Steering Tips
It is important to take curves at a reasonable speed.
Traction in a curve depends on the condition of the tires
and the road surface, the angle at which the curve is
banked, and your speed. While in a curve, speed is the
one factor you can control.
If you need to reduce speed, do it before you enter the
curve, while the front wheels are straight ahead.
Try to adjust the speed so you can drive through the
curve. Maintain a reasonable, steady speed. Wait to
accelerate until you are out of the curve, and then
accelerate gently into the straightaway.
Steering in Emergencies
There are times when steering can be more effective
than braking. For example, you come over a hill and nd
a truck stopped in your lane, or a car suddenly pulls out
from nowhere, or a child darts out from between parked
cars and stops right in front of you. You can avoid these
problems by braking — if you can stop in time. But
sometimes you cannot; there is not room. That is the time
for evasive action — steering around the problem.
Your vehicle can perform very well in emergencies like
these. First apply the brakes. SeeBraking on page 4-4.
It is better to remove as much speed as you can from a
possible collision. Then steer around the problem, to the
left or right depending on the space available.An emergency like this requires close attention and a
quick decision. If you are holding the steering wheel at
the recommended 9 and 3 o’clock positions, you can turn
it a full 180 degrees very quickly without removing either
hand. But you have to act fast, steer quickly, and just as
quickly straighten the wheel once you have avoided the
object.
The fact that such emergency situations are always
possible is a good reason to practice defensive driving
at all times and wear safety belts properly.
4-10

The fuel cap is behind a hinged fuel door on the
passenger side. To open the fuel door, push the
rearward center edge in and release and it will open.To remove the fuel cap, turn it slowly counterclockwise.
The fuel cap has a spring in it; if the cap is released
too soon, it will spring back to the right.
5-9

While refueling, hang the tethered fuel cap from the
hook on the fuel door.
{CAUTION:
Fuel can spray out on you if you open the fuel cap
too quickly. If you spill fuel and then something
ignites it, you could be badly burned. This spray
can happen if the tank is nearly full, and is more
likely in hot weather. Open the fuel cap slowly and
wait for any hiss noise to stop. Then unscrew the
cap all the way.Be careful not to spill fuel. Do not top off or overll the
tank and wait a few seconds after you have nished
pumping before removing the nozzle. Clean fuel
from painted surfaces as soon as possible.
SeeWashing Your Vehicle on page 5-110.
When replacing the fuel cap, turn it clockwise until it
clicks. Make sure the cap is fully installed. The diagnostic
system can determine if the fuel cap has been left off or
improperly installed. This would allow fuel to evaporate
into the atmosphere. SeeMalfunction Indicator Lamp on
page 3-43.
The Tighten Gas Cap message in the Driver Information
Center (DIC) displays if the fuel cap is not properly
installed. SeeDIC Warnings and Messages on page 3-58
for more information.
5-10

{CAUTION:
Steam and scalding liquids from a hot cooling
system can blow out and burn you badly. They are
under pressure, and if you turn the surge tank
pressure cap — even a little — they can come
out at high speed. Never turn the cap when the
cooling system, including the surge tank pressure
cap, is hot. Wait for the cooling system and surge
tank pressure cap to cool if you ever have to turn
the pressure cap.
If coolant is needed, add the proper DEX-COOL
®
coolant mixture at the coolant surge tank.If no coolant is visible in the surge tank, add coolant as
follows:
1. Remove the coolant surge tank pressure cap when
the cooling system, including the coolant surge tank
pressure cap and upper radiator hose, is no longer
hot. Turn the pressure cap slowly counterclockwise
about one-quarter turn and then stop.
If you hear a hiss, wait for that to stop. A hiss
means there is still some pressure left.
2. Then keep turning the pressure cap slowly and
remove it.
5-34

Checking Coolant in the Intercooler
System (CTS-V)
The vehicle must be on a level surface when checking
the coolant level.
The super charged engine intercooler coolant ll bottle
is located in the engine compartment on the passenger
side of the vehicle. SeeEngine Compartment
Overview on page 5-14.
Check to see if coolant is visible in the coolant ll bottle.
If the coolant inside the coolant ll bottle is boiling, do not
do anything else until it cools down. If coolant is visible
but the coolant level is not at or above the COLD FILL
mark, add a 50/50 mixture of clean, drinkable water and
DEX-COOL
®coolant at the coolant ll bottle, but be sure
the cooling system is cool before this is done.
If the engine is warm or hot, the coolant level should be
at or above the COLD FILL line on the side of the coolant
ll bottle. If the engine is cold, the coolant level should be
near the COLD FILL line on the side of the coolant ll
bottle. If it is not, you could have a leak in the cooling
system.
Adding Coolant to the Intercooler
System Coolant (CTS-V)
1. Remove the intercooler system pressure cap when
the intercooler system hoses are no longer hot.
Turn the pressure cap slowly counterclockwise
about one-quarter of a turn. If you hear a hiss, wait
for that to stop. This allows any pressure still left
to be vented.
2. Then keep turning the pressure cap slowly and
remove it.
5-36

7. Locate the vertical headlamp aiming screws, which
are under the hood near each headlamp assembly.
They are covered by a rubber caps.
The adjustment screw can be turned with a
6 mm hex driver.
8. Turn the vertical aiming screw until the headlamp
beam is aimed to the horizontal tape line. Turn it
clockwise or counterclockwise to raise or lower the
angle of the beam.
The top edge of the cut-off should be positioned at
the bottom edge of the horizontal tape line.9. Make sure that the light from the headlamp is
positioned at the bottom edge of the horizontal tape
line. The lamp on the left (A) shows the correct
headlamp aim. The lamp on the right (B) shows the
incorrect headlamp aim.
10. Repeat Steps 7 through 9 for the opposite
headlamp. Driver Side Shown
5-56

Front Turn Signal and Fog Lamps
To replace fog lamp bulb:
1. Pull out the push-pins located on the underside of
the protection shield to remove the shield.
2. Reach up behind the front bumper area from under
the vehicle to access the lamp housing.3. Remove the electrical connector from the bulb by
lifting the two plastic clips.
4. Remove the bulb socket from the lamp housing by
turning the bulb socket one-quarter turn
counterclockwise.
5. Pull the old bulb from the lamp housing keeping the
bulb straight as you pull it out.
6. Install a new bulb.
7. Reinstall the electrical connector by pushing in the
two plastic clips.
8. Push the bulb socket into the lamp housing and
turn the socket one-quarter turn clockwise.
5-58

License Plate Lamp
To replace one of these bulbs, do the following:
1. Push tab to remove the license plate lamp.
2. Turn the license plate lamp assembly down to
remove it.
3. Turn the socket counterclockwise and remove it.
4. Pull the bulb straight out to remove it.
5. Push the new bulb straight into the socket.
6. Reverse Steps 1 through 3 to reinstall the license
plate lamp assembly.
Replacement Bulbs
Exterior Lamp Bulb Number
Fog Lamp (Up Level Only) H11LL
License Plate Lamp W5WLL
For replacement bulbs not listed here, contact your
dealer/retailer.
Windshield Wiper Blade
Replacement
Windshield wiper blades should be inspected for wear or
cracking. SeeOwner Checks and Services on page 6-10.
It is a good idea to clean or replace the wiper blade
assembly on a regular basis or when worn. For proper
windshield wiper blade length and type, see
Maintenance Replacement Parts on page 6-16.
To replace the wiper blade assembly:
1. Turn the ignition to ON/RUN with the engine off.
2. Turn on the windshield wipers and turn them
off again when the wipers are in the out-wipe
position. The driver side blade will be straight up
and down on the windshield.
3. Pull the windshield wiper assembly away from the
windshield.
5-59
