GETTING STARTED
Always check the Owner’s Manual for more operating information and safety features
Lighting control knob= Lights off
= Tail, parking and
dashboard lights on: Rotate
knob to first notch
= Tail, parking, dashboard
and headlights on: Rotate knob
to second notch
= Autolamp control*:
With ignition switch in ON position;
headlights and exterior lights
automatically turn ON/OFF
depending on surrounding
darkness/lightness
A
= Foglamp control:
Pull headlamp control knob
towards you while in
,
or position
Tip: Exterior lights turn on
automatically with ignition
on, headlamp control in
Autolamp position and
windshield wipers activated
for a fixed period of time.
Turn signals/headlight high
beams/wiper/washer lever
High beams on/off: Push lever
forward to detent/pull back.
To flash high beams: Pull lever
rearward and release.
A
Ignition switch must be in ACC
or ON position.
To turn on wipers: Rotate knob (
1)
forward to increase; turn rearward
to decrease speed.
To activate washers: Push in end of
knob (1); will also operate wipers.
Rear wiper/washer
0= OFF
1= Intermittent: Rotate
knob (2) to first notch
2= Normal speed: Rotate
knob (2) to second notch
= Rear wash/wiper cycle:
Rotate knob (2) to third notch,
hold as desired
Tip: Courtesy wipe feature
will give one extra wipe a few
seconds after wipers are turned
off, this will help clear off
any residual drops left from
using the washer fluid.
Cruise control*Operates above 30 mph.
Press ON (1).
To set speed:Press and release
SET+ (2) at desired speed; hold
(2) to accelerate.
To decelerate:Press and hold
CST – (3), release at desired
speed; or tap brake pedal, press
and release (2) at desired speed.Incremental deceleration:
Press and release (3), each
tap = minus 1 mph.
Incremental acceleration:
Press and release (2), each
tap = plus 1 mph.
To cancel: Tap brake/clutch*
pedal or press OFF button (1).
Return to preset speed
(after braking):Press and
release RESUME button (4).
Tilt steering-wheel
release lever
Pull lever (5) down to unlock column
and pull up to lock column.
WARNING: Do not adjust
steering-wheel while driving
because you may lose control
of the vehicle.
Getting
Started
Getting
Started
RES
UME
SET
+
C
ST –
O
FF
ON1324
5*Denotes optional equipment
A
2
1
0
0
12

INSTRUMENT CLUSTER
Always check the Owner’s Manual for more operating information and safety features
WARNING LIGHTS
• Anti-lock BrakeSystem (ABS)
ABS malfunction, normal brakes
only, dealer inspection required
• Always fasten seat belts
• Air bag readiness Front or side air bag malfunction,
dealer inspection required
• High beams on
• Cruise control on*,see Getting Started
• Door ajar
• Brake system Parking brake on/low brake fluid

• Overdrive off indicator*, see Transaxle
• Check engine indicator Dealer inspection required if light
remains on, see Owner’s Manual
• Engine oil pressure Stop car when safe and turn
off engine; check oil level
• Charging system Charging system malfunction;
dealer inspection required
• Turn signals/hazard warning on
• Low fuel
• Check fuel cap Fuel cap not securely tightened
• Anti-theft on
• Throttle control/ powertrain
Illuminates when a powertrain
or throttle body fault has been
detected; dealer inspection
required if indicator remains on
• Tire Pressure MonitoringSystem (TPMS),
see Getting Started
• Traction Control System (TCS)/Dynamic
Stability Control (DSC)/
Roll Stability Control (RSC)
Light flashes when system is
activated while driving; dealer
inspection required if light
remains on
Instrument Cluster
Instrument Cluster
*Denotes optional equipment
GAUGES
1. Tachometer
2. Speedometer
3. Fuel gauge 16.5-gallon/62-liter tank
(2.3L and 3.0L). 4. Odometer/trip odometer
selector
Press to toggle between
odometer and trip odometer.
Tip: Press and hold for more
than 1 second to reset trip
odometer.
5. Odometer
6. Coolant temperature gauge
If above normal range, stop
vehicle and turn off engine, check
coolant level when safe.
4x1000r/min3
2
1
0 5
EF
6
7
453.2
2081.4TRIP
A80mph
200 180
160
140
120
100
80
60
40
20 012 010 0
80
60
40
20
CH
3126
45
O/D
OFF

UNDER HOOD
Always check the Owner’s Manual for more operating information and safety features
1. Windshield washer
reservoir
Fill with windshield washer
fluid, not water.
2. Engine coolant reservoir
Level should be at cold fill level
or within the cold fill range
when cold.
WARNING: Never remove
coolant reservoir cap while
engine is running or hot;
remove only when system
is cool.
3. Brake/clutch fluid
reservoir
Fill to MAX mark with DOT 3
fluid, check with cap on.4. Air filter
5. Power distribution box
6. Battery
7. Engine oil filler cap
5W-20 engine oil.
8. Hood latch
9. Engine oil dipstick
Check with engine off and
at normal temperature; oil
level should be within
crosshatched area of dipstick.
10. Automatic transaxle
fluid dipstick*
Check with engine on at
operating temperature; fluid
level should be within
crosshatched area.
Under Hood
Under Hood
Tip: Check all fluids with
vehicle parked on a level
surface and engine off
unless otherwise stated.
*Denotes optional equipment
8 17 69 2310 4 51698 27 3410 5
2.3L Engine 3.0L Engine

DRIVING TIPS
Always check the Owner’s Manual for more operating information and safety features
Driving Tips
Tire economy and tipsCheck pressure monthly when
tires are cold, see Owner’s Manual
for rotation schedule and chart.
Tire pressure Decal on driver’s door latch
pillar provides tire size and
pressure information.
Tire chains**
†Tire chains can damage
aluminum wheels; use on
steel wheels only.
Tips: Use only SAE class “S”
chains, install only on front
axles if vehicle is 2WD
(with P235/70R16 tires) and
on both axles if 4WD.
Install as tightly as possible
and retighten periodically.
Never exceed 30 mph with
tire chains.
Anti-lock Braking
System (ABS)
ABS automatically reduces
hydraulic pressure to any wheel
on the verge of locking up.
You may feel a slight pulsing of
the brake pedal and hear a clicking
noise; this tells you the ABS is
functioning properly; increase pressure
on pedal for maximum braking.
Tips: Maintain constant
pressure on the brake pedal.
Do not pump the brakes.
ABS self test
A self-diagnostic test is performed
when starting; you may feel some
brake pedal pulsation and hear
some noise, this is normal.Traction Control System (TCS)
Enhances traction and safety
by regulating engine torque.
When TCS detects drive wheel
slippage it lowers engine torque
to prevent loss of traction.
Dynamic Stability Control (DSC)
Controls braking and engine
torque in conjunction with ABS
and TCS to help control side slip
on slippery surfaces or during
sudden or evasive maneuvering.
Roll Stability Control (RSC)
System determines when corrective
action is needed; by controlling
engine torque and braking
on each wheel.
Tip: For additional service
details, see Owner’s Manual.
Break-in period
First 1,000 miles: Avoid heavy
repeated brake use; avoid full
throttle, rapid acceleration or
kick-down of transaxle; drive at
varying road and engine speeds.
Do not tow a trailer for first 500 miles.
Do not use special break-in oils.
Tip: Follow the same procedures
with newly overhauled engine
or when brakes are replaced.
Normal maintenance notes
Change engine oil/replace filter
every 5,000*/7,500 miles; rotate
tires every 7,500 miles or sooner
if needed; replace cabin air filter
every 25,000 miles or 24 months.
A.Change: Engine oil/replace filter
Inspect: Engine coolant level, brake
fluid level, tire inflation pressure
and tire wear, power steering
fluid level, washer fluid level
Lube: Locks and hingesB.Inspect: Disc brakes
C.Inspect: Drive belts (3.0 liter),
fuel lines and hoses, brake lines,
hoses and connections, drum
brakes, steering operation and
linkages, front and rear suspension
ball joints, driveshaft dust
boots, exhaust system heat
shields, chassis/bodybolts and
nuts, cooling system and hoses
Replace: Fuel filter
D.Inspect: Drive belts (2.3 liter)
Replace: Air filter
E.Inspect: Hoses and tubes
for emission system
F. Replace: Spark plugs
Inspect: Engine valve clearance
(2.3 liter), adjust if noisy
G.Replace: PCV valve (3.0 liter),
engine coolant (yellow)
7,500 miles
15,000 miles
22,500 miles
30,000 miles
37,500 miles
45,000 miles
52,500 miles
60,000 miles
67,500 miles
75,000 miles
82,500 miles
90,000 miles
A A C
A A D F A
A B C E A A
A D
A B C
A A
A B
5,000 miles*A
97,500 miles
G 100,000 miles* Special operating conditions
** Denotes optional equipment†See Owner’s Manual
