Each torque indicator is displayed as
a bar graph divided into 5 segments.
The number of segments represents
the amount of torque distributed to
each wheel.
When there is only a slight change in
torque distribution while driving,
such as cruising on level roads at the
same speed, the torque distribution
monitor may stop displaying the
amount of torque. This is not a
system problem. The monitor will
show the amount if the system
senses any change in torque
distribution.If the SH-AWD indicator blinks while
driving, it indicates the dif f erential
temperature is too high. You will also
see an ‘‘SH-AWD DIFF TEMP.
HIGH’’ message on the multi-
inf ormation display. If this happens,
pull to the side of the road when it is
saf e, shif t to Park, and let the engine
idle until the indicator goes out. If
the indicator does not go out, take
your vehicle to a dealer to have it
checked.
If the SH-AWD indicator on the
instrument panel stays on, and the
‘‘CHECK SH-AWD SYSTEM’’
message also appears on the multi-
inf ormation display, there is problem
with the SH-AWD system.
Your vehicle still has normal f ront-
wheel drive with vehicle stability
assist (VSA), but does not have the
advantages of SH-AWD. Have your
vehicle checked by a dealer as soon
as possible.
Super Handling-A ll Wheel Drive (SH-A WD)System
414
TM
2009 RL

on loose or
uneven surfaces, such as gravel or
snow, than a vehicle without anti-
lock.
It only helps with steering
control during braking.
such as trying to take a
corner too f ast or making a sudden
lane change. Always drive at a safe
speed f or the road and weather
conditions.
Always steer moderately
when you are braking hard. Severe
or sharp steering wheel movement
can still cause your vehicle to veer
into oncoming traffic or off the road.
If the ABS indicator and the brake
system indicator come on together,
and the parking brake is f ully
released, the EBD system may also
be shut down.
Test your brakes as instructed on
page . If the brakes f eel normal,
drive slowly and have your vehicle
repaired by your dealer as soon as
possible. Avoid sudden hard braking
which could cause the rear wheels to
lock up and possibly lead to a loss of
control.
The VSA indicator will come on
alongwiththeABSindicator.
508
A vehicle with A BS may require a
longer distance to stop
Important Saf ety Reminders
A BS does not reduce the time or
distance it takes to stop the
vehicle.
A BS will not prevent a skid that
results f rom changing direction
abruptly,
A BS cannot prevent the loss of
stability.
Anti-lock Brakes (ABS)
418
2009 RL

As required by the FCC:This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device.
Themainpurposeof theCMBSisto
reduce the severity of injuries
caused by an unavoidable collision.
While the CMBS may help to alert
you and minimize the severity of a
collision, it may not activate in every
dangerous situation.
Even with the CMBS, it is still your
responsibility to operate the brake
pedal and steering wheel
appropriately, according to the
driving conditions.
Important Saf ety Reminder
Collision Mitigation Brake System (CMBS)
428
2009 RL

ÝÛÝÛ
The message will be canceled if the
or buttononthesteeringwheel
is pressed. Press the or button
to see the message again.
When the remaining engine oil lif e is
15 to 6 percent, the multi-inf ormation
display shows a ‘‘SERVICE DUE
SOON’’ message along with the
maintenance schedule code
indicating the main and sub items
required at the time of the oil change.
Refer to page and for a
complete list of the maintenance
main items and sub items. Press the SEL/RESET button on the
steering wheel repeatedly to select
the engine oil lif e. The message
‘‘OIL LIFE’’ along with the
percentage of oil lif e remaining and
the maintenance item code(s),
appear on the lower part of the multi-
inf ormation display.
453 454
Maintenance Minder
446
MESSAGE
MAINTENANCE
MAIN ITEM REMAINING
ENGINE OIL LIFE
MAINTENANCE
SUB ITEM(S) MAINTENANCE
ITEM CODE(S)
2009 RL

ÝÛÛÝ
Press and hold the SEL/RESET
button on the steering wheel f or
more than 10 seconds. The
remaining engine oil lif e reset
mode will be shown on the multi-
inf ormation display.
To reset the engine oil lif e, press
the or button on the steering
wheel to select RESET on the
display, and press the SEL/
RESET button. To cancel resetting the oil life,
press the or button on the
steering wheel to select CANCEL
on the display, and press the SEL/
RESET button.
If you do not complete the reset
procedure within 30 seconds af ter
selecting the reset mode, the mode
will be canceled automatically.
Your dealer will reset the display
af ter completing the required
maintenance service. You will see
‘‘OIL LIFE 100%’’ on the display the
next time you turn the ignition
switch to the ON (II) position.
If maintenance service is done by
someone other than your dealer,
reset the maintenance minder as
f ollows:
If the oil lif e minder is not
displayed, press the SEL/RESET
buttononthesteeringwheel
repeatedly until it is.
Turn the ignition switch to the ON
(II) position.
The maintenance item code or codes
indicate the main and sub items
required at the time of the oil change
(see page ).
1.
2.
3.
453
Maintenance Minder
448
U.S.
CANADA
2009 RL

ÚUse the extension and the wheel
nut wrench as shown to raise the
vehicle until the f lat tire is of f the
ground.
Remove the wheel nuts, then
remove the f lat tire. Temporarily
place the flat tire on the ground
with the outside surface of the
wheel f acing up. You could scratch
the wheel if you put it f ace down.
Loosen each wheel nut 1/2 turn
with the wheel nut wrench.
Place the jack under the jacking
point nearest the tire you need to
change. It is pointed to by a
mark molded into the underside of
the body. Turn the end bracket
clockwise until the top of the jack
contacts the jacking point. Make
sure the jacking point tab is
restinginthejacknotch.
6. 7. 8.
9.
Changing a Flat Tire
496
WHEEL NUT WRENCH EXTENSION
WHEEL NUT WRENCH
2009 RL

µµÎ
Î
Î
Î
Specif ications
524
Dimensions
Weights
Air Conditioning
Seating Capacities Capacities
4.2 US qt (4.0
)
195.8 in (4,973 mm)
72.7 in (1,847 mm)
57.3 in (1,455 mm)
110.2 in (2,800 mm)
62.0 in (1,575 mm)
62.4 in (1,585 mm)
1.59 US gal (6.0
)
2.27 US gal (8.6)
4.5 US qt (4.3
)
5.3 US qt (5.0
)
3.0 US qt (2.8)
8.1 US qt (7.7)
Length
Width
Height
Wheelbase
Track
Gross vehicle weight rating See the certification label attached
to the driver’s doorjamb.
Excluding the oil remaining in the engine
Including the coolant in the reserve tank and that remaining in the
engine
Reserve tank capacity:6.9 US qt (6.5
)
2.6 US qt (2.5)
0.45 US qt (0.43
)
0.48 US qt (0.45)
3.3 US qt (3.1
)
Refrigerant type
Charge quantity
Lubricant type ND-OIL8 15.8 17.60 oz (450 500 g)HFC-134a (R-134a)
Total
Front
Rear
5
2
3 0.77 US qt (0.73
)
0.79 US qt (0.75)
19.4 US gal (73
)
2.8 US qt (2.7
)
0.16 US gal (0.58
)
Fuel tank
Engine
coolant
Engine oil
Automatic
transmission
fluid
Rear differential fluid
SH-AWD
differential
case
SH-AWD
clutch case
Transfer
assembly
fluid
Windshield
washer
reservoir
1:
2: Approx.
Front
Rear Change
Total
Change
Including filter
Without filter
Total
Change
Total
Change
Total
Change
Total
Change
Total
U.S. vehicles
Canadian
vehicles
1
2
2009 RL

CONT INUED
Three Way Catalytic.................................
Converters .534
Tilt/Telescopic Steering
.........................................
Wheel .148
....................................
Timing Belt .467
....................................
Tire Chains .487
.........
Tire, How to Change a Flat .495
Tire Pressure Monitoring
............
System (TPMS) .429,530
Monitoring Tire Pressure ..................................
Reading .429
...........
TPMS System Warning .429
...............................................
Tires .480
..............................
Air Pressure .482
........................................
Chains .487
.........................
Checking Wear .483
..........................
Compact Spare .494
......
DOT Tire Quality Grading .526
......................................
Inf lation .480
..................................
Inspection .483
.............................
Labeling .528,529
Low Tire Pressure
...........................
Indicator .67,429
......................
Pressure Monitor .431
........
Pressure Monitor System .429
...................................
Replacing .485 ......................................
Rotating .485
...........................................
Snow .487
............................
Specif ications .525
...................
Tools, Tire Changing .495
Torque Distribution Monitor
.................................
(SH-AWD) .413
Towing .....................................
A Trailer .437
....
Equipment and Accessories .438
.............................
Weight Limit .437
TPMS (Tire Pressure Monitoring ..................................
System) .429
Required Federal ............................
Explanation .530
.....................
Warning Message .433
.............................
Trailer Loading .437
......................
Trailer Towing Tips .441
Transmission
Checking Fluid Level, ..............................
Automatic .464
...........................
Fluid Selection .465
..............
Identif ication Number .522
.............
Shif ting the Automatic .405
.............................
Treadwear .483,494
.......................................
Trip Meter .72 ..............................................
Trunk .154
..................
Emergency Opener .155
...............................
Opening the .154
.......
Open Monitor Indicator .13,79
..................................
Turn Signals .140
Unexpected, Taking Care
..........................................
of the .493
....
Unif orm Tire Quality Grading .526
........................
Unleaded Gasoline .384
.......
Used Oil, How to Dispose of .460
.................
Vehicle Capacity Load .396
......................
Vehicle Dimensions .524
....
Vehicle Identif ication Number .522
Vehicle Stability Assist (VSA)
....................................
System .435
...
VSA Activation Indicator .65,435
.........................
VSA Of f Switch .436
........
VSA System Indicator .65,435
