63 Getting started
Driving
Switching on windshield wipers
Turn the combination switch to the
desired position depending on the
intensity of the rain.
MWindshield wipers off
USlow intermittent wiping
Rain sensor operation with low
sensitivity.
VFast intermittent wiping
Rain sensor operation with high
sensitivity.
uSlow continuous wiping
tFast continuous wipingIntermittent wiping
Only switch on intermittent wiping under
wet weather conditions or in the presence
of precipitation.
When you select intermittent wiping, the
rain sensor is activated. The rain sensor
automatically sets a suitable wiping
interval depending on the wetness of the
sensor surface.
Turn the combination switch to
positionU orV.After the initial wipe, pauses between
wipes are automatically controlled by the
rain sensor.
Single wipe
Press the combination switch briefly in
direction of arrow1 to the resistance
point.
The windshield wipers wipe one time
without washer fluid.
If windshield wipers fail to function at all in the
combination switch positionU orV,

set the combination switch to the next
higher wiper speed

have the windshield wipers checked at the
nearest authorized Mercedes-Benz Light
Truck Center
!Do not leave windshield wipers on an inter-
mittent setting when the vehicle is taken to an
automatic car wash or during windshield clean-
ing. Wipers will operate in the presence of water
sprayed on the windshield, and windshield
wipers may be damaged as a result.
!If you have set intermittent wiping, dirt on
the surface of the rain sensor or optical effects
may cause the windshield wipers to wipe in an
undesired fashion. This could then damage the
windshield wiper blades or scratch the windows.
You should therefore switch off the windshield
wipers when weather conditions are dry.
iIntermittent wiping is interrupted when the
vehicle is at a standstill and a front door is
opened. This protects persons getting into or out
of the vehicle from being sprayed.
Intermittent wiping will be continued when all
doors are closed and

the automatic transmission is set to
positionD orR
or

the wiper setting is changed using the
combination switch
164.boo Seite 63 Freitag, 30. März 2007 12:54 12

64 Getting started
Driving
Wiping with windshield washer fluid
Press the combination switch in direc-
tion of arrow1 past the resistance
point.
The windshield wipers operate with
washer fluid.
For information on cleaning the headlamps
with washer fluid, see “Headlamp cleaning
system*” (
page 208).
For information on filling up the washer
reservoir, see “Windshield/rear window
washer system and headlamp cleaning
system*” (
page 383).
Rear window wiper/washer
The combination switch is located on the
left of the steering column.
Combination switch
1Rear window wiper switch
2Wiping rear window with washer fluid
3Intermittent wiping
4Rear window wiper off
5Wiping rear window with washer fluid6Rear window wiper indicator
Switch on the ignition (page 42).
Activating intermittent wipe
Turn rear window wiper switch1 to
position3 (
page 64).
In the lower multifunction display you
will see indicator6, indicating that
the rear window wiper is activated.
iTo prevent smears on the windshield or
noisy/chattering wiper blades, wipe with
windshield washer fluid every now and then even
when it is raining.
iThe rear window wiper engages automatical-
ly when the automatic transmission is shifted to
positionR with the windshield wipers switched
on.
164.boo Seite 64 Freitag, 30. März 2007 12:54 12

208 Controls in detail
Good visibility
For information on windshield wipers, see
“Windshield wipers” (
page 62).
Headlamp cleaning system*
The headlamps will automatically be
cleaned with a high-pressure water jet
when you have

switched on the headlamps
and

operated the windshield wipers with
windshield washer fluid five times
When you switch off the headlamps, the
counter resets.
For information on filling up the washer
reservoir, see “Windshield/rear window
washer system and headlamp cleaning
system*” (
page 383).
Rear view mirrors
For more information on setting the rear
view mirrors, see “Mirrors” (
page 51).
Interior rear view mirror, antiglare
position
1Lever
Tilt the mirror to the antiglare position
by moving lever1 towards the wind-
shield.
The interior rear view mirror is dimmed.Auto-dimming rear view mirrors*
The reflection brightness of the exterior
rear view mirror on the driver’s side and
the interior rear view mirror will respond
automatically to glare when

the ignition is switched on
and

incoming light from headlamps falls on
the sensor in the interior rear view
mirror
The rear view mirror will not react if

the automatic transmission is set to
positionR

the interior lighting is turned on
164.boo Seite 208 Freitag, 30. März 2007 12:54 12

381 Operation
Engine compartment
Adding engine oil
Example illustration GL 450 (GL 320 CDI,
GL 550 similar)
1Filler cap
Unscrew filler cap1 from filler neck.
Add engine oil as required. Never over-
fill with oil.
Be careful not to spill any oil when adding.
Avoid environmental damage caused by oil
entering the ground or water.
Screw filler cap1 back on filler neck.
For more information on engine oil, see
“Technical data” section (
page 562) and
(
page 564).
Transmission fluid level
The transmission fluid level does not need
to be checked. If you notice transmission
fluid loss or gear shifting malfunctions,
have an authorized Mercedes-Benz Light
Truck Center check the automatic trans-
mission.
Coolant level
The engine coolant is a mixture of water
and anticorrosion/antifreeze.
When checking the coolant level

the vehicle must be parked on level
ground

the coolant temperature must be below
158°F (70°C)
!Only use approved engine oils and oil filters
required for vehicles with Maintenance System.
For a listing of approved engine oils and oil
filters, refer to the Factory Approved Service
Products pamphlet (USA only) in your vehicle
literature portfolio, or contact an authorized
Mercedes-Benz Light Truck Center.
Using engine oils and oil filters of specification
other than those expressly required for the
Maintenance System, or changing of oil and oil
filter at change intervals longer than those called
for by the Maintenance System will result in
engine or emission control system damage not
covered by the Mercedes-Benz Limited
Warranty.
!Excess oil must be siphoned or drained off.
It could cause damage to the engine and/or
catalytic converter (gasoline engine) or the oxi-
dation catalyst (diesel engine) not covered by
the Mercedes-Benz Limited Warranty.
164.boo Seite 381 Freitag, 30. März 2007 12:54 12

562 Technical data
Fuels, coolants, lubricants
Capacities
Vehicle components and their respective
lubricants must match. Therefore only use
products tested and approved by
Mercerdes-Benz.
Please refer to the Factory Approved
Service Products pamphlet (USA only), or
inquire at an authorized Mercedes-Benz
Light Truck Center.
Warning!G
Comply with all valid regulations with re-
spect to handling, storing and disposing of
service fluids. Otherwise you could
endanger persons or the environment.
Keep service fluids out of the reach of
children.
For health reasons, you should prevent
service fluids from coming into direct
contact with your skin or clothing.
If a service fluid is swallowed, contact a
physician immediately.
ModelCapacityFuels, coolants, lubricants, etc.
Engine with oil filterGL 320 CDI9.0 US qt (8.5 l)Approved engine oils
GL 450, GL 5509.5 US qt (9.0 l)Approved engine oils
Automatic transmissionAll models9.5 US qt (9.0 l)MB Automatic Transmission Fluid
Transfer case single speedAll models0.5 US qt (0.5 l)MB Automatic Transmission Fluid
Transfer case double speed*All models1.6 US qt (1.5 l)MB Automatic Transmission Fluid
Front axleAll models1.2 US qt (1.1 l)Hypoid gear oil
Rear axleAll models1.2 US qt (1.1 l)Hypoid gear oil
Rear axle with differential lock*All models1.7 US qt (1.6 l)Hypoid gear oil
Power steeringAll modelsapprox. 1.3 US qt (1.2 l)MB Power Steering Fluid or approved
Dexron III ATF
164.boo Seite 562 Freitag, 30. März 2007 12:54 12

572 Index
Automatic climate control (3-zone)* 228
Air conditioning refrigerant 563
Air conditioning, Cooling 239, 240
Air distribution, Front 234
Air distribution, Rear 243
Air recirculation mode 237
Air vents*, second-row seats 245
Air vents*, third-row seats 245
Air vents, Front 234
Air volume 235
Control panel, Front 230
Control panel, Rear 241
Deactivating system 232
Defogging 235
Defrosting 235
Maximum cooling, MAXCOOL 237
Rear passenger compartment 241
Rear window defroster 212
Residual engine heat (REST) 241
Using driver-side settings for
all temperature zones 240Automatic headlamp mode 144
Automatic lighting control, Interior
lighting 150
Automatic locking when driving 128
Automatic transmission 56
Accelerator position 195
Emergency operation
(limp-home mode) 200
Gear ranges 197
Gear selector lever 56, 189
Gear selector lever position 192
Gear shifting malfunctions 200
Hill start assist system 196
Kickdown 196
Shifting procedure 192
Starting the engine 56
Steering wheel gearshift control 198
Towing a trailer 197
Transmission fluid level 381
Transmission positions 193
Automatic Transmission Fluid see ATFB
Backrest
Seat 46
Seat, Lumbar support 137
Seat, Multicontour* 138
Backup lamps
Messages in the multifunction
display 477
Replacing bulbs 511
Bar 416
BAS 103
Lamps in instrument cluster 436
Messages in the multifunction
display 451
Batteries, SmartKey
Check lamp 112, 115
Checking battery condition 120
Messages in the multifunction
display 466
Replacing 502
164.boo Seite 572 Freitag, 30. März 2007 12:54 12

578 Index
ETD 89, 446
Safety guidelines 78
Expanding cargo compartment 304
Exterior rear view mirrors 51, 208
Folding 210
Power folding* 209
Synchronizing 209
F
Fastening the seat belts 53
Filler neck, Engine oil 381
First aid kit 490
Flat tire 519
Lifting the vehicle 520
Lowering the vehicle 526
Minispare wheel 494
Mounting the spare wheel 520
Preparing the vehicle 520
Floormats 325Fluids
Automatic transmission fluid 381,
562
Brake fluid 377, 563, 564
Capacities 562
Engine coolant 377, 381, 563, 567
Engine oil 380, 562, 564
Power steering fluid 562
Windshield washer and headlamp
cleaning system* 377, 569
Fog lamps 146
Corner-illuminating front fog
lamps* 147
Messages in the multifunction
display 478
Rear fog lamp 146
Replacing bulbs 510
4-ETS 107
Off-road - 4-ETS 108
Front air bags 79
Front defroster 221, 235
Front lamps see Headlamps
Front passenger front air bag 74, 79
Messages in the multifunction
display 460, 461, 462, 463Front passenger front air bag off indicator
lamp 31, 32, 85
Front seat head restraints see
Head restraints
Front towing eye 540
Fuel 375, 563
Additives 566
Capacities, Fuel tank 563
Consumption statistics 184, 185
Filling the tank 374
Fuel filler flap and cap 374, 497
Fuel gauge 29
Fuel tank reserve warning lamp 29,
446
Premium unleaded gasoline 375,
563, 565
Requirements, Octane rating 565
Fuel cap
Messages in the multifunction
display 474
164.boo Seite 578 Freitag, 30. März 2007 12:54 12

584 Index
Multifunction display messages 449
ABS 451
ABS, ESP
®451
Air suspension 486
Air suspension program 486
Brake fluid 469
Brake lamps 477
Brake pads 467
Coolant 472
Corner-illuminating front fog
lamps* 478
Cruise control 452
Distronic* 453
Doors 474
Downhill Speed Regulation 467
EBP 468
Engine coolant 470, 472
ESP
®441
Fog lamps, Front 478
Fog lamps, Rear 480
Front passenger front air bag 460,
461, 462, 463
Fuel cap 474
Headlamps 477, 478, 480, 482
Hood 474Key, SmartKey 476
Key, SmartKey with
KEYLESS-GO* 475, 476
Lamps 477, 478, 479, 480, 482
Low tire pressure 464, 484, 485
Parking brake 468
Parking lamps 480
Tele Aid 483
Telephone* 483
Turn signals 482
Vehicle battery 466
Windshield washer fluid 483
Multifunction steering wheel 30, 156
Button operation 156
N
Navigation system* 166
See separate COMAND System
operating instructions
Net, Cargo* 312
Net, Parcel 319
Neutral gear position, Automatic
transmission 189
New vehicle, Break-in period 346
Night security illumination 146, 176
Normal occupant weight 417
Number, Vehicle Identification (VIN) 550O
Occupant distribution 417
Occupant safety 74
Active head restraint 90
Air bags 76
Children and air bags 77, 91, 93
Children in the vehicle 91
Fastening the seat belt 53
Front passenger front air bag off
indicator lamp 81, 85, 86
Infant and child restraint systems 92
LATCH-type child seat anchors 95
OCS 81
OCS, Messages in the multifunction
display 460, 461, 462, 463
Seat belts 53, 78
OCS 81
Self-test 86
Odometer 153, 155, 162
164.boo Seite 584 Freitag, 30. März 2007 12:54 12
