Contents
Maximum tire inflation pressure .. 320
Uniform Tire Quality Grading
Standards (U.S. vehicles) ............. 321
Tire ply material ........................... 323
Tire and loading terminology ........ 323
Rotating tires ............................... 326
Winter driving .................................... 328
Winter tires .................................. 328
Block heater* (Canada only) ........ 329
Snow chains................................. 329
Maintenance ...................................... 330
Maintenance service indicator
message....................................... 330
Calling up the maintenance
service indicator........................... 331
Resetting the maintenance
service indicator........................... 332
Vehicle care ....................................... 333
Cleaning and care of vehicle ........ 333
Practical hints.................................. 343
What to do if … ................................... 344
Lamps in instrument cluster ......... 344
Lamp in center console................. 356
Vehicle status messages in the
multifunction display..................... 358
Where will I find...? ............................. 393
First aid kit .................................... 393
Spare wheel .................................. 393
Vehicle tool kit .............................. 395
Luggage box ................................. 397
Unlocking/locking in an emergency... 398
Unlocking the vehicle.................... 398
Locking the vehicle ....................... 399
Fuel filler flap emergency release . 400
Manually unlocking the gear
selector lever ................................ 400
Resetting activated head restraints .... 401
Replacing SmartKey batteries ............ 402
Replacing bulbs .................................. 404
Bulbs ............................................. 404
Replacing bulbs for front lamps .... 407
Replacing bulbs for rear lamps ..... 409
Replacing wiper blades....................... 410
Wiper blades ................................. 410Flat tire............................................... 412
Preparing the vehicle .................... 412
Mounting the spare wheel ............ 412
MOExtended system* ................... 419
Battery ............................................... 420
Disconnecting the battery ............ 421
Removing the battery ................... 421
Charging and reinstalling the
battery .......................................... 422
Reconnecting the battery ............. 422
Jump starting...................................... 423
Towing the vehicle.............................. 425
Installing towing eye bolt .............. 426
Fuses.................................................. 428
Fuse box in passenger
compartment ................................ 429
Fuse box in trunk .......................... 429

37 Getting started
Unlocking
For more information, see “Locking and
unlocking” (
page 100).
Unlocking with KEYLESS-GO*
With the KEYLESS-GO function, you can
lock and unlock the vehicle without using
the remote control buttons on the
SmartKey and start the engine without in-
serting the SmartKey in the starter switch. Pull an outside door handle.

All turn signal lamps flash once.

An acoustic signal sounds once.

The locking knobs in the doors
move up.

The anti-theft alarm system is dis-
armed.
Get in the vehicle.
For more information, see “SmartKey with
KEYLESS-GO*” (
page 103).
iOpening a door causes the window on that
door to open slightly. They will return to the up
position when the door is closed.
!The side windows will not open or close if
the battery is discharged or the windows are cov-
ered with ice. As a result, you may no longer be
able to properly close the door. Do not attempt
to force the door shut. Doing so may damage the
door or the side window. Correct the condition
that prevents the windows from operating before
attempting to close the door.
Warning!G
When leaving the vehicle, always take the
SmartKey with KEYLESS-GO with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. A child’s unsupervised ac-
cess to a vehicle could result in an accident
and/or serious personal injury.
iTo unlock the vehicle, the SmartKey with
KEYLESS-GO must be outside the vehicle, no fur-
ther than approximately 3 feet (1 meter) away
from the door.
iOpening a door causes the window on that
door to open slightly. They will return to the up
position when the door is closed.
!The side windows will not open or close if
the battery is discharged or the windows are cov-
ered with ice. As a result, you may no longer be
able to properly close the door. Do not attempt
to force the door shut. Doing so may damage the
door or the side window. Correct the condition
that prevents the windows from operating before
attempting to close the door.

39 Getting started
Unlocking
For information on starting the engine with
the SmartKey, see “SmartKey”
(
page 100).SmartKey with KEYLESS-GO*
I f t h e S m a r t K e y w i t h K E Y L E S S - G O i s i n s i d e
the vehicle, pressing the KEYLESS-GO
start/stop button on the gear selector le-
ver corresponds to turning the SmartKey
to the various starter switch positions.
If you firmly depress the brake pedal dur-
ing pressing the KEYLESS-GO start/stop
button, the engine starts automatically.
KEYLESS-GO start/stop button
1USA only
2Canada only
The SmartKey with KEYLESS-GO must be
located in the vehicle.
Make sure the gear selector lever is set
toP.
Do not depress the brake pedal.
iThe SmartKey can only be removed from the
starter switch with the gear selector lever in
position P.
iIf the SmartKey is left in starter switch posi-
tion 0 for an extended period of time, it can no
longer be turned in the switch. In this case, the
steering is locked. To unlock, remove SmartKey
from the starter switch and reinsert.
!If the SmartKey cannot be turned in the
starter switch, the battery may not be sufficient-
ly charged.

Check the battery and charge it if necessary
(
page 420).

Get a jump start (page 423).
To prevent accelerated vehicle battery discharge
or a completely discharged vehicle battery, al-
ways remove the SmartKey from the starter
switch when the engine is not in operation.
iThe function of the SmartKey overrules the
KEYLESS-GO function.

52 Getting started
Driving
Starting with KEYLESS-GO*
You can start your vehicle without the
SmartKey in the starter switch using the
KEYLESS-GO start/stop button on the
gear selector lever.
For information on turning off the engine
with KEYLESS-GO, see “Locking with
KEYLESS-GO*” (
page 62).
The SmartKey with KEYLESS-GO must be
located in the vehicle.
KEYLESS-GO start/stop button
1USA only
2Canada only
Make sure the gear selector lever is set
toP.
Depress the brake pedal during the
starting procedure. Do not depress
accelerator.
The selector lever lock is released.
Press KEYLESS-GO start/stop
button1 once.
The engine starts if the SmartKey with
KEYLESS-GO is in the vehicle.Starting difficulties
If the engine does not start as described,
carry out the following steps:
If you are starting the engine with the
SmartKey, turn SmartKey in starter
switch to position0 and repeat starting
procedure.
If you are starting the engine with
KEYLESS-GO: Close any doors that
may be open to allow for better detec-
tion of the SmartKey with
KEYLESS-GO.
Or:
Start the engine with the SmartKey as
radio signals from another source may
be interfering with the SmartKey with
KEYLESS-GO.
Repeat the starting procedure
(
page 51). Remember that extended
starting attempts can drain the battery.
Get a jump start (page 423).
Warning!G
As long as the SmartKey with KEYLESS-GO
is in your vehicle, the vehicle can be started.
Therefore, never leave children unattended
in the vehicle, as they could otherwise acci-
dentally start the engine.
When leaving the vehicle, always take the
SmartKey with KEYLESS-GO with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle.

62 Getting started
Parking and locking
Locking with the SmartKey
After exiting the vehicle, press lock
button‹ on the SmartKey
(
page 36).
With the trunk and all doors closed:

All turn signal lamps flash three
times.

An acoustic signal sounds three
times.
For more information, see “Factory
setting” (
page 106).

The locking knobs in the doors
move down.

The anti-theft alarm system is
armed.
For more information, see “Locking and
unlocking” (
page 100).
Locking with KEYLESS-GO*
1Lock button
After exiting the vehicle, press lock
button1 at the outside door handle or
on the trunk lid.
With the trunk and all doors closed:

All turn signal lamps flash three
times.

An acoustic signal sounds three
times.
For more information, see “Factory
setting” (
page 106).

The locking knobs in the doors
move down.

The anti-theft alarm system is
armed.
For more information, see “Locking and
unlocking” (
page 100).
iIf you hear a warning signal you have forgot-
ten to switch off the low beam headlamps or the
parking lamps before opening the driver’s door.
In addition the message
Switch Off Lights
appears in the multifunction display.
Switch off the low beam headlamps or the park-
ing lamps.
If the message
Switch Off Lights or
Remove Key
appears in the multifunction dis-
play remove the SmartKey from the starter
switch or switch off the automatic headlamp
mode.
!Failure to switch off the exterior lamps when
leaving the vehicle may result in a discharged
battery.

97 Safety and Security
Anti-theft systems
Anti-theft systems
Immobilizer
The immobilizer prevents unauthorized
persons from starting your vehicle.
Activating
With the SmartKey
Remove the SmartKey from the starter
switch.
The immobilizer is activated.
With KEYLESS-GO*
Press the KEYLESS-GO start/stop but-
ton once.
The engine is turned off.
Open the driver’s door.Deactivating
With the SmartKey
Turn the SmartKey in the starter switch
to position2 (
page 38).
With KEYLESS-GO*
Start the engine by means of the
start/stop button on the gear selector
lever.
Anti-theft alarm system
Once the alarm system has been armed, a
visual and audible alarm is triggered when
someone opens

a door

the trunk

the hood
The alarm will stay on, even if the activat-
ing element (a door, for example) is imme-
diately closed.
The alarm system will also be triggered
when

someone attempts to raise the vehicle
(only vehicles with tow-away alarm)

the vehicle is opened with the
mechanical key

someone opens a door from the inside
iIn case the engine cannot be started (yet the
vehicle’s battery is charged), the system is not
operational. Contact an authorized
Mercedes-Benz Center or call
1-800-FOR-MERCedes (in the USA), or
1-800-387-0100 (in Canada).

100 Controls in detail
Locking and unlocking
In the “Controls in detail” section you will
find detailed information on how to oper-
ate the equipment installed on your vehi-
cle. If you are already familiar with the
basic functions of your vehicle, this section
will be of particular interest to you.
To quickly familiarize yourself with the ba-
sic functions of the vehicle, refer to the
“Getting started” section of this manual.
The corresponding page numbers are giv-
en at the beginning of each segment.
For more information on locking and
unlocking, see “Getting started”
(
page 36) and (page 59).
SmartKey
Your vehicle comes supplied with two
SmartKeys, each with remote control and
a removable mechanical key.
The SmartKey provides an extended oper-
ating range. To prevent theft, however, it is
advisable to only unlock the vehicle when
you are in close proximity to it.
The SmartKey centrally locks and unlocks:

the doors

the trunk

the fuel filler flap
SmartKey with remote control
1‹Lock button
2ŠOpening button for trunk
(
page 109)
3Mechanical key locking tab
4ŒUnlock button
5Battery check lamp
6ÂPanic button (
page 88)
!To prevent possible malfunction, avoid ex-
posing the SmartKey to high levels of electro-
magnetic radiation.

101 Controls in detail
Locking and unlocking
Factory setting
Warning!G
When leaving the vehicle, always remove the
SmartKey from the starter switch, take it
with you, and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. It is possible
for children to open a locked door from the
inside, which could result in an accident
and/or serious personal injury.
iWhen you open a door, the side window on
that side lowers slightly. Once you close the
door, the window moves up again.
!The side windows will not open or close if
the battery is discharged or the windows are cov-
ered with ice. As a result, you may no longer be
able to properly close the door. Do not attempt
to force the door shut. Doing so may damage the
door or the side window. Correct the condition
that prevents the windows from operating before
attempting to close the door.
iUSA only:
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interfer-
ence, and
(2) this device must accept any interference re-
ceived, including interference that may
cause undesired operation.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
iCanada only:
This device complies with RSS-210 of Industry
Canada. Operation is subject to the following
two conditions:
(1) This device may not cause interference, and
(2) this device must accept any interference re-
ceived, including interference that may
cause undesired operation of the device.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
iYou can also open and close the windows
and tilt/sliding sunroof using the SmartKey
(
page 208).
!If you can no longer lock or unlock the vehi-
cle with the SmartKey, then the batteries in the
SmartKey are discharged, the SmartKey is mal-
functioning or the vehicle battery is drained.

Check the batteries in the SmartKey
(
page 103) and replace them if necessary
(
page 402).

Use the mechanical key to unlock the driv-
er’s door (
page 398) and the trunk
(
page 399).

Have the vehicle battery checked by an au-
thorized Mercedes-Benz Center.
If the SmartKey is malfunctioning, contact an au-
thorized Mercedes-Benz Center.
iWhen unlocking or locking the vehicle with
the SmartKey an acoustic signal sounds. The
acoustic signal is activated at the factory. If you
wish to deactivate the feature, or adjust its signal
volume, contact an authorized Mercedes-Benz
Center.
