ÎTo use the horn, press the center pad of the steering wheel.
On models with navigation system, refer to the navigation system manual.
If equipped.
Canadian models only
1:
2:
3:
4:
Controls Near the Steering Wheel
136
MIRROR CONTROLS
VEHICLE STABILITY ASSIST (VSA)
SYSTEM OFF SWITCH
PADDLE SHIFTERS
DISTANCEBUTTON
STEERING WHEEL
AUDIO CONTROLS
STEERING WHEEL
ADJUSTMENTS
HEADLIGHTWASHER
SWITCH
COLLISION MITIGATION
BRAKE SYSTEM (CMBS)
OFF SWITCH
ADAPTIVE FRONT LIGHTING
SYSTEM (AFS) OFF SWITCH
VOICE CONTROL
BUTTONSHORN
(P.138)
HEADLIGHTS/
TURN SIGNAL/FOG
LIGHTS
(P.140,142) INSTRUMENT
PANEL BRIGHTNESS
WINDSHIELD WIPER/
WASHER HAZARD WARNING
BUTTON
PASSENGER AIRBAG
OFF INDICATOR
(P.35)
(P.137)
BLUETOOTHHANDSFREELINKBUTTONS HEATED MIRROR BUTTON
REAR WINDOW DEFOGGER
BUTTON
CRUISE CONTROL
BUTTONS
ADAPTIVE CRUISE CONTROL
(ACC) BUTTONS
FRONT SEAT HEATER AND
SEAT VENTILATION BUTTONS
MULTI INFORMATION
DISPLAY BUTTONS
FRONT SEAT HEATER
SWITCHES (P.71)
(P.145)
(P.162) (P.148) (P.356)
(P.278)(P.304) (P.182)(P.181)/
(P.316)/
(P.162)
(P.147)/
(P.146)
(P.146)
(P.328,333) (P.319,324)
(P.409)
(P.422)
(P.436)
2 4
4
31 4
4
2009 RL

´The rear window def ogger clears f og,
frost,andthinicefromthewindow.
Push the def ogger button to turn it
onandoff.Pushingthisbuttonalso
turns the mirror heaters on and of f .
The indicator in the button comes on
to show the def ogger is on. If you do
not turn it of f , the def ogger will shut
itself of f af ter 5 to 40 minutes
(depending on the ambient
temperature). It also shuts of f when
you turn of f the ignition switch. You have to turn it on again when you
restart the vehicle.
Make sure the rear window is clear
and you have good visibility bef ore
starting to drive.
The def ogger and antenna wires on
the inside of the rear window can be
accidentally damaged. When
cleaning the glass, always wipe side
to side.
To reduce glare at night, the
instrument panel illumination dims
when you turn the light switch to
or . To cancel the glare
reduction f unction, set the
brightness to the highest level, then
press the button. You will hear a
beep when it is canceled. Rear Window Def ogger
Instrument Panel Brightness, Rear Window Def ogger
Inst rument s and Cont rols
147
REAR WINDOW DEFOGGER BUTTON
2009 RL

The outside mirrors are heated to
remove fog and frost. With the
ignition switch in the ON (II)
position, turn on the heaters by
pressing the button. The indicator in
the button comes on as a reminder.
Press the button again to turn the
heaters off. Pressing this button also
turns the rear window def ogger on
and off.
When you f inish, move the
selector switch to the center (off)
position. This turns of f the
adjustment switch so you can’t
move a mirror out of position by
accidentally bumping the switch.
Outside mirror positions can be
stored in the driving position
memory system (see page ). Both outside door mirrors have a
reverse tilt f eature. When in reverse,
the selected mirror will tilt down
slightly to improve your view as you
parallel park. Shif ting out of reverse
will return the mirror to its original
position.
To tilt the driver’s mirror, place
the selector switch in the left
position.
To tilt the passenger’s mirror,
place the switch in the right
position.
To turn the feature off, place the
switch in the center position.
3.
163 PowerMirrorHeaters
Reverse Tilt Door Mirror
Mirrors
162
HEATED MIRROR BUTTON
2009 RL

The engine may not run, and some
malf unctions may occur, if the
remote is:The engine may not start if the
remote is subjected to strong radio
waves.
Also, the engine may not start if the
remote is too close to the windows.
Outside the vehicle.
On the dashboard.
On the rear interior panel.
In the glove box.
In the door pockets.
In the trunk, etc.
Ignition Switch Operating Range
K eyless A ccess System
Inst rument s and Cont rols
175
Make sure you know where the remote
is when you are inside the vehicle.
Remember that you can start the engine
without using the built-in key when the
remote is inside the vehicle.
Make sure you always carry the remote
with you.
2009 RL

Thebatteriesintheremotenormally
last about 2 years. To ensure
maximum battery lif e, do not store
the remote close to electrical devices
such as computers or TVs. When the
multi-inf ormation display shows
‘‘KEYLESS REMOTE LOW
BATTERY,’’ replace the batteries as
soon as possible (see page ).
The engine does not restart if you
turn the ignition switch to the LOCK
(0) position when the remote is
outside the vehicle. Check where the
remote is. Make sure that you carry
the remote or built-in key with you
when you operate the ignition switch.
When the ignition switch is in the
ON (II) position, the multi-
inf ormation display shows
‘‘KEYLESS REMOTE NOT
DETECTED,’’ and the inside and
outside beepers sound.
The multi-inf ormation display
message goes away when you
bring the remote back inside the
vehicle, and close the door or
apply the parking brake.
The outside beeper sounds when
the ignition switch is in the
ACCESSORY (I) or the ON (II)
position.
If the engine is running and you
removetheremotefromthe
vehicle, it will continue to run.
Once turned to the LOCK (0)
position, the engine will not restart
until a remote is brought back into
the vehicle. If you pass the remote through an
open window, the system does not
respond.Also,evenwhentheremote
is inside the vehicle, the beeper may
sound when the location of the
remote is not detected due to
surrounding conditions. It is not a
f ailure. Make sure that you carry the
remote with you.
174
K eyless Remot e L ow Bat t ery
K eyless A ccess System
178
2009 RL

If the MAIN switch is pushed down
(OFF), the passenger windows
cannot be raised or lowered. Keep
the MAIN switch off when you have
children in the vehicle so they do not
injure themselves by operating the
windows unintentionally.
Turn the ignition switch to the ON
(II) position bef ore operating any of
the window switches. To open a
window, push the switch down and
hold it. To close the window, pull the
switchupandholdit.Releasethe
switch to stop the window.
CONT INUED
Power Windows
Inst rument s and Cont rols
185
DRIVER’S WINDOW SWITCH
MAIN SWITCH
Closing a power window on
someone’s hands or fingers can
cause serious injury.
Make sure your passengers are
away from the windows before
closing them.
2009 RL

µAuto reverse stops sensing when the
window is almost closed. You should
always check that all passengers and
objects are away from the window
bef ore closing it.
To open the window f ully,
push the window switch firmly down
to the second detent, then release it.
The window automatically goes
down all the way. To stop the
window f rom going all the way down,
pull back on the window switch
brief ly.
To close the window f ully, pull back
the window switch firmly to the
second detent, then release it. The
window automatically goes all the
way up. To stop the window f rom
going all the way up, push down on
the window switch briefly. To open or close the window
partially, push down or pull back on
the window switch lightly to the first
detent, and hold it. The window will
stop when you release the switch.
All window switches also have the
AUTO feature.
If the window runs into any obstacle
while it is closing automatically, it
will reverse direction, and then stop.
To close the window, remove the
obstacle, then use the window switch
again.The indicators in the switches come
on when you turn the ignition switch
to the ON (II) position.
The power windows have a key-of f
delay. You can still open and close
the windows f or up to 10 minutes
after you turn off the ignition switch.
The key-of f delay cancels as soon as
you open either f ront door. You must
then turn the ignition switch to the
ON (II) position f or the power
windows to operate.
Auto Reverse
AUTO
Power Windows
186
2009 RL

You can open all of the windows and
the moonroof f rom outside with the
remote.Press the UNLOCK button once
to unlock the driver’s door.
To open the windows and
moonroof f urther, press the
button again and hold it. If the
windows and the moonroof stop
bef ore the desired position, repeat
steps 1 and 2.
You cannot close the windows or the
moonroof with the remote. You can open and close the windows
and moonroof with the built-in key in
the driver’s door lock.
Insert the built-in key in the driver’s
door lock.
To open: Turn the key clockwise, then
release it.
Turn the built-in key clockwise
again, and hold it. All four
windows and the moonroof start to
open. To stop the windows and
moonroof , release the built-in key.
Press the UNLOCK button a
second time, and hold it. All the
doors unlock, and all f our windows
and moonroof start to open. To
stop the windows and moonroof ,
release the button. When the windows or moonroof
stops bef ore opening f ully, to open
the windows and moonroof f urther,
turnandholdthekeyagain
(within 10 seconds).
1.
2.
3.
1.2.
3.
4.
CONT INUED
Opening the Windows and
Moonroof with the Remote
Opening/Closing the Windows
and Moonroof with the Built-in
Key
Power Windows
Inst rument s and Cont rols
187
Open
Close
UNLOCK BUTTON
