2008 MERCEDES-BENZ S-Class Bluetooth

179 Control systems
COMAND telephone*
Saving a phone book entry from the mo-
bile phone in an existing address book
entry
Search for a phone book entry in the
mobile phone (
page 170).
or

Display details of a phone book entry in
the mobile phone (
page 173).

Select “Options”
“Save”
“Add”.

Select a number category, e.g. “Home”.

Select a telephone category, e.g. “Land
Line”.

Select “Save”.
The search menu for address book en-
tries appears.

Search for desired entry.

After selecting an entry, press n.
COMAND saves the data if there are
fewer than four numbers assigned to
the selected entry in the selected num-
ber category. Otherwise, you will see a
prompt asking whether one of the ex-
isting numbers should be overwritten.

Select “Yes” or “No”.
If you select “Yes”, a selection list will
appear containing the four existing
numbers.

Select the number to be overwritten.
COMAND overwrites the selected num-
ber with the new data.Importing data from external
Bluetooth
® devices
You can import vCards from external
Bluetooth® devices into the address book.
Please keep the following in mind:


Bluetooth
® is activated in COMAND
(
page 180) and in the device con-
cerned.


The external device must be able to
send vCards by Bluetooth
®.


The external device is inside the vehi-
cle, switched on and authorized
(page 180).
i
The mobile phone must be inserted in the
cradle*.
i
There is a detailed description of how to
search for an address book entry in the “Search-
ing for an address book entry” section
(
page 170).

180 Control systemsCOMAND telephone*
Importing: Start data transfer on the
external device (see operating instruc-
tions of the device concerned).
If there is no address book entry with
the same first name and last name,
COMAND imports the data.
If there is already an address book en-
try with the same first name and last
name, a prompt will appear asking
whether the existing data should be
overwritten.

Select “Yes” or “No”.
The existing address book entry will be
overwritten or not, depending on your
selection.
Bluetooth
® settings
General information about Bluetooth
®
Bluetooth
® technology is the standard for
short-range wireless technologies, suitable
for transmitting voice and data. It is possi-
ble to connect Bluetooth
® devices wire-
lessly. Bluetooth
® can be used to
exchange vCards or make calls using a
headset.
Bluetooth
® technology uses the freely
available ISM (Industrial Scientific Medi-
cal) wireless network that works at
2.45 GHz. Ranges of up to ten meters are
possible with Bluetooth
®.
Activate or deactivate Bluetooth
®

Select “Telephone”
“Data/Connec-
tions”
“Bluetooth”
“Deactivate
Bluetooth”.
You have activated or deactivated
Bluetooth
®. A checkmark appears
when Bluetooth
® is deactivated.Connecting Bluetooth
® devices
It is possible to establish a Bluetooth
® con-
nection between COMAND and the follow-
ing types of device:


Mobile phone (only for transferring
business cards)


Headset


Laptop/PDA
You can connect up to twelve devices to
COMAND but only one device can be ac-
tive at a time.
The connection process includes search-
ing for the device and its subsequent au-
thorization.
i
To connect a Bluetooth
® device, the
Bluetooth
® function must be activated in
COMAND and in the device concerned. The
Bluetooth® device must also be set to “visible”
or “findable” in order for COMAND to find and
display it. For the setting procedures, please see
the operating instructions for the Bluetooth
®
device.

181 Control systems
COMAND telephone*
Calling up the Bluetooth
® device list
and searching for devices

Calling up the list: Select “Telephone”

“Data/Connections”
“Bluetooth”
“Search for Bluetooth devices”.
When you call up the list for the first
time after switching on COMAND, the
search for devices in the reception
range starts automatically. You will see
a display to this effect.
The device list appears after a short
while.
Canceling search:
Select “Cancel”.
The second time you call up the list, and
each time thereafter, the device list ap-
pears immediately if COMAND has not
been switched off and on again in the
meantime.

Starting search manually:
Select “Update”.The device list can contain the following
devices:


All detected devices, whether autho-
rized or not.


All authorized devices, whether detect-
ed or not.
1Authorized and detected device – de-
vice and padlock symbol are the same
color
2Device which was not detected, but
which has been authorized in the past
– device and padlock symbol are differ-
ent colors (the device may be switched
off or not in the vehicle, for example)
3Newly detected device - not yet autho-
rized (no symbol)Displaying details of a Bluetooth
® de-
vice

Call up Bluetooth
® device list
(
page 181).

Select desired device.

Select “Details”.
The detailed display for this device ap-
pears.

Closing detailed display: Slide qmr
or ymz.
i
If the device list already contains twelve au-
thorized devices, you must revoke authorization
for one of the authorized devices. Then you must
switch this device off and then restart the
search. Any new devices for which you would like
to search will otherwise not appear in the list.

182 Control systemsCOMAND telephone*Authorizing a Bluetooth
® device

Call up the Bluetooth
® device list
(
page 181).

Select unauthorized device.

Select “Authorize”.
The input menu for the passkey ap-
pears.

Entering passkey into COMAND:
Select the digits one by one.

Deleting digits: Select ) and briefly
press n.

Canceling entry into COMAND:
Select “Back”.

Confirming entry into COMAND:
Select?.

If necessary, enter the same passkey
into the Bluetooth
® device (see the op-
erating instructions for the device).
The device is authorized.De-authorizing a Bluetooth
® device

Call up Bluetooth
® device list
(
page 181).

Select authorized device.

Select “De-authorize”.
A prompt appears asking whether you
really want to de-authorize this device.

Select “Yes” or “No”.
If you select “Yes”, the device will be
de-authorized.
i
The passkey is any one to sixteen-digit num-
ber which you can set yourself. You must enter
t he s ame n um ber in C OM AND an d als o in th e de-
vice to be authorized.
i
On devices which do not have an input key-
pad (e.g. headsets), the passkey is predeter-
mined. In this case, it is not necessary to enter
the number on the device itself. You will usually
find the passkey in the operating instructions for
the device.
i
If you de-authorize a device which has been
authorized in the past and which is not detected
in the search, this device will no longer be dis-
played in the device list.
Devices which have been authorized in the past
but which are not detected in the search are ei-
ther not switched on or not in the vehicle.

540 Controls in detailUseful features
When the mobile phone is inserted in the
cradle, you can operate the telephone us-
ing the following devices:

mobile phone keypad


COMAND telephone keypad
(page 144)


buttonss andt on the multi-
function steering wheel (
page 288)


Voice Control (
page 313)


Bluetooth
® headset (
page 157)
Please note that these functions are only
available with Mercedes-Benz approved
mobile phones. Please contact an autho-
rized Mercedes-Benz Center for informa-
tion on features available for your mobile
phone of choice.

Open telephone compartment
(page 527).Inserting mobile phone in mobile phone
cradle
Once the mobile phone has been inserted
in the mobile phone cradle, you have to
use the hands-free device or Bluetooth
headset to respond during phone calls.

If applicable, remove the cover for the
external antenna connection from the
back of the mobile phone and store it in
a s a f e p l a c e . B e s u r e t o c o m p l y w i t h t h e
mobile phone’s operating instructions,
as well.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet (approximate-
ly 14 m) every second.i
Various mobile phone cradles can be in-
stalled in the front center armrest, see separate
installation instructions for the mobile phone
cradle. These mobile phone cradles can be ob-
tained from an authorized Mercedes-Benz Cen-
ter.
The functions and services available to you while
using the mobile phone depend on your service
provider and the type of mobile phone you are
using. See also separate operating manual for in-
structions on how to use your mobile phone.
i
The roof cargo container* may impair mo-
bile phone reception. In an emergency, remove
the mobile phone from the mobile phone cradle
to make a call.
!
Do not try to remove the mobile phone along
with the cradle. You could otherwise damage the
mobile phone cradle.
