6 2.6
1.4 16V205/55 R16 91H 2.3 2.3 2.6 2.6
225/45 R17 91V 2.3 2.3 2.6 2.6
195/65 R15 91H 2.3 2.3 2.6 2.6
205/55 R16 91H 2.3 2.3 2.6 2.6
225/45 R17 91V 2.3 2.3 2.6 2.6
225/40 R18 92V REINFORCED 2.6 2.6 2.9 2.9
195/65 R15 91V 2.3 2.3 2.6 2.6
205/55 R16 91V 2.3 2.3 2.6 2.6
225/45 R17 91V 2.3 2.3 2.6 2.6
225/40 R18 92V REINFORCED 2.6 2.6 2.9 2.9STANDARD TYRES
Size Medium load Full load
Front Rear Front Rear
1.4 T-JET 120 HP
1.6 Multijet
1.9 Multijet
8V
1.4 T-JET 150HP
1.9 Multijet 16V
2.0 Multijet
1.4 16V- 1.4 T-JET 1.6 Multijet - 1.9 - Multijet8V- 1.9 Multijet 16V2.0 Multijetlitres kg litres kg litres kg
Fuel tank 2.75 2.4 4.3 3.6 4.3 3.6
Engine sump and filter 2.9 2.55 4.6 3.85 4.9 4.1
