359 Operation
Tires and wheels
Uniform Tire Quality Grading Standards
A tire information system that provides
consumers with ratings for a tire’s traction,
temperature and treadwear. Ratings are
determined by tire manufacturers using
government testing procedures. The
ratings are molded into the sidewall of the
tire.
Vehicle maximum load on the tire
Load on an individual tire that is
determined by distributing to each axle its
share of the maximum loaded vehicle
weight and dividing it by two.
Rotating tiresTire rotation can be performed on vehicles
with tires of the same dimension all
around. If your vehicle is equipped with
tires of the same dimension all around,
tires can be rotated, observing a
front-to-rear rotation pattern that will
maintain the intended rotation (spinning)
direction of the tire (
page 334).
In some cases, such as when your vehicle
is equipped with mixed-size tires (different
tire dimension front vs. rear), tire rotation
is not possible.
If applicable to your vehicle’s tire configu-
ration, tires can be rotated according to
the tire manufacturer’s recommended in-
tervals in the tire manufacturer’s warranty
pamphlet located in your vehicle literature
portfolio. If none is available, tires should
be rotated every 3 000 to 6 000 miles
(5 000 to 10 000 km), or sooner if neces-
sary, according to the degree of tire wear.
The same rotation (spinning) direction
must be maintained (
page 334). Rotate tires before the characteristic tire
wear pattern becomes visible (shoulder
wear on front tires and tread center wear
on rear tires).
Thoroughly clean the mounting face of
wheels and brake disks, i.e. the inner side
of the wheels/tires, during each rotation.
Check for and ensure proper tire inflation
pressure.
For information on wheel change, see the
“Practical hints” section (
page 440).
Warning!G
Rotate front and rear wheels only if the tires
are of the same dimension.
If your vehicle is equipped with mixed-size
tires (different tire dimensions front vs.
rear), tire rotation is not possible.
Warning!G
Have the tightening torque checked after
changing a wheel. Wheels could become
loose if not tightened with a torque of
96 lb-ft (130 Nm).
Only use genuine Mercedes-Benz wheel
bolts specified for your vehicle’s rims.
504 Index
services 302
System self-check 296
Telephone* 28, 152
“911” emergency call
(Audio system) 231
Answering/ending a call 163
Hands-free microphone 31
Operation 160
Operation (Audio system) 222
Phone book 162
Redialing 163
Redialing (Instrument cluster control
system) 163
Switching on/off (Audio system) 226
Temperature
Display mode 158
Interior temperature 253
Outside temperature indicator 27
Tires 340
Tightening torque, Wheel bolts 445
Tilt/sliding sunroof see Power tilt/sliding
sunroof
Time 170
TIN 358
Tire and Loading Information
Placard 335Tire Identification Number see TIN
Tire inflation pressure
Air pressure 339, 356
Checking tire pressure electronically,
Tire Pressure Monitoring System
(TPMS), (USA only) 344
Tires 331
And Rims 467
And Wheels 331
Care and maintenance 332
Chains 361
Cleaning 333
Cold tire inflation pressure 356
Direction of rotation 334
Driving instructions 315
Important notes on tire inflation
pressure 340
Inflation pressure 339
Information placard 335
Inspection 332
Load rating 349, 358
Load rating, Maximum 353, 357
Low tire pressure telltale 383
Minispare wheel 422, 471
Ply composition and material
used 358Problems under-/overinflation 339
Retreads 331
Rotating 359
Run Flat Indicator*
(Canada only) 342
Service life 332
Sizes 467
Snow 360
Speed rating 316, 350, 358
Storing 333
Temperature 340, 355
Terminology 356
Tire Pressure Monitoring System
(TPMS)*, (USA only) 344
Total load limit 358
TPMS* (USA only) malfunction
telltale 383
Traction 316, 358
Tread depth 333
Tread depth, Winter 360
Treadwear indicators 358
Vehicle maximum load on 359
Wear pattern 359
Winter 360
