Page 86 of 123
PRACTICAL INFORMATION82 -
1. Power steering reservoir
2. Windscreen and headlamp wash
reservoir
3. Coolant reservoir
4. B r a k e fl u i d r e s e r v o i r
5. Battery
6. A i r fi l t e r
7. Dipstick
8. Engine oil reservoir
1.9 LITRE DIESEL ENGINE
Page 87 of 123
83PRACTICAL INFORMATION-
1. Power steering reservoir.
2. Windscreen/headlamp wash res-
ervoir.
3. Coolant reservoir.
4. B r a k e fl u i d r e s e r v o i r .
5. Battery.
6. A i r fi l t e r .
7. Dipstick.
8. Engine oil reservoir.
9. P r i m i n g p u m p .
1.6 LITRE TURBO DIESEL HDI ENGINE
Page 94 of 123
91PRACTICAL INFORMATION-
O n l y u s e H 4 b u l b s m a n u f a c -
t u r e d b y :
- GE/TUNGSRAM,
- PHILIPS,
- OSRAM,
to avoid damaging the headlamps.
T h e s e m e e t t h e a n t i - U V ( u l t r a - v i o l e t )
s p e c i fi c a t i o n s n e c e s s a r y f o r t h e c o r -
rect operation and reliability of the
headlamps.
T h e h e a d l a m p s a r e fi t t e d w i t h a p o l y -
carbonate lens coated with a protec-
t i v e v a r n i s h . Y o u a r e s t r o n g l y a d v i s e d
t o a v o i d c l e a n i n g t h e m u s i n g a d r y o r
a b r a s i v e c l o t h a n d u s i n g d e t e r g e n t
p r o d u c t s o r s o l v e n t s .
Use a soft, damp cloth.
High pressure washing : w h e n u s -
i n g t h i s t y p e o f w a s h i n g o n s t u b b o r n
dirt, do not persist on the headlamps,
t h e l i g h t s a n d t h e i r s u r r o u n d t o a v o i d
damaging their coating and their
seal. Direction indicator side repeaters
( W Y 5 W a m b e r )
-
P u s h t h e t r a n s p a r e n t c o v e r f o r -
wards or rearwards and release it.
- T u r n t h e b u l b h o l d e r a q u a r t e r
t u r n .
- C h a n g e t h e b u l b .
A m b e r c o l o u r e d b u l b s ( d i r e c -
tion indicators and side re-
p e a t e r s ) m u s t b e r e p l a c e d b y
b u l b s o f i d e n t i c a l s p e c i fi c a -
t i o n a n d c o l o u r .
Page 95 of 123
PRACTICAL INFORMATION92 - - Open the rear door.
- U n s c r e w t h e n u t A .
- P u s h t h e l i g h t u n i t g e n t l y t o w a r d s t h e i n t e r i o r o f t h e v e h i c l e t o u n c l i p
the two side retaining clips.
- R e m o v e t h e l i g h t u n i t a n d d i s c o n - nect it.
- U n c l i p t h e b u l b h o l d e r b y p r e s s i n g the tabs B ,
- C h a n g e t h e f a u l t y b u l b . N u m b e r p l a t e l i g h t s ( W 5 W )
Insert a thin screwdriver into one
o f t h e e x t e r n a l h o l e s o f t h e l e n s .
P u s h i t o u t w a r d s t o u n c l i p i t .
Remove the lens.
C h a n g e t h e f a u l t y b u l b .
Rear lights
1. F o g l a m p ( P 2 1 W ) .
2. Direction indicators (P21 W).
3. Reversing lights (P21 W).
4. B r a k e l i g h t s / S i d e l i g h t s
( P 2 1 / 5 W ) .
High pressure washing: w h e n u s i n g
t h i s t y p e o f w a s h i n g o n s t u b b o r n d i r t ,
do not persist on the headlamps, the
l i g h t s a n d t h e i r s u r r o u n d t o a v o i d d a m -
aging their coating and their seal.
