2009 Acura RL tow

A convenient ref erence to the
sections in this manual.
A quick ref erence to the main
controls in your vehicle.
Explains the purpose of each
instrument panel indicator and gauge,
and how to use the controls on the
dashboard and steering column.What gasoline to use, how to break-
in your new vehicle, and how to load
luggage and other cargo.
The proper way to start the engine,
shif t the transmission, and park; plus
what you need to know if you’re
planning to tow a trailer.
ID numbers, dimensions, capacities,
and technical information.
How to operate the climate control
system, the audio system, and other
convenience f eatures. The maintenance minder shows you
when you need to take your vehicle
to the dealer for maintenance service.
There is also a list of things to check
and instructions on how to check
them.
This section covers several problems
motorists sometimes experience,
and details how to handle them.
Important inf ormation about the
proper use and care of your vehicle’s
seat belts, an overview of the
supplemental restraint system, and
valuable inf ormation on how to
protect children with child restraints.
A summary of the warranties
covering your new vehicle, and how
to contact us for any reason. Refer to
your warranty manual f or detailed
inf ormation.
How to order manuals and other
technical literature.
A summary of the inf ormation you
need when you pull up to the f uel
pump.
Overview of Contents
Your Vehicle at a Glance
Driver and Passenger Saf ety
Instruments and Controls
FeaturesBef ore Driving
Driving
Maintenance
T echnical Inf ormation
Contents
T aking Care of the UnexpectedWarranty and Client Relations
(U.S. and Canada only)
Authorized Manuals
(U.S. only)
Index
Service Inf ormation Summary
3
2009 RL

Pull to the side of the road when it is
saf e, shif t to Park, and let the engine
idle until the indicator goes out.You will also see a ‘‘CHECK TIRE
PRESSURE’’ message on the multi-
inf ormation display (see page ).
Check the tire pressure monitor on
the multi-inf ormation display and
determinethecause(seepage ).
If this happens, pull to the side of the
road when it is saf e, check which tire
has lost pressure on the multi-
inf ormation display, and determine
the cause. If it is because of a flat tire,
have the flat tire repaired as soon as
possible. If two or more tires are
underinf lated, call a prof essional
towing service. For more
inf ormation, see page .
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position.
This indicator has two f unctions:
If it comes on while driving, it
indicates that one or more of your
vehicle’s tires are signif icantly low
on pressure. If this indicator begins to f lash,
there is a problem with the tire
pressure monitoring system
(TPMS). You will also see a
‘‘CHECK TPMS SYSTEM’’
message on the multi-inf ormation
display. The indicator continues to
f lash f or a while (approximately 1
minute), then stays on. If this
happens, have your dealer check
the system as soon as possible.
For more inf ormation, see page
.
1. 2.
79
431
519 429
Instrument Panel Indicators
Low Tire Pressure/
TPMS Indicator
Inst rument s and Cont rols
67
Continuing to drive with the SH-AWD
indicator blinking may cause serious
damage to the system.
2009 RL

Make any steering wheel adjustment
bef ore you start driving.Move the steering wheel in, out, up,
or down by pushing and holding the
adjustment switch in that direction.Release the switch when the
steering wheel reaches the desired
position. Make sure the steering
wheel points towards your chest, not
toward your f ace, and that you can
see the instrument panel gauges and
indicators.
Steering Wheel A djustments
148
Adjusting the steering wheel
position while driving may
cause you to lose control of the
vehicle and be seriously injured
inacrash.
Adjust the steering wheel only
when the vehicle is stopped.
2009 RL

You can extend the sun visor f urther
by pulling it back.
To use a sun visor, pull it down. You
can also use a sun visor at the side
window. Remove the support rod
f rom the clip, and swing the sun
visor toward the side window.Do not use the sun visor extension
feature over the rear view mirror.
Make sure to slide the sun visor
back to its original position bef ore
f lipping it back in place.
Make sure you put the sun visor
back in place when you are getting
into or out of the vehicle.
Tousethevanitymirrorontheback
of the sun visor, pull up the cover.
Thevanitymirrorlightscomeon
when you pull up the cover.
Sun Visors Vanity Mirror
Interior Convenience Items
196
2009 RL

Help assure your vehicle’s f uture
reliability and perf ormance by paying
extra attention to how you drive
during the f irst 600 miles (1,000 km).
During this period:Avoid full-throttle starts and rapid
acceleration.
Avoidhardbrakingforthefirst
200 miles (300 km).
Do not change the oil until the
scheduled maintenance time.
You should also f ollow these
recommendations with an
overhauled or exchanged engine, or
when the brakes are replaced. Do not tow a trailer. We recommend quality gasolines
containing detergent additives that
help prevent f uel system and engine
deposits.
In addition, in order to maintain good
perf ormance, f uel economy, and
emissions control, we strongly
recommend, in areas where it is
available, the use of gasoline that
does NOT contain manganese-based
f uel additives such as MMT.
Use of gasoline with these additives
may adversely af f ect perf ormance,
and cause the malfunction indicator
lamp on your instrument panel to
come on. If this happens, contact
your authorized dealer f or service.
Your vehicle is designed to operate
on premium unleaded gasoline with a
pump octane of 91 or higher. If this
octane grade is unavailable, regular
unleaded gasoline with a pump
octane of 87 or higher may be used
temporarily. The use of regular
unleaded gasoline can cause metallic
knocking noises in the engine and
will result in decreased engine
perf ormance. The long-term use of
regular-grade gasoline can lead to
engine damage.
Break-in Period Fuel Recommendation
Break-in Period, Fuel Recommendation
384
2009 RL

Remove the dipstick again, and
check the level. It should be
between the upper and lower
marks.
If it is near or below the lower
mark, see on
page .
Wait a f ew minutes af ter turning the
engine of f bef ore you check the oil.
Remove the dipstick (orange loop).
Wipe the dipstick with a clean
cloth or paper towel.
Insert the dipstick all the way back
into its hole. Look at the coolant level in the
radiator reserve tank. Make sure it is
between the MAX and MIN lines. If
it is below the MIN line, see
on page .
Refer to on page f or inf ormation
about checking other items on your
vehicle.
4.
1.
2.
3. 458 461
452
Engine Coolant Check
A dding Engine Oil
Oil Check
A dding
Engine Coolant
Owner’s Maintenance
Checks
Service Station Procedures
Bef ore Driving
389
MAX
MIN
LOWER MARK UPPER MARK
DIPSTICK
RESERVE TANK
2009 RL

µ·
µ The resulting f igure equals the
available amount of cargo and
luggage load capacity. For
example, if the ‘‘XXX’’ amount
equals 1,400 lbs. and there will be
f ive 150 lb. passengers in your
vehicle, the amount of available
cargo and luggage load capacity is
650 lbs.
(1,400 750 (5 150) = 650 lbs.)
Determine the combined weight
of luggage and cargo being loaded
on the vehicle. That weight may
not saf ely exceed the available
cargo and luggage load capacity
calculated in Step 4.
If yourvehiclewillbetowinga
trailer, load f rom your trailer will
be transf erred to your vehicle.
Consult this manual to determine
how this reduces the available
cargo and luggage load capacity of
your vehicle.
Subtract the combined weight of
the driver and passengers f rom
XXX kg or XXX lbs.
Locate the statement ‘‘The
combined weight of occupants and
cargo should never exceed XXX
kg or XXX lbs.’’ on your vehicle’s
placard.
Steps f or Determining Correct Load
Limit
The maximum load f or your vehicle
is 850 lbs (385 kg).
See Tire And Loading Inf ormation
label attached to the driver’s
doorjamb.
Label Example
This f igure includes the total weight
of all occupants, cargo, and
accessories, and the tongue load if
you are towing a trailer.
Determine the combined weight
of the driver and passengers that
will be riding in your vehicle.
(1)
(2)
(3)
(6)
(5)
(4)
Carrying Cargo
Load Limits
396
Overloading or improper
loading can affect handling and
stability and cause a crash in
which you can be hurt or killed.
Follow all load limits and other
loading guidelines in this
manual.
2009 RL

This section gives you tips on
starting the engine under various
conditions, and how to operate the
automatic transmission. It also
includes important inf ormation on
parking your vehicle, the braking
system, the Super Handling-All
Wheel Drive (SH-AWD
)system,
the vehicle stability assist (VSA)
system, the tire pressure monitoring
system (TPMS), the collision
mitigation brake system (CMBS),
and f acts you need if you are
planning to tow a trailer. ........................
Preparing to Drive .402
.......................
Starting the Engine .403
Check Starting System .................................
Message .404
..............
Automatic Transmission .405
Driving with the Paddle
...................................
Shif ters .409
................
D-Paddle Shif t Mode .409
..............
Sequential Shif t Mode .411
Super Handling-All Wheel Drive .................
(SH-AWD
) System .413
...........................................
Parking .415
.............................
Braking System .416
...............
Anti-lock Brakes (ABS) .417
Collision Mitigation Brake
........................
System (CMBS) .419
Tire Pressure Monitoring ........................
System (TPMS) .429
Vehicle Stability Assist (VSA
),
aka Electronic Stability ........
Control (ESC), System .435
...........................
Towing a Trailer .437
...................
Towing Your Vehicle .442
Driving
Driving
401
TM
TM
2009 RL
