78 Safety and SecurityDriving safety systemsPRE-SAFE
® Brake can react to stationary
obstacles such as standing or parked vehi-
c le s a t roa d s pe eds of up to ap proxim a tel y
40 mph (70 km/h).

Activating and deactivating: Activate
or deactivate PRE-SAFE
® Brake using
the instrument cluster control system
(
page 298).
After the function has been activated,
indicator : appears on the
left-hand side of the multifunction dis-
play.PRE-SAFE
® Brake does not always clearly
interpret complex traffic situations. If a vi-
sual and/or acoustic warning is issued in
an uncritical driving situation, or if the ve-
hicle brakes lightly, you can interrupt the
PRE-SAFE® Brake maneuver by


pressing down all the way on the accel-
erator or using kickdown


releasing the brake pedal
The PRE-SAFE
® Brake maneuver is termi-
nated immediately when


you avoid the obstacle by evasive
steering


you drive less than 9 mph (15 km/h)


an obstacle can no longer be identified
ahead of you


the system no longer senses the risk of
a collisionAfter a hard collision or damage to the
front of the vehicle from an accident, have
the settings and operation of the radar
sensors checked by an authorized
Mercedes-Benz Center.
Warning!
G
If you do not receive visual or acoustic warn-
ing signals, PRE-SAFE
® Brake has either not
recognized the collision risk, has been deac-
tivated or is malfunctioning. Apply the
brakes yourself to avoid a collision.
i
PRE-SAFE
® Brake will remain passive while
DISTRONIC Plus* is switched on (
page 443).

255 Control systems
COMAND system settings
COMAND system settings
Systems settings menu overviewDisplay settings
Switching the display on or off
Switching off: Select “Vehicle”

“Display OFF”.

Switching back on: Rotate ymz or
slideqmr.Setting the display design

Select “Vehicle”
“System Settings”

“Display”.

Select “Day Mode”, “Night Mode” or
“Automatic”.
Time settings
Setting the time
Select “Vehicle”
“System Settings”

“Time”
“Time”.

Selecting hour or minute(s):
Slideomp.
i
The components and operating principles of
COMAND can be found on (
page 83).
Display
(page 255)
Time
(page 255)
Voice Control
(page 257)
Language
(page 258)
Favorite
(page 259)
Reset
(page 255)
Display settings
Time settings
Voice Control set-
tings
Language settings
Assign favorite but-
ton
Reset COMAND to
factory settings
i
In the “Automatic” setting, COMAND ana-
lyzes the automatic vehicle light sensor and
switches between the display design automati-
cally.
i
The correct time must be set for the follow-
ing navigation system functions to operate cor-
rectly:


Route guidance on routes with time-depen-
dent traffic guidance


Calculation of estimated arrival time


285 Control systems
Instrument cluster control system
Telephone* (
page 294)
Assistance* (
page 298)
Service (
page 299)
Settings (
page 301)
Commands/submenusDialing a number from the
phone book
Displaying the distance graphic*,
DISTRONIC Plus*
Calling up vehicle malfunction,
warning and system status
messages stored in memory
Setting daytime running lamp
mode (USA only)
Redialing
Activating/deactivating
PRE-SAFE
® Brake* (vehicles with
DISTRONIC Plus* only)
Checking tire inflation pres-
sure
Switching additional
speedometer on or off
Answering a call
Switching on or off Rear View
Camera* automatically
Calling up maintenance service
display
Switching on or off radar
sensors*
Ending a call or rejecting an
incoming call
Switching on or off Blind Spot
Assist*
Checking engine oil level
(CL 600)

301 Control systems
Instrument cluster control system
Settings menu
In the “Settings” menu, you can:

switch the daytime running lamps on or
off (USA only)


switch the additional speedometer on
or off


switch the radar sensors* on or off
(USA only)
Setting daytime running lamp mode
(USA only)

Press ( or & to select the “Set-
tings” menu.

Press % or $ to select the “Day-
time Running Lamps” function.

Press #.

Press # again if you would like to
change the current status.
Depending on the previous status, the
daytime running lamps will be switched
on or off.
With “Daytime Running Lamps” mode se-
lected and the exterior lamp switch at po-
sition M or *, the low beam
headlamps are switched on when the en-
gine is running.
In low ambient light conditions the follow-
ing lamps will switch on additionally:


Parking lamps


Tail lamps


License plate lamps


Side marker lamps
For more information on the daytime run-
ning lamp mode (
page 393).Showing or hiding additional
speedometer
You can have an additional digital speed-
ometer shown on the multifunction dis-
play. The speed is shown in the unit of
kilometers/hour (USA) or miles/hour
(Canada).

Press ( or & to select the “Set-
tings” menu.

Press % or $ to select the “Add.
Speedometer” function.

Press #.

Press # again if you would like to
change the current status.
Depending on the previous status, the
additional speedometer will be
switched on or off.
i
The menu overview can be found on
(
page 284).
i
This function is not available in countries
where the daytime running lamp mode is manda-
tory and therefore in a constant mode.
i
If you turn the exterior lamp switch to anoth-
er position, the corresponding lamp(s) will
switch on.
i
Make sure that the light switch is set
toB or * when you switch off the day-
time running lamps while driving at night.

302 Control systemsInstrument cluster control systemSwitching on or off radar sensors*
If your vehicle is equipped with DISTRONIC
Plus*, BAS Plus*, or Park Assist* it is
equipped with a radar sensor system
which you can switch on and off.
When travelling in Canada in a vehicle not
registered in Canada, you must switch off
the radar sensor system. Canadian law
does not permit the use of the radar sensor
system for vehicles from outside of Cana-
da. When you switch off the radar sensor
system, the following functions are
deactivated:

BAS Plus* (
page 68)


PRE-SAFE
® Brake* (
page 75)


DISTRONIC Plus* (
page 443)


Park Assist* (
page 467)


Advanced Parking Guidance*
(page 471)


Blind Spot Assist* (
page 485)

Press ( or & to select the “Set-
tings” menu.

Press % or $ to select the “Ra-
dar Sensors” function.

Press #.

Press # again if you would like to
change the current status.
Depending on the previous status, the
radar sensors will be switched on or
off.
i
USA only:
This device has been approved by the FCC as a
“Vehicular Radar System”. The radar sensor is
intended for use in an automotive radar system
only. Removal, tampering, or altering of the de-
vice will void any warranties, and is not permitted
by the FCC. Do not tamper with, alter, or use in
any non-approved way.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
i
Canada only:
This device complies with RSS-210 of Industry
Canada. Operation is subject to the following
two conditions:
(1) This device may not cause interference, and
(2) this device must accept any interference re-
ceived, including interference that may
cause undesired operation of the device.
Removal, tampering, or altering of the device will
void any warranties, and is not permitted. Do not
tamper with, alter, or use in any non-approved
way.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
i
The selected status of the radar sensors re-
mains stored in memory even if the engine is
turned off and restarted.
i
The following message appears in the multi-
function display if the radar sensors are
switched off and you attempt to activate
DISTRONIC Plus*, Park Assist* or PRE-SAFE
®
Brake*:
“Radar Sensors
(See Oper. Manual)
Disabled”

383 Controls in detail
Mirrors
Auto-dimming rear view mirrors
The reflection brightness of the exterior
rear view mirror on the driver’s side and
the interior rear view mirror will respond
automatically to glare when

the ignition is switched on
(page 365)
and


incoming light from headlamps falls on
the sensor in the interior rear view
mirror
The interior rear view mirror will not react if


reverse gear R is engaged
and


the interior lighting is turned on
Warning!
G
The auto-dimming function does not react if
incoming light is not aimed directly at the
sensors in the interior rear view mirror.
The interior rear view mirror and the exterior
rear view mirror on the driver’s side do not
react, for example, if the rear window sun-
shade is in raised position.
Light hitting the mirror(s) at certain angles
(incident light) could blind you. As a result,
you may not be able to observe traffic con-
ditions and could cause an accident.
Warning!
G
Exercise care when using the passen-
ger-side exterior rear view mirror. The mirror
surface is convex (outwardly curved surface
for a wider field of view). Objects in mirror
are closer than they appear. Check your in-
side rear view mirror or glance over your
shoulder before changing lanes.

400 Controls in detailWindshield wipersCombination switch1Switching on windshield wipers
2Single wipe
Wiping with windshield washer fluid

Switch on the ignition (
page 365).
Switching on/off windshield wipers
Turn the combination switch to the de-
sired position depending on the inten-
sity of the rain.
MWindshield wipers off
USlow intermittent wiping
(rain sensor operation low sen-
sitivity)
VFast intermittent wiping
(rain sensor operation high sen-
sitivity)
uSlow continuous wiping
tFast continuous wiping
!
If the windshield wipers leave smears on the
windshield after the car has been driven through
an automatic car wash, then wax or other resi-
due is on the windshield. Shortly after washing
the car in an automatic car wash, clean the wind-
shield with windshield washer fluid
(
page 401).
!
Do not operate the wipers when the wind-
shield is dry. Dust that accumulates on a wind-
shield might scratch the glass and/or damage
the wiper blades when wiping occurs on a dry
windshield. If it is necessary to operate the wip-
ers in dry weather conditions, always operate
the wipers with windshield washer fluid
(
page 401).
!
If anything blocks the windshield wipers
(leaves, snow, etc.), switch them off immediate-
ly.


For safety reasons, stop the vehicle in a safe
location,

turn off the engine by turning the
SmartKey to position0 and withdraw
SmartKey from starter switch
or


turn off the engine by pressing the
KEYLESS-GO* start/stop button
(page 366) and open the driver’s door
(with the driver’s door open, starter
switch is in position0, same as with
SmartKey removed from starter switch)
before attempting to remove any blockage.


Remove blockage.


Turn the windshield wipers on again.If the windshield wipers fail to function at all with
the combination switch in position u,


set the combination switch to the next high-
er wiper speed


have the windshield wipers checked at the
nearest authorized Mercedes-Benz Center

401 Controls in detail
Windshield wipers
Intermittent wiping
Only switch on intermittent wiping under
wet weather conditions or in the presence
of precipitation.

Turn the combination switch to posi-
tion U or V.
The wipers move across the wind-
shield. Afterward, the wiping intervals
are determined by the wetness of the
windshield.
After the initial wipe, pauses between
wipes are automatically controlled by the
rain sensor.
Single wipe
Press the combination switch briefly in
the direction of arrow2 (
page 400)
to the resistance point.
The windshield wipers wipe one time
without washer fluid.
Wiping with windshield washer fluid
Press the combination switch in the di-
rection of arrow2 (
page 400) past
the resistance point.
The windshield wiper operates with
washer fluid.
For information on filling up the washer
reservoir, see “Windshield washer system
and headlamp cleaning system”
(
page 560).
i
When the windshield wipers are switched on
and you brake the vehicle to a stop, the wipers
operate more slowly.
!
Do not leave windshield wipers on an inter-
mittent setting when the vehicle is taken to an
automatic car wash or during windshield clean-
ing. Wipers will operate in the presence of water
sprayed on the windshield, and windshield wip-
ers may be damaged as a result.
!
If you have set intermittent wiping, dirt on
the surface of the rain sensor or optical effects
may cause the windshield wipers to wipe in an
undesired fashion. This could then damage the
windshield wiper blades or scratch the windows.
You should therefore switch off the windshield
wipers when weather conditions are dry.
i
Intermittent wiping is interrupted when the
vehicle is at a standstill and a door is opened.
This protects persons getting into or out of the
vehicle from being sprayed.
Intermittent wiping will be continued when


both doors are closed and the automatic
transmission is set to positionD orR
or


the wiper setting is changed using the com-
bination switch
i
To prevent smears on the windshield or
noisy/chattering wiper blades, wipe with wind-
shield washer fluid every now and then even
when it is raining.
