2008 TOYOTA PRIUS bluetooth

TABLE OF CONTENTSIndex
4
PRIUS_U_(L/O_0802)
Using the AUX adapter ...... 268
Using the steering switches ........................... 269
3-4. Using the hands-free system ............................. 272
Hands-free system (for cellular phone) ................. 272
Using the Bluetooth
®
phone ............................... 277
Setting the hands-free system .............................. 291
3-5. Using the interior lights ... 318 Interior lights list ................. 318
3-6. Using the storage features ........................... 322
List of storage features....... 322
3-7. Other interior features ..... 329 Sun visors .......................... 329
Vanity mirror ....................... 330
Clock .................................. 331
Power outlet ....................... 332
Armrest............................... 334
Floor mats .......................... 335
Luggage compartment features ............................ 336
Garage door opener ........... 339 4-1. Maintenance and care ...... 346
Cleaning and protecting the vehicle’s exterior ............... 346
Cleaning and protecting the vehicle’s interior ................ 348
4-2. Maintenance ...................... 351 Maintenance requirements .................... 351
General maintenance ......... 353
Emission inspection and maintenance (I/M)
programs .......................... 356
4-3. Do-it-yourself maintenance ................... 357
Do-it-yourself service precautions ....................... 357
Hood ................................... 361
Positioning a floor jack........ 362
Engine compartment .......... 364
Tires.................................... 379
Tire inflation pressure ......... 388
Wheels................................ 392
Air conditioning filter ........... 394
Key battery ......................... 396
Checking and replacing fuses ................................. 398
Light bulbs .......................... 407
4Maintenance and care

Interior features3
185
PRIUS_U_(L/O_0802)
3-3. Using the audio system. 219Audio system type (Vehicle with AUX adapter).......... 219
Audio system type (Vehicle without AUX adapter)..... 222
Using the radio (vehicle with AUX adapter).......... 225
Using the radio (Vehicle without AUX adapter)..... 234
Using the CD player (Vehicle with AUX
adapter) ......................... 239
Using the CD player (Vehicle without AUX
adapter) ......................... 247
Playing MP3 and WMA discs............................... 254
Optimal use of the audio (Vehicle with AUX
adapter) ......................... 262
Optimal use of the audio system (Vehicle without
AUX adapter) ................. 266
Using the AUX adapter .... 268
Using the steering switches ......................... 269 3-4. Using the hands-free
system .......................... 272
Hands-free system (for cellular phone) ............... 272
Using the Bluetooth
®
phone ............................. 277
Setting the hands-free system ........................... 291
3-5. Using the interior lights ............................. 318
Interior lights list ............... 318
3-6. Using the storage features ......................... 322
List of storage features .......................... 322
3-7. Other interior features ......................... 329
Sun visors ........................ 329
Vanity mirror..................... 330
Clock ................................ 331
Power outlet ..................... 332
Armrest ............................ 334
Floor mats ........................ 335
Luggage compartment features .......................... 336
Garage door opener......... 339

194 3-1. Using the touch screen
PRIUS_U_(L/O_0802)
Screen settingsPress .
Touch on the “Information” screen.
The following screen settings can be changed.
Automatic transition
20 seconds after air-conditioning
or audio system use, the system
will return the display to the previ-
ous screen.
Switch color
You can select the switch color.
Personal data deletion
The following personal data is
deleted:
• User selection settings
• Phone book data
• Dialed numbers and receivedcalls
• Speed dial
• Bluetooth
® phone data
• Security code
• Maintenance conditions
*
• Maintenance information “off” setting
*
• Memory points*
• Areas to avoid*
• Previous points*
• Route trace*
*
:If the navigation system is equipped
STEP1
STEP2

272
PRIUS_U_(L/O_0802)
3-4.Using the hands-free system
Hands-free system (for cellular phone)
The hands-free system is a function that allows you to use your
mobile phone without touching it.
This system supports Bluetooth
® mobile phones. Bluetooth® is a
wireless data system that allows th e mobile phone to wirelessly con-
nect to the hands-free syst em and make/receive calls.
Telephone switch
Sending/Receiving/“Tele-
phone” screen display
(when stopped)
End call
Microphone The person you are speaking
to can be heard from the
driver’s side speaker.
To use the hands-free system yo u must register your Bluetooth
®
phone in the system. (P. 277)
12
ITY34P001
ITY34P002

274 3-4. Using the hands-free system
PRIUS_U_(L/O_0802)
■When using the hands-free system
● The audio system and voice guidance are muted when making a call.
● If both parties speak at the same time it may be difficult to hear.
● If the received call volume is overly loud, an echo may be heard.
● Try to face the microphone as much as possible when speaking.
● In the following circumstances it may be difficult to hear the other party.
• When driving on unsealed roads
• When driving at high speeds
• If the window is open
• If the air-conditioning is blowing directly on the microphone
• If the air-conditioning is set to high
■ Conditions under which th e system will not operate
● If using a mobile phone that does not support Bluetooth
®.
● If the mobile phone is switched off.
● If you are outside service range.
● If the mobile phone is not connected.
● If the mobile phone’s battery is low.
■ Bluetooth
® antenna
The antenna is built into the display. If the mobile phone is behind the seat or
in the console box, or touching or covered by metal objects, connection sta-
tus may deteriorate.
■ Battery charge/Signal status
This display may not correspond exactly with the mobile phone itself.

275
3-4. Using the hands-free system
3
Interior features
PRIUS_U_(L/O_0802)
■
About Bluetooth®
■Compatible models
Compatible with HFP (Hands Free Profile) Ver. 1.0 and OPP (Object Push
Profile) Ver. 1.1.
If you cellular phone does not support HFP, you cannot enter the Bluetooth
®
phone. If you cellular phone supports OPP alone, you cannot use the Blue-
tooth® phone.
■ Certification for the hands-free system
This device complies with Part 15 of the FCC Rules and RSS-210. Opera-
tion is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) This device must accept any interference
received, including interference that may cause undesired operation.
Bluetooth is a registered trademark of
Bluetooth SIG. Inc.
FCC ID: BABBT003A
IC ID: 2024B-BT003A

276 3-4. Using the hands-free system
PRIUS_U_(L/O_0802)
FCC WARNING:
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
CAUTION:
Radio Frequency Radiation Exposure
This equipment complies with FCC radiation exposure limits set forth, for
uncontrolled equipment and meets the FCC radio frequency (RF) Exposure
Guidelines in Supplement C to OET65. This equipment has very low levels
of RF energy that it deemed to comply without maximum permissive expo-
sure evaluation (MPE). But it is desirable that it should be installed and oper-
ated with at least 7.9 in (20 cm) and more between the radiator and person’s
body (excluding extremities: hands, wrists, feet and legs).
Co-location:
This transmitter must not be co-located or operated in conjunction with any
other antenna or transmitter.
CAUTION
■Caution while driving
Do not use a cellular phone or connect the Bluetooth
® phone.
NOTICE
■When leaving the vehicle
Do not leave your mobile phone in the vehicle. The inside of the vehicle may
become hot, causing damage to the phone.

277
3-4. Using the hands-free system
3
Interior features
PRIUS_U_(L/O_0802)
Using the Bluetooth® phone
Registering a Bluetooth® phone
You can register up to 6 phones in the system. Press .
Touch on the “Information” screen.
Touch on the “Telephone” screen.
Telephone screen
To display the screen shown above, press , then touch
on the “Information” screen.
ITY34P004
Bluetooth® Connection Status Display Last
Person CalledMake A Call
Character Deletion
STEP1
STEP2
STEP3
