2009 Acura RDX display

Û
Ý
To change the display, press the
SEL/RESET button or INFO ( / )buttononthesteeringwheel
repeatedly until the desired
information appears (see page ).
You can also change the display by
pressing the select/reset knob in the
instrument panel. When you turn the ignition switch to
the ON (II) position, your last
selection is displayed.
In the multi-information display, the
system message is also displayed
(see page ) and you can
customize your vehicle control
settings (see page ).
The multi-inf ormation display in the
instrument panel displays various
inf ormation and messages when the
ignition switch is in the ON (II)
position. Some of the messages help
you operate your vehicle more
comf ortably. Others help to keep
you aware of the periodic
maintenance your vehicle needs f or
continued trouble-f ree driving.
When you open the driver’s door, a
‘‘Welcome’’ message is shown on the
multi-inf ormation display. When you
turn the ignition switch from the ON
(II) position to the ACCESSORY (I)
position, a ‘‘Goodbye’’ message is
shownonthedisplay.73 77
80
Multi-Inf ormation Display
72
SEL/RESET
BUTTON
INFO BUTTONS
\f—\f—

y


y
() \fy\f\fy
2009 RDX

ÛÝ
Multi-Inf ormation Display
Inst rument s and Cont rols
73
U.S. model is shown.IGNITION OFF
IGNITION ON
: Press the INFO ( / ) Button
: Press the SEL/
RESET Button
\f—\f—

y

y
() \fy\f\fy
2009 RDX

The odometer shows the total
distance your vehicle has been
driven. It measures miles in U.S.
models and kilometers in Canadian
models. It is illegal under U.S.
federal law and Canadian provincial
regulations to disconnect, reset, or
alter the odometer with the intent to
change the number of miles or
kilometers indicated.
This meter shows the number of
miles (U.S.) or kilometers (Canada)
driven since you last reset it. There
are two trip meters: Trip A and Trip
B. Each trip meter works
independently, so you can keep track
of two dif f erent distances.When you reset Trip A, AVG.
FUEL A is reset at the same time.
When you reset Trip B, AVG.
FUEL B is reset.
The temperature sensor is in the
f ront bumper. The temperature
reading can be affected by heat
ref lection f rom the road surf ace,
engine heat, and the exhaust f rom
surrounding traf f ic. This can cause
an incorrect temperature reading
when your vehicle speed is under
19 mph (30 km/h). When you start
your trip, the sensor is not f ully
acclimatized, theref ore it may take
several minutes until the proper
temperature is displayed.
In certain weather conditions,
temperature readings near f reezing
(32°F, 0°C) could mean that ice is
f orming on the road surf ace.
To reset a trip meter, display it, then
press and hold the SEL/RESET
button until the number resets to
‘‘0.0’’. You can customize the Trip A and
AVG. FUEL A reset condition on the
multi-inf ormation display (see page
).
You can adjust the outside
temperature display (see page ).
This shows the outside temperature
in Fahrenheit (U.S. models), or in
Celsius (Canadian models).
91
89
Odometer
Trip Meter
Outside Temperature Display
Multi-Inf ormation Display
74
\f—\f—

y

y
() \fy\f\fy
2009 RDX

This shows the estimated distance
you can travel on the fuel remaining
in the f uel tank. This distance is
estimated f rom the f uel economy
you received over the last several
miles(U.S.) or kilometers (Canada),
so it will vary with changes in speed,
traf f ic, etc.
This shows the time passed traveled
since you last reset it. When you turn
the ignition switch to the ON (II)
position, ELAPSED TIME is reset.
You can customize the ELAPSED
TIME reset condition on the multi-
inf ormation display (see page ).This shows your vehicle’s average
f uel economy in mpg (U.S. models)
or liter/100 km (Canadian models)
since you last reset the Trip A or
Trip B.
When you reset Trip A, AVG.
SPEED is also reset.
This shows the average speed you
are traveling in miles per hour (mph)
forU.S.modelsorkilometersper
hour (km/h) f or Canadian models.
When the battery is disconnected, or
you ref uel, RANGE is also reset.
The multi-inf ormation display in the
instrument panel shows you the
engine oil lif e and maintenance
service items when the ignition
switch is in the ON (II) position. This
inf ormation helps to keep you aware
of the periodic maintenance your
vehicle needs f or continued trouble-
f ree driving. Ref er to page f or
more inf ormation.
This shows your current f uel
mileage.
When you turn of f the engine, INST.
MPG or INST. L/100 km is also
reset.
The average f uel mileage will be
reset when you reset the trip meter,
or if the vehicle’s battery goes dead
or is disconnected.
You can customize the Trip A and
AVG. FUEL A reset condition on the
multi-inf ormation display (see page).
327
91
93
RANGE
EL A PSED T IME
AVG. FUEL A/B
A VG. SPEED
Maintenance Minder
INST.MPG(U.S.models)/INST.
L /100km (Canadian models)
Multi-Inf ormation Display
Inst rument s and Cont rols
75
\f—\f—

y

y
() \fy\f\f\fy
2009 RDX

This monitor shows how much
torque is being delivered to each
wheel. For more inf ormation, see
page .
You can see the pressure of each tire
in this monitor. If one or more tire
pressure are low, inflate them to the
correct pressure. For more
inf ormation, see page .This shows the temperature of the
engine’s coolant. During normal
operation, the reading should rise
f rom the ‘‘C (Cold)’’ mark to about
the middle of the gauge. In severe
driving conditions, such as very hot
weather or a long period of uphill
driving, the reading may rise to near
the ‘‘H (Hot)’’ mark of the gauge. If
it reaches the ‘‘H’’ mark, pull saf ely
to the side of the road. See page
f or instructions and precautions
on checking the engine’s coolant
system. You can receive or make phone calls
f rom your cell phone through your
vehicle’s Bluetooth
HandsFreeLink(HFL) system
without touching your cell phone.
To use the system, your cell phone
and the HFL system must be linked.
Not all cell phones are compatible
with this system. Ref er to page for instructions on how to link
your cell phone to the HFL and how
to receive or make phone calls, or
visit the handsf reelink.com website.
301
308379 257
SH-AWD T orque Distribution
Monitor
Tire Pressure Monitor
Temperature Gauge Bluetooth
HandsFreeL ink
Multi-Inf ormation Display
76
\f—\f—

y


y
() \fy\f\f
y
2009 RDX

If there is a problem with your
vehicle, f or example, the engine oil
level is low or a door is not f ully
closed, the multi-inf ormation display
will show you the problem. It does
this by interrupting the current
display with one or more messages.
Here is a list of messages shown on
the multi-information display:See page
19
See page 11
See page 65
See page 383
See pages 383,384 See page
310
See page 309
See page 381
See page 381
See page 382
CONT INUED
System Messages
Multi-Inf ormation Display
Inst rument s and Cont rols
77
U.S. Canada
Canada
U.S.
Canada
U.S.
——

y

y
() yy
2009 RDX

See page293
See page 302
See page 302
See page 31
See page 305 See page
312
See page 31
See page 116
See page 66
See page 11 See page
274
See page 342
See page 122
See page
328
Multi-Inf ormation Display
78
U.S. Canada
\f—\f—

y


y
() \fy\f\fy
2009 RDX

ÛÝÛÝ
ÛÝ
ÛÝ
The system message(s) triggers the
appropriate indicator(s) on the
instrument panel, including the
system message indicator, to come
on. The system message indicator
does not go of f until the problem(s)
is corrected.
You will also hear a beep when the
system message comes on f or the
first time.
Most of the messages are displayed
f or about 5 seconds, and then the
normal display returns. If there are
several system messages to be
shown, the display switches these
messages every 5 seconds. Even if you press the INFO ( / )
button, some messages stay on or
come on again at regular intervals
until the problem is corrected.
FASTEN SEAT BELT
FASTEN PASSENGER SEAT
BELT
RELEASE PARKING BRAKE
DOOR & TAILGATE OPEN If the system message indicator
remains lit on the instrument panel,
you can see the corresponding
message(s) again by pressing the
INFO ( / ) button repeatedly.
To switch the message(s) bef ore 5
seconds have elapsed, press the
INFO( / )buttononthesteering
wheel.
Multi-Inf ormation Display
Inst rument s and Cont rols
79
SYSTEM MESSAGE INDICATOR
Press the INFO ( / ) button
