Power Lumbar
On vehicles with this feature:
Press and hold the top of the control (B) to increase
support to the top of the seatback and decrease
support to the bottom of the lumbar.
Press and hold the bottom of the control to
decrease support to the top of the seatback and
increase support to the bottom of the seatback.
Press and hold the front or rear of the control to
increase or decrease support to the entire
seatback.
Side Bolster
On vehicles with this feature:
Press the top or bottom of control (A) to increase or
decrease support in seat cushion bolsters.
Press the top or bottom of the control (C) to
increase or decrease support in the seatback
bolsters.
Heated and Ventilated Seats
On vehicles with this feature, the buttons are located on
the climate control panel.
z(Heated Seat and Seatback):Press to heat the
seat and seatback.
{(Ventilated Seat):Press to ventilate the seat.
A light bar in the climate control display shows the
setting; high, medium, or low.
Press either button to start that feature at the highest
setting. Each press of the button, decreases the setting.
To turn the feature off, press the button until the light
turns off.
The heated or ventilated seats shut off when the vehicle
is turned off.
1-7

Programming Transmitters to the
Vehicle
Only RKE transmitters programmed to the vehicle will
work. If a transmitter is lost or stolen, a replacement
can be purchased and programmed through your
dealer/retailer. When the replacement transmitter is
programmed to the vehicle, all remaining transmitters
must also be programmed. Any lost or stolen transmitters
no longer work once the new transmitter is programmed.
Each vehicle can have up to eight transmitters
programmed to it. See “Relearn Remote Key”
underDIC Operation and Displays on page 3-51.
Battery Replacement
Replace the battery if the Replace Battery In Remote
Key message displays in the DIC. See “Replace Battery
In Remote Key” underDIC Warnings and Messages
on page 3-58for additional information.
Notice:When replacing the battery, do not touch
any of the circuitry on the transmitter. Static
from your body could damage the transmitter.To replace the battery:
1. Separate the transmitter with a at, thin object
inserted into the notch, located above the
metal base.
2. Remove the old battery. Do not use a metal object.
3. Insert the new battery, positive side facing up.
Replace with a CR2032 or equivalent battery.
4. Snap the transmitter back together.
2-7

4. Turn the key to the unlock position ve times within
ve seconds.
5. The Driver Information Center (DIC) displays Ready
To Learn Electronic Key #2, 3 or 4.
6. Place the new transmitter into the transmitter
pocket with the buttons facing the front of the
vehicle. The transmitter pocket is inside the center
console storage area located between the driver
and front passenger seats.7. A beep sounds once the transmitter is programmed.
The DIC displays Ready To Learn Electronic
Key #3 or 4, or Maximum # Electronic Keys
Learned.
8. Press the ignition control knob to exit
programming mode.
9. Remove the transmitter from the transmitter pocket
and press
Kon the keyless access transmitter
two times.
10. To program additional transmitters, repeat Steps 6
through 9.
Programming without a Recognized
Transmitter
United States owners are permitted to program a new
transmitter to their vehicle when a recognized transmitter
is not available. The Canadian immobilizer standard
requires that Canadian owners see their dealer/retailer
for programming new transmitters when two recognized
transmitters are not available.
2-11

The procedure requires three, ten minute cycles to
complete the matching process.
1. The vehicle must be off.
2. Place the new transmitter into the transmitter
pocket with the buttons facing the front of the
vehicle. The transmitter pocket is inside the center
console storage area located between the driver
and front passenger seats.
3. Insert the vehicle key into the key lock cylinder
located on the driver door.
4. Turn the key to the unlock position ve times within
ve seconds.
5. The DIC displays Press Start Control To Learn Keys.6. Press the ignition switch in.
7. The DIC reads Learn Delay Active Wait XX Min and
counts down to zero.
8. The DIC displays Press Start Control To Learn
Keys again.
9. Press the ignition switch in again.
10. Repeat Steps 7, 8 and 9.
11. The DIC reads Learn Delay Active Wait XX Min and
counts down to zero.
12. A beep sounds and the DIC reads Ready To Learn
Electronic Key # X. All previously known transmitter
programming has been erased.
13. A beep sounds once programming is complete. The
DIC displays Ready To Learn Electronic Key # 2.
To program additional transmitters, insert each
transmitter in the pocket until a beep is heard and
the DIC advances to the next electronic key number.
Up to four transmitters can be programmed. The
DIC displays Maximum # Electronic Keys Learned
and exits the programming mode.
Press the ignition control knob to complete the
process.
14. Press the ignition control knob if programming is
complete.
15. Press
Kon each newly programmed transmitter to
complete the process.
2-12

Starting the Vehicle with a Low
Transmitter Battery
Replace the battery if the Replace Battery In Remote
Key message displays in the DIC. See “Replace Battery
In Remote Key” underDIC Warnings and Messages
on page 3-58for additional information.
If the transmitter battery is weak, the DIC may display
Electronic Key Not Detected when you try to start the
vehicle. To start the vehicle, place the transmitter in the
center console storage area transmitter pocket with the
buttons facing to the front of the vehicle. Then, with the
vehicle in P (Park) or N (Neutral), press the brake pedal
and the ignition control knob. SeeStarting the Engine on
page 2-33, for additional information about the vehicle’s
electronic keyless ignition with push start. Replace the
transmitter battery as soon as possible.
Battery Replacement
Notice:When replacing the battery, do not touch
any of the circuitry on the transmitter. Static
from your body could damage the transmitter.
1. Separate the transmitter with a at, thin object
inserted into the slot on the side or back of the
transmitter.
2. Remove the old battery. Do not use a metal object.
3. Insert the new battery, positive side facing down.
Replace with a CR2032 or equivalent battery.
4. Snap the transmitter back together.
2-13

Power Door Locks
The power door lock switches are located on the
front doors.
"(Unlock):Press to unlock the doors.
Q(Lock):Remove the key from the ignition and press
to lock the doors.
Delayed Locking
With this feature, you can delay the actual locking of
the doors.
When the power door lock switch is pressed when the
key is not in the ignition and the driver’s door is opened,
a chime will sound three times indicating that delayed
locking is active.
When all the doors are closed, the doors will lock
automatically after ve seconds. If a door is reopened
before ve seconds have elapsed, the ve second timer
will reset itself once all the doors are closed again.
You can press the door lock switch again or the lock
button on the RKE transmitter to override this feature
and lock the doors immediately.
You can turn this feature off using the Driver Information
Center (DIC). When delayed locking is off, the doors
will lock immediately when you press the powerdoor lock switch or the lock button on the RKE
transmitter. SeeDIC Vehicle Customization on
page 3-72for more information.
Programmable Automatic Door
Locks
If the vehicle has an automatic transmission, the vehicle
is programmed so that the doors will lock automatically
when all doors are closed, the ignition is on, and
the shift lever is moved out of P (Park). The doors will
automatically unlock when the vehicle is stopped
and the shift lever is moved into P (Park).
If the vehicle has a manual transmission, the vehicle is
programmed so that the doors will lock automatically
after the vehicle speed reaches 5 mph (8 km). The doors
will automatically unlock when the ignition is turned
off and the key is removed from the ignition.
If someone needs to exit the vehicle once the doors
are locked, have that person use the manual lever
or power door lock switch. When the door is closed
again, it will not lock automatically. Use the manual
lever or the power door lock switch to lock the door.
The power door locks can be programmed through
prompts displayed on the Driver Information
Center (DIC). For more information on programming,
seeDIC Vehicle Customization on page 3-72.
2-17

Retained Accessory Power (RAP)
These vehicle accessories can be used for up to
10 minutes after the engine is turned off:
Audio System
Power Windows
Sunroof (if equipped)
Power to the audio system will work up to 10 minutes or
until the driver door is opened. Power to the windows or
sunroof will work up to 10 minutes or until any door is
opened. For an additional 10 minutes of operation, close
all the doors and turn the key to ON/RUN and then back
to LOCK/OFF.
Starting the Engine
Place the transmission in the proper gear.
Automatic Transmission
Move the shift lever to P (Park) or N (Neutral). The
engine will not start in any other position. To restart
the engine when the vehicle is already moving, use
N (Neutral) only.If the vehicle has the keyless access system, put your
foot on the brake pedal and turn the ignition control knob
to the START position. When the engine begins cranking,
let go of the ignition control knob, it will return to the
ON/RUN position.
If the transmitter is not in the vehicle or something is
interfering with the transmitter, the Driver Information
Center (DIC) will display Electronic Key Not Detected.
SeeDIC Warnings and Messages on page 3-58for
more information.
If the battery in the keyless access transmitter needs
replacing, the DIC displays Replace Battery In Remote
Key. The vehicle can still be driven. See “Battery
Replacement” underKeyless Access System Operation
on page 2-8for more information.
Notice:Do not try to shift to P (Park) if the
vehicle is moving. If you do, you could damage
the transmission. Shift to P (Park) only when
the vehicle is stopped.Manual Transmission
The shift lever should be in neutral position and the
parking brake engaged. Hold the clutch pedal down to
the oor and start the engine. The vehicle will not start if
the clutch pedal is not all the way down.
2-33

M (Manual Mode):This position allows the driver to
select the range of gears appropriate for current driving
conditions. If the vehicle has this feature, see Driver
Shift Control (DSC) later in this section.
Notice:Spinning the tires or holding the vehicle in
one place on a hill using only the accelerator pedal
may damage the transmission. If you are stuck, do
not spin the tires. When stopping on a hill, use the
brakes to hold the vehicle in place.
Driver Shift Control (DSC)
Notice:If you drive the vehicle at high RPMs without
upshifting while using Driver Shift Control (DSC), you
could damage the vehicle. Always upshift when
necessary while using DSC.
Driver Shift Control (DSC) allows you to shift an
automatic transmission similar to a manual transmission.
To use the DSC feature:
1. Move the shift lever to the right from D (Drive) to
M (Manual Mode).
Once in M (Manual Mode), if you do not move the
shift lever forward or rearward, the vehicle will be in
sport mode. When you are in sport mode the vehicle
will still shift automatically. The transmission may
remain in a gear longer than it would in the normal
driving mode based on braking, throttle input, and
vehicle lateral acceleration.SPORT MODE will be displayed in the DIC
momentarily. The vehicle will remain in sport mode
if the shift lever is not moved. Sport mode will
shift automatically but remain in a gear longer then
it would in normal driving mode based on braking
and acceleration.
2. Press the shift lever forward to upshift or rearward
to downshift.
The tachometer display on the instrument panel cluster
will show which gear the vehicle is in. The number
indicates the requested gear range when moving the
shift lever forward or rearward. SeeSpeedometer and
Odometer on page 3-33for more information on the
odometer.
2-38
