AlternativeHigh Voltage SystemShut Down Procedure
NOTE:
If the service disconnect procedure cannot be performed, the following alternative shut down procedure is
acceptable.
A.Locate the fuse/fusible link box (1) under the hood near the driver
side strut tower (2).
Page 24 of 27
- 24-
Roadside Assistance
Nissan Altima Hybridroadside assistance may be handled like conventionalNissan vehicles, except as noted
in the following pages.
Towing
The AltimaHybrid is a frontwheeldrive vehicle and it must be towed with the front wheels off the ground.
Failure to do somay cause serious damage to the hybridsystemcomponents.
