2009.5 Citroen C5 headlamp
[x] Cancel search: headlampPage 173 of 314
X
!
155
C H E C K S
PETROL ENGINES
The various caps and covers allow
a c c e s s f o r c h e c k i n g fl u i d l e v e l s a n d
for replacing certain components.
1. Screenwash and headlamp wash
reservoir.
2. P o w e r s t e e r i n g fl u i d r e s e r v o i r o r
power steering and suspension
fl u i d r e s e r v o i r .
3. Engine coolant reservoir.
4. Engine oil dipstick.
5. E n g i n e o i l fi l l e r c a p .
6. B r a k e fl u i d r e s e r v o i r .
7. Battery.
8. A i r fi l t e r .
V e h i c l e s fi t t e d w i t h t h e 2.0i
16v e n g i n e m a y b e fi t t e d
with metal suspension. In this
case, a different power steering
fl u i d r e s e r v o i r i s fi t t e d .
1.6i 16V/1.8i 16V
2.0i 16V
Page 174 of 314
X
156
C H E C K S
3 litre V6 petrol engine
1. Screen wash and headlamp
wash reservoir.
2. Power steering and suspension
fl u i d r e s e r v o i r .
3. Engine coolant reservoir.
4. E n g i n e o i l fi l l e r c a p .
5. Engine oil topping-up.
6. B r a k e fl u i d r e s e r v o i r .
7. Battery.
8. A i r fi l t e r .
3.0i V6
Page 175 of 314
X
!
157
C H E C K S
DIESEL ENGINES
The various caps and covers allow
a c c e s s f o r c h e c k i n g fl u i d l e v e l s , f o r
replacing certain components and
for priming the fuel system.
1. Screenwash and headlamp wash
reservoir.
2. P o w e r s t e e r i n g fl u i d r e s e r v o i r o r
power steering and suspension
fl u i d r e s e r v o i r , d e p e n d i n g o n
equipment.
3. Engine coolant reservoir.
4. Engine oil dipstick.
5. E n g i n e o i l fi l l e r c a p .
6. A i r fi l t e r .
7. B r a k e fl u i d r e s e r v o i r .
8. Battery.
As the Diesel fuel system op-
erates under high pressure,
any work on the fuel system
is prohibited.
V e h i c l e s fi t t e d w i t h t h e HDi 140 en-
g i n e m a y b e fi t t e d w i t h m e t a l s p r i n g s . In this case, a different power steer-
i n g fl u i d r e s e r v o i r i s fi t t e d .
HDi 110
HDi 140
Page 176 of 314
X!
158
C H E C K S
HDi 163 - V6 HDi 240 engines
(with particle filter)
1. Screen wash and headlamp
wash reservoir.
2. Power steering and suspension
fl u i d r e s e r v o i r .
3. Engine coolant reservoir.
4. Engine oil dipstick.
5. E n g i n e o i l fi l l e r c a p .
6. A i r fi l t e r .
7. B r a k e fl u i d r e s e r v o i r .
8. Battery.
9. "+" and "-" terminals for starting
with a slave battery.
As the Diesel fuel system op-
erates under high pressure:
- Any work on the fuel system is prohibited.
- HDi engines make use of ad- vanced technology.
All maintenance and repairs re-
q u i r e s p e c i a l q u a l i fi c a t i o n s w h i c h
only a CITROËN dealer can guar-
antee.
HDi 163
V6 HDi 240
Page 178 of 314
X
!
160
C H E C K S
Screenwash and headlamp
wash fluid
F l u i d s p e c i fi c a t i o n
For optimum cleaning and to avoid
f r e e z i n g , t h i s fl u i d m u s t n o t b e
topped up or replaced with water.
Reservoir capacities:
-
screenwash: approximately 3.5 litres,
- screenwash and headlamp wash: approximately 6.15 litres. Diesel additive level
(Diesel engine with particle
emission filter)
A low additive level is indicated by
lighting of the service warning lamp,
accompanied by an audible warning
and a message on the multifunction
screen.
Topping up
This additive must be topped up by
a CITROËN dealer without delay.
Used products
Avoid prolonged contact of
u s e d o i l o r fl u i d s w i t h t h e s k i n .
M o s t o f t h e s e fl u i d s a r e h a r m f u l t o
health or indeed very corrosive.
Do not discard used oil or
fl u i d s i n t o s e w e r s o r o n t o t h e
ground.
Take used oil to a CITROËN dealer
(France) or an authorised waste
disposal site.
I n t h e c a s e o f v e h i c l e s fi t t e d
with headlamp washers, the
m i n i m u m l e v e l o f t h i s fl u i d i s
indicated by an audible sig-
nal and a message on the multifunc-
tion screen.
Top up the level when you stop the
vehicle.
Coolant level
Coolant change
The coolant does not have to be
changed.
F l u i d s p e c i fi c a t i o n
The coolant must conform to the
manufacturer's recommendations. The coolant level should be
close to the "MAX" mark but
should never exceed it.
When the engine is warm, the tem-
perature of the coolant is regulated
by the fan. This can operate with the
ignition off.
O n v e h i c l e s w h i c h a r e fi t t e d w i t h
a p a r t i c l e e m i s s i o n fi l t e r , t h e f a n
may operate after the vehicle has
been switched off, even if the en-
gine is cold.
In addition, as the cooling system is
pressurised, wait at least one hour
after switching off the engine before
carrying out any work.
To avoid any risk of scalding, un-
screw the cap by two turns to al-
low the pressure to drop. When the
pressure has dropped, remove the
cap and top up the level.
Page 189 of 314
XI
!
1 7 0
P R A C T I C A L I N F O R M A T I O N
CHANGING A BULB Headlamps
Model with Xenon headlamps (D1S)
1. Sidelamps: W 5 W
2. Dual-function Xenon
headlamps (dipped/main): D1S
3. Cornering
lighting: HP19
4. Daytime running lamps: H P 2 4
F o r t h e m a i n t e n a n c e o f t h e f r o n t
h e a d l a m p u n i t a n d t h e c h a n g i n g o f
H P 1 9 , D 1 S a n d H P 2 4 b u l b s , c o n t a c t a C I T R O Ë N d e a l e r .
Risk of electrocution
X e n o n b u l b s m u s t b e r e p l a c e d b y a
C I T R O Ë N d e a l e r .
You are advised to change both
D 1 S b u l b s a t t h e s a m e t i m e , i f o n e
o f t h e m h a s f a i l e d .
T h e h e a d l a m p s a r e fi t t e d w i t h
p o l y c a r b o n a t e g l a s s w i t h a
p r o t e c t i v e c o a t i n g :
do not clean them using a dry
or abrasive cloth, nor with a
detergent or solvent product,
u s e a s p o n g e a n d s o a p y w a t e r ,
w h e n u s i n g a h i g h p r e s s u r e
w a s h e r o n p e r s i s t e n t m a r k s , d o
n o t d i r e c t a t t h e l a m p s o r t h e i r
o u t l i n e s f o r t o o l o n g , s o a s n o t t o
d a m a g e t h e i r p r o t e c t i v e c o a t i n g
a n d s e a l s .
D o n o t t o u c h t h e b u l b d i r e c t l y
w i t h y o u r fi n g e r s , u s e l i n t - f r e e
c l o t h s .
Changing a halogen bulb should
o n l y b e d o n e a f t e r t h e h e a d l a m p
has been switched off for a few
m i n u t e s ( r i s k o f s e r i o u s b u r n s ) .
I t i s i m p e r a t i v e t o u s e o n l y a n t i - u l t r a -
v i o l e t ( U V ) t y p e b u l b s i n o r d e r n o t t o
d a m a g e t h e h e a d l a m p .
Page 190 of 314
XI
171
P R A C T I C A L I N F O R M A T I O N
Main beams
R e m o v e t h e p r o t e c t i v e c a p A .
D i s e n g a g e t h e r e t a i n i n g s p r i n g .
R e m o v e t h e b u l b a n d r e p l a c e i t ,
p a y i n g a t t e n t i o n t o t h e d i r e c t i o n
o f fi t t i n g .
R e fi t t h e r e t a i n i n g s p r i n g .
R e fi t t h e p r o t e c t i v e c a p A .
Model with halogen headlamps
1. Main beams: H1
2. Sidelamps: W 5 W
3. Dipped beams: H7
4. Directional lighting: H7
5. Daytime running lamps: H P 2 4
F o r t h e m a i n t e n a n c e o f t h e f r o n t
h e a d l a m p u n i t a n d c h a n g i n g H P 2 4
b u l b s , c o n t a c t a C I T R O Ë N d e a l e r .
Sidelamps
R e m o v e t h e p r o t e c t i v e c a p A .
P u l l t h e b u l b h o l d e r t o r e m o v e i t .
R e p l a c e t h e b u l b a n d r e fi t t h e
b u l b h o l d e r .
R e fi t t h e p r o t e c t i v e c a p A .
