79
IV
A C C E S S
Unlocking
Press button A again to unlock
the vehicle.
The red indicator lamp on the button
switches off.
If the vehicle is locked or dead-
locked from the outside, the red in-
d i c a t o r l a m p fl a s h e s a n d b u t t o n A
is inactive.
In this case, use the remote
control or the key to unlock the
vehicle.
Automatic centralised control
System which provides full auto-
matic locking or unlocking of the
doors, boot and rear screen while
driving.
You can activate or deactivate this
function.
Locking
When the speed exceeds 6 mph
(10 km/h), the doors, the boot and
the rear screen lock automatically. Unlocking
Above 6 mph (10 km/h), press
button A to unlock the doors, the
boot and the rear screen tempo-
rarily.
Activation
Press button A for more than
two seconds.
A c o n fi r m a t i o n m e s s a g e a p p e a r s o n
the multifunction screen.
Deactivation
Press button A again for more
than two seconds.
A c o n fi r m a t i o n m e s s a g e a p p e a r s o n
the multifunction screen.
Emergency control
System which locks or unlocks the doors mechanically in the event of a malfunction of the battery or of the central locking.
Locking the driver's door
Insert the key in the lock, then turn it to the right.
Unlocking the driver's door
Insert the key in the lock, then turn it to the left.
Locking the front and rear passenger doors
Insert the key in the lock, located on the edge of the door, then turn it one eighth of a turn .
Unlocking the front and rear passenger doors
Pull the interior door opening control.
If one of the doors or the boot or
rear screen is open, the automatic
central locking does not take place.
Page 93 of 337
82
IV
A C C E S S
FUEL TANK
Capacity of the tank: approxi-
mately 60 litres.
Low fuel level
When the minimum level in the
tank is reached, this warning
lamp on the instrument panel
comes on, accompanied by
an audible warning and a message
on the multifunction screen.
You have enough fuel left to drive
approximately 30 miles (approx.
50 kms).
Press on the the control A , situ-
ated on the control panel on the
r i g h t h a n d s i d e . T h e f u e l fl a p a u -
tomatically opens up. The petrol or diesel engine of your
v e h i c l e i s fi t t e d w i t h a c a t a l y t i c c o n -
verter, a device which helps to re-
duce the level of harmful emissions
in the exhaust gases.
For petrol engines, unleaded fuel
is obligatory.
T h e fi l l e r n e c k i s n a r r o w e r , p e r m i t -
ting unleaded petrol only.
Take care to select the pump
that corresponds to the correct
fuel type for your vehicle.
Introduce the nozzle so as to
push in the metallic gate valve B.
Make sure that the nozzle is
pushed in as far as possible
before starting to refuel (risk of
blowback).
Maintain this position throughout
the refuelling operation.
P u s h t h e f u e l fl a p t o r e c l o s e i t .
Fuel cut-off switch
Your vehicle is equipped with a safe-
ty device which cuts off the fuel sup-
ply in the event of a collision.
Refuelling
I f y o u a r e fi l l i n g y o u r t a n k t o t h e
top, do not persist after the third
cut-off; this could cause your
vehicle to malfunction.
Page 94 of 337
83
IV
A C C E S S
UNLEADED PETROL After switching off the ignition, the
control
A is active for only a few
minutes. If necessary, switch on
the ignition again to reactivate it.
If you have put in fuel that is
wrong for your vehicle, it is es-
sential to have the tank drained
before you start the engine.
Fuel quality
A l a b e l a f fi x e d t o t h e i n s i d e o f t h e
f u e l fl a p i n d i c a t e s t h e f u e l s t h a t a r e
authorised.
DIESEL FUEL
The petrol engines are designed to
run on RON 95.
However, for better vehicle perform-
ance (petrol engines), we recom-
mend RON 98.
Page 95 of 337
84
V I S I B I L I T Y
LIGHTING CONTROLS
System for selection and control of
the various front and rear lamps pro-
viding the vehicle's lighting.
Main lighting
The various front and rear lamps of
the vehicle are designed to adapt
the driver's visibility progressively in
relation to the climatic conditions:
- sidelamps, to be seen,
- dipped headlamps to see with-out dazzling other drivers,
- main beam headlamps to see clearly when the road is clear,
- directional headlamps for im- proved visibility when cornering.
Additional lighting
O t h e r l a m p s a r e fi t t e d t o f u l fi l t h e r e -
quirements of particular driving con-
ditions:
- a rear foglamp to be seen from a distance,
- front foglamps for even better forward vision,
- daytime running lamps to be seen during the day. Programming
Various automatic lighting control
modes are also available depending
on options:
- guide-me-home lighting,
- automatic lighting,
- directional lighting.
Manual controls
lamps off,
automatic switching on of
the lamps,
sidelamps only,
dipped headlamps or
main beam headlamps.
B. stalk for switching headlamps by
pulling: dipped headlamps/main
beam headlamps.
In the lamps off and sidelamps
modes, the driver can switch on the
main beam headlamps temporarily
( " h e a d l a m p fl a s h " ) b y m a i n t a i n i n g a
pull on the stalk.
Displays
Lighting of the corresponding indi-
cator lamp on the instrument panel
c o n fi r m s t h e s e l e c t i v e s w i t c h i n g o n
of the lighting selected.
The lighting commands are issued
directly by the driver by means of
the ring
A and the stalk B .
A. main lighting mode selection ring,
with:
Page 96 of 337
85
V I S I B I L I T Y
V
C. fog lamps selection ring.
The fog lamps operate with the
sidelamps and the dipped and main
beam headlamps.
- 1 st turn forwards: rear foglamp on.
- 1 st turn rearwards: rear foglamp off. - 1 st turn forwards: front foglamps
on.
- 2 nd turn forwards: rear foglamps on.
- 1 st turn rearwards: rear foglamps off.
- 2 nd turn rearwards: front foglamps off.
Model with rear foglamp only
Model with front and rear
foglamps In good or rainy weather, both day
and night, the front foglamps and
the rear foglamp are prohibited. In
these situations, the power of their
beams may dazzle other drivers.
They should only be used in fog or
snow.
In these weather conditions, it is
your responsibility to switch on the
foglamps and dipped headlamps
manually as the brightness sensor
m a y d e t e c t s u f fi c i e n t l i g h t .
Do not forget to switch off the front
foglamps and the rear foglamp when
they are no longer necessary.
Lighting on buzzer
The triggering of an audible signal
when a front door is opened warns
the driver that he has forgotten to
switch off his vehicle's lamps, with
the ignition off and in manual light-
ing mode.
In this case, switching off the lamps
stops the audible signal.
With the ignition off, if the dipped
headlamps remain on, they will
switch off automatically after thirty
minutes to prevent discharging of
the battery.
Page 97 of 337
86
V I S I B I L I T Y
V
* According to country.
Daytime-running lamps *
System which switches on the ve-hicle's dipped headlamps automati-cally on starting.
This safety system makes the vehi-cle more visible to other road users during the day.
The lighting of the instruments and controls (instrument panel, multi-function screen, air conditioning c o n t r o l p a n e l , . . . ) i s i n d e p e n d e n t o f this function. It is provided by the automatic lighting mode or when the lamps are switched on manually.
Manual guide-me-home
lighting
The temporary lighting of dipped
headlamps after the vehicle's igni-
tion has been switched off makes
the driver's exit easier when the light
is poor.
Switching on
W i t h t h e i g n i t i o n o f f , " fl a s h " t h e
headlamps using the lighting
stalk B .
A s e c o n d " h e a d l a m p fl a s h "
switches the function off again.
Switching off
The manual guide-me-home lighting
switches off automatically after a set
time.
The manual guide-me-home light-
ing is also available by pressing the
lighting button on the remote con-
trol (refer to the section "Access -
§ R e m o t e c o n t r o l k e y " ) . Automatic lighting
The sidelamps and dipped head-
lamps are switched on automatically,
without any action on the part of the
driver, when a low level of external
light is detected or in certain cases of
activation of the windscreen wipers.
As soon as the brightness returns
t o a s u f fi c i e n t l e v e l o r a f t e r t h e w i n d -
screen wipers are switched off, the
lights are switched off automatically.
Activation
Turn ring A to the "AUTO" posi-
tion. The automatic lighting is ac-
companied by a message on the
multifunction screen.
Deactivation
Turn ring A to a position other
than "AUTO" . Deactivation is
accompanied by a message on
the multifunction screen.
regulations:
-by default, this function is activated,
-the sidelamps and the number plate lamps are also switched on.
Page 98 of 337
87
V I S I B I L I T Y
V
Linking with the automatic
"Guide-me-home" lighting
Association with the automatic light-
ing provides the "guide-me-home"
lighting with the following additional
options:
- selection of the lighting duration for 15, 30 or 60 seconds in the
vehicle parameters on the mul-
t i f u n c t i o n s c r e e n c o n fi g u r a t i o n
menu (in the case of the mono-
chrome screen A, the duration is
fi x e d ) ,
- automatic activation of "guide- me-home" lighting when auto-
matic lighting is in operation.
Operating fault
In the event of a malfunction of
the brightness sensor, the lighting
comes on, a message appears on
the multifunction screen, accompa-
nied by an audible signal.
Consult a CITROËN dealer. In fog or snow, the brightness
s e n s o r m a y d e t e c t s u f fi c i e n t l i g h t .
Therefore, the lights will not come
on automatically.
Do not cover the brightness sen-
sor, linked with the rain sensor and
located in the centre of the wind-
screen behind the interior mirror;
the associated functions would no
longer be controlled.
EXTERIOR SIDE SPOTLAMPS
These illuminate:
- the zones facing the driver’s and passenger’s doors,
- the zones forward of the door mirrors and rearward of the front
doors.
Switching on
The side spotlamps come on:
- when you unlock the vehicle or press on the lighting button on
the remote control,
- when you remove the key from the ignition,
- when you open a door,
- when you use the remote control.
Switching off
They are timed to go out automati-
cally.
THE HEADLAMPS
To avoid dazzling other road users,
the height of the halogen bulb head-
lamps must be adjusted according
to the load in the vehicle. To do this,
turn the control, located below the
fascia to the right of the driver, to the
appropriate position:
0. 1 or 2 people in the front seats.
-. 3 people.
1. 4 to 7 people.
-. Intermediate setting.
2. 4 to 7 people + maximum author-
ised loads.
-. Intermediate setting.
3.
Driver + maximum authorised loads.
Initial setting is position "0".
Page 99 of 337
88
V I S I B I L I T Y
V
AUTOMATIC ADJUSTMENT OF THE DIRECTIONAL HEADLAMPS
In order to avoid causing a nuisance
to other road users, this system cor-
rects the height of the xenon head-
lamps beam automatically and when
stationary, in relation to the load in
the vehicle. If a malfunction oc-
curs, this warning lamp
is displayed on the in-
strument panel, ac-
companied by an au-
dible signal and a message on the
multifunction screen.
The system then places your head-
lamps in the lowest position.
Do not touch the xenon bulbs.
Consult a CITROËN dealer.
DIRECTIONAL LIGHTING
When the dipped or main beam
headlamps are on, this function ena-
bles the light beam to follow the di-
rection of the road.
The use of this function, coupled
with the xenon headlamps only,
considerably improves the quality of
your lighting when cornering.
with directional lighting
without directional lighting Programming
The function is activat-
ed or deactivated via
the multifunction screen
c o n fi g u r a t i o n m e n u .
Operating fault If a malfunction occurs, this
w a r n i n g l a m p fl a s h e s o n t h e
instrument panel, accompa-
nied by a message on the
multifunction screen.
Consult a CITROËN dealer.
When stationary or moving at very
low speed or when reverse gear is
engaged, the system is inactive.
The status of the system remains
in the memory when the ignition is
switched off.
O n v e h i c l e s fi t t e d w i t h d a y t i m e
running lights, the function is acti-
vated if the lighting stalk is in the
"AUTO" or "Dipped/main beam
headlamps" position. In position
"0" , the function is not activated.
