IX
D R I V I N G
LANE DEPARTURE WARNING SYSTEM
System which detects the involun-
tary crossing of longitudinal traffi c
lane markings on the ground (solid
or broken line).
Sensors, fi tted below the front
bumper, trigger a warning if the vehi-
cle drifts over a lane marking (speed
higher than 50 mph (80 km/h)).
This system is particularly useful on
motorways and main roads. Activation

 Press button A , the indicator
lamp comes on.
Deactivation

 Press button A again, the indica-
tor lamp switches off.
The status of the system remains
in the memory when the ignition is
switched off.
Detection
You are warned by the vibration of
the driver's seat cushion:
- on the right-hand side, if the marking on the ground has been
crossed on the right,
- on the left-hand side, if the mark- ing on the ground has been
crossed on the left.
No warning is transmitted while the
direction indicator is active and for
approximately 20 seconds after the
direction indicator is switched off.
A warning may be transmitted if a
direction marking (e.g. arrow) or
non-standard marking (e.g. graffi ti)
is crossed. Operating fault
In the event of a malfunction, the
service warning lamp comes on, ac-
companied by an audible signal and a
message on the multifunction screen.
Consult a CITROËN dealer.
The lane departure warning system
cannot, in any circumstances, re-
place the need for vigilance and re-
sponsibility on the part of the driver. The detection may be impeded:
- if the sensors are dirty (mud, snow...),
- if the markings on the ground
are worn,
- if there is little contrast between the markings on the ground and
the road surface.

153
IX
D R I V I N G
PNEUMATIC SUSPENSION

Grand
C4 Picasso
C4 Picasso
The rear pneumatic suspension en-
hances driving comfort by maintain-
ing a constant body height whatever
the vehicle load. Operation
- If there is an increase in vehi-
cle load, a sinking of the rear of
the vehicle is detected and the
pneumatic springs infl ate in or-
der to compensate for the extra
weight.
- If there is a decrease in load, a rising of the rear of the vehicle is
detected and so the pneumatic
springs defl ate to return the ve-
hicle to its nominal height.
- If the vehicle has been unused for a long period, the pneumatic
springs may infl ate if necessary
when you unlock or open a door,
so as to return the vehicle to its
nominal height.
If you do not reactivate the system
manually, the automatic correction
will be activated as soon as the ve-
hicle starts to move. During the cor-
rection, the service warning lamp
lights up and a message on the
screen reminds you not to exceed
10 km/h (6 mph).
The automatic correction does not
function if the doors or the boot are
open.
The automatic correction operates
even if your vehicle is in power
economy mode. Activation/Deactivation
The automatic correction can be de-
activated:

 press on the button B for approx-
imately two seconds,

 release the button when you
hear a beep. Deactivation is con-
fi rmed by the lighting of the indi-
cator lamp on the button B .

In the event of the system mal-
functioning, alert messages,
always in association with the
service warning lamp, will dis-
play in the instrument panel .
Consult a CITROËN dealer.
It is essential that you should deactivate
the system in the following instances:
- working under the vehicle,
- changing a wheel,
- transporting the vehicle on a
truck or on a boot.
To reactivate the automatic correction:

 press again on the button B for
approximately two seconds,

 release the button when you hear
a beep. Activation is confi rmed
by the extinction of the indicator
lamp on the button B .

161
C H E C K S
CHECKING LEVELS
Check all of these levels regularly
and top them up if necessary, unless
otherwise indicated.
If a level drops signifi cantly, have the
corresponding system checked by a
CITROËN dealer.
Oil level
Oil change
Refer to the Maintenance and
Warranty Guide for details of the in-
terval for this operation. Oil specifi cation
The oil must correspond to your en-
gine and conform to the manufactur-
er's recommendations.
Brake fluid level
Fluid change
Refer to the Maintenance and
Warranty Guide for details of the in-
terval for this operation.
This fl uid must be changed regu-
larly. Fluid which has been used for
too long may cause a loss of braking
effi ciency.
Fluid specifi cation
The brake fl uid must conform to the
manufacturer's recommendations
and fulfi l the DOT4 standards.
Coolant level
Draining the system
The coolant does not have to be
changed.
Fluid specifi cation
The coolant must conform to the
manufacturer's recommendations.
The reading will only be
correct if the vehicle is on
level ground and the engine
has been off for more than
15 minutes.
The check is carried out either when
the ignition is switched on using the
oil level indicator on the instrument
panel, or using the dipstick.
Between two oil changes, the con-
sumption should not exceed 0.5 litre
per 600 miles (approx. 1 000 km).
Check this level also between each
scheduled service and before long
journeys. The brake fl uid level should
be close to the "MAX" mark.
If it is not, check the brake
pad wear.
The coolant level should be
close to the "MAX" mark but
should never exceed it.
When the engine is warm,
the temperature of the coolant is
regulated by the fan. This can oper-
ate with the ignition off.

On vehicles which are fi tted with
a particle emission fi lter, the fan
may operate after the vehicle has
been switched off, even if the en-
gine is cold.
In addition, as the cooling system is
pressurised, wait at least one hour
after switching off the engine before
carrying out any work.
To avoid any risk of scalding, un-
screw the cap by two turns to al-
low the pressure to drop. When the
pressure has dropped, remove the
cap and top up the level.
In order to maintain the re-
liability of the engine and
emission control system,
the use of additives in the engine
oil is prohibited.
