2008 NISSAN ROGUE display

Black plate (50,1)
Model "NISSAN_NAVI" EDITED: 2007/ 2/ 26
The map view can be changed between Plan
View and BirdviewTM. The map can also be
displayed in the split screen mode.
NAV2711
1. Pushwhile the current location
map screen is displayed.
NAV2712
2. Highlight [Map View] and push.
SWITCHING THE MAP VIEW
3-4Map settings

Black plate (51,1)
Model "NISSAN_NAVI" EDITED: 2007/ 2/ 26
NAV2747
3. Highlight the preferred map view and push
. The indicator of the selected
map view illuminates.
4. Push

Black plate (55,1)
Model "NISSAN_NAVI" EDITED: 2007/ 2/ 26
NAI0415
RETURNING TO THE CURRENT VEHI-
CLE LOCATION
Push

Black plate (56,1)
Model "NISSAN_NAVI" EDITED: 2007/ 2/ 26
MAP SCROLLING INFORMATION
Information about the location, on which the
center of the cross pointer is placed by scrolling
on the map, can be set to be displayed.
1. Push.
NAV3055Maxima, Quest, Titan
NAV3029350Z
2. Highlight [Navigation] and push.
NAV2752
3. Highlight [Map Scrolling Information] and
push.
3-10Map settings

Black plate (57,1)
Model "NISSAN_NAVI" EDITED: 2007/ 2/ 26
NAV2753
4. Highlight the preferred information item and
push. The indicator of the
selected information item illuminates.
Available information items:
.Address Book Icons.Destination/Waypoint Icons.Latitude/Longitude Info
NAV2754
5. Push

Black plate (59,1)
Model "NISSAN_NAVI" EDITED: 2007/ 2/ 26
MAP SCALE
The following scales are available depending on
the map view.
.In Plan View:
Widest (1/51,200,000) to the most detailed
(1/5,000)
.In Birdview
TM:
Widest (1/20,480,000) to the most detailed
(viewpoint height at 1/25,000)
Scale level of the Plan View display
Map scale Actual distance
1:51.2 million 400 miles (640 km)
1:5.12 million 32 miles (64 km)
1:1.28 million 8 miles (16 km)
1:320,000 2 miles (4 km)
1:160,000 1 mile (2 km)
1:80,000 1/2 mile (1 km)
1:40,000 1/4 mile (500 m)
1:20,000 1/8 mile (200 m)
1:10,000 1/16 mile (100 m)
1:5,0001/32 mile (50 m)
NAV2755Example: The most detailed level
NAV2756Example: The widest level
Map settings3-13

Black plate (60,1)
Model "NISSAN_NAVI" EDITED: 2007/ 2/ 26
Scale level of the BirdviewTMdisplay
Map scale Distance between grids
1:20.48 million 160 miles (256 km)
1:5.12 million 32 miles (64 km)
1:2.56 million 16 miles (32 km)
1:1.28 million 8 miles (16 km)
1:640,000 4 miles (8 km)
1:320,000 2 miles (4 km)
1:160,000 1 mile (2 km)
1:80,000 1/2 mile (1 km)
1:40,000 1/4 mile (500 m)
1:25,0001/6 mile (250 m)
NAV2757Example: The most detailed level
NAV2758Example: The widest level
3-14Map settings

Black plate (61,1)
Model "NISSAN_NAVI" EDITED: 2007/ 2/ 26
Other settings are also available for the map
screen, such as changing the map direction,
splitting the screen, etc.
SETTINGS OF HEADING/LONG
RANGE MAP VIEW
You can change the map direction (orientation)
in Plan View or change the position of the
vehicle icon to view a wider area in the traveling
direction.
These settings are available only in the Plan
View or Split (Plan View) mode.
NAV4173
1. Pushwhile the current location
map screen is displayed.
NAV4174
2. Highlight [Heading] and push.
OTHER SETTINGS FOR THE MAP
SCREEN
Map settings3-15
