Contents
Driving abroad .............................. 567
Control and operation of
radio transmitters......................... 567
Catalytic converter ....................... 568
Emission control........................... 568
Coolant temperature .................... 569
At the gas station............................... 570
Refueling ...................................... 570
Check regularly and
before a long trip .......................... 572
Engine compartment.......................... 573
Hood ............................................ 573
Engine oil...................................... 575
Transmission fluid level ................ 578
Active Body Control* (ABC*)
fluid level ...................................... 579
Coolant level ................................ 579
Windshield washer system and
headlamp cleaning system ........... 580
Tires and wheels ................................ 582
Important guidelines .................... 582
Tire care and maintenance ........... 583
Direction of rotation ..................... 585
Loading the vehicle ...................... 585
Recommended tire
inflation pressure ......................... 590Checking tire inflation pressure ... 592
Tire labeling.................................. 598
Load identification ....................... 601
DOT, Tire Identification Number (TIN) ..
602
Maximum tire load ....................... 603
Maximum tire inflation pressure .. 603
Uniform Tire Quality Grading
Standards (U.S. vehicles) ............. 604
Tire ply material ........................... 606
Tire and loading terminology ........ 606
Rotating tires ............................... 609
Winter driving .................................... 610
Winter tires .................................. 610
Snow chains ................................. 611
Maintenance ...................................... 612
Maintenance service
indicator message ........................ 612
Calling up the maintenance
service indicator display............... 613
Resetting the maintenance
service indicator........................... 614
Vehicle care ....................................... 615
Cleaning and care of vehicle ........ 615
Practical hints................................. 627
What to do if …? ................................ 628
Lamps in instrument cluster ........ 628
Air bag off indicator lamp............. 640
Vehicle status messages in the
multifunction display.................... 642
Where will I find ...? ........................... 705
First aid kit ................................... 705
Vehicle jack, vehicle tool kit,
luggage bowl, Minispare wheel .... 705
Unlocking/locking in an emergency .. 708
Unlocking the vehicle................... 708
Locking the vehicle ...................... 709
Resetting activated head restraints ... 710
Head restraints (standard) ........... 710
Luxury head restraints* ............... 711
Replacing SmartKey batteries ........... 712
Replacing bulbs ................................. 714
Bulbs ............................................ 715
Replacing bulbs for front lamps ... 717
Replacing wiper blades ...................... 721
Placing wiper arms in
vertical position ........................... 721
Removing wiper blades ................ 722
Installing wiper blades ................. 722

48 Safety and SecurityOccupant safetyFurthermore, the occupant weight may ap-
pear to increase or decrease due to the fol-
lowing: objects hanging on the seat,
lodged underneath the seat, stuffed be-
tween the seat and middle console or the
seat and door, other passengers pushing
on the seat or objects applying pressure to
the back of the seat.
Both driver and the front passenger should
always use the 59indicator
lamp as an indication of whether or not the
front passenger is properly positioned.i
If your seat, including your trim cover and
cushion needs to be serviced in any way, take
the vehicle to an authorized Mercedes-Benz
Center.
Only seat accessories approved by
Mercedes-Benz may be used.
Warning!
G
If the 59indicator lamp illumi-
nates when an adult or someone larger than
a small individual is in the front passenger
seat, have the front passenger re-position
himself or herself in the seat until the
59indicator lamp goes out, or
check whether objects are caught under or
around the seat.
More information about air bag display mes-
sages (
page 649).
In the event of a collision, the air bag control
unit will not allow front passenger front air
bag deployment when the OCS classified
the front passenger seat occupant as being
up to or less than the weight of a typical
12-month-old child in a standard child re-
straint or if the front passenger seat is
sensed as being empty.
When the OCS senses that the front passen-
ger seat occupant is classified as being up
to or less than the weight of a typical
12-month-old child in a standard child
restraint, the 59indicator
lamp will illuminate when the engine is start-
ed and remain illuminated, indicating that
the front passenger front air bag is deacti-
vated.
When the OCS senses that the front passen-
ger seat is classified as being empty, the
59indicator lamp will illumi-
nate when the engine is started and remain
illuminated, indicating that the front
passenger front air bag is deactivated.
When the OCS senses that the front passen-
ger seat occupant is classified as being
heavier than the weight of a typical
12-month-old child seated in a standard
child restraint or as being a small individual
(such as a young teenager or a small adult),
the 59indicator lamp will illu-
minate for approximately 6 seconds when
the engine is started and then, depending on
occupant weight sensor readings from

83 Safety and Security
Anti-theft systems
1Indicator lamp
Arming: Lock your vehicle with the
SmartKey or KEYLESS-GO*.
The turn signal lamps flash three times
to indicate that the vehicle is locked.
The indicator lamp1 flashes to indi-
cate that the alarm system is armed.

Disarming: Unlock your vehicle with
the SmartKey or KEYLESS-GO*.
The turn signal lamps flash once to in-
dicate that the alarm system is dis-
armed.
Canceling the alarm
To cancel the alarm, do one of the follow-
ing:
Insert the SmartKey or SmartKey with
KEYLESS-GO* in the starter switch.

Press the Œ or ‹ button on the
SmartKey or SmartKey with
KEYLESS-GO*.
In vehicles with KEYLESS-GO*:

Grasp an outside door handle.
The SmartKey with KEYLESS-GO must
be within 3 ft (1 m) of the vehicle.

Press the KEYLESS-GO start/stop but-
ton (
page 372).
The SmartKey with KEYLESS-GO must
be inside the vehicle.
i
If the alarm stays on for more than
30 seconds, a call to the Response Center is ini-
tiated automatically by the Tele Aid system
(
page 542) provided Tele Aid service was sub-
scribed to and properly activated, and that nec-
essary mobile phone, power supply and GPS
coverage are available.
i
If the turn signal lamps does not flash three
times one of the following elements may not be
properly closed:


a door


the trunk
Close the respective element and lock the vehi-
cle again.
i
The alarm system will rearm automatically
again after approximately 40 seconds if no door
was opened.

305 Control systems
Instrument cluster control system
The vehicle status message memory menu
only appears if there are any messages
stored.
Press ( or & to select the
“Service” menu.If conditions have occurred causing
status messages to be recorded, the
number of messages appears in the
multifunction display: “2 messages”.

Press % or $ to select the mes-
sage.

Press # to confirm.
Checking tire inflation pressure
For information about checking tire infla-
tion pressure (
page 593).Calling up the maintenance service in-
dicator display
For information about calling up the main-
tenance service indicator display
(
page 612).
Checking engine oil level (S 600 and
S65AMG)
For information about checking engine oil
level (
page 575).
Settings menu
In the “Settings” menu, you can:

switch the daytime running lamps on or
off (USA only)


switch the additional speedometer on
or off


switch the radar sensors* on or off
(USA only)
Warning!
G
Malfunction and warning messages are only
indicated for certain systems and are inten-
tionally not very detailed. The malfunction
and warning messages are simply a remind-
er with respect to the operation of certain
systems and do not replace the owner’s
and/or driver’s responsibility to maintain
the vehicle’s operating safety by having all
required maintenance and safety checks
performed on the vehicle and by bringing
the vehicle to an authorized Mercedes-Benz
Center to address the malfunction and
warning messages (
page 642).
i
See the “Practical hints” section for mal-
function and warning messages (
page 642).
i
If you turn the SmartKey in the starter
switch to position0 and then back to position2,
all messages will be deleted from the message
memory.
i
The menu overview can be found on
(
page 289).

420 Controls in detailDriving and parkingFor more information, see “Driving instruc-
tions” (
page 559).
Turn signalsCombination switch1Turn signals, right
2Turn signals, left
Press the combination switch in the
direction of arrow1 or2.
The corresponding turn signal indicator
lampL orK in the instrument
cluster flashes (
page 28).
The combination switch resets automati-
cally after major steering wheel move-
ments.
Problems while driving
The engine runs erratically and misfires

An ignition cable may be damaged.


The engine electronics may not be op-
erating properly.


Unburned gasoline may have entered
the catalytic converter and damaged it.

Give very little gas.

Have the problem repaired by an au-
thorized Mercedes-Benz Center as
soon as possible.
!
Shift the automatic transmission to park
positionP or reverse gearR only when the vehi-
cle is stopped in order to avoid damaging the
transmission.
!
Do not run cold engine at high engine
speeds. Running a cold engine at high engine
speeds may shorten the service life of the en-
gine. This is not covered by the Mercedes-Benz
Limited Warranty.
S63AMG and S65AMG only:
At engine temperatures below 68°F (20° C), the
maximum speed is restricted in order to protect
the engine. Avoid driving the vehicle at full speed
while the engine is cold in order to prevent pre-
mature engine wear as well as diminished com-
fort.
!
Simultaneously depressing the accelerator
pedal and applying the brakes reduces engine
performance and causes premature brake and
drivetrain wear which is not covered by the
Mercedes-Benz Limited Warranty.
i
To signal minor directional changes such as
changing lanes, press combination switch only
to point of resistance and release. The corre-
sponding turn signals will flash three times.

544 Controls in detailUseful featuresEmergency calls
An emergency call is initiated
automatically following an accident in
which the emergency tensioning devices
(ETDs) or air bags deploy.
An emergency call can also be initiated
manually by opening the cover next to the
interior rear view mirror labeled SOS, then
briefly pressing the button located under
the cover. For instructions on initiating an
emergency call manually (
page 545).
Once the emergency call is in progress, the
indicator lamp in the SOS button will begin
to flash. The message:


“Connecting Call” appears in the multi-
function display


“Emergency Call Activated” appears in
the COMAND display
and the audio system is muted. When the
connection is established, the message:


“Call Connected” appears in the multi-
function display


“Emergency Call Activated” appears in
the COMAND display
All information relevant to the emergency,
such as the location of the vehicle (deter-
mined by the GPS satellite location sys-
tem), vehicle model, identification number
and color are generated.
A voice connection between the Response
Center and the occupants of the vehicle
will be established automatically soon af-
ter the emergency call has been initiated.
The Response Center will attempt to deter-
mine more precisely the nature of the acci-
dent provided they can speak to an
occupant of the vehicle.The Tele Aid system is available if


it has been activated and is operation-
al. Activation requires a subscription
for monitoring services, connection,
and cellular air time


the relevant monitoring service and
GPS coverage are available and pass
the information on to the Response
Center


there is sufficient voltage in the vehicle
batteries
i
During the emergency call message “Emer-
gency Call Activated” is displayed, operation
from COMAND is not possible. The automatic cli-
mate control can be still adjusted using the
switches on the climate control panel.
i
If no vehicle occupant responds, an ambu-
lance will be sent to the vehicle immediately.
i
Location of the vehicle on a map is only pos-
sible if the vehicle is able to receive signals from
the GPS satellite network and pass the informa-
tion on to the Response Center.Warning!
G
If the indicator lamp in the SOS button is
flashing continuously and there was no
voice connection to the Response Center
established, then the Tele Aid system could
not initiate an emergency call (e.g. the rele-
vant mobile phone network is not available).

545 Controls in detail
Useful features
Initiating an emergency call manually
1SOS button
2Cover
Briefly press button on cover2 to
open.
Cover 2 will open.

Press SOS button1 (for longer than
2 seconds).
The indicator lamp in SOS button1
will flash until the emergency call is
concluded.

Wait for a voice connection to the
Response Center.

Close cover2 after the emergency
call is concluded.
The message:

“Call Failed” appears in the multifunc-
tion display for approximately
10 seconds.


A pop-up window with the message:
“Call could not be connected! Please dial
911 directly using the mobile telephone
keypad.” appears in the COMAND dis-
play. Confirm the message pressing
n

(
page 90).
Should this occur, assistance must be sum-
moned by other means.
i
During the emergency call the mobile phone
is switched off automatically and must be
switched back on to make a call.
i
The roof cargo container* may impair mo-
bile phone reception. In an emergency, remove
the mobile phone from the mobile phone cradle
(
page 539) to make a call.
i
The “911” emergency call system is a public
service. Using it without due cause is a criminal
offense.
Warning!
G
If you feel at any way in jeopardy when in the
vehicle (e.g. smoke or fire in the vehicle, ve-
hicle in a dangerous road location), please
do not wait for voice contact after you have
pressed the emergency button. Carefully
leave the vehicle and move to a safe loca-
tion. The Response Center will automatically
contact local emergency officials with the
vehicle’s approximate location if they
receive an automatic SOS signal and cannot
make voice contact with the vehicle occu-
pants.

547 Controls in detail
Useful features
Information button¡
Press and hold Information button
¡ (for longer than 2 seconds).
A call to the Customer Assistance Cen-
ter will be initiated. The button will
flash while the call is in progress. The
message:

“Connecting Call” appears in the
multifunction display


“Information Call Activated” ap-
pears in the COMAND display
and the audio system is muted.
When the connection is established, the
message:


“Call Connected” appears in the multi-
function display


“Information Call Activated” appears in
the COMAND display
The Tele Aid system will transmit data gen-
erating the vehicle identification number,
model, color and location (subject to avail-
ability of cellular and GPS signals).A voice connection between the Customer
Assistance Center representative and the
occupants of the vehicle will be estab-
lished. Information regarding the operation
of your vehicle, the nearest authorized
Mercedes-Benz Center or Mercedes-Benz
USA products and services is available to
you.
For more details concerning the Tele Aid
system, please visit www.mbusa.com and
use your ID and password (sent to you sep-
arately) to learn more (USA only).
i
The indicator lamp in the Roadside Assis-
tance button• remains illuminated in red for
approximately 10 seconds during the system
self-check after switching on the ignition (togeth-
er with the SOS button and the Information
button¡).
See system self-check (
page 543) if the indi-
cator lamp does not come on in red or stays on
longer than approximately 10 seconds.
If the indicator lamp in the Roadside Assistance
button• is flashing continuously and no
voice connection to the Response Center was
established, the Tele Aid system could not ini-
tiate a Roadside Assistance call (e.g. the relevant
mobile phone network is not available). The mes-
sage:


“Call Failed” appears in the multifunction
display for approximately 10 seconds


“Call could not be connected!” appears in
the COMAND display. Confirm the message
pressing
n
(page 90).
Roadside Assistance calls can be terminated us-
ing button t on the multifunction steering
wheel or COMAND (page 141).
i
The indicator lamp on the Information
button¡ remains illuminated in red for ap-
proximately 10 seconds during the system
self-check after switching on the ignition (togeth-
er with the SOS button and the Roadside Assis-
tance button•).
See system self-check (
page 543) if the indi-
cator lamp does not come on in red or stays on
longer than approximately 10 seconds.
If the indicator lamp in the Information
button¡ is flashing continuously and no
voice connection to the Response Center was
established, then the Tele Aid system could not
initiate an Information call (e.g. the relevant
