2008 MERCEDES-BENZ G-Class display

28 At a glance
Multifunction steering wheel

Multifunction steering wheel
FunctionPage
1Multifunction display
2Volume setting:
ç Volume down
æ Volume up
34
34
3Making calls:
s
Accepting calls,
Redialing
t
Ending or rejecting calls
94
96
96
4Multifunction display
menu change:
è forward
ÿ back
29
FunctionPage
5Radio mode:
j Next station
k Previous station
46
46
Single CD and CD changer
mode:
j Next track
k Previous track
60
60
MP3 CD mode:
j Next track
k Previous track
71
71
Satellite radio mode
j Next station
k Previous station
79
79
Telephone* mode
j Next list entry
k Previous list entry
102
102

29 At a glance
Multifunction steering wheel
Switch the multifunction display to the
respective system if you wish to
operate the system using the buttons
on the multifunction steering wheel.
On the multifunction steering wheel,
press è or ÿ repeatedly until
one of the following, Radio, Single CD
or MP3 CD, CD changer, Satellite radio
or Telephone* display appears in the
multifunction display of the instrument
cluster.Radio operation
1Waveband
2Station frequencySingle CD/ CD changer operation
1Current CD
2Current track
Selecting the multifunction display

30 At a glance
Multifunction steering wheel
MP3 CD operation
1MP3 mode
2Current MP3 trackSatellite radio operation
1SAT mode and preset channel number
2Channel nameTelephone* operation
List with a phone book entry
On display will appear either:
the main display with the READY
message
a list with either a phone book entry or
one of the last 10 outgoing calls
In order to close the list display,
press t.
This switches to the telephone main
display.

31 At a glance
Menu system

Menu system
The menu system allows for easy
operation of COMAND.
Main menus are provided for the following
main functions:
Audio (AM/FM radio, CD, CD changer,
MP3 CD)
Satellite radio
Telephone*
Navigation
SystemCalling up main menus Menu display
A display may consist of three areas.
Example: FM menu
1Soft keys area
2Main area
3Status bar
The functions currently assigned to the
soft keys are displayed in the soft key
sections 1.
Main functionActivating main
menu
Audio
(
page 42)
Press A.
Satellite radio
(
page 78)
Press B.
Telephone*
(
page 92)
Press a.
Navigation
(
page 108)
Press b.
System
(
page 170)
Press {.
i
A maximum of five soft keys may be
displayed on each side of the main
area2.

32 At a glance
Menu system
The main area 2 shows messages and
settings.
You can change the settings by operating
the system.
The status bar 3 is divided into three
areas.
Left side:
The current operating mode is indicated. In
this example: Radio
Center:
The status of the current operating mode
or other selectable functions are indicated.
In this example:
FM = current waveband
1 = memory location of station,
e.g. “1”
Right side:
9:33 = actual time (page 33)
 = reception strength of the
mobile phone*
n = text message in the inbox
(
page 215)
G = phone call active
Menu functions and submenus
Using the soft keys, functions can be
switched ON or OFF, or submenus can be
called up.
E.g. the radio menu:
The FM/AM soft key switches between
FM and AM band.
The Scan soft key starts/stops the
channel scan.
In some situations, soft keys may not have
any function and are not operational. A soft key without function appears
shaded out.
E.g.: Soft keys on the left and right side
Exiting from submenus
Use the
Back soft key 1 to exit a
submenu. The display switches to the next
higher menu level.
The system does not accept setting
modifications which have not been stored.
There are exceptions where pressing the
Back soft key will also store new settings.
These exceptions, whenever applicable,
are referenced on the following pages.

33 At a glance
Menu system
Permanent time display
The system permanently shows the actual
time in the status bar.
Time display with ignition on and mobile
phone inserted
1Actual time
2Indication of the current field strength
of the mobile phone signal
Time display with ignition on and no mobile
phone insertion clamp connected
1Actual time shown with large
characters
i
The time only appears in the status bar
when the ignition is switched on.
If there is no phone connected, the
field strength indicator is not shown.

36 At a glance
Quick reference COMAND
Common balance and fader settings apply
to the following systems:
Radio operation
CD operation (CD)
CD changer operation (CD)
MP3 CD operation (MP3)
Satellite radio
When you make balance or fader settings,
the system will automatically save the
settings for the current operating mode
and others.Setting balance and fader
In any audio source operation:
Press the Bal/Fad soft key.
Cross-hairs are displayed. The
horizontal hair line indicates the
balance setting. The vertical hair line
indicates the fader setting. You can
now make balance and fader settings.
Push the joystick to H or h.
Move the cross-hairs horizontally and
adjust the balance.
or
Push the joystick to g or G.
Move the cross-hairs vertically and
adjust the fader.
Press E or the Back soft key.
or
Wait until the display changes.
The new setting is saved.
Balance and fader
i
Push the joystick to F and f to
move the cross-hairs simultaneously in
vertical and horizontal direction.

37 At a glance
Quick reference COMAND
Different bass and treble settings are
possible for the following operating modes:
Radio: FM-, AM- and
Weather (WB) bands
Single CD (CD) and CD changer
(
CD)
MP3 CD operation (MP3)
Satellite radio
When you adjust bass or treble, the
settings apply to other sources within the
group, but not to the other modes. For
example, if you adjust the bass while
listening to FM, that same bass level
applies to AM and Weather band, but not
to satellite radio or CD/MP3 CD.Activating the Bass or Treble menu
In any audio source operation:
Press the Bass or Treble soft key.
The Bass or Treble menu will appear.
Setting Bass and Treble
Push the joystick to H or h.
Bass or Treble is adjusted.
Press E or the Back soft key.
or
Wait until the display changes.
The new setting is saved.

Bass and Treble
i
Press the Bass or Treble soft key and
keep it depressed to move the cursor
continuously. Release the soft key to
set the current value.
