27
I
I N S T R U M E N T S a n d C O N T R O L S
Airbags If this comes on, it indicates
the occurrence of a fault in
one of the airbag or seat belt
pretensioner systems.
Door open
A door, the boot or the bonnet
is open:
- if the speed is below 6 mph (10 km/h), this warning lamp
comes on continuously.
- if the speed is higher than 6 mph (10 km/h), this warning lamp
comes on continuously, accom-
panied by an audible signal. Seat belt not fastened/
unfastened
Driver's seat belt not fastened:
-
The warning lamp comes on if the
driver’s seat belt is not fastened
when the ignition is switched on and
between 0 and 12 mph (approx.
20 km/h).
- Above 12 mph (approx. 20 km/h),
t h e w a r n i n g l a m p fl a s h e s f o r a p p r o x i -
mately 120 seconds, accompanied by
an audible signal. It then remains on.
Front passenger and rear passenger
seat belts not fastened:
- When the ignition is switched on, the warning lamp always comes
on if the passenger's seat belt is
not fastened.
It goes off when the engine is running,
doors closed and after 30 seconds.
- If a seat belt is unfastened, the warning lamp comes on between 0
and 12 mph (approx. 20 km/h).
- Above 12 mph (approx. 20 km/h), t h e w a r n i n g l a m p fl a s h e s f o r a p -
proximately 120 seconds, accom-
panied by an audible signal. Maintenance indicator
System which informs the driver
when the next service is due, in ac-
cordance with the manufacturer’s
servicing schedule.
The point at which the service is due
is calculated from the last indicator
zero reset. It is determined by two
parameters:
- the distance travelled,
- the time elapsed since the last
service.
Page 11 of 279
27
I
I N S T R U M E N T S a n d C O N T R O L S
Airbags If this comes on, it indicates
the occurrence of a fault in
one of the airbag or seat belt
pretensioner systems.
Door open
A door, the boot or the bonnet
is open:
- if the speed is below 6 mph (10 km/h), this warning lamp
comes on continuously.
- if the speed is higher than 6 mph (10 km/h), this warning lamp
comes on continuously, accom-
panied by an audible signal. Seat belt not fastened/
unfastened
Driver's seat belt not fastened:
-
The warning lamp comes on if the
driver’s seat belt is not fastened
when the ignition is switched on and
between 0 and 12 mph (approx.
20 km/h).
- Above 12 mph (approx. 20 km/h),
t h e w a r n i n g l a m p fl a s h e s f o r a p p r o x i -
mately 120 seconds, accompanied by
an audible signal. It then remains on.
Front passenger and rear passenger
seat belts not fastened:
- When the ignition is switched on, the warning lamp always comes
on if the passenger's seat belt is
not fastened.
It goes off when the engine is running,
doors closed and after 30 seconds.
- If a seat belt is unfastened, the warning lamp comes on between 0
and 12 mph (approx. 20 km/h).
- Above 12 mph (approx. 20 km/h), t h e w a r n i n g l a m p fl a s h e s f o r a p -
proximately 120 seconds, accom-
panied by an audible signal. Maintenance indicator
System which informs the driver
when the next service is due, in ac-
cordance with the manufacturer’s
servicing schedule.
The point at which the service is due
is calculated from the last indicator
zero reset. It is determined by two
parameters:
- the distance travelled,
- the time elapsed since the last
service.
Page 12 of 279
27
I
I N S T R U M E N T S a n d C O N T R O L S
Airbags If this comes on, it indicates
the occurrence of a fault in
one of the airbag or seat belt
pretensioner systems.
Door open
A door, the boot or the bonnet
is open:
- if the speed is below 6 mph (10 km/h), this warning lamp
comes on continuously.
- if the speed is higher than 6 mph (10 km/h), this warning lamp
comes on continuously, accom-
panied by an audible signal. Seat belt not fastened/
unfastened
Driver's seat belt not fastened:
-
The warning lamp comes on if the
driver’s seat belt is not fastened
when the ignition is switched on and
between 0 and 12 mph (approx.
20 km/h).
- Above 12 mph (approx. 20 km/h),
t h e w a r n i n g l a m p fl a s h e s f o r a p p r o x i -
mately 120 seconds, accompanied by
an audible signal. It then remains on.
Front passenger and rear passenger
seat belts not fastened:
- When the ignition is switched on, the warning lamp always comes
on if the passenger's seat belt is
not fastened.
It goes off when the engine is running,
doors closed and after 30 seconds.
- If a seat belt is unfastened, the warning lamp comes on between 0
and 12 mph (approx. 20 km/h).
- Above 12 mph (approx. 20 km/h), t h e w a r n i n g l a m p fl a s h e s f o r a p -
proximately 120 seconds, accom-
panied by an audible signal. Maintenance indicator
System which informs the driver
when the next service is due, in ac-
cordance with the manufacturer’s
servicing schedule.
The point at which the service is due
is calculated from the last indicator
zero reset. It is determined by two
parameters:
- the distance travelled,
- the time elapsed since the last
service.
Page 39 of 279
52
III
C O M F O R T
REAR SEATS
Bench seat, the left-hand section
(2/3) or right-hand section (1/3) of
which can be folded independently
to vary the load space in the boot.
R e a r h e a d r e s t r a i n t s
The rear head restraints can be removed
and have two positions:
- high, when in use,
- low, to store.
To raise the head restraint, pull it up-
wards.
To lower it, press the catch then
press on the head restraint.
To remove it, move it to the high po-
sition, push the catch and pull the
head restraint upwards.
To put it back in place, engage the
rods of the head restraint in the
holes keeping them in line with the
backrest.
Never drive with the head restraints
removed; they must be in place and
adjusted correctly. F o l d i n g t h e s e a t c u s h i o n
raise the front of the seat cushion,
tilt it towards the front seats.
When repositioning the seat base,
make sure that the seat belt buckles
are back in place.
When you fold a rear seat cushion,
you should also fold the corresponding
backrest. Before tipping the rear seat, make
sure that the seat belts will not be
snagged or trapped by the seat and
its catches. Position them carefully
to the sides of the backrests.
B e f o r e f o l d i n g t h e s e a t
Page 43 of 279
56
IV
A C C E S S
REMOTE CONTROL KEY
System which permits central unlocking
or locking of the vehicle using the lock
or remotely. It is also used to locate
the vehicle, activate the guide-me-
home lighting and start the engine, as
well as providing protection against
theft.
Unlocking the vehicle
Complete unlocking using the
remote control
Unfolding the key
First press button A to unfold the
key.
Press the open padlock
to unlock the vehicle. Complete unlocking using the key Turn the key to the left in the driver's door lock to unlock the vehicle.
U n l o c k i n g i s c o n fi r m e d b y r a p i d fl a s h i n g o f t h e d i r e c t i o n i n d i c a t o r s a n d switching on of the courtesy lamp for approximately two seconds.
According to version, the exterior
mirrors unfold at the same time.
L o c k i n g i s c o n fi r m e d b y fi x e d l i g h t -
ing of the direction indicators for ap-
proximately two seconds.
According to version, the exterior
mirrors fold at the same time.
Locking the vehicle
Normal locking using the remote
control
Press the closed pad-
lock to lock the vehicle
completely.
Press the closed padlock for more
than two seconds to close the
windows in addition to locking.
If one of the doors or the boot is
still open, the central locking does
not take place.
When the vehicle is locked, if it is
unlocked inadvertently, it will relock
automatically after thirty seconds
unless a door is opened.
The folding and unfolding of the
exterior mirrors using the remote
control can be deactivated by a
CITROËN dealer.
Normal locking using the key
Turn the key to the right in the
driver’s door lock to lock the ve-
hicle completely.
Page 51 of 279
61
IV
A C C E S S
ALARM
System which protects and provides
a deterrent against the theft of your
vehicle. It provides two types of pro-
tection, exterior and interior, as well
as an anti-tamper function.
Exterior perimeter protection
The system detects opening of the
vehicle.
The alarm is triggered if anyone tries
to enter the vehicle by forcing a door,
the boot or the bonnet.
Interior volumetric protection
The system detects any variation in
the volume in the passenger com-
partment.
The alarm is triggered if anyone breaks
a window or moves inside the vehicle.
If you wish to leave a pet in the vehicle
or a window partially open, deactivate
the interior volumetric protection.
Anti-tamper function
The system detects the putting out
of service of its components.
The alarm is triggered if anyone
tries to put the wires of the siren, the
central control or the battery out of
service.
D o n o t m a k e a n y m o d i fi c a t i o n s t o
the alarm system, this could cause
malfunctions. Locking the vehicle with full
alarm
Activation
Switch off the ignition and get out
of the vehicle.
Lock or deadlock the vehicle using
the locking button on the remote
control.
The alarm is activated; the indicator
light on button A fl a s h e s o n c e p e r
second.
Deactivation
Unlock the vehicle using the
unlocking button on the remote
control.
The alarm is deactivated; the indicator
light on button A switches off. Locking the vehicle with
exterior protection alarm only
Deactivation of the interior
volumetric protection
Switch off the ignition.
Within ten seconds, press but-
ton A until the indicator lamp is lit
continuously.
Get out of the vehicle.
Lock or deadlock the vehicle using
the locking button on the remote
control.
The exterior protection alarm alone
remains activated; the indicator
lamp on button A fl a s h e s o n c e p e r
second.
To be effective, this deactivation
must be carried out each time the
ignition is switched off.
Reactivation of the interior
volumetric protection
Unlock the vehicle using the
unlocking button on the remote
control.
Relock the vehicle using the
remote control.
The alarm is activated again with
both types of protection; the indicator
lamp on button A switches off.
Page 52 of 279
62
IV
A C C E S S
Triggering
This is indicated by sounding of the
s i r e n a n d fl a s h i n g o f t h e d i r e c t i o n
indicators for approximately thirty
seconds.
After it has been triggered, the alarm
is again operational.
If the alarm is triggered ten times in
succession, the eleventh time will
result in it becoming inactive. If the indicator lamp on button A
fl a s h e s r a p i d l y , t h i s i n d i c a t e s t h a t
the alarm was triggered during
your absence. When the ignition is
s w i t c h e d o n , t h i s fl a s h i n g s t o p s i m -
mediately.
To avoid triggering the alarm when
washing your vehicle, lock it using
the key.
Do not activate the alarm before
disconnecting the battery, otherwise
the siren will sound. Failure of the remote control
Unlock the vehicle using the key
in the driver's door lock.
Open the door; the alarm is trig-
gered.
Switch on the ignition; the alarm
stops.
Locking the vehicle without
alarm
Lock or deadlock the vehicle us-
ing the key in the driver's door
lock.
* According to country.
Malfunction
When the ignition is switched on,
lighting of the indicator lamp on
button
A for ten seconds indicates
a siren fault.
Have it checked by a CITROËN
dealer. Automatic operation *
Depending on the legislation in force
in your country, one of these cases
may occur:
- 45 seconds after the vehicle is
locked using the remote control,
the alarm is activated, regard-
less of the status of the doors
and boot.
- 2 minutes after the last door or the boot is closed, the alarm is
activated.
To avoid triggering the alarm
o n e n t e r i n g t h e v e h i c l e , fi r s t
press the unlocking button on
the remote control.
Page 55 of 279
65
IV
A C C E S S
DOORS
Opening
From outside When the selective unlocking is acti-
v a t e d , t h e fi r s t p r e s s o f t h e r e m o t e
control unlocking button permits
unlocking of the driver’s door only.
Pull on the front door control to
open the door; this unlocks the
vehicle completely.
Pull on the rear door control to
open the door; this unlocks the
door concerned only.
With the selective unlocking acti-
vated:
- the driver’s door control unlocks the driver’s door only,
- the other door controls unlock the other doors and the boot.
The interior door controls do not
operate when the vehicle is dead-
locked. Central manual control
System which provides full manual
locking or unlocking of the doors
and boot from the inside.
Locking
Press button A to lock the vehicle.
The red indicator lamp on the button
comes on.
If one of the doors is open, the cen-
tral locking from the inside does not
take place.
If the boot is open, the central lock-
ing from the inside is active for the
doors, to permit the transportation
of long objects.
After unlocking the vehicle com-
pletely using the remote control
or the key, pull the door handle. From inside
