Page 42 of 189
58
II
21
M
M E M O R I S A T I O N
DRIVING POSITIONSMEMORISED VIABUTTONS 1 AND 2
T o m e m o r i s e a d r i v i n g p o s i t i o n :a. P l a c e t h e i g n t i o n k e y i n "Drive" p o s i t i o n ( s e c o n d p o s i t i o n ) .b. M a k e y o u r a d j u s t m e n t s o f t h e seat , t h e steering wheel , t h e rear view mirrors a n d t h e Head-up Display.c. P r e s s s u c c e s s i v e l y o n button M then on button 1 ( fi r s t d r i v i n g p o s i t i o n ) o r 2 ( s e c o n d d r i v i n g p o s i t i o n ) .
T h e m e m o r i s a t i o n i s c o n fi r m e d b y a s o u n d s i g n a l .Note: The memorisation of a new driving position cancels and replaces the previous one.
T h e m e m o r i s a t i o n f u n c t i o n a l l o w s t o m a k e t h e f o l l o w i n g d a s h b o a r d a d j u s t m e n t s : D r i v e r ' s s e a t
S t e e r i n g w h e e l
E x t e r i o r r e a r v i e w m i r r o r s H e a d - u p d i s p l a y .
S e e " S t e e r i n g c o l u m n a d j u s t m e n t " , " R e a r v i e w m i r r o r s " a n d " H e a d - u p Display".
Y o u h a v e t h e p o s s i b i l i t y t o m e m o -rise two driving positions u s i n g buttons 1 a n d 2.
Page 51 of 189
67
II
0
0
13
24
A
C
C R U I S E C O N T R O L
SELECTION OF CRUISE CONTROL
T h i s d r i v i n g a s s i s t a n c e f u n c t i o n a l l o w s y o u t o d r i v e a t t h e s p e e d o f your choice without the need to action the accelerator.
Cruise control is available in thehigher gears only , for speeds greater than 24 mph (40 km/h).Note: Information relating to the cruise control is displayed in zone A of your instrument panel.
T o a c t i v a t e c r u i s e c o n t r o l , p r e s s b u t t o n 1 t o d i s p l a y i n z o n e A o f y o u r i n s t r u m e n t p a n e l t h e s y m b o l C f o r c r u i s e c o n t r o l .
T h e c r u i s e s p e e d i s t h e n m e m o r i s e d . T h e c r u i s e s p e e d w i l l b e d i s p l a y e d i n z o n e A i n t h e i n s t r u m e n t p a n e l .
A t t h e t i m e y o u s e l e c t t h e f u n c t i o n , no cruise speed has yet been memorised.
TO SELECT A CRUISE SPEED
A c c e l e r a t e t o t h e d e s i r e d s p e e d , t h e n g i v e a s h o r t p r e s s o n b u t t o n 3 or button 4.
Y o u c a n t h e n r e l e a s e t h e a c c e l e r a t o r p e d a l . T h e v e h i c l e w i l l a u t o m a t i c a l l y k e e p t o t h a t c h o s e n s p e e d .Note: The vehicle speed may vary slightly from that memorised.
Temporary override of the cruise speed
W h i l e c r u i s e c o n t r o l i s i n o p e r a t i o n , i t i s a l w a y s p o s s i b l e t o g o a b o v e t h e c r u i s e s p e e d s i m p l y b y p r e s s i n g t h e a c c e l e r a t o r p e d a l ( f o r e x a m p l e t o o v e r - t a k e a n o t h e r v e h i c l e ) . T h e s p e e d d i s p l a y e d fl a s h e s . Y o u h a v e o n l y t o r e l e a s e t h e a c c e l e r a t o r p e d a l t o r e t u r n t o y o u r c r u i s e s p e e d .Note: If during cruise control the system cannot keep to the cruise speed ( e . g . o n a s t e e p d e s c e n t ) , t h e n t h e s p e e d fl a s h e s . I f n e c e s s a r y , b r a k e t o curb your speed.
Page 69 of 189
85
III
1
2a2b1
3a3b4
765
A U T O M A T I C A I R C O N D I T I O N I N G
The system has a differentiated adjustment for the driver's side and passenger's side, in terms of temperature and a i r d i s t r i b u t i o n . T h e a i r fl o w i s c o m m o n t o b o t h s i d e s .
Symbols and messages relating to the automatic air conditioning controls will display on the multifunction screen.
2. TEMPERATURE ADJUSTMENT
To adjust the temperature, press on button 2a to modify the temperature on the passenger's side and on but-ton 2b to modify it on the driver's side.
An adjustment around 21 will give you the optimum comfort level. However, depending on your preferences anywhere between 18 and 24 is quite usual.
Operating the air conditioning system on "AUTO"guarantees good ventilation inside the cabin.Note: there may be a difference between the actual c a b i n t e m p e r a t u r e a n d t h e fi g u r e d i s p l a y e d .
This is the normal operating mode for the system. Depending on the temperature chosen, a press on this b u t t o n , c o n fi r m e d b y t h e l i g h t i n g o f t h e w a r n i n g l a m p , will automatically and simultaneously bring all the fol-lowing functions into play: A i r fl o w .
Cabin temperature.
Air distribution.
Exterior air intake/Air recirculation.
It is recommended to keep all the air vents open. Just by pressing any of the buttons, except for temperature 2aand 2b, you can change to manual mode. The warning lamp goes off, and the automatic air intake function is deactivated.
Page 70 of 189
86
III
A U T O M A T I C A I R C O N D I T I O N I N G
Remarks:When starting from cold, in order to prevent u n w a n t e d c o l d a i r , t h e a i r fl o w w i l l i n c r e a s e o n l y gradually to its optimum level.
If you enter the vehicle after a fairly prolonged stop and the temperature inside the vehicle is uncomfortable, it serves no purpose to modify the temperature that is displayed as an attempt to go immediately to the desired comfort level. The system automatically uses all of its power to compensate the temperature gap as quickly as possible.
Remarks:Water arising from the condensation in the air conditioning drains out through a hole provided for this purpose; a pool of water may thus form underneath the vehicle when stationary.
Whatever the time of year, even in cool weather the air conditioning is useful in removing humidity and misting.You are advised to have the air conditioning system checked on a regular basis. See "Maintenance and Warranty Guide".
If you are towing a heavy trailer and outside temperatures are high, the air conditioning may be temporarily paused if the engine cooling requires this.
Page 71 of 189
87
III
3a3b
4
A U T O M A T I C A I R C O N D I T I O N I N G
3. ADJUSTING THE AIR DISTRIBUTION
Successive or continuous presses on buttons 3a and 3b d i r e c t t h e fl o w o f a i r t o t h e p a s s e n g e r ' s i d e o r t o t h e driver's side.
The symbol (arrows) corresponding to the direction chosen is displayed on the multifunction screen:Windscreen and side windows.
Central, lateral and soft diffusion air conditioning vents (if open).
Passenger footwells."AUTO" automatic distribution.
Page 73 of 189
89
III
A U T O M A T I C A I R C O N D I T I O N I N G
To activate/deactivate the air conditioning system
Press on the control "CLIM" to go into the "air conditioning" mode. Then press button "OK" or on the control to bring up the "Air Conditioning menu" on the multifunction screen.
This menu allows you:To deactivate the air conditioning: "Cut aircon (A/C OFF)".Press button "OK", or on the control, to validate the offer to activate or deactivate the air conditioning.
The symbol "A/C OFF" displays on the multifunctionscreen in the case of deactivation.
Note:Your temperature adjustment value may not be reached and you risk having the windows misted up.You can cancel deactivation of the air conditioning,by pressing the control 1"AUTO".
Page 75 of 189
91
III
The programmable heating sys-tem operates independently of the engine.
With the engine off, it is used to preheat the engine cooling system so as to have an optimum engine operating temperature on starting.
The programmable heating sys-tem is started using a long-range remote control. It can be started immediately or programmed to start later.
In the event of a malfunction of the programmable heating sys-tem, contact a CITROËN dealer.the programmable heating sys-programmable heating
Remote control
The remote control for the program-mable heating system includes the following buttons and display infor-mation:1. Menu function scroll buttons.2. Function symbols: clock, temperature, operating duration, programmed time, heater operation, heater control.3. Digital display of: time, temperature, operating duration, programmed time or heating level.4. Off button.5. On button.
Information displayed in the remote control screen
Display of functions
Press buttons 1 repeatedly to bring up the functions.
T h e fi r s t p r e s s o f t h e r i g h t o r l e f t button displays the time.
The left button then gives access to the programming time, then the heating level (C1 to C5).
The right button gives access to the cabin temperature, then the operating duration of the heater where the system is to be started immediately.
Information on the cabin tem-perature is only available with the engine off.
P R O G R A M M A B L E H E A T I N G
Page 76 of 189
92
III
Setting the timeImmediate startAdjusting the operating duration
After displaying the time, using buttons 1, within 10 seconds press buttons 4 and 5 simultaneously.
Press button 5 (ON) until the "OK"message appears.
When the signal has been received, the "OK" message is displayed together with the operating dura-tion.
Press buttons 1 to display the operating duration.
P R O G R A M M A B L E H E A T I N G
T h i s s y m b o l fl a s h e s .
Set the time using buttons 1. Press buttons 4 and 5 simultaneously to store the setting.
This symbol is displayed (constant).
The heater starts and this symbol is displayed.
To stop operation, press but-ton 4 (OFF) until the "OK" mes-sage appears.
This symbol goes off.
If the "FAIL" message appears dur-ing these operations, this indicates that the signal was not received. Go to a different location and then repeat the procedure.
This symbol is displayed.
After displaying the operating dura-tion, within 10 seconds press but-tons 4 and 5 simultaneously.
T h i s s y m b o l fl a s h e s .
Set the duration using buttons 1(adjustment in steps of 10 mins up to a maximum of 30 mins).
Press buttons 4 and 5 simultane-ously to store the duration setting.
This symbol is displayed (constant).
The factory setting is 30 minutes.
