2008 Peugeot 206 SW key
[x] Cancel search: keyPage 64 of 127
119
SPECIAL FEATURES
-
Emergency cut-off
(if the remote control is not
working)
U n l o c k t h e d o o r s w i t h t h e k e y .
Open the door.
The alarm is triggered.
- Turn on the ignition.
- The locking system recognises
the key.
- The siren stops and the alarm is disarmed. Selection of the type of
protection
To set the alarm to external
protection only.
I f y o u w a n t t o l e a v e a w i n d o w p a r t i a l
-
l y o p e n , o r a p e t i n s i d e t h e v e h i c l e ,
you need to select external protec-
tion only:
- S w i t c h o f f t h e i g n i t i o n .
- W i t h i n t h e n e x t t e n s e c o n d s , press the internal protection but-
ton 1 u n t i l t h e w a r n i n g l i g h t c o m e s
on continuously.
- Get out of the vehicle.
- Deadlock the vehicle.
- The doors lock.
- The direction indicators light for t w o s e c o n d s .
-
T h e r e d l i g h t o n t h e s w i t c h l a s h e s
once a second.
To de-activate external protection
only
Press the unlocking button on the
remote control.
The doors unlock.
T h e d i r e c t i o n i n d i c a t o r s l a s h f o r
t w o s e c o n d s .
T h e r e d l i g h t o n t h e s w i t c h g o e s o u t . To lock the vehicle without setting
the alarm
I t i s t h e r e m o t e c o n t r o l w h i c h s e t s t h e
alarm.
T h e r e f o r e , t o l o c k t h e v e h i c l e w i t h o u t
setting the alarm: use the key.
To recharge or replace the
battery:
- Turn on the ignition.
- You have 10 seconds after turn-
ing on the ignition to press the
i n t e r n a l p r o t e c t i o n s w i t c h 1 and
h o l d i t d o w n f o r t w o s e c o n d s .
- T h e w a r n i n g l i g h t l a s h e s r a p i d l y for three seconds.
-
Y o u c a n n o w d i s c o n n e c t t h e b a t t e r y .
After reconnecting the battery:
Page 66 of 127
ACCESS
60 -
CHILD SAFETY LOCK
On each rear door this prevents
opening of the door from the inside.
T u r n s w i t c h 1 an eighth turn (45 de-
grees) using the ignition key.
Automatic central locking of the
doors
The doors can lock automatically
w h e n y o u a r e d r i v i n g ( a t a s p e e d o f
more than 6 mph (10 km/h)).
A b o v e 6 m p h ( 1 0 k m / h ) , p r e s s b u t
-
ton B b r i e l y t o u n l o c k t h e d o o r s t e m -
porarily.
You can activate or deactivate this
function. To switch off
Press and hold button
B.
Notes: i f o n e o f t h e d o o r s i s o p e n ,
locking from the inside and automatic
central locking are not possible.
I f t h e b o o t i s o p e n , a u t o m a t i c c e n t r a l
locking of the doors is possible.
To switch on
Press and hold button
B.
Activation of the function is accom-
panied by an audible signal and a
message on the multifunction display.The message is displayed each time
the vehicle is started.
Page 68 of 127
ACCESS
62 -
OPENING THE BONNET
Inside the vehicle: pull the handle on
t h e l e f t - h a n d s i d e , u n d e r t h e f a s c i a .
Outside the vehicle: lift the catch
and raise the bonnet.
BONNET STRUTSecure the strut to hold the bonnet
open.
B e f o r e c l o s i n g t h e b o n n e t , r e p l a c e
the strut in its housing.
FILLING THE FUEL TANK
T h e t a n k m u s t b e i l l e d w i t h f u e l w i t h
the engine switched off .
Insert the key then turn it to the left.
Remove the cap.
A l a b e l i n d i c a t e s w h i c h t y p e o f f u e l t o
use.
I f y o u i l l y o u r t a n k , d o n o t c o n t i n u e
after the third cut-off of the pump
nozzle. This could result in vehicle
malfunctions.
The capacity of the tank is approxi-
mately 50 litres.
To close
L o w e r t h e b o n n e t a n d r e l e a s e i t a t
the end of its travel.
Check that the bonnet is locked.
Page 70 of 127
VISIBILITY
64 -
"Follow me home" lighting
W h e n y o u l e a v e y o u r v e h i c l e , t h e
side lights and dipped headlamps
can be left on for approximately
30 seconds.
To do this:
- place the key in the STOP
p o s i t i o n ,
- place the lights stalk in the 0 p o s i t i o n ,
- l a s h t h e h e a d l a m p s ,
- get out of the vehicle and lock it.AUTOMATIC SWITCHING ON
OF LIGHTS
The side lights and dipped beam
h e a d l a m p s s w i t c h o n a u t o m a t i c a l -
l y i f t h e l i g h t i s p o o r a n d w h e n t h e
w i n d s c r e e n w i p e r s o p e r a t e c o n t i n u -
o u s l y a n d s w i t c h o f f w h e n t h e l i g h t
b e c o m e s b r i g h t e n o u g h o r t h e w i n d -
s c r e e n w i p e r s a r e s w i t c h e d o f f .
In foggy weather or in snow, the
brightness sensor can detect suf-
i c i e n t l i g h t , t h e l i g h t s w i l l n o t
come on automatically. If neces-
sary, the dipped headlamps must
be switched on manually.
T h i s f u n c t i o n i s a c t i v e w h e n t h e v e -
hicle is supplied to the customer.
To disarm or activate the function:
- Place the key in the accessories p o s i t i o n ( 1 s t n o t c h ) ,
- Place the lights stalk in the AUTO/0 p o s i t i o n ,
- Press the end of the lights stalk for more than four seconds.
Do not cover the brightness sen-
sor, coupled with the rain sensor,
located in the centre of the wind-
screen, behind the interior mirror.
It is used for automatic switching
on of the lights. Operating check
I n g o o d o r r a i n y w e a t h e r ,
b o t h d a y a n d n i g h t , t h e
front fog lamps and the
rear fog lamp are dazzling
and are prohibited.
D o n o t f o r g e t t o s w i t c h t h e m o f f
w h e n t h e y a r e n o l o n g e r n e e d e d .
Direction indicators
( l a s h e r s ) Left: d o w n w a r d s .
Right: u p w a r d s . Disarming
The disarmed function is accompa-
nied by an audible signal.
When the driver uses the manual
l i g h t i n g c o n t r o l s , t h e f u n c t i o n i s t e m
-
porarily disarmed.
If the brightness sensor does not
function correctly, the lights come
on accompanied by an audible signal
and a message on the multifunction
display.
Consult a PEUGEOT dealer.
Activation
The activated function is accompa-
nied by an audible signal and a mes-
sage on the multifunction display.
Page 71 of 127
VISIBILITY
64 -
"Follow me home" lighting
W h e n y o u l e a v e y o u r v e h i c l e , t h e
side lights and dipped headlamps
can be left on for approximately
30 seconds.
To do this:
- place the key in the STOP
p o s i t i o n ,
- place the lights stalk in the 0 p o s i t i o n ,
- l a s h t h e h e a d l a m p s ,
- get out of the vehicle and lock it.AUTOMATIC SWITCHING ON
OF LIGHTS
The side lights and dipped beam
h e a d l a m p s s w i t c h o n a u t o m a t i c a l -
l y i f t h e l i g h t i s p o o r a n d w h e n t h e
w i n d s c r e e n w i p e r s o p e r a t e c o n t i n u -
o u s l y a n d s w i t c h o f f w h e n t h e l i g h t
b e c o m e s b r i g h t e n o u g h o r t h e w i n d -
s c r e e n w i p e r s a r e s w i t c h e d o f f .
In foggy weather or in snow, the
brightness sensor can detect suf-
i c i e n t l i g h t , t h e l i g h t s w i l l n o t
come on automatically. If neces-
sary, the dipped headlamps must
be switched on manually.
T h i s f u n c t i o n i s a c t i v e w h e n t h e v e -
hicle is supplied to the customer.
To disarm or activate the function:
- Place the key in the accessories p o s i t i o n ( 1 s t n o t c h ) ,
- Place the lights stalk in the AUTO/0 p o s i t i o n ,
- Press the end of the lights stalk for more than four seconds.
Do not cover the brightness sen-
sor, coupled with the rain sensor,
located in the centre of the wind-
screen, behind the interior mirror.
It is used for automatic switching
on of the lights. Operating check
I n g o o d o r r a i n y w e a t h e r ,
b o t h d a y a n d n i g h t , t h e
front fog lamps and the
rear fog lamp are dazzling
and are prohibited.
D o n o t f o r g e t t o s w i t c h t h e m o f f
w h e n t h e y a r e n o l o n g e r n e e d e d .
Direction indicators
( l a s h e r s ) Left: d o w n w a r d s .
Right: u p w a r d s . Disarming
The disarmed function is accompa-
nied by an audible signal.
When the driver uses the manual
l i g h t i n g c o n t r o l s , t h e f u n c t i o n i s t e m
-
porarily disarmed.
If the brightness sensor does not
function correctly, the lights come
on accompanied by an audible signal
and a message on the multifunction
display.
Consult a PEUGEOT dealer.
Activation
The activated function is accompa-
nied by an audible signal and a mes-
sage on the multifunction display.
Page 78 of 127
71
LAYOUT
-
COURTESY LIGHTS
Map-reading light (button B)
With the key in the accessories or
i g n i t i o n o n p o s i t i o n , t u r n b u t t o n B to
the left or to the right.
AREAS FOR TOLL CARDS/
CAR PARK TICKETS
T h e a t h e r m i c w i n d s c r e e n h a s t w o
n o n - r e l e c t i v e z o n e s l o c a t e d e i t h e r
side of the base of the interior mirror.
T h e y a r e i n t e n d e d f o r a f i x i n g t o l l
cards and/or car park tickets.
SUN VISOR
T h e s u n v i s o r s a r e i t t e d w i t h a v a n i t y
m i r r o r , w i t h a c o n c e a l i n g l a p o n t h e
driver’s side.
Permanently off
P e r m a n e n t l y o n w h e n t h e
key is in the accessories po-
s i t i o n o r w i t h t h e i g n i t i o n o n .
Front courtesy light (button A)
I n t h i s p o s i t i o n , i t c o m e s o n
for about 30 seconds:
- o n u n l o c k i n g t h e v e h i c l e ,
- w h e n o p e n i n g a d o o r ,
- w h e n o p e n i n g t h e t a i l g a t e a n d t h e r e a r s c r e e n ( 2 0 6 S W ) ,
- o n s w i t c h i n g o f f t h e i g n i t i o n .
I t s w i t c h e s o f f o n l o c k i n g t h e v e h i c l e . T h e c o u r t e s y l i g h t l a s h e s w h i l e d r i v i n g i f
a door or the boot is not closed correctly.
Page 79 of 127
LAYOUT
72 -
GLOVE BOX
T o o p e n t h e g l o v e b o x , l i f t t h e h a n d l e .
T h e l i g h t c o m e s o n w h e n t h e c o v e r
is opened.
1. Handbook pack storage.
2. Can holder.
3. Pen holder.
4. Spectacles storage.
5. Map storage.
6. Coin storage.
FRONT ASHTRAY
T o e m p t y , c l o s e t h e c o v e r .
Pull the lug and release the ashtray
u p w a r d s .
LIGHTER
P r e s s a n d w a i t a f e w m o m e n t s u n t i l i t
springs out automatically.
I t i s s u p p l i e d w i t h p o w e r w i t h t h e i g n i -
tion key in the accessories position
(1st notch).
Page 81 of 127
DRIVING
74 -
'PORSCHE TIPTRONIC
SYSTEM' AUTOMATIC
GEARBOX
The four speed automatic gearbox
o f f e r s a c h o i c e b e t w e e n t h e c o m f o r t
of integral automatic operation ,
enhanced by a sport and a snow pro-
g r a m m e , o r manual gear changing .
Gear selection gate
F Move the lever in the gate to
select a position.
The indicator light corresponding to the position selected appears
on the instrument panel screen.
P ark: to immobilise the vehicle and
to start the engine , w i t h t h e h a n d-
brake on or off.
R everse: to reverse (select this
p o s i t i o n w i t h t h e v e h i c l e s t a t i o n a r y ,
engine at idle).
N eutral: to start the engine and to
park , w i t h t h e h a n d b r a k e o n .
If position N is inadvertently engaged
w h i l e d r i v i n g , a l l o w t h e e n g i n e t o r e -
turn to idle before engaging position D
to accelerate.
D rive: for driving in automatic mode.
Manual: for selection of gears.
S : sport programme.
T : s n o w p r o g r a m m e . Moving Off
W i t h t h e e n g i n e r u n n i n g , t o m o v e o f f
from position
P:
F it is essential to press the
brake pedal to exit position P ,
F select position R , D or M , t h e n
gradually release the pressure
o n t h e b r a k e p e d a l ; t h e v e h i c l e
moves off immediately.
You can also move off from position N:
F r e l e a s e t h e h a n d b r a k e , w i t h y o u r
f o o t o n t h e b r a k e ,
F select position R , D or M , t h e n
gradually release the pressure
o n t h e b r a k e p e d a l ; t h e v e h i c l e
moves off immediately.
Starting the engine
F w i t h t h e h a n d b r a k e o n , s e l e c t
position P or N i n t h e g a t e ,
F turn the ignition key to the Start
position. WARNING
W h e n t h e e n g i n e i s a t i d l e , b r a k e s n o t
a p p l i e d , i f p o s i t i o n
R , D or M is se-
l e c t e d , t h e v e h i c l e m o v e s e v e n w i t h -
out the accelerator being pressed.
F o r t h i s r e a s o n , do not leave children
unsupervised inside the vehicle,
with the engine running .
When maintenance operations need
t o b e c a r r i e d o u t w i t h t h e e n g i n e r u n -
n i n g , a p p l y t h e h a n d b r a k e a n d s e l e c t
position P.
