Page 2 of 337
5
F A M I L I A R I S A T I O N
A. Central locking
B. Unlocking
C. Guide-me-home lighting
D. Key release/storage
Press on control A , located on the con-
trol panel to the right of the dashboard.
T h e f u e l fl a p a u t o m a t i c a l l y o p e n s u p
fully.
Insert the nozzle so as to push in the
metallic gate valve B .
P u s h t h e f u e l fl a p t o r e c l o s e i t .
After switching off the ignition, con-
trol A is only active for a few minutes.
If necessary, switch on the ignition
again to reactivate it.
Bonnet stay: detach the stay and pivot
it upwards to insert it into the notch.
68 Bonnet opening/closing
To unlock, pull the control located on the
right-hand side under the dashboard to-
wards you.
156
82
Opening
Using the multifunction screen, you can
choose from the following options when
opening your vehicle with the remote
control:
- either all of the doors and the tail-
gate,
- o r t h e d r i v e r ’ s d o o r w i t h a fi r s t p r e s s , then all of the other doors with a
second press.
To close: move the stay back to
its initial position, lower the bon-
net, then allow it to slam shut at
the end of its travel.
O P E N I N G
Remote control key Fuel tank
Capacity: approximately 60 litres.
Page 11 of 337
14
F A M I L I A R I S A T I O N
Front seats
Head restraint
Backrest angle
Seat height adjustment
Lumbar support
Longitudinal adjustment
Armrest Electric adjustments
Manual adjustments
58
Heated seat control (locat-
ed on the inside of the front
seats)
57
1. Adjustment of seat height, angle
and longitudinal position
2. Adjustment of backrest angle and
lumbar support
3. Driver: memorisation of driving
positions
The seats can also be adjusted on a
temporary basis:
- on opening one of the front doors,
- after switching on the ignition.
G E T T I N G S T A R T E D
Page 12 of 337
15
F A M I L I A R I S A T I O N
Adjusting the steering wheel
The steering wheel can be adjusted in
terms of height and reach.
Unlock the steering wheel by pulling
control A towards you.
Adjust the position of the steering
wheel then lock it pushing the control
back fully.
67 T h i s m o d i fi e s i t s r o l e a u t o m a t i c a l l y a n d
progressively between day use and
night use.
It can be deactivated using control
1 . This operates with the ignition switched
on.
From the driver’s seat, select the rear
view mirror by moving control
1 to the
left or right, then adjust the rear view
m i r r o r a s r e q u i r e d i n t h e 1 d i r e c t i o n s u s -
ing control 2 .
Demisting-deicing of the rear view mir-
rors is linked to that of the rear screen.
93
66
For safety reasons, these adjust-
ments must not be carried out whilst
driving. Child monitoring mirror
This device
2 allows you to monitor the
rear passengers. It can be folded away
to eliminate dazzle.
Rear view mirrors foldback
When the vehicle is parked, the rear
view mirrors can be folded back either
manually or automatically.
G E T T I N G S T A R T E D
Automatic photochromic
interior rear view mirror Rear view mirrors adjustment
67
Page 14 of 337
17
F A M I L I A R I S A T I O N
Ring B Ring D: rear screen wipe Stop.
Intermittent.
Timed wash and wipe. Fixed central controls steering
wheel
Lighting control
Ring A
85 Control C: windscreen wipe
89
D R I V I N G
1. Off
2. Automatic lighting
3. Sidelamps
4. Dipped beams/Main beams
Front foglamps
Rear foglamp Wiper control
1. Optional function controls
2. Cruise control/speed limiter and
parking space sensor
3. Audio system controls
4. Multifunction screen controls
142
5. Horn
113
6. Warning lamps for direction indica-
tors and vehicle lamps
27
84 Switching on "AUTO" mode
Press the control down and release it.
Switching off "AUTO" mode
Press the control up and return it to
position "0" .
The automatic wipe must be reactivated
each time the vehicle is started.
Page 17 of 337
20
F A M I L I A R I S A T I O N
Driver’s and front passenger’s control panel
Automatic air conditioning
Rear passengers’ control panel
V E N T I L A T I O N
1. Automatic comfort regulation.
2. Adjustment and display of driver’s
temperature.
3. Adjustment of air blower speed.
Maintaining of ventilation with the engine switched off (REST).
4. Adjustment and display of air distri-
bution.
5. Air recirculation.
6. Mode of adjustment for rear pas-
sengers.
7. Panel and buttons display mode
(black panel).
8. De-icing/Demisting of rear screen
and rear view mirrors.
9. Rapid de-icing/demisting of wind-
screen and windows.
10. Air conditioning.
11. Adjustment and display of front pas-
senger’s temperature.
49, 54
12. Adjustment of air blower speed.
52
13. Temperature adjustment (no warm
air distribution).
14. Adjustment of air blower speed.
53
Page 21 of 337
24
I
I N S T R U M E N T S a n d C O N T R O L S
MONOCHROME INSTRUMENT PANEL
MULTIFUNCTION SCREEN A
The instrument panel groups all the driving and comfort information at the centre of the dashboard.
Central display
1. Rev counter
2. Electronic gearbox or automatic
gearbox selector position and
gear
3. Electronic gearbox or automatic
gearbox "Foot on brake" warning
lamp
4. Speedometer
5. Cruise control or speed limiter
setting
6. Fuel gauge
7. Trip mileage recorder
8. Multifunction screen A
9. Total mileage recorder
In this zone, the following infor- mation appears in succession
when the ignition is switched on:
- maintenance indicator,
- engine oil level indicator,
- total mileage recorder. Control buttons
A. Lighting rheostat (available day
and night)
B. Trip mileage recorder reset
C. Personalisation of the instru-
ment panel (display of desired
information)
D. CHECK (list of alerts)
Page 22 of 337
25
I
I N S T R U M E N T S a n d C O N T R O L S
TWO - TONE INSTRUMENT PANEL
MULTIFUNCTION SCREEN C
The instrument panel groups all the driving and comfort information at the centre of the dashboard.
Central display
1. Rev counter
2. Electronic gearbox or automatic
gearbox selector position and
gear
3. Electronic gearbox or automatic
gearbox "Foot on brake" warning
lamp
4. Speedometer
5. Cruise control or speed limiter
setting
6. Fuel gauge
7. Trip mileage recorder
8. Multifunction screen C
9. Total mileage recorder
In this zone, the following infor- mation appears in succession
when the ignition is switched on:
- maintenance indicator,
- engine oil level indicator,
- total mileage recorder. Control buttons
A. Lighting rheostat (available day
and night)
B. Trip mileage recorder reset
C. Personalisation of the instru-
ment panel (display of desired
information)
D. COLOUR (choice of background
colour ranging from white to
blue)
Page 23 of 337
26
I
I N S T R U M E N T S a n d C O N T R O L S
NAVIDRIVE INSTRUMENT PANEL
NAVIDRIVE MULTIFUNCTION SCREEN
The instrument panel groups all the driving and comfort information at the centre of the dashboard.
Central display
1. Cruise control or speed limiter
setting
2. Speeometer
3. NaviDrive multifunction screen
(see "NaviDrive instructions")
4. Rev counter
5. Electronic gearbox or automatic
gearbox "Foot on brake" warning
lamp
6. Fuel gauge
7. Electronic gearbox or automatic
gearbox selector position
8. Trip mileage recorder
9. Total mileage recorder
In this zone, the following infor- mation appears in succession
when the ignition is switched on:
- maintenance indicator,
- engine oil level indicator,
- total mileage recorder. Control buttons
A. Personalisation of the instru-
ment panel (display of desired
information)
B. COLOUR (choice of background
colour ranging from white to
blue)
C. Lighting rheostat (available day
and night)
D. Trip mileage recorder reset
