RKE Unlock
WhenDriver Door 1st Pressis selected, only the driver’s
door will unlock on the first press of the Remote Keyless
Entry (RKE) transmitter UNLOCK button. When Driver
Door 1st Press is selected, you must press the RKE
transmitter UNLOCK button twice, to unlock the passen-
ger’s doors. WhenAll Doors 1st Pressis selected, all of
the doors will unlock on the first press of the RKE
transmitter UNLOCK button. To make your selection,
press and release the RESET button until “Driver Door
1st Press” or “All Doors 1st Press” appears.
RKE Linked To Memory
When this feature is selected the memory seat, mirror,
and radio settings will return to the memory set position
when the RKE transmitter UNLOCK button is pressed. If
this feature is not selected then the memory seat, mirror,
and radio settings can only return to the memory setposition using the door mounted switch. Pressing the
RESET button when in this display will selectYe sor
No.
Flash Lamp Lock
When ON is selected, the front and rear turn signals will
flash when the doors are locked or unlocked with the
RKE transmitter. This feature may be selected with or
without the sound horn on lock feature selected. To make
your selection, press and release the RESET button until
ON or OFF appears.
Headlamp Off Delay
When this feature is selected, the driver can choose to
have the headlights remain on for 0, 30, 60, or 90 seconds
when exiting the vehicle. To make your selection, press
and release the RESET button until 0, 30, 60, or 90
appears.
260 UNDERSTANDING YOUR INSTRUMENT PANEL
ProCarManuals.com
The numbers inside the TIPM cover correspond to the
following table.
FUSES/TIPM
CavityCartridge
FuseMini-
FuseDescription
J1 40 Amp
Green— Power Folding Seat
J2 30 Amp
Pink— Power Liftgate Mod-
ule
J3 40 Amp
Green— Rear Door Module
(RR Door Node)
J4 25 Amp
Natural— Driver Door Node
J5 25 Amp
Natural— Passenger Door Node
J6 40 Amp
Green— Anti-Lock Brake Sys-
tem (ABS) Pump/ESP
J7 30 Amp
Pink— Anti-Lock Brake Sys-
tem (ABS) Valve
FUSES/TIPM
CavityCartridge
FuseMini-
FuseDescription
J8 40 Amp
Green— Power Memory Seat
(If Equipped)
J9 40 Amp
Green— PZEV Motor/Flex
Fuel
J10 30 Amp
Pink— Headlamp Wash
Relay/Manual Tuning
Valve
J11 30 Amp
Pink— Power Sliding Door
Module
J13 60 Amp
Yellow— Ignition Off Draw
(IOD) — Main
J14 40 Amp
Green— Rear Window Defog-
ger
J15 30 Amp
Pink— Rear Blower
J17 40 Amp
Green— Starter Solenoid
468 MAINTAINING YOUR VEHICLE
ProCarManuals.com
FUSES/TIPM
CavityCartridge
FuseMini-
FuseDescription
M33 — 10 Amp
RedNext Generation Con-
troller (NGC), Global
Powertrain Engine
Controller (GPEC)
M34 — 10 Amp
RedPark Assist (PRK
ASST), Heater Venti-
lation, Air Condition-
ing Module (HVAC
MOD), Headlamp
Wash (HDLP WASH),
Compass (COMPAS)
M35 — 10 Amp
RedHeated Mirrors
M36 — 20 Amp
YellowPower Outlet #3
(BATT)
FUSES/TIPM
CavityCartridge
FuseMini-
FuseDescription
M37 — 10 Amp
RedAnti-Lock Brake Sys-
tem (ABS), Electronic
Stability Program
(ESP), Stop Lamp
Switch (STP LP SW),
Fuel Pump Rly Hi
Control
M38 — 25 Amp
NaturalLock/Unlock Motors
(LOCK/UNLOCK
MTRS)
The heated mirrors, lower instrument panel power outlet
and removable floor console, when in the front position
are fused with self-resetting fuses that are only service-
able by an authorized dealer. The power seats are fused
by a 30 Amp circuit breaker located under the driver’s
seat. The power windows are fused by a 25 Amp circuit
breaker located under the instrument panel near the
MAINTAINING YOUR VEHICLE 473
