80 Satellite radio*Satellite radio operationTwo options are available:
Storing using the number keys

Storing using the Presets menu
Storing via number keys
Press and hold a number key between 3
and
"
for more than 2 seconds.
The currently selected station is stored
in the corresponding preset location.
Storing via Presets menu
Press the
Presets
soft key.
The Preset list appears.

Use

or

to select a preset loca
-
tion.

Press

for more than 2 seconds.
The currently selected station is stored
in the corresponding preset location.
Resetting Presets menu The
Presets
soft key is active indicated by
its color changed.

Press the
Presets
soft key.
All channels in the Preset list are delet
-
ed.

Press the
Service
soft key.
The telephone number of the Sirius
Service Center and the twelve-digit
electronic serial number (ESN) of the
particular receiver appear.
It may be necessary to call the Sirius Ser
-
vice Center if, for example:
you want to cancel the subscription or
to re-subscribe at a later date,

you forget to pay the bill, or

you sell the car to another person.
Storing stationsiWhen storing a station out of the cate
-
gory
All
, later selection of this channel
does not lead into the category mode.
Calling the Sirius Service Center

87 Telephone*
Telephone operation

In succession, press the number keys !
, 3
and
3
.

Press
0
.
The telephone establishes the connec
-
tion, the ringing tone is audible.

Wait until the emergency call center
answers, then describe the emergency.
The PIN protects the telephone against un
-
authorized use. Your PIN is found in the
telephone service provider's documenta
-
tion.
Commit your PIN to memory.

Most telephone functions are not available
before entering the PIN.
Press the corresponding number key 3
- "
for each digit.
In case of erroneous entry, you can de
-
lete the last or more digits:
Press the
Delete
soft key as often
as required.

Once all digits have been entered,
press the
OK soft key.
If the input is correct, the telephone
will log itself into the network.If the input is incorrect, message

Wrong PIN number
will appear briefly.

Re-enter the PIN.
After three incorrect entries, the SIM
card is blocked. Message
SIM
card
blocked
will appear briefly.


The PUK has to be entered.
( Telephone Operation Guide)
Entering the PIN (only GSM) iIf a GSM cellular phone is used, a PIN
may also have to be entered.The PIN may be entered on the cellular
phone itself (
 Telephone Operation
Guide).
iThe telephone cannot be used before it
is logged- in.

90 Telephone*Telephone operationSelectable soft keys and options
soft key

Opens the phone book
( page
97)
,

Recvd.#
soft key

Opens the accepted and missed calls
list
( page
93)
,

Dialed
# soft key

Opens dialed calls list
( page
94)
,

SMS
soft key

Provides access to the SMS menu ( page
100)
,

Entry of a phone number
( page
91)
.
The ringing tone is audible in the event of
an incoming call. The call screen pops up
on the current display.If the multifunction display in the instru
-
ment cluster is set to telephone mode, the
call screen also appears in the multifunc
-
tion display.
Answering calls On the COMAND control unit
Press
0
.
iIf a list is empty, the corresponding soft
key is without function. This is indicat
-
ed by the corresponding soft key dis
-
play being shaded out.
Answering an incoming call
iThe caller’s number appears only if it is
transmitted.

The caller’s name only appears if, in ad
-
dition, the number and the name are
stored in the phone book
( page
97)
.

100 Telephone*SMS (Mail)SMS messages can be received if your ve
-
hicle is equipped with a telephone and
SMS messaging is available from your car
-
rier.Received messages are saved in the folder
SMS inbox.
Open the Telephone main menu ( page
89)
.

Press the
SMS
soft key.
The folder SMS inbox appears.
The SMS inbox shows the list of re
-
ceived messages. The list is sorted
chronologically, the last message re
-
ceived is displayed at the top of the list.The corresponding date and time ap
-
pears in the status bar when the select
-
ed message has been received.

Use

or

to select another mes
-
sage.
iIncoming new messages are indicated
by the
symbol in the status bar.

Symbol
appears in the status bar if
the SMS memory is full.In addition, a corresponding message
is displayed when the folder is opened.SMS inbox
iIf no SMS messages have been re
-
ceived the
SMS
soft key is without func
-
tion and therefore shaded out.

124 Navigation*Destination entry
Memory
soft key

The current map location is stored ( page
126)
.

Display
soft key

You can select which POIs will appear
as symbols on the map
( page
143)
.

soft key

The map scale will change to display a
more detailed map.

soft key

The map scale will change to display a
map that shows a wider area.
Moving the map and selecting a desti
-
nation
Move the cursor using

,
, ,
, (
or
+
to select the desired
destination.

Release the button.If the system finds a street name at the
location the cursor is pointing to, the
corresponding street name is shown in
the status bar. In this example:
WATER
ST
Start route guidance to the selected
destination
Press

.
The Start Route Guidance menu ap
-
pears if route guidance has not yet
been activated.
Press

.
Route calculation begins.
If route guidance is already active, you
will be prompted to confirm that you
wish to accept the new destination.
Press

to select
Yes
.

Press

.
Route calculation begins.
iThe soft keys
Coord.
, Memory
and
Dis
-
play
are visible only if the map has
been called up using
%
.
iThe destination selection will be lost
when pressing the
Back
soft key.

The system reverses to the details of
the previously entered destination.

134 Navigation*Route guidanceRoute guidance to an off-road destina
-
tion
COMAND can guide you to destinations
within the area covered by the digital map,
even if a destination is not located at a
road known to the system.These destinations are shown as off-road
destinations, which you can enter using
the map, for example.In these cases, COMAND guides you for as
long as possible with navigation announce
-
ments and displays on roads known to the
system.Shortly before you reach the last known
point in the digitized road network, you will
hear the announcement “The destination is
nearby. Follow the arrow on the display”.You will then see an arrow that indicates
the direction to the off-road destination.
When the off-road destination is close to
the road,
Area of dest. reached
appears
in addition below the arrow.
When you leave the last known point in the
digitized road network, direction arrows
showing the compass heading to the desti
-
nation guide you. You will also see the
Di-
rection to destination
display.
Route guidance from an off-road loca
-
tion to a destinationIf there is no road available on map at cur
-
rent position of the car, vehicle is off road.COMAND is also able to guide you to a des
-
tination from such a location.At the start of the route guidance, you will
see the
Off Road
message and a direction
arrow. The direction arrow shows the com
-
pass heading to the actual destination.The route is highlighted blue from the near
-
est road known to the system. As soon as the vehicle is back on a road
known to the system, route guidance con
-
tinues in the usual way.
Off-road and off-mapWarning
G
The COMAND navigation system may direct
you to off-road routes that your vehicle may
not be capable of traversing through without
damaging your tires, wheels or vehicle. It is
the driver’s sole responsibility to determine
the suitability of the route. Off-road routes
may be of varying conditions and their ap
-
propriateness for use may be affected by
various factors such as time of day, time of
year and immediate weather conditions that
cannot be judged or taken into consider
-
ation by the COMAND system.

145 Navigation*
During route guidance
You can set the following to be displayed in
the status bar:
Time of arrival/Dist. to Dest.

If the full-screen map display is activat
-
ed
( page
131)
, the estimated time of
arrival and the remaining distance to
the destination will be displayed. If you
have entered a stopover destination ( page
140)
, the corresponding data
will be displayed.

Current-Location display

If the full-screen map display is activat
-
ed
( page
131)
, the following data will
be displayed:
The current position as coordi
-
nates.

The number of satellites that can
currently be received.

The current elevation (ALT = alti
-
tude) above sea level.

No display

The name of the current road is dis
-
played.

In the Display menu
( page
143)
,
press the
Map
soft key.
The possible options appear.

Use

or

to select the desired
option.

Press

.
The map display is switched.

Finally, press the
Back
soft key or wait
for the screen to change.
iDuring route guidance, a symbol will
appear on the left-hand side of the bot
-
tom status bar if map display is
switched ON.
North symbol
:
Fixed map orientation, north is al
-
ways pointing up,

Compass symbol
:
Dynamic map orientation, driving
direction is always pointing up.
Map display menu
iThe COMAND uses GPS to calculate
the elevation above sea level. For rea
-
sons of tolerance, this value may devi
-
ate from the actual value.
iThe solid circle
shows the current
setting.

160 ServiceTele Aid*Tele Aid incorporates the following func
-
tions:
Emergency call system

Roadside Assistance

Information
For certain emergency situations, the sys
-
tem automatically triggers an emergency
call. An emergency call can also be trig
-
gered manually. Refer to your vehicle Op
-
erator's Manual for additional information.If the system initiates an emergency call, Connecting
appears on the display.
During the emergency call
Call Connected

appears on the display. No operation from
COMAND is possible.
Mercedes-Benz Roadside Assistance will
assist if technical problems with your vehi
-
cle are experienced. Roadside Assistance can be requested
manually. Refer to your vehicle Operator's
Manual for additional information.Upon request of Roadside Assistance the
system initiates the call to the Mercedes-
Benz Response Center.

Connecting
appears on the display.
If the connection is made, the message Call Connected
appears on the display.
Even after ending of the connection, the
service may remain active for up to anoth
-
er 5 minutes in order to transmit any re
-
quired data. During this time, phone calls
cannot be made, nor can SMS messages
be received.
During activation of a roadside assistance
call, it is not possible to switch to another
application.The transmitted data can contain, e.g., text
messages or address details of a

Mercedes-Benz Center.Cancelling text messages
Press

after you have read the mes
-
sage.The message disappears.
Starting route guidanceYou are prompted to confirm if route guid
-
ance to the address is to be started.
Use

to select the
Yes
menu item
and confirm with

.
The system starts the route calcula
-
tion, and subsequently the route guid
-
ance to the defined address ( page
128)
.
Emergency call system
Roadside Assistance
