Instruments and controls
WARNING LIGHTS
Each time the engine is started: a series of warning lights comes on applying a check auto-test. They are switched off almost immediately.
When the engine is running: the warning light becom es a warning if it remains on continuously or flashes. This initial warning may be
accompanied by an audible signal and a message on t he display.
Do not ignore these warnings
Warning light is indicates Solution-action
STOP lit, associated
with another
warning light and
accompanied by
a message on
the display. major faults linked with the
"Brake fluid level", "Engine oil
pressure and temperature",
"Coolant temperature",
"Electronic brake force
distribution" and "Power
steering" warning lights.
You must stop, park, switch off the ignition and ca ll
a CITROËN dealer.
Handbrake/
Brake fluid
level/EBFD lit.
handbrake applied or not
released correctly. Releasing the handbrake switches off the warning l
ight.
lit. low brake fluid level. Top up using a fluid recommended by CITROËN.
remaining on,
even though the
level is correct and
associated with the
ABS warning light. failure of the electronic brake
force distribution.
You must stop, park, switch off the ignition and ca ll
a CITROËN dealer.
Engine oil
pressure and
temperature lit while driving.
insufficient pressure or
temperature too high. Park, switch off the ignition and allow to cool. V
isually
check the level. Chapter 6, "Levels" section.
remaining on,
even though the
level is correct. major fault. Call a CITROËN dealer.
Page 102 of 231
107
Under the bonnet
CHECKS
6
DIESEL ENGINES
8 - Power steering reservoir.
9 - Removable towing eye.
10 - Repriming pump ( a : 1.6 litre HDi;
b : 2 litre HDi).
11 - Engine oil filling funnel (2 litre HDi).
UNDER THE BONNET
1 - Windscreen/headlamp wash reservoir.
2 - Fuse box.
3 - Coolant reservoir.
4 - Brake and clutch fluid reservoir.
5 - Air filter.
6 - Dipstick.
7 - Engine oil filler cap.
7.1 - Engine oil filler cap.
If your vehicle is fitted with this oil filler tub e,
proceed as follows:
A - Remove the oil filler cap.
B - Remove the filler tube from its location.
C - Place the filler tube in the filler opening
as shown on the illustration.
D - Turn it a 1/4 of a turn to the left to lock it
then top up the oil.
To refit, proceed in the reverse order without
forgetting to retighten the cap A correctly.
Page 103 of 231
108
Under the bonnet
PETROL ENGINE
4. Brake and clutch fluid reservoir.
5. Air filter.
6. Dipstick.
1. Windscreen/headlamp wash reservoir.
2. Fuse box.
3. Coolant reservoir.
7. Engine oil filler cap.
8. Power steering reservoir.
9. Removable towing eye.
Page 112 of 231
117
Repairing a wheel
TROUBLESHOOTING
7
PUNCTURE REPAIR KIT
The temporary tyre repair kit consists of
a compressor and a bottle (containing a
sealant).
Using the kit
1. Tick the deflated wheel on the speed
limitation sticker then affix the sticker to
the vehicle’s steering wheel to remind
you that a wheel is in temporary use.
2. Clip the bottle 1 on the compressor 2 .
3. Connect the bottle 1 to the valve of the
tyre to be repaired.
4. Take care to unwind the compressor
pipe before connecting it to the bottle.
5. Connect the power lead to one of the
vehicle’s 12 V sockets.
6. Switch on the compressor by pressing
button A until the tyre pressure reaches
2.0 bars. If this pressure cannot be
reached, the tyre cannot be repaired.
7. Remove and store the compressor.
8. Drive immediately, for a few miles
(kilometres), at reduced speed, to fill the
puncture.
9. Adjust the pressure using the
compressor in accordance with the
recommendation for the vehicle and
check that the leak is filled correctly (no
further loss of pressure).
10. Drive at reduced speed (50 mph
[80 km/h]). The tyre must be examined
and repaired by a professional as soon
as possible. After use, the bottle can be stored in a
plastic bag, supplied in the kit, to avoid
staining your vehicle with traces of fluid.
Warning: the bottle of gel contains
ethylene-glycol, a product which is
harmful if swallowed and which causes
irritation to the eyes.
Keep it out of reach of children.
After use, do not discard the bottle into the
environment, take it to a CITROËN dealer or
to an specialised waste disposal site.
Replacement bottles of sealant are available
from CITROËN dealers.
Vehicles supplied with a temporary puncture
repair kit do not have a spare wheel or
tooling (jack, wheelbrace, ...).
