Contents
Safety and Security........................... 63
Occupant safety................................... 64
Air bags .......................................... 66
Occupant Classification System ..... 71
Seat belts ....................................... 76
Children in the vehicle .................... 79
Panic alarm .......................................... 83
Activating ....................................... 83
Deactivating ................................... 83
Driving safety systems ......................... 84
ABS ................................................ 84
BAS ................................................ 86
ESP
®............................................... 86
Anti-theft systems................................ 90
Immobilizer..................................... 90
Anti-theft alarm system .................. 90
Tow-away alarm ............................. 91
Controls in detail............................... 93
Locking and unlocking ......................... 94
SmartKey ....................................... 94
Opening the doors from the
inside ............................................. 98
Opening the trunk .......................... 99
Closing the trunk.......................... 100
Valet locking ................................ 101
Trunk lid emergency release ........ 102
Automatic central locking ............ 102
Locking and unlocking from the
inside ........................................... 103
Seats ................................................. 104
Seat heating* ............................... 104
Lumbar support*.......................... 105
AIRSCARF neck-level heating* ..... 105
Memory function* ............................. 107
Storing positions into memory ..... 108
Recalling positions from
memory ........................................ 108Lighting ............................................. 109
Exterior lamp switch .................... 109
Combination switch ..................... 113
Corner-illuminating front
fog lamps* ................................... 114
Hazard warning flasher ................ 115
Interior lighting ............................ 116
Door entry lamps ......................... 117
Instrument cluster ............................. 118
Adjusting instrument cluster
illumination .................................. 118
Tachometer.................................. 119
Outside temperature indicator ..... 119
Resetting trip odometer ............... 120
Clock............................................ 120

27 At a glance
Instrument cluster
ItemPage
1Multifunction display
with:
Main odometer127
Trip odometer120,
127
Automatic transmission*:
Gear range indicator160
Automatic transmission*:
Program mode indicator161
Outside temperature
indicator (or digital speed-
ometer when selected)140
Set speed for cruise control249
2Tachometer with:
?Engine malfunction
indicator lamp,
USA only351
±Engine malfunction
indicator lamp,
Canada only351
ItemPage
353
HUSA only:
Combination low tire
pressure/TPMS mal-
function telltale317,
356
AHigh beam
headlamp indicator
lamp55,
113
3Fuel gauge with:
4Fuel reserve warning
lamp355
The arrow indicates that the
fuel filler flap is on the rear
right-hand side.291
4Clock120
5Speedometer with:
1Supplemental
Restraint System
(SRS) indicator lamp64,
355
ItemPage
-Antilock Brake
System (ABS)
indicator lamp84,
348
LLeft turn signal
indicator lamp
KRight turn signal
indicator lamp55
vElectronic Stability
Program (ESP®)
warning lamp
86,
352
;Brake warning lamp,
USA only59,
350
3Brake warning lamp,
Canada only59,
350
6Reset button for:

Resetting trip odometer

Resetting all settings
120
136
7Knobs for instrument
cluster illumination118

120 Controls in detail
Instrument cluster
Resetting trip odometer
Make sure you are viewing the
standard display menu (
page 127).
If it is not displayed, press
buttonèorÿ repeatedly until
the standard display appears in the
multifunction display.
Press and hold reset buttonJ until
the trip odometer is reset.
Clock
Vehicles with COMAND*:
The clock in the instrument cluster can be
synchronized with the time set in
COMAND using the time synchronization
with head unit feature (
page 141), or set
independently from COMAND using the
control system (
page 141) with the time
synchronization with head unit feature set
to
Off.
For setting the time in COMAND, see
separate COMAND operating instructions.
For setting the time with audio system,
(
page 141).

175 Controls in detail
Climate control
Switching climate control system
on/off
Switching off
Set air volume control2 (page 174)
to position0.
Switching on
Switch on the ignition (page 37).
Set air volume control2 to any speed
(
page 174).
The previous settings are once again in
effect.
Setting the temperature
Use temperature controls1 and4
(
page 174) to separately adjust the air
temperature on each side of the passenger
compartment. You should raise or lower
the temperature setting in small incre-
ments, preferably starting at 72°F (22°C).
The climate control will adjust to the set
temperature as fast as possible.
Increasing
Turn temperature control 1
and/or4 (
page 174) slightly
clockwise.
The climate control system will corre-
spondingly adjust the interior air tem-
perature.
Warning!G
Follow the recommended settings for
heating and cooling given on the following
pages. Otherwise the windows could fog up,
impairing visibility and endangering you and
others.
iIf the vehicle interior is hot, ventilate the in-
terior before driving off. The climate control will
then adjust the interior temperature to the set
value much faster.
Keep the air intake grille in front of the wind-
shield free of snow and debris.
When the retractable hardtop is closed, do not
obstruct air flow by placing objects on the air
flow-through exhaust slots below the rear
window.
Warning!G
When the climate control is switched off, the
outside air supply and circulation are also
switched off. Only choose this setting for a
short time. Otherwise the windows could
fog up, impairing visibility and endangering
you and others.

181 Controls in detail
Climate control
Set air volume control2 (page 177)
to position5.
The ventilation operates with maximum
blower speed.
Turn temperature controls1and4
(
page 174) completely counterclock-
wise to their end stops.
The lowest temperature for both sides
is set.
Residual engine heat utilization
With the engine switched off, it is possible
to continue to heat or ventilate the interior
for up to 30 minutes. This feature makes
use of the residual heat produced by the
engine.
Activating
Switch off the ignition (page 37).
Press button9 (page 174).
The indicator lamp on the button
comes on.Deactivating
Press button9 (page 174) again.
The indicator lamp on the button goes
out.
iWhen the vehicle’s interior has cooled down
enough, reduce the air volume and increase the
air temperature to comfortable settings if
desired.
iHow long the system will provide heating
depends on

the coolant temperature

the temperature set by the operator
The blower will run at speed setting1 regardless
of the air distribution control setting.
iThe residual heat is automatically turned off

when the ignition is switched on (page 37)

after about 30 minutes

if the battery voltage drops

291 Operation
At the gas station
At the gas station
Refueling
The fuel filler flap is located on the
right-hand side of the vehicle towards the
rear.
Locking and unlocking the vehicle with the
SmartKey automatically locks and unlocks
the fuel filler flap.1To open fuel filler flap
2To insert fuel filler cap
Remove the SmartKey from the starter
switch.
Open fuel filler flap by pushing at point
indicated by arrow1.
The fuel filler flap springs open.
Turn fuel filler cap counterclockwise
and hold on to it until possible pressure
is released.
Take off fuel filler cap and set it in
direction of arrow2 in the recess on
the inside of fuel filler flap.
To prevent fuel vapors from escaping
into open air, fully insert filler nozzle
unit.
Only fill your tank until the filler nozzle
unit cuts out – do not top off or
overfill.
Replace the fuel filler cap by turning it
clockwise until it audibly engages.
Warning!G
Gasoline is highly flammable and poisonous.
It burns violently and can cause serious
personal injury.
Never allow sparks, flame or smoking mate-
rials near gasoline!
Turn off the engine before refueling.
Whenever you are around gasoline, avoid
inhaling fumes and skin contact, extinguish
all smoking materials.
Direct skin contact with fuels and the
inhalation of fuel vapors are damaging to
your health.
iIn case that the central locking system does
not release the fuel filler flap, or the opening
mechanism is clamping, contact Roadside
Assistance or an authorized Mercedes-Benz
Center.
Warning!G
Overfilling of the fuel tank may create pres-
sure in the system which could cause a gas
discharge. This could cause the gas to spray
back out when removing the fuel pump noz-
zle, which could cause personal injury.


391 Practical hints
Where will I find...?
The vehicle jack is located in the storage
compartment underneath the trunk floor.
Storage position
Remove vehicle jack from its
compartment.
Turn crank handle in the direction of
arrow as far as it will go.
Operational position
Turn crank handle clockwise.
Before storing the vehicle jack in its
compartment:

It should be fully collapsed.

The handle must be folded in (storage
position).Setting up the collapsible wheel chock
The collapsible wheel chock serves to
additionally secure the vehicle, e.g. while
changing the wheel.
1Tilt the plate upward
2Fold the lower plate outward
3Insert the plate

425 Practical hints
Battery
Reconnecting the battery
Turn off all electrical consumers.
Connect the battery positive lead2
(
page 422) and fasten its cover.
Connect the battery negative lead3
(
page 422).
Reinsert water tray 1 (page 423).
Push in locks2 (page 423) and turn
one quarter turn.
!Always connect the battery in the order
described below. Otherwise the vehicle’s
electronics can be damaged.
!Never invert the terminal connections!
iThe following procedures must be carried
out following any interruption of battery power
(e.g. due to reconnection):

Set the clock (page 141).

Synchronize the power windows
(
page 239).
