FAMILIARISATION8 -
FRONT SEATS
Never travel with the head
restraints removed.

2. Armrest.

3. Seat back angle adjustment.

4. Forwards-backwards adjustment.

5. Storage drawer
(passenger).

 40

1. Head restraint height adjustment.

9FAMILIARISATION-
REAR BENCH SEATS (7 SEAT VERSION)
Disarming the passenger air bag

 With the ignition off , insert the
ignition key into the passenger
air bag switch 1 and turn it to the

"OFF" position.

 As soon as you remove the child
seat, turn the air bag switch to the

"ON" position to activate the air
bag again. Disarming check
With the ignition switched
on (2 nd
notch), illumination
of this warning light indi-
cates that the passenger
air bag is disarmed (switch
in the "OFF" position).
The warning light remains on through-
out the duration of disarming.

 79
Front air bags
These are folded in the centre of the
steering wheel for the driver and in the
fascia for the front passenger. They are
deployed simultaneously, except in cases
where the passenger air bag is disarmed.
Precautions regarding the
passenger air bag

 disarm the air bag if you install a
rear-facing child seat,

 activate the air bag for an adult
passenger.

 78 Side air bags *
Side air bags are incorporated into the
front seat back frame, on the door side.
They are deployed independently of
each other, on whichever side the
collision occurs.
AIR BAGS

 44
The 7 seat version is fi tted with a
2-seat bench in row 2 and a 3-seat
bench in row 3.
* According to version.

41SEATS-
FRONT SEATS

The adjustment is correct when
the upper edge of the head re-
straint is level with the top of the
head.
To remove the head restraint, place it
in the top position, press the tabs and
pull it upwards.
To put it back in position, locate the
stems of the restraint in the holes,
taking care to keep them in line with
the seat back.
No person or object must pre-
vent the seat from returning
to its initial position; return to
this position is necessary for
the seat to lock in place.
4. Forwards-backwards
adjustment
Lift the control and slide the seat for-
wards or backwards.
1. Head restraint height
adjustment
To raise or lower the restraint, slide it.
2. Armrests
These can be folded back. 3. Seat back angle adjustment
5. Storage drawer (version with
passenger air bag)
There is a storage drawer under the
front passenger seat.
To open it, lift it and pull. 6. Heated seats switch
Press the switch. The temperature is
controlled automatically.
Pressing the switch again stops op-
eration.

Note: the command for activation of
heating of the seat(s) remains mem-
orised for two minutes after the igni-
tion has been switched off.
7. Access to rear seats (version with one
sliding side door only)
Do not place heavy objects
in the drawers.
A. Turn the knob.

B. Pull the lever (version
with one sliding side
door only).
Never drive with the head re-
straints removed; they must
be in place and correctly ad-
justed. Lift the control to fold the seat back
and move the seat forwards.
On repositioning, the seat returns to
its initial position (driver's side).

SEATS42-
MULTIFUNCTION PASSENGER SEAT
To fold the seat fully:
Pull the control 2 upwards and tilt the
whole seat.
It is not necessary to remove the
head restraint.
This provides access to a box which
enables you to store objects so that
they cannot be seen from outside the
vehicle. If your vehicle is not fi tted with a load
blocking partition, it can accommo-
date long objects (up to 2.10 m).
These must be placed on the front
edge of the fl oor and secured using
the rear bar of the boot or using the
lashing rings.
To fold the seat back:
Pull the control
1 upwards and tilt the
seat back.
This provides a fl at surface, recess-
es for drinks and a strap for retaining
documents.

43SEATS-
To fold the rear bench seat:
- lower the head restraint,
- press control 1 to unlock the seat
back 2 ,
- fold the seat back 2 onto the seat,
- place the seat in the "folded" posi- tion. When repositioning:
- tilt the folded seat rearwards,
- lift the seat back,
- check that the seat is locked cor-
rectly.

Take care not to trap the seat belts.
REAR BENCH SEAT(5 SEAT VERSION)
HEAD RESTRAINT
This is of the "comma" type.
High position: press the two tabs at
the same time, lift the head restraint
and raise it.
Low position: push the two tabs at
the same time and press the top to
lower the head restraint.
To remove the head restraint: place
it in the high position, lift it then re-
move it.
Store it inside the vehicle, securing
it fi rmly.
To install the head restraint: engage
the rods of the head restraint in the
holes keeping it in line with the seat
back.

45SEATS-
Row 3 bench seat
Placing the seat back in the table
position
- Lower the head restraints fully.
- Operate the two controls simulta-neously to fold the seat back onto
the bench seat cushion.
Returning the seat back to the sitting position
- Return the seat back to its original position and check that it is se-
cured on the pillars of the vehicle. Placing the bench seat in the fully
folded position
- Place the seat in the table posi-
tion.
- Raise the handle, located behind the bench seat, to release the
feet from their anchorage on the
fl oor.
- Tilt the bench seat forwards.
Returning the bench seat to its
original position
- Before folding back the bench seat, ensure that the seat belt
is available for the side passen-
gers.
- Fold back the bench seat.
Access to row 3
From the vehicle's right-hand sliding
door, a passage next to the row 2
bench seat provides access to the
row 3 bench seat.
Good practice
Do not place hard or heavy
objects on the seat backs
forming a table, they could
become dangerous projectiles in the
event or sharp braking or impact.
Following the various operations:
- do not remove a head restraint without storing it, fi x it to a sup-
port in the vehicle,
- do not block the passage to row 3,
- ensure that the passengers can always access the seat belts and
fasten them easily,
- a passenger must never take his seat without adjusting and fasten-
ing his seat belt.
- a passenger seated in row 3 must ensure that he does not obstruct
the row 2 bench seat anchoring
recesses.

71COMFORT AND SAFETY-
1. Load-space cover
To install it:
- position the front ends of the load space cover on its support and
press gently to put it in place,
- unfold the load space cover fully,
- position the rear ends of the load space cover on its support and
press gently to put it in place.
To remove it:
- unclip the rear ends,
- fold the load space cover fully,
- unclip the front ends and remove the load space cover.
To store it, fold it like an accordion.

Do not roll it . 2. High load retaining net
The high load retaining net can be fi t-
ted behind the front or rear seats.
Open the covers
A of the correspond-
ing upper fastenings.
Fit the ends of the metal bar in these
fastenings.
Secure the two net strap hooks be-
hind the front seats, with the rear
seat folded, or in the stowing rings B
on the fl oor.
The rings are located directly below
the corresponding upper fastenings.
Pull the two straps C taut. 3. Stowing rings
4. Side door storage
compartments
5. Trays between the front and rear seats
6. Seat back storage pockets
7. Cup holder
