2008 TOYOTA FJ CRUISER spare wheel

5
When trouble arises
337 5−2. Steps to take in an emergency
If the tire pressure warning system is inoperative
The tire pressure warning system may become inoperative in the follow−
ing conditions:
(When the condition be
comes normal, the system will work properly.)
If tires not equipped with tire pressure warning valves and transmit−
ters are used.
If the ID code on the tire pressure warning valves and transmitters is
not registered in the tire pressure warning computer.
If electronic devices or facilities us ing similar radio wave frequencies
are nearby.
If a radio set at similar frequencies is in use in the vehicle.
If a window tint that affects the radio wave signals is installed.
If there is a lot of snow or ice on the vehicle, in particular around the
wheels or wheel housings.
If non−genuine Toyota wheels are used.
If tire chains are used.
If the spare tire is in a location subject to poor radio wave signal
reception.
If the tire inflation pressure is more than 73 psi (500 kPa, 5.1 kgf/cm2
or bar) or higher.
If the tire pressure warning light comes on after blinking for 1
minute frequently
If the tire pressure warning light comes on after blinking for 1 minute fre−
quently when the engine switch is
turned to the ON position, have it
checked by your Toyota dealer.
 After changing the engine oil (U.S.A. only)
Make sure to reset the oil maintenance data. ( P. 278)
 Customization that can be configured at Toyota dealer
The vehicle speed linked seat belt reminder buzzer can be disabled.
(Customizable features
P. 386)

5
When trouble arises
339 5−2. Steps to take in an emergency
CAUTION
TPMS (tire pressure warning system ) malfunction may occur for a vari−
ety of reasons, including the installati
on of replacement or alternate tires
or wheels on the vehicle that prevent the TPMS (tire pressure warning
system) from functioning properly. Always check the TPMS (tire pres−
sure warning system) malfunction te
lltale after replacing one or more
tires or wheels on your vehicle to ensure that the replacement or alter−
nate tires and wheels allow the TPMS (tire pressure warning system) to
continue to function properly.
If the tire pressure warning light comes on
Be sure to observe the following precautions. Failure to do so could
cause loss of vehicle control and result in death or serious injury.
Stop your vehicle in a safe place as
soon as possible. Adjust the tire
inflation pressure immediately.
If the tire pressure warning light comes on even after tire inflation pres−
sure adjustment, it is probable that you have a flat tire. Check the tires.
If the tire is flat, change to the spare tire and have the flat tire repaired
by the nearest Toyota dealer.
Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate,
you could lose control of the steering wheel or the brakes.
If a blowout or sudden air leakage should occur
The tire pressure warning system may not activate immediately.
NOTICE
Precaution when installing a different tire
When a tire of a different specification or maker is installed, the tire pres−
sure warning system may
not operate properly.

5
When trouble arises
341 5−2. Steps to take in an emergency
Taking out the jack and tool bag
Remove the cover and loosen
the strap.
Tighten
Loosen
Taking out the spare tire
Vehicles with an aluminum
wheel, remove the wheel orna−
ment.
To protect the wheel and wheel
ornament, place a rag between
the wrench and the wheel orna−
ment, as shown in the illustra−
tion.

370 6−1. Specifications
Tires and wheels
Tire size P265/75R16 114T, P265/70R17 113S
Tire inflation pressure
(Recommended cold tire
inflation pressure)Front tires:
32 psi (220 kPa, 2.2 kgf/cm
2 or bar)
Rear tires:
32 psi (220 kPa, 2.2 kgf/cm
2 or bar)
Spare tire:
32 psi (220 kPa, 2.2 kgf/cm
2 or bar)
Wheel size 16 7 J, 17
7 1/2 J
Wheel nut torque 85 ft⋅lbf (113 N⋅m, 11.5 kgf⋅m)

399
Alphabetical index
Seat belts
Adjustment ............................. 51
ALR ........................................ 53
Automatic Locking Retractor .. 53
Child restraint system
installation ............................ 93
Cleaning and maintaining ..... 261
ELR ........................................ 53
Emergency Locking
Retractor .............................. 53
How to wear your seat belt ..... 51
How your child should wear
the seat belt ......................... 53
Pregnant women, proper
seat belt use......................... 53
Reminder buzzer .................. 334
Reminder light ...................... 334
Seat belt extenders ................ 54
Seat belt pretensioners .......... 52
Seating capacity ...................... 168
Seats
Adjustment ............................. 43
Adjustment precautions .......... 43
Child seats/child restraint
system installation................ 93
Cleaning ....................... 258, 260
Folding down the rear seat ..... 44
Folding down the rear seat
precautions .......................... 48
Front seat adjustment............. 43
Front seat adjustment
precautions .......................... 43
Head restraint ......................... 49
Properly sitting in the seat ...... 71
Service reminder
indicators .............................. 128
Shift lever
Automatic transmission ........ 117
Four−wheel drive................... 144
Front−wheel drive.................. 146
If the shift lever cannot be
shifted from P ..................... 351
Manual transmission ............ 119Shift lock system ..................... 351
Side airbags................................ 73
Side doors .................................. 33
Side marker lights
Replacing light bulbs ..... 317, 318
Switch.................................... 131
Wattage ................................. 371
Side mirror
Adjusting and folding ............... 59
Spare tire
Inflation pressure................... 370
Replacing .............................. 340
Spare tire............................... 340
Spark plug ................................ 366
Specifications........................... 362
Speedometer ............................ 124
SRS airbags
Curtain shield airbags ............. 73
Front airbags ........................... 73
Precautions ............................. 80
Side airbags ............................ 73
Steering wheel
Adjustment .............................. 57
Stop lights
Replacing light bulbs ............. 318
Wattage ................................. 371
Storage feature......................... 228
Storage precautions ................ 165
Stuck
If the vehicle becomes
stuck ................................... 359
Sun visors
Front ...................................... 235
Side ....................................... 235
Switch
Active traction control
switch .................................. 148
AUTO LSD switch ................. 150
Clutch start cancel switch...... 155
Cruise control switch ............. 136
Engine switch ........................ 114
Ignition switch........................ 114
S
