If you have a physical impairment or condition that prevents you
from sitting properly on the seat with the safety belt properly fastened,
special modifications to your vehicle may be necessary. Contact your
authorized Volkswagen dealer or authorized Volkswagen Service
Facility or call the Volkswagen Customer CARE Center at 1-800-822-
8987 for information about possible modifications to your vehicle.
Safety belt height adjusters

Fig. 69 Next to the front seats: Safety belt height adjuster.

WARNING
Driving with an open luggage compartment lid can cause poi-
sonous carbon monoxide in the engine exhaust to get into the
passenger compartment.
Carbon monoxide causes drowsiness, inattentiveness, poi-
soning, and loss of consciousness. It can lead to accidents and
severe personal injuries.
Always keep the luggage compartment lid closed while driv-
ing to help keep poisonous exhaust fumes from being drawn
into the vehicle.
Never transport objects that are too large to fit completely
into the luggage area, because then the luggage compartment
lid cannot be fully closed.
If you absolutely must drive with an open luggage compart-
ment lid, do the following to reduce the risk of carbon monox-
ide poisoning:
– Close all windows and the power sunroof.
– Switch off the climate control system's air recirculation fea-
ture.
– Open all air vents in the instrument panel.
– Set the fresh air fan to the highest speed.
NOTICE
The open luggage compartment lid changes the vehicle height.
Driving a loaded vehicle

WARNING
Transporting heavy or bulky loads on the roof rack will change
the way the vehicle handles by shifting the vehicle's center of
gravity and increasing the wind drag.
Always secure the load properly with suitable and undam-
aged straps so that the load will not shift.
Cargo that is large, heavy, bulky, long or flat will have a nega-
tive effect on the vehicle's aerodynamics, center of gravity and
overall handling.
Always avoid sudden maneuvers and hard braking.
Always adapt your speed and driving to the heavier load and
the weight distribution in the vehicle. Take road, weather, traf-
fic, and visibility conditions into account as well.
NOTICE
Always remove the roof rack before driving through an auto-
matic car wash.
Your vehicle is higher when the roof rack is installed, especial-
ly when it is loaded. Compare the vehicle height with existing
clearance heights, such as underpasses and garage doors.
Always make sure that the roof rack system and anything be-
ing carried on it does not interfere with the roof antenna, the
power sunroof or the luggage compartment lid.
Make sure that the luggage compartment lid does not touch
items on the roof rack when opened.
If a roof rack is installed, fuel consumption increases due to in-
creased air resistance.

from the center of the hitch ball to the surface of the road ⇒ fig. 109
(D) be less than the specified minimum. This minimum height must be
present even when the vehicle is fully loaded and subject to the max-
imum tongue weight.
Distance dimensions ⇒ fig. 109:
(A) Attachment points.
(B) 46 inches (1170 mm)
(C) at least 3 inches (79 mm)
(D) 14–16 inches (350 – 420 mm)
(E) 10 inches (251 mm)
(F) 21 inches (546 mm)
(G) 41 inches (1031 mm)
(H) 41 inches (1036 mm)
WARNING
Improper or incorrect connections to the vehicle electrical sys-
tem can cause malfunctions that affect the entire vehicle elec-
trical system and cause accidents and serious personal injury.
Never connect the electrical system of the trailer directly to
the electrical connections of the rear lights or other unsuitable
power sources. Use only a suitable connector to provide power
to the trailer.
Have any trailer hitch retrofit or other work on a trailer hitch
done by a qualified workshop.
WARNING
An improperly installed or unsuitable trailer hitch can cause the
trailer to separate from the towing vehicle and result in a major
accident with serious personal injuries.
Maximum permissible trailer weight

Tire labeling
(example)
Meaning
Brand, Logo Manufacturer
Tire name Individual tire designation of the manufac-
turer.
P255 / 55 R 18
Dimensions:
P Tire application: Passenger car
255 Nominal sidewall-to-sidewall width of
tire in millimeters.
55 Ratio of height to width (aspect ratio)
R Tire belt design letter code for radial.
18 Rim diameter (in inches)
109 H Load rating code and speed rating code
XL Indicates “reinforced” tire (heavy-duty)
M+S or M/S Indicates Mud and Snow capability (also
M/S) ⇒  Winter tires.
RADIAL TUBELESS Tubeless radial tire.
E4 ... Labeling according to international regula-
tions (E) including number of the approving
country. The multi-digit approval number is
listed next.
DOT BT RA TY5 1709
Tire identification number (TIN)3 – In some
cases the manufacturing date is only on one
side of the tire:
3 TIN represents the serial number of the tire.

Accessory weight
The combined weight (in excess of those standard items which may
be replaced) of automatic transmission, electro-mechanical power
steering, power brakes, power windows, power seats, radio, and
heater, to the extent that these items are available as factory-installed
equipment (whether installed or not).
Aspect ratio
The ratio of sidewall height to tire width, expressed as a percentage.
A number of 70 (0.7:1 or 70%) or lower indicates a low-profile tire with
a shorter sidewall for improved steering response and better overall
handling on dry pavement.
Bead
The part of a tire made of steel wires, wrapped or reinforced by ply
cords, with the shape and structure to ensure proper fit to the wheel
rim.
Bead separation
A breakdown of the bond between components in the bead.
Carcass
The tire structure, except tread and sidewall rubber which, when in-
flated, bears the load.
Chunking
The breaking away of pieces of the tread or sidewall.
Cord
The strands of material forming the plies in the tire.
Cord separation
The parting of cords from adjacent rubber compounds.
Cracking
Any parting within the tread, sidewall, or inner liner of the tire extend-
ing to cord material.
Cold tire inflation pressure
The tire pressure recommended by the vehicle manufacturer for a tire
of a specified size that has not been driven for more than a couple of

Heat buildup in the passenger and luggage compartment of a
parked vehicle can result in temperatures in the vehicle that are
much higher than the outside temperatures, particularly in
summer. Temperatures can quickly reach levels that can cause
unconsciousness and death, particularly to small children.
NOTICE
Always be careful when you park in areas with parking barri-
ers or high curbs. These vary in height and could damage your
bumper and related parts if the front of your vehicle hits a barrier
or curb that is too high while you are getting into or out of a
parking spot. To help prevent damage, stop before the tires of
your vehicle touch a parking barrier or curb.
Always be careful when you enter a driveway or drive up or
down steep ramps or over curbs or other obstacles. Parts of the
vehicle close to the ground may be damaged (such as bumper
covers, spoilers, and parts of the engine, suspension, and ex-
haust systems).
Warning and indicator lights

Facing downhill, turn the front wheels so that they point toward the
curb.
Facing uphill, turn the front wheels so that they point away from the
curb.
WARNING
The vehicle exhaust system and the catalytic converter get very
hot. They can cause fires and serious personal injury.
Never park where the hot exhaust system could ignite flam-
mable materials, such as brush, leaves, dry grass, spilled fuel,
etc.
NOTICE
Always be careful when you park in areas with parking barri-
ers or high curbs. These vary in height and could damage your
bumper and related parts if the front of your vehicle hits a barrier
or curb that is too high while you are getting into or out of a
parking spot. To help prevent damage, stop before the tires of
your vehicle touch a parking barrier or curb.
Always be careful when you enter a driveway or drive up or
down steep ramps or over curbs or other obstacles. Parts of the
vehicle close to the ground may be damaged (such as bumper
covers, spoilers, and parts of the engine, suspension, and ex-
haust systems).
About the brakes
