2008 MAZDA MODEL TRIBUTE HEV alarm

Vehicle Symbol Glossary
Rear Window
Defrost/Demist
Power Windows
Power Window LockoutPersonal Alarm System
Feature
Engine OilEngine Coolant
Engine Coolant
TemperatureDo Not Open When Hot
BatteryAvoid Smoking, Flames,
or Sparks
Battery AcidExplosive Gas
Fan WarningPower Steering Fluid
Maintain Correct Fluid
LevelMAX MIN
Service Engine Soon
Engine Air FilterSpeed Control
Passenger Compartment
Air FilterJack
Check Fuel CapLow Tire Pressure
Warning
INFORMATION ABOUT THIS GUIDE
The information found in this guide was accurate at the time of printing.
Mazda may change the contents without notice.
2008 Tribute Hybrid (thv)
Owners Guide (post-2002-fmt)
USA (fus)
Introduction
17

REMOTE ENTRY SYSTEM (IF EQUIPPED)
The Integrated Keyhead Transmitter (IKT) complies with part 15 of the
FCC rules and with RSS-210 of Industry Canada. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.
The typical operating range for your
IKT is approximately 33 feet (10
meters). A decrease in operating
range could be caused by:
•weather conditions,
• nearby radio towers,
• structures around the vehicle, or
• other vehicles parked next to
your vehicle.
The IKT allows you to:
• remotely unlock the vehicle
doors.
• remotely lock all the vehicle
doors.
• remotely open the power liftgate glass.
• activate the personal alarm.
• operate the illuminated entry feature.
The remote entry lock/unlock feature operates in any ignition position
except while the key is held in the 4 (START) position. The panic
feature operates with the key in the 1 (LOCK) position.
If there are problems with the remote entry system, make sure to take
ALL Integrated Keyhead Transmitters with you to the authorized
dealer in order to aid in troubleshooting the problem.
Two step door unlocking
1. Pressand release to unlock the driver’s door. Note:The interior
lamps will illuminate if the lamp is in the DOOR position.
2008 Tribute Hybrid (thv)
Owners Guide (post-2002-fmt)
USA (fus)
Locks and Security
88

2. Pressand release again within three seconds to unlock the
passenger doors, the liftgate and liftgate glass.
The battery saver feature will turn off the interior lamps 10 minutes after
the ignition is turned to the 1 (OFF/LOCK) position.
One step door unlocking
If the one step door unlocking feature is activated, press
and release
once to unlock all of the doors, the liftgate and liftgate glass. Note:The
interior lamps will illuminate (refer to Illuminated entryinformation
later in this section), if the control on the overhead lamp is in the DOOR
position.
Switching from two step to one step door unlocking
Unlocking can be switched between two step and one step door
unlocking by pressing and holding both
andbuttons
simultaneously on the remote entry transmitter for approximately 4
seconds. The turn signal will flash twice to indicate that the vehicle has
switched to one step unlocking. Repeat the procedure to switch back to
two step unlocking.
Locking the doors
1. Pressand release to lock all the doors. Assuming all vehicle
doors and the liftgate are properly closed and the park/turn lamps
will flash once.
2. Press
and release again within three seconds to confirm that all
the doors and liftgate are closed and locked. Note:The doors will
lock again and the horn will chirp once.
If any of the doors or the hood are not properly closed, the horn will
chirp twice and park/turn lamps will not flash when the
control is
pressed.
Opening the liftgate (if equipped)
Presstwice within 3 seconds to open the liftgate glass.
Car finder
Press
twice within 3 seconds. The horn will chirp and the turn lamps
will flash. It is recommended that this method be used to locate your
vehicle, rather than using the panic alarm.
2008 Tribute Hybrid (thv)
Owners Guide (post-2002-fmt)
USA (fus)
Locks and Security
89

Sounding a panic alarm
Press and hold
for 1.5 seconds to activate the alarm. To deactivate
the feature, press the control again, turn the ignition to the 3 (RUN) or 4
(START) position, or wait for the alarm to time out in approximately 3
minutes.
Note: The panic alarm will only operate when the ignition is in the 1
(LOCK) position.
Replacing the battery
The Integrated Keyhead Transmitter uses one coin type three-volt
lithium battery CR2032 or equivalent.
To replace the battery:
1. Twist a thin coin in the slot of the IKT near the key ring in
order to remove the battery
cover.
2. Do not wipe off any grease on the battery terminals on the
back surface of the circuit
board.
3. Remove the old battery. Note:Please refer to local regulations when
disposing of transmitter batteries.
4. Insert the new battery. Refer to the instructions inside the IKT for the correct orientation of the battery. Press the battery down to
ensure that the battery is fully seated in the battery housing cavity.
5. Snap the battery cover back onto the key.
Note: Replacement of the battery will notcause the IKT to become
deprogrammed from your vehicle. The IKT should operate normally after
battery replacement.
2008 Tribute Hybrid (thv)
Owners Guide (post-2002-fmt)
USA (fus)
Locks and Security
90

WARNING: Add-On Electrical and Electronic Equipment:
Incorrectly choosing or installing improper add-on equipment or
choosing an improper installer could be dangerous. Essential
systems could be damaged, causing engine stalling, air-bag
(SRS) activation, ABS inactivation, or a fire in the vehicle. Be
very careful in choosing and installing add-on electrical
equipment, such as mobile telephones, two-way radios, stereo
systems, and car alarm systems.
Mazda assumes no responsibility for death, injury, or expenses that may
result from the installation of add-on non-genuine parts or accessories.
SERVICE PUBLICATIONS
Factory-authorized Mazda service publications are available for owners
who wish to do some of their own maintenance and repair.
When requesting any of our publications through an Authorized Mazda
Dealer, refer to the chart below.
If they don’t have what you need in stock, they can order it for you.
PUBLICATION ORDER NUMBER PUBLICATION DESCRIPTION 9999 95 062B 08 WORKSHOP MANUAL
9999 95 038G 08 WIRING DIAGRAM 9999 95 014C 08 OWNER’S MANUAL
WORKSHOP MANUAL:
Covers recommended maintenance and repair procedures of the drive
train, body and chassis.
WIRING DIAGRAM:
Provides electrical schematics as well as component location for the
entire electrical system.
OWNER’S MANUAL:
This booklet contains information regarding the proper care and
operation of your vehicle. This is not a technician’s manual.
Please note that your Authorized Mazda Dealership has trained
personnel and special service tools to correctly and safely
maintain Mazda vehicles.
2008 Tribute Hybrid (thv)
Owners Guide (post-2002-fmt)
USA (fus)
Customer Assistance
240

doors ..........................................87
Lubricant specifications ...........281
Lug nuts ....................................221
Luggage rack ...............................84
M
Manual transmission fluid capacities ........................281
lubricant specifications ..........281
Message center ...........................74 english/metric button ...............78
system check button ................76
warning messages .....................79
Mirrors ...................................65, 68 automatic dimming rearview
mirror ........................................65
fold away ...................................68
heated ........................................68
side view mirrors (power) .......68
Moon roof ....................................73
Motorcraft parts ........................264
N
Navigation system .......................41
O
Octane rating ............................268
Oil (see Engine oil) ..................253
P
Parking brake ............................189
Passenger Occupant
Classification Sensor .................107
Power distribution box
(see Fuses) ...............................207 Power door locks ........................87
Power mirrors .............................68
Power point .................................61
Power Seats .................................99
Power steering ..........................190
Power Windows ...........................64
Preparing to drive
your vehicle ...............................190
R
Radio ............................................27
Relays ........................................204
Remote entry system .................88
illuminated entry ......................91
locking/unlocking doors .....88–89
opening the trunk .....................89
panic alarm ...............................90
replacement/additional
transmitters ...............................91
replacing the batteries .............90
Roof rack .....................................84
S
Safety Canopy ...........................130
Safety defects, reporting ..........241
Safety restraints ........105, 109–113 Belt-Minder ...........................115
extension assembly ................114
for adults .........................110–112
for children .....................135–136
Occupant Classification
Sensor ......................................107
seat belt maintenance ............114
warning light and chime ........115
Safety seats for children ..........139
2008 Tribute Hybrid (thv)
Owners Guide (post-2002-fmt)
USA (fus)
Index
306
