Disconnecting the
iPod
Remove the iPod from this unit.
When removing the iPod from this
unit, the iPod main menu appears
in the iPod display after a few sec-
onds.
Remove the iPod and Bye Bye iPod
is indicated in the display.
When disconnecting, hold part of
the connector and press the lock
while pulling. Pulling out by the
cord may pull the cord out of the
connector.
16
NOTICE
•Switch to the iPod Direct
Control after disconnecting
the iPod.
If the iPod is connected, the
switching may not correctly
operate.

19
• MENU
This calls up the iPod MENU. If you
first press the MULTI SELECTOR up,
play lists are displayed. Each time
you press the MULTI SELECTOR up
the display changes to one level up
from the current level.
If you turn the MULTI SELECTOR
counterclockwise or clockwise or
press to the left or right, the MENU
changes as follows:
PlaylistsArtistsAlbums
Songs
• Category (Sub Menu)
Each MENU has SUB MENUS called
Categories that you can call up. If
you select a MENU and press the
MULTI SELECTOR in the center, you
move to one level lower. Each of the
SUB MENUS has the following lev-
els:
• Playlists =List name =Track title
• Artists =Artists name =Album title
=Track title
• Albums =Album title =Track title
• Songs =Track title
With each SUB MENU, turning the
MULTI SELECTOR or pressing it to
the left or right changes the selected
item.
3PRESET 1 (Random)
If you press this, is indicat-
ed in the display and starts to play
tracks on the iPod being played in
random order. Press again to cancel.
After playback finishes of the track
playing when PRESET 1 was
pressed, random playback begins.
4PRESET 2 (Repeat)
If you press this, is indicated
in the display and starts to repeat
the track being played. Press again
to cancel.
5PRESET 5 (1)
While this is pressed, play of the
track is reversed.
Only this track is reversed. (There is
sound.)
6PRESET 6 (¡)
While this is pressed, play of the
track is fast forwarded.
Only this track is fast forwarded.
(There is sound.)
7TEXT
Text information recorded on the
iPod can be displayed.
Up to 16 characters can be displayed
at once.
Press and display indications change
as follows:
ELAPSED TIME =ALB TITLE (Album
Title) =TR TITLE (Track Title) =ART
NAME (Artist Name)
When 3is displayed, if you press
and hold until you hear a beep, the
display will change to the next page.
A maximum of 2 pages (32 charac-
ters) can be displayed.
8AUDIO CONT
When the AUDIO CONT is held
while the power is in “OFF” posi-
tion, switches to the iPodDirect
Control ON/OFF setting Mode.
When the AUDIO CONT is pressed,
the setting item of the PodDirect
Control ON/OFF setting MENU will
switch in the following order:
DirectContON DirectContOFFThe “iPodDirect Control ON/OFF set-
ting Mode” returns to the “PWR
OFF’ after you leave the button for 6
sec.

22
Listening to a XM
Satellite Radio broad-
cast
1AM•SAT
Switches between the AM mode and
SAT1/2/3 modes. (must have Satellite
Radio receiver and antenna installed
at an additional charge to listen to
Satellite Radio.)
2MULTI SELECTOR
The channel preset in PRESET 1-6
switches each time you press the
MULTI SELECTOR in the center.
• TUNE
Turning the MULTI SELECTOR
clockwise or pressing it to the right
selects the next higher channel.
If you press and hold, you can rapidly
scroll forward through the channels.
While displaying Channel Category
by TYPE UP/DOWN, you can select
the next channel forward within the
currently selected type (Channel
Category) by pressing the MULTI
SELECTOR to the right.
5TEXT
4SCAN
TYPE UP 2MULTI SELECTOR
TUNE UP
TYPE DOWN
TUNE DOWN
3PRESET1-6
1AM·SAT

23
• TUNE
Turn the MULTI SELECTOR counter-
clockwise or press to the left to
select the previous channel.
If you press and hold, you can rapidly
scroll down through the channels.
While displaying Channel Category
by TYPE UP/DOWN, you can select
the previous channel within the cur-
rently selected type (Channel
Category) by pressing the MULTI
SELECTOR to the left.
• TYPE
Press the MULTI SELECTOR up to
see the Channel Category of the
channel that is currently received.
When Channel Category is displayed
(TYPEis indicated), press again to
switch to the next category.
• TYPE
Press the MULTI SELECTOR down
to see Channel Category of channel
that is currently received.
When Channel Category is displayed
(TYPEis indicated), press again to
switch to the previous category.
3PRESET 1-6
Press to recall previously stored
channels (Preset Channels).
Press and hold until you hear a beep,
and the channel you are currently
receiving will be stored as a Preset
Channel.
4SCAN
Press and SCAN of the currently
selected type (Channel Category)
starts. At this time,
SCANis indicat-
ed in the display.
If you press and hold until you hear a
beep, SCAN of preset channels
starts.
Also at this time,
SCANis indicated
in the display.
5TEXT
Press and indication in the display
changes as follows:
CH NAME =TITLE (SONG/PROGRAM
TITLE) =NAME (ARTIST NAME/FEA-
TURE) =CH NUMBER =CH NAME
NOTICE
About the display
Up to a maximum of 16 alphanu-
meric characters can be displayed.
(Some information will not be
fully displayed.)
NOTICE
You can store up to 6 chan-
nels per band.

24
Display the RADIO ID
Each XM tuner is identified with a
unique Radio ID. You will need the
Radio ID when activating XM ser-
vice or when reporting a problem.
How to display RADIO ID
If you select “CH 000”, the ID Code
is displayed.
Select the Channel Number zero
(000) by turning the MULTI
SELECTOR or pressing it to the
left or right.
The RADIO ID is displayed as 8
alphanumeric characters.
(Refer to page 25 to confirm your radio
ID code)
Record your ID Code below
ID CODE ___ ___ ___ ___ ___ ___ ___ ___
NOTICE
• If you select another Channel,
display of the ID Code is can-
celed.
• Channel (000) alternates the
display between "RADIO ID"
and the specific radio ID code.

25
Radio ID
Refer to the corresponding chart to
verify the Radio ID Code before
contacting XM Satellite Radio to
activate your service.
Corresponding chart
ID Display
1
2
3
5
6
8 7
9 4
0E C B
A
D
G F (Not used.)
J
K I (Not used.) HO (Not used.)
L
MR
U Q P
S (Not used.)
T
V
Z X W
ID Display ID
Y Display
N

28
Changing the
Opening Screen
With the main unit switched on
after pressing the Power button,
once the key is turned from the
ACC position to the off position and
back to ACC again, “Scion” is dis-
played as the Opening Screen.
Users can edit the text themselves
to make another Opening Screen,
as an alternate to the default
“Scion” display. Up to a maximum
of 16 characters can be displayed.
The procedure is described below.
1Moving to “Customize Mode”
to Enable Editing
1 With the main unit on, turn the
key from the ACC position to the
off position.
2
On the main unit, press and hold
MUTE button then turn the key to
ACC. The horizontal line in the LCD
display will start flashing.
3 Within 15 sec. after confirming
the horizontal line is flashing, press
and hold the PRESET 1 button
then turn the key to OFF position.
(If 15 sec. elapses before you com-
plete the button presses, “TIME
OUT” will be displayed and the
unit will beep twice. If this occurs,
repeat the procedure from Step 1).
This completes shifting to the cus-
tomize mode.
POWER
MUTE
PRESET3-6PRESET1

29
2Editing the Text
After completing the shift to cus-
tomize mode, a flashing cursor
shows the letter that can be edited by
selecting a letter starting from “A”.
The letter selection method is
described below. The time allowed
for editing is limited to 60 sec.
1 Press the PRESET 3 or 4 buttons
to change the flashing letter by
displaying other letters one by
one. The letters will change con-
tinuously if you press and hold the
PRESET 3 or 4 button.
List of the letters and numbers
that can be selected.
•Upper case letters (A to Z)
•Lower case letters (a to z)
•Numbers 0 to 9, spaces, sym-
bols (!”# and so on)
2 With the character that you want
to select displayed, press the
PRESET 6 button to select it.
After selecting the character, the
cursor moves to the right so you
can edit the next character. After
you select the 16th character, the
entire line starts flashing.
To delete a selected character,
press the PRESET 5 button. After
you delete a character the cursor
shifts left so you can edit the pre-
vious character. If you delete all ofthe text, you can edit from the
first character.
3 After you are finished selecting
the text for the line, press and
hold down the PRESET 6 button.
The selected text string is regis-
tered as the Opening Screen. The
customize mode ends and the
registered text string is displayed
for 6 sec.
3New Message Display
The next time the ACC is switched
on, the text edited by the user will be
displayed.
NOTICE
To prevent the battery from
being discharged, do not
leave the car audio on longer
than necessary when the
engine is not running.
NOTICE
•If the unit leaves the cus-
tomize mode during editing,
repeat procedure
1from
Step 2.
•If the edit is registered with
no new text, the original
Opening Screen, “Scion” ,
will be restored.
