2008 TOYOTA FJ CRUISER rear view mirror

169
2−5. Driving information
2
When driving
Winter driving tips
Carry out the necessary preparations and inspections before driving
the vehicle in winter. Always drive the vehicle in a manner appropri
ate to the prevailing weather conditions.
 Prewinter preparations
 Use fluids that are appropriate to the prevailing outside tem−
peratures.
Engine oil
Engine coolant
Washer fluid
 Have a service technician inspect the level and specific grav−
ity of battery electrolyte.
Have the vehicle fitted with four snow tires or purchase a set
of tire chains for the rear tires.
Ensure that all tires are the same size and brand, and that chains
match the size of the tires.
 Before driving the vehicle
Perform the following according to the driving conditions.

Do not try to forcibly open a window, scrape an outside rear
view mirror surface or move a wiper or outside rear view mir−
ror that is frozen. Pour warm water over the frozen area to
melt the ice. Wipe away the water immediately to prevent it
from freezing.
To ensure proper operation of th e climate control system fan,
remove any snow that has accumulated on the air inlet vents
in front of the windshield.
Remove any ice that has accumulated on the vehicle chassis.

Periodically check for and remo ve any excess ice or snow
that may have accumulated in the wheel well or on the
brakes.

175
2−5. Driving information
2
When driving
 Before towing
Check that the following conditions are met:

Ensure that your vehicle’s tires are properly inflated. ( P. 370)
 Trailer tires should be inflated according to the trailer manufacturer ’s rec−
ommendation.
All trailer lights work to be legal.
Confirm all lights work each time you connect them.
The trailer ball is set up at the proper height for the coupler on the trailer.
Check that your vehicle remains level when a loaded or unloaded trailer
is hitched. Do not drive if the vehicle is not level, and check for improper
tongue load, overloading, worn suspension, or other possible causes.
 Make sure the trailer cargo is securely loaded.
Check that your rear view mirrors conform to any federal, state/provincial
or local regulations. If they do not, in
stall rear view mirrors appropriate for
towing purposes.
Breakin schedule
Toyota recommends that you do not use a new vehicle or a vehicle with
any new power train components (engine, transmission, differential,
wheel bearings, etc.) to tow a trailer for the first 500 miles (800 km) of
driving.
 Maintenance
 If you tow a trailer, your vehicle will require more frequent maintenance
due to the additional load. (See “Scheduled Maintenance Guide” or
“Owner ’s Manual Supplement”.)
 Retighten the fixing bolts of the towing ball and bracket after approxi−
mately 600 miles (1000 km).

312 4−3. Do−it−yourself maintenance
7 ECU−IG 10 AAnti−lock brake system, vehicle sta−
bility control system, traction con−
trol system, active traction control
system, AUTO LSD system, multi−
port fuel injection system/sequen−
tial multiport fuel injection system,
cruise control system, back door
lock system, shift lock system, mul−
tiplex communication system
8 IG1 15 ATurn signal lights, air conditioning
system, charging system, clutch
start cancel switch, anti−lock brake
system, traction control system,
active traction control system, vehi−
cle stability control system, AUTO
LSD system, back−up lights, intui−
tive parking assist, rear differential
lock system, power outlet, acces−
sory meter, meter and gauge
9 STA 7.5 AStarting system, clutch start cancel
switch, power outlet
10 TAIL 10 ATail lights, license plate lights, park−
ing lights, instrument panel light
control, illuminations
11 A C C 7 . 5 AShift lock system, outside rear view
mirrors, audio system, power out−
let, clock, accessory meter, multi−
plex communication system
12 POWER 30 A Power windows
FuseAmpereCircuit

319
4−3. Do−it−yourself maintenance
4
Maintenance and care
 License plate lights
Remove the screws and cover.
Remove the light bulb.
 Lights other than the above
If any of the lights listed below has burnt out, have it replaced by
your Toyota dealer.
Outside rear view mirror illumination lights
High mounted stoplight

371
6−1. Specifications
6
Vehicle specifications
Light bulbs
A: HB2 halogen bulbs
B: Single end bulbs
C: Wedge base bulbs (clear)
D: Wedge base bulbs (amber)
E: Double end bulbs
Light BulbsBulb No.WTy p e
ExteriorHeadlights — 60/55 A
Front turn signal/
parking and front side
marker lights— 21/5 B
Outside rear view
mirror illumination
lights—5 C
Rear turn signal lights 5674 21 D
Stop/tail and rear side
marker lights7443 21/5 C
Back−up lights 921 18 C
License plate lights — 5 C
Interior
Front interior light 8 E
Rear interior light 8 E

397
Alphabetical index
Fuel door .................................... 64
Fuel filler door ........................... 64
Fuel pump shut off system .... 328
Fuses
Fuses.................................... 303
Locations ...................... 307, 311
Gas station information .......... 408
Gauges ..................................... 124
Glass hatch ................................ 41
Glove box ................................. 228
Head restraints
Adjusting ................................ 49
Headlights
Replacing light bulbs ............ 315
Switch ................................... 131
Wattage ................................ 371
Hood ......................................... 273
Hooks
Cargo net.............................. 250
Shopping bag ....................... 251
I/M test ...................................... 268
Identification
Engine .................................. 363
Tire ....................................... 376
Vehicle.................................. 363
Ignition switch ......................... 114
Illuminated entry system ........ 226
Immobilizer system ................... 68
Indicator lights ........................ 127
Initialization
Items to initialize ................... 388
Inside rear view mirror.............. 58
Interior lights
Switch ................................... 227
Wattage ................................ 371
Instrument panel light
control.................................... 125
Intuitive parking assist ........... 139Jack
Positioning the jack ............... 342
Replacing the wheel .............. 340
Jack handle .............................. 342
Keyless entry.............................. 30
Keys
Engine switch ........................ 114
If you lose your keys ............. 352
Ignition switch........................ 114
Key battery ............................ 301
Keyless entry........................... 30
Key number ............................. 28
Keys ........................................ 28
Reminder buzzer ................... 336
Wireless remote control
key .................................. 28, 30
License plate lights
Replacing light bulbs ............. 319
Switch.................................... 131
Wattage ................................. 371
Light bulbs
Replacing .............................. 314
Wattage ................................. 371
Lights
Automatic light off system ..... 132
Headlights switch .................. 131
Instrument panel light control
dial ...................................... 125
Interior light switch ................ 227
Replacing light bulbs ............. 314
Turn signal lights switch ........ 121
Wattage ................................. 371
Limited slip differential............ 150
Load capacity ........... 165, 168, 362
Lock steering column ................ 57
Luggage storage box............... 248
Luggage compartment
features................................... 249
G
H
I
J
K
L

398
Alphabetical index
Maintenance
Do−it−yourself maintenance ... 269
General maintenance ............ 265
Maintenance data.................. 362
Maintenance requirements.... 263
Vehicle exterior ..................... 258
Vehicle interior ...................... 260
Malfunction indicator lamp ..... 332
Manual air conditioning
system .................................... 184
Manual transmission ............... 119
Meter
Accessory meter ................... 130
Instrument panel light
control ................................. 125
Meters ................................... 124
Mirrors
Inside rear view mirror............. 58
Side mirrors ............................. 59
Vanity mirrors ........................ 236
MP3 disc ................................... 208
Odometer .................................. 124
Offroad precautions
Driving ................................... 162
Vehicle .................................. 160
Oil
Engine oil .............................. 275
Warning light .................. 332,334
Opener
Hood...................................... 273
Outside rear view mirror
illumination lights
Replacing light bulbs ............. 319
Switch.................................... 131
Wattage ................................. 371
Outside rear view mirrors
Adjusting and folding ............... 59
Outside temperature
display .................................... 238
Overheating, Engine ................ 356Parking assist .......................... 139
Parking brake ........................... 122
Parking lights
Replacing light bulbs ............. 317
Switch ................................... 131
Wattage................................. 371
Power outlet ..................... 239, 240
Power steering
Fluid ...................................... 282
Power windows .......................... 62
Radiator ............................ 274, 280
Radio ......................................... 194
Rear seat
Folding down........................... 44
Removing rear seat bottom
cushions ............................... 45
Rear side marker lights
Replacing light bulbs ............. 318
Switch ................................... 131
Wattage................................. 371
Rear turn signal lights
Lever ..................................... 121
Replacing light bulbs ............. 318
Switch ................................... 121
Wattage................................. 371
Rear window............................... 41
Rear window defogger ............ 190
Replacing
Key battery ............................ 301
Fuses .................................... 303
Light bulbs............................. 314
Tires ............................... 287,340
Wheels .................................. 296
Rear differential lock
system .................................... 152
Rear step bumper ...................... 40
Rear window wiper .................. 135
Reporting safety defects for
U.S. owners ............................ 390
M
O
P
R
