Auxiliary socket
This connection box, consisting of a JACK socket is located on the centre console. It permits the connection of por table equipment, such as a digital audio player of the iPod ® type. It reads the audio file formats (mp3, ogg, wma, wav, ...) which are transmitted to your audio equipment and played via the vehicle's speakers. You can manage these files using the steering wheel controls or the audio equipment control panel and display them on the multifunction screen.
USB Player
When it is in use, the por table equipment charges automatically. When it is in use, the por table equipment charges automatically.
For more information on the use of this equipment, refer to the MyWay or Audio system
par t of the "Audio and Telematics" section.
This connection box, consisting of a JACK socket and a USB por t, is located on the centre console. It permits the connection of por table equipment, such as a digital audio player of the iPod ® or USB stick type. ®
It reads the audio file formats (mp3, ogg, wma, wav...) which are transmitted to your audio equipment and played via the vehicle's speakers. You can manage these files using the steering wheel controls or the audio equipment control panel and display them on the multifunction screen.
For more information on the use of this equipment, refer to the Audio system par t of the
"Audio and Telematics" section.
12 V accessories
socket
 To connect a 12 V accessory (max power: 120 Watts), remove the cover and connect a suitable adaptor.

Gear change indicator *
Operation
The system inter venes only when driving economically.
Depending on the driving situation and your vehicle's equipment, the system may advise you to skip one or more gears. You can follow this instruction without engaging the intermediate gears. The gear engagement recommendations must not be considered compulsory. In fact, the configuration of the road, the amount of traffic and safety remain determining factors when choosing the best gear. Therefore, the driver remains responsible for deciding whether or not to follow the advice given by the system. This function cannot be deactivated.
- The system may suggest that you engage a higher gear, if appropriate.
The information appears in the form of an arrow on the instrument panel display. Depending on your vehicle's equipment, this arrow may be accompanied by the recommended gear.
In the case of driving which makes par ticular demands on the per formance of the engine (firm pressure on the accelerator pedal, for example, when over taking...), the system will not recommend a gear change. The system never suggests: - engaging first gear, - engaging reverse gear, - engaging a lower gear.
* According to engine.
Example:
- You are in third gear.
- You press the accelerator pedal moderately.

When you move the lever in the gate to select a position, the corresponding indicator is displayed on the instrument panel. P. Park R. Reverse N. Neutral D. Drive (Automatic driving) S. Spor t programme  . Snow programme 1, 2, 3, 4. Gear engaged during manual operation -. Invalid value during manual operation
Displays on the instrument panel
Foot on brake
 Press the brake pedal when this indicator lamp is displayed on the instrument panel (e.g.: star ting the engine).
Moving off
If position N is engaged inadver tently while driving, allow the engine to return to idle then engage position D to accelerate.
When the engine is running at idle, with the brakes released, if position R , D or
M is selected, the vehicle moves even without the accelerator being pressed. When the engine is running, never leave children in the vehicle without super vision. When carrying out maintenance with the engine running, apply the parking brake and select position P . PP
 Apply the parking brake.  Select position P or N .  Star t the engine. If this procedure is not followed, an audible signal is heard, accompanied by a message on the multifunction screen.  With the engine running, press the brake pedal.  Release the parking brake.  Select position R , D or M ,  Gradually release the brake pedal. The vehicle moves off immediately.

Manual operation
D disappears and the gears engaged appear in succession on the instrument panel. In the event of the engine labouring or over-revving, the gear selected flashes for a few seconds, then the actual gear engaged is displayed.
It is possible to change from position D(automatic) to position M (manual) at any time. When the vehicle is stationary or moving very slowly, the gearbox selects gear M1automatically. The spor t and snow programmes do not operate in manual mode.
Invalid value during manual operation
 Select position M for sequential changing of the four gears.  Push the lever towards the + sign to change up a gear.  Pull the lever towards the - sign to change down a gear. It is only possible to change from one gear to another if the vehicle speed and engine speed permit; other wise, the gearbox will operate temporarily in automatic mode.
This symbol is displayed if a gear is not engaged correctly (selector between two positions).
Stopping the vehicle
Before switching off the engine, you can engage position P or N to place the gearbox in neutral. In both cases, apply the parking brake to immobilise the vehicle.
When the ignition is on, the lighting of this warning lamp, accompanied by an audible signal and a message on the multifunction screen, indicates a gearbox malfunction. In this case, the gearbox switches to back-up mode and is locked in 3rd gear. You may feel a substantial knock when changing from P to R RRand from N to R . This will not cause any damage to the gearbox. Do not exceed 60 mph (100 km/h), local speed restrictions permitting. Contact a CITROËN dealer as soon as possible.
Operating fault
If the lever is not in position P , Pwhen the driver's door is opened or approximately 45 seconds after the ignition is switched off, a message appears in the multifunction screen.  Return the lever to position P ; the
message disappears.
There is a risk of damage to the gearbox: - if you press the accelerator and
brake pedals at the same time, - if you force the movement of the gear lever from the P position to
another position when the battery is flat.
To reduce fuel consumption when at a prolonged standstill with the engine running (traffic jam...), put the gear lever in the N position and apply the parking brake.

155Driving
System which prevents the vehicle from exceeding the speed programmed by the driver. When the programmed speed limit is reached, pressing the accelerator pedal in the normal manner no longer has any effect. The speed limiter is switched on manually: it requires a programmed speed of at least 20 mph (30 km/h). The speed limiter is switched off by manual d offoperation of the control. The programmed speed can be exceeded temporarily by pressing the accelerator firmly. To return to the programmed speed, simply slow down to a speed below the programmed speed. The programmed speed remains in the memory when the ignition is switched off.
Speed limiter
The speed limiter cannot, in any circumstances, replace the need to respect speed limits, nor can it replace the need for vigilance and responsibility on the par t of the driver.
The controls of this system are grouped together on stalk A . 1. Speed limiter mode selection thumb wheel 2. Value decrease button 3. Value increase button 4. Speed limiter on/off button
Steering mounted controls
The programmed information is grouped together on the instrument panel display. 5. Speed limiter on/off indication 6. Speed limiter mode selection indication 7. Programmed speed value
Displays on the instrument panel

 Turn thumb wheel 1 to the "LIMIT"position: the speed limiter mode is selected but is not switched on (PAUSE). You do not have to switch the speed limiter on
in order to set the speed.  Set the speed value by pressing button 2or 3 (e.g.: 55 mph (90 km/h)).
Programming
You can then change the programmed speed using buttons 2 and 3 : - by + or - 1 mph (km/h) = shor t press, - by + or - 5 mph (km/h) = long press, - in steps of + or - 5 mph (km/h) = maintained press.  Switch the speed limiter on by pressing button 4 .  Switch the speed limiter off by pressing button 4 : the display confirms that it has been switched off (PAUSE).  Switch the speed limiter back on by pressing button 4 again.
Exceeding the programmed speed
Pressing the accelerator pedal to exceed the programmed speed will not have any effect unless you press the pedal firmly past the mlypoint of resistance . The speed limiter is deactivated temporarily and the programmed speed, which is still displayed, flashes. Returning to the programmed speed, by means of inten tional or unintentional deceleration of the vehicle, automatically cancels the flashing of the programmed speed.
On a steep descent or in the event of sharp acceleration, the speed limiter will not be able to prevent the vehicle
from exceeding the programmed speed. To avoid any risk of jamming of the pedals: - ensure that the mat is positioned correctly, - do not fit one mat on top of another.
Leaving limiter mode
 Turn thumb wheel 1 to the "0" position: the speed limiter mode is deselected. The display returns to the distance recorder.
Operating fault
In the event of a speed limiter malfunction, the speed is cleared resulting in flashing of the dashes. Have the system checked by a CITROËN dealer.

157Driving
Cruise control
System which automatically maintains the speed of the vehicle at the value programmed by the driver, without any action on the accelerator pedal. The cruise control is switched on manually: it requires a minimum vehicle speed of 25 mph (40 km/h), as well as the engagement of: - four th gear on a manual gearbox, - second gear on an automatic gearbox, in sequential mode, - position D on an automatic gearbox. The cruise control is switched off manually d offor by pressing the brake or clutch pedal or on triggering of the ESP system for safety reasons. It is possible to exceed the programmed speed temporarily by pressing the accelerator pedal. To return to the programmed speed, simply release the accelerator pedal. Switching off the ignition cancels any programmed speed value.
The controls of this system are grouped together on stalk A . 1. Cruise control mode selection thumb whel 2. Value decrease button 3. Value increase button 4. Cruise control off/resume button
Steering mounted controls
The cruise control cannot, in any circumstances, replace the need to respect speed limits, nor can it replace the need for vigilance and responsibility on the par t of the driver.
The programmed information is grouped together on the instrument panel display. 5. Cruise control off/resume indication 6. Cruise control mode selection indication 7. Programmed speed value
Displays on the instrument panel

Programming
 Turn thumb wheel 1 to the "CRUISE"position: the cruise control mode is selected but is not switched on (PAUSE).  Set the programmed speed by
accelerating to the required speed, then press button 2 or 3 (e.g.: 70 mph(110 km/h)).
You can then change the programmed speed using buttons 2 and 3 : - by + or - 1 mph (km/h) = shor t press, - by + or - 5 mph (km/h) = long press, - in steps of + or - 5 mph (km/h) = maintained press.  Switch off the cruise control by pressing button 4 : the display confirms that it has been switched off (PAUSE).
 Switch the cruise control back on by pressing button 4 again.
Exceeding the programmed speed
Intentional or unintentional exceeding of the programmed speed results in flashing of this speed on the display. Return to the programmed speed, by means of intent ional or unintentional deceleration of the vehicle, automatically cancels the flashing of the speed.
Leaving cruise control mode
 Turn thumb wheel 1 to the "0" position: the cruise control mode is deselected. The display returns to the distance recor der.
Operating fault
In the event of a cruise control malfunction, the speed is cleared resulting in flashing of the dashes. Have it checked by a CITROËN dealer.
When the cruise control is switched on, be careful if you maintain the pressure on one of the programmed speed changing buttons: this may result in a very rapid change in the speed of your vehicle. Do not use the cruise control on slippery roads or in heavy traffic. On a steep descent, the cruise control will not be able to prevent the vehicle from exceeding the programmed speed. To avoid any risk of jamming of the pedals: - ensure that the mat is positioned correctly, - never fit one mat on top of another.
