#(Air Conditioning):Press to turn the air conditioning
(A/C) compressor on and off. An indicator light comes on
to show that the air conditioning is on.
If this button is pressed when the air conditioning
compressor is unavailable, the indicator ashes three
times and then turns off. If the air conditioning is on and
the outside temperature drops below a temperature
which is too cool for air conditioning to be effective, the air
conditioning light turns off to show that the air
conditioning mode has been canceled.
On hot days, open the windows long enough to let hot
inside air escape. This helps to reduce the time it takes
for the vehicle to cool down. It also helps the system to
operate more efficiently.
The air conditioning system removes moisture from the
air, so a small amount of water might drip under the
vehicle while idling or after turning off the engine. This is
normal.@(Recirculation):Press to turn the recirculation
mode on or off. An indicator light comes on to show that
the recirculation is on.
This mode recirculates and helps to quickly cool the air
inside the vehicle. It can be used to help prevent
outside air and odors from entering the vehicle.
The recirculation mode cannot be used with oor, defog,
or defrost modes. If recirculation is selected with one of
those modes, the indicator light ashes three times and
then turns off. The air conditioning compressor also
comes on when this mode is activated. While in
recirculation mode the windows may fog when the
weather is cold and damp. To clear the fog, select either
the defog or defrost mode and increase the fan speed.
The recirculation mode can also be turned off by turning
off the ignition.
REAR:For vehicles with the rear heat and air
conditioning controls. Press to turn the rear climate
control system on or off. SeeRear Air Conditioning and
Heating System and Electronic Climate Controls on
page 3-32.
3-28

Fog Lamp Light
The fog lamp light comes
on when the fog lamps are
in use.
The light goes out when the fog lamps are turned off.
SeeFog Lamps on page 3-17for more information.
Cruise Control Light
The cruise control light
comes on whenever the
cruise control is set.
The light goes out when the cruise control is turned off.
SeeCruise Control on page 3-12for more information.
Highbeam On Light
This light comes on when
the high-beam headlamps
are in use.
SeeHeadlamp High/Low-Beam Changer on page 3-8
for more information.
Tow/Haul Mode Light
This light comes on when
the Tow/Haul mode has
been activated.
For more information, seeTow/Haul Mode on page 2-38.
3-49

Lighter colored interiors may require more frequent
cleaning. Use care because newspapers and garments
that transfer color to home furnishings may also transfer
color to the vehicle’s interior.
When cleaning the vehicle’s interior, only use cleaners
specically designed for the surfaces being cleaned.
Permanent damage may result from using cleaners on
surfaces for which they were not intended. Use glass
cleaner only on glass. Remove any accidental over-spray
from other surfaces immediately. To prevent over-spray,
apply cleaner directly to the cleaning cloth.
Notice:Using abrasive cleaners when cleaning
glass surfaces on the vehicle, could scratch the glass
and/or cause damage to the rear window defogger.
When cleaning the glass on the vehicle, use only a
soft cloth and glass cleaner.
Many cleaners contain solvents that may become
concentrated in the vehicle’s breathing space. Before
using cleaners, read and adhere to all safety instructions
on the label. While cleaning the vehicle’s interior,
maintain adequate ventilation by opening the vehicle’s
doors and windows.
Dust may be removed from small buttons and knobs
using a small brush with soft bristles.Products that remove odors from the vehicle’s upholstery
and clean the vehicle’s glass can be obtained from your
dealer/retailer.
Do not clean the vehicle using:
A knife or any other sharp object to remove a soil
from any interior surface.
A stiff brush. It can cause damage to the vehicle’s
interior surfaces.
Heavy pressure or aggressive rubbing with a
cleaning cloth. Use of heavy pressure can damage
the interior and does not improve the effectiveness
of soil removal.
Laundry detergents or dishwashing soaps with
degreasers can leave residue that streaks and
attracts dirt. For liquid cleaners, about 20 drops per
gallon (3.78 L) of water is a good guide. Use
only mild, neutral-pH soaps.
Too much cleaner that saturates the upholstery.
Organic solvents such as naptha, alcohol, etc. that
can damage the vehicle’s interior.
5-107

Fuses Usage
47 Not Used
48 Auxiliary Climate Control (Ignition)
49Center High-Mounted Stoplamp
(CHMSL)
50 Rear Defogger
51 Heated Mirrors
52 SEO B1 Uptter Usage (Battery)
53Cigarette Lighter, Auxiliary Power
Outlet
54Automatic Level Control Compressor
Relay
55 Climate Controls (Ignition)
56Engine Control Module, Secondary
Fuel Pump (Ignition)
J-Case Fuses Usage
57 Cooling Fan 1
58 Automatic Level Control Compressor
59 Heavy Duty Antilock Braking System
60 Cooling Fan 2
61 Antilock Brake System 1
62 Starter
63 Stud 2 (Trailer Brakes)
64 Left Bussed Electrical Center 1
J-Case Fuses Usage
65 Electric Running Boards
66 Heated Windshield Washer System
67 Transfer Case
68Stud 1 (Trailer Connector Battery
Power)
69 Mid-Bussed Electrical Center 1
70 Climate Control Blower
71 Power Liftgate Module
72 Left Bussed Electrical Center 2
Relays Usage
FAN HI Cooling Fan High Speed
FAN LO Cooling Fan Low Speed
FAN CNTRL Cooling Fan Control
HDLP LO/HID Low-Beam Headlamp
FOG LAMP Front Fog Lamps
A/C CMPRSR Air Conditioning Compressor
STRTR Starter
PWR/TRN Powertrain
FUEL PMP Fuel Pump
PRK LAMP Parking Lamps
REAR DEFOG Rear Defogger
RUN/CRANK Switched Power
5-121

Appearance Care (cont.)
Washing Your Vehicle.................................5-110
Weatherstrips............................................5-109
Windshield, Backglass, and Wiper Blades......5-111
Ashtray.........................................................3-21
Assistance Program, Roadside........................... 7-7
Audio System.................................................3-83
Audio Steering Wheel Controls....................3-138
Navigation/Radio System, see Navigation
Manual.................................................3-115
Setting the Clock.........................................3-84
XM™ Satellite Radio Antenna System...........3-140
Audio System(s).............................................3-86
Audio Systems
Radio Reception........................................3-139
Rear Seat (RSA).......................................3-136
Theft-Deterrent Feature...............................3-138
Automatic Headlamp System............................3-16
Automatic Transmission
Fluid..................................................5-22, 5-25
Operation...................................................2-32
Autoride
®.......................................................4-50
Auxiliary
Roof Mounted Lamp....................................3-18
Axle, Rear.....................................................5-49
B
Battery..........................................................5-43
Electric Power Management..........................3-19
Run-Down Protection...................................3-20
Belt Routing, Engine.......................................6-16
Bench Seat, Split (60/40).................................1-14
Bluetooth
®....................................................3-115
Brake
Emergencies................................................ 4-6
Pedal and Adjustable Throttle........................2-30
Brakes..........................................................5-40
Antilock....................................................... 4-5
Parking......................................................2-45
System Warning Light..................................3-40
Braking........................................................... 4-4
Braking in Emergencies..................................... 4-6
Break-In, New Vehicle.....................................2-26
Bucket Seats, Rear.........................................1-20
Bulb Replacement...........................................5-58
Fog Lamps .................................................3-17
Halogen Bulbs............................................5-56
Headlamp Aiming........................................5-53
Headlamps.................................................5-56
License Plate Lamps....................................5-58
Taillamps, Turn Signal, Stoplamps and
Back-up Lamps........................................5-57
Buying New Tires...........................................5-78
2

F
Filter
Engine Air Cleaner......................................5-20
Finish Damage.............................................5-113
Flashers, Hazard Warning.................................. 3-6
Flash-to-Pass................................................... 3-8
Flat Tire........................................................5-85
Flat Tire, Changing.........................................5-86
Flat Tire, Storing...........................................5-102
Fluid
Automatic Transmission........................5-22, 5-25
Power Steering...........................................5-38
Windshield Washer......................................5-39
Fog Lamps
Bulb Replacement.......................................3-17
Light..........................................................3-49
Four-Wheel Drive....................................2-40, 5-51
Front Axle......................................................5-52
Fuel............................................................... 5-5
Additives...................................................... 5-6
California Fuel.............................................. 5-6
E85 (85% Ethanol)........................................ 5-7
Economy Driving........................................... 4-2
Filling a Portable Fuel Container....................5-11
Filling the Tank............................................. 5-9
Fuels in Foreign Countries.............................. 5-8
Gage .........................................................3-50
Gasoline Octane........................................... 5-5Fuel (cont.)
Gasoline Specications.................................. 5-6
Low Fuel Warning Light................................3-51
Management, Active.....................................2-31
Fuses
Center Instrument Panel Fuse Block.............5-118
Fuses and Circuit Breakers.........................5-115
Instrument Panel Fuse Block.......................5-116
Underhood Fuse Block...............................5-119
Windshield Wiper.......................................5-115
G
Gages
Engine Coolant Temperature.........................3-42
Fuel..........................................................3-50
Oil Pressure...............................................3-46
Speedometer..............................................3-36
Tachometer.................................................3-36
Trip Odometer.............................................3-36
Voltmeter Gage...........................................3-39
Garage Door Opener.......................................2-71
Gasoline
Octane........................................................ 5-5
Specications............................................... 5-6
Glove Box.....................................................2-78
GM Mobility Reimbursement Program.................. 7-7
6

L
Labeling, Tire Sidewall.....................................5-62
Lamps
Auxiliary Roof Mounted Lamp........................3-18
Daytime Running (DRL)................................3-16
Dome ........................................................3-18
Dome Lamp Override...................................3-19
License Plate..............................................5-58
Malfunction Indicator....................................3-43
Reading.....................................................3-19
Lap Belt ........................................................1-52
Lap-Shoulder Belt...........................................1-45
LATCH System for Child Restraints...................1-65
Level Control..................................................4-49
Liftgate, Power...............................................2-15
Liftgate/Liftglass..............................................2-13
Liftglass/Liftgate..............................................2-13
Lighting
Entry.........................................................3-19
Exit ...........................................................3-19
Lights
Airbag Readiness........................................3-37
Antilock Brake System (ABS) Warning............3-41
Brake System Warning.................................3-40
Charging System.........................................3-39
Cruise Control.............................................3-49
Exterior Lamps............................................3-14
Flash-to-Pass............................................... 3-8Lights (cont.)
Fog Lamps .................................................3-49
Highbeam On.............................................3-49
High/Low Beam Changer................................ 3-8
Low Fuel Warning.......................................3-51
Oil Pressure...............................................3-48
On Reminder..............................................3-15
Passenger Airbag Status Indicator..................3-38
Safety Belt Reminders..................................3-36
Security.....................................................3-48
StabiliTrak
®Indicator....................................3-42
Tire Pressure..............................................3-43
Tow/Haul Mode ...........................................3-49
Loading Your Vehicle.......................................4-33
Locking Rear Axle............................................ 4-9
Locks
Delayed Locking..........................................2-11
Door ..........................................................2-10
Lockout Protection.......................................2-12
Power Door................................................2-10
Programmable Automatic Door Locks.............2-11
Rear Door Security Locks.............................2-11
Loss of Control...............................................4-11
Low Fuel Warning Light...................................3-51
Lower Anchors and Tethers for Children.............1-65
Luggage Carrier..............................................2-79
Lumbar
Manual Controls............................................ 1-6
Power Controls............................................. 1-6
8
