2008 LINCOLN MKZ check engine

BRAKE FLUID
The fluid level will drop slowly as
the brakes wear, and will rise when
the brake components are replaced.
Fluid levels between the “MIN” and
“MAX” lines are within the normal
operating range; there is no need to
add fluid. If the fluid levels are
outside of the normal operating
range the performance of the
system could be compromised; seek
service from your authorized dealer
immediately.
TRANSAXLE FLUID
Checking 6–speed automatic transmission fluid
Refer to yourscheduled maintenance informationfor scheduled
intervals for fluid checks and changes. Your transaxle does not consume
fluid. However, the fluid level should be checked if the transaxle is not
working properly, i.e., if the transaxle slips or shifts slowly or if you
notice some sign of fluid leakage.
Checking automatic transmission fluid at normal operating
temperature (140°F-158°F [60°C-70°C])
Automatic transmission fluid expands when warmed. To obtain an
accurate fluid check, drive the vehicle until it is warmed up
(approximately 20 miles [30 km]) until the engine coolant gauge
indicates normal operating temperature. If your vehicle has been
operated for an extended period at high speeds, in city traffic
during hot weather or pulling a trailer, the vehicle should be
turned off for about 30 minutes to allow fluid to cool before
checking.
1. Drive the vehicle 20 miles (30 km) or until the coolant gauge indicates
normal operating temperature.
2. Park the vehicle on a level surface and engage the parking brake.
3. With the parking brake engaged and your foot on the brake pedal,
start the engine and move the gearshift lever through all of the gear
ranges. Allow sufficient time for each gear to engage (approximately
10–15 seconds in each position).
4. Move the gearshift lever to P (Park) and leave the engine running.
2008 MKZ(378)
Owners Guide (post-2002-fmt)
USA(fus)
Maintenance and Specifications
263

5. Remove the dipstick, wiping it clean with a clean, dry, lint-free rag. If
necessary, refer toIdentifying components in the engine compartment
in this chapter for the location of the dipstick.
6. Install the dipstick making sure it is fully seated in the filler tube.
7. Remove the dipstick and inspect
the fluid level. The fluid should read
within the hot range on the dipstick
if at normal operating temperature
(140°F-158°F [60°C-70°C]).
Checking automatic transmission fluid at cool temperature
(59°F-77°F [15°C-25°C])
If a fluid check is necessary at a low
fluid temperature (59°F-77°F
[15°C-25°C]), perform the check
using the cold range on the dipstick.
However, the fluid must be
re-checked at the proper fluid temperature.
Low fluid level
Do not drive the vehicle if the fluid
level does not show at all on the
dipstick.
Driving the vehicle with less than
the recommended fluid level may result in transaxle failure. An under fill
condition of transmission fluid may cause shift and/or engagement
concerns and /or possible damage to the transaxle.
High fluid level
Fluid levels above the normal
operating range may result in
transaxle failure. An overfill
condition of transmission fluid may
cause shift and/or engagement
concerns and/or possible damage to
the transaxle.
High fluid levels can be caused by an overheating condition.
2008 MKZ(378)
Owners Guide (post-2002-fmt)
USA(fus)
Maintenance and Specifications
264

Item Capacity Ford part nameFord part number /
Ford specification
Automatic transmission
fluid7.4 quarts (7.0L)
3
Motorcraft Premium
Automatic Transmission
FluidXT-8-QAW /
WSS-M2C924-A
Rear Differential (AWD)
fluid2.4 pints (1.15L)Motorcraft SAE 80W-90
Premium Rear Axle
LubricantXY-80W90-QL /
WSP-M2C197-A
Power Transfer Unit
(PTU) fluid (AWD)
4
12 ounces (0.35L)Motorcraft SAE 75W-140
Synthetic Rear Axle
LubricantXY-75W140-QL /
WSL-M2C192-A
Windshield washer fluid 4.75 quarts (4.5L)Motorcraft Premium
Windshield Washer
ConcentrateZC-32-A /
WSB-M8B16-A2
Fuel tank (front-wheel
drive)17.5 gallons
(66.2L)——
Fuel tank (all- wheel
drive)16.5 gallons
(62.5L)——
1Use of synthetic or synthetic blend motor oil is not mandatory. Engine oil need only meet the
requirements of Ford specification WSS-M2C930-A and the API Certification mark.2Add the coolant type originally equipped in your vehicle.3Indicates only approximate dry-fill capacity. Some applications may vary based on cooler size and
if equipped with an in-tank cooler. The amount of transmission fluid and fluid level should be set
by the indication on the dipstick’s normal operating range.4The Power Transfer Unit is lubricated for life with synthetic lube. Lubricant levels are not to be
checked or changed unless a leak is suspected or repair required. Replace Power Transfer Unit
lubricant with specified synthetic lubricant anytime the unit is submerged in water.
See your authorized dealer for fluid level checking or filling of the Power Transfer Unit.
2008 MKZ(378)
Owners Guide (post-2002-fmt)
USA(fus)
Maintenance and Specifications
269

The Vehicle Identification Number (VIN) contains the following
information:
1. World manufacturer identifier
2. Brake system / Gross Vehicle
Weight Rating (GVWR) / Restraint
System
3. Vehicle line, series, body type
4. Engine type
5. Check digit
6. Model year
7. Assembly plant
8. Production sequence number
TRANSMISSION/TRANSAXLE CODE DESIGNATIONS
You can find a
transmission/transaxle code on the
Safety Compliance Certification
Label. The following table tells you
which transmission or transaxle
each code represents.
Description Code
Aisin AW F21 Automatic transaxle (TR-VX) B
2008 MKZ(378)
Owners Guide (post-2002-fmt)
USA(fus)
Maintenance and Specifications
272

A
Accessory delay ..........................58
Air cleaner filter ...............265–267
Air conditioning ....................31, 33
Airbag supplemental
restraint system ........125, 134, 137
and child safety seats ............127
description ..............125, 134, 137
disposal ....................................140
driver airbag ............127, 135, 138
indicator light .........134, 136, 140
operation .................127, 135, 138
passenger airbag .....127, 135, 138
side airbag ...............................134
All Wheel Drive (AWD),
driving off road .........................193
Antifreeze
(see Engine coolant) ................245
Anti-lock brake system
(see Brakes) ......................184–185
Anti-theft system ................96, 100
arming the system ..................100
disarming a triggered
system .....................................101
Audio system (see Radio) .........16
Automatic transmission
driving an automatic
overdrive .................................189
fluid, adding ............................263
fluid, checking ........................263
fluid, refill capacities ..............268
fluid, specification ..................268
Auxiliary input jack (Line in) ....23
Axle
lubricant specifications ..........268
B
Battery .......................................243acid, treating emergencies .....243
jumping a disabled battery ....214
maintenance-free ....................243
replacement, specifications ...267
servicing ..................................243
Belt-Minder
.............................120
Booster seats .............................141
Brakes ........................................184
anti-lock ...........................184–185
anti-lock brake system (ABS)
warning light ...........................185
fluid, checking and adding ....263
fluid, refill capacities ..............268
fluid, specifications .................268
lubricant specifications ..........268
parking ....................................185
shift interlock ..........................188
Break-in period .............................5
Bulbs ............................................42
C
Capacities for refilling fluids ....268
Cell phone use ..............................7
Changing a tire .........................208
Child safety restraints ..............141
child safety belts ....................141
Child safety seats ......................144
attaching with tether straps ..148
in front seat ............................145
in rear seat ..............................145
Child safety seats - booster
seats ...........................................141
Cleaning your vehicle
engine compartment ..............230
instrument panel ....................231
interior .....................................232
plastic parts ............................230
2008 MKZ(378)
Owners Guide (post-2002-fmt)
USA(fus)
Index
275

washing ....................................228
waxing .....................................229
wheels ......................................229
wiper blades ............................231
Climate control (see Air
conditioning or Heating) ......31, 33
Clock ............................................55
Compass, electronic
set zone adjustment .................72
Console
overhead ....................................54
Controls
power seat ...............................103
steering column ........................62
Coolant
checking and adding ..............245
refill capacities ................249, 268
specifications ..........................268
Cruise control
(see Speed control) ....................60
Cupholder(s) .............................111
Customer Assistance ................199
Ford Extended Service
Plan ..........................................224
Getting assistance outside
the U.S. and Canada ..............225
Getting roadside assistance ...199
Getting the service you
need .........................................220
Ordering additional owner’s
literature .................................226
Utilizing the
Mediation/Arbitration
Program ...................................224
D
Daytime running lamps
(see Lamps) ................................38Dipstick
automatic transmission fluid .263
engine oil .................................239
Driving under special
conditions ..................191, 194, 196
sand .........................................195
snow and ice ...........................197
through water .................196, 198
E
Electronic message center .........69
Emergencies, roadside
jump-starting ..........................214
Emission control system ..........259
Engine ........................................270
cleaning ...................................230
coolant .....................................245
fail-safe cooling .......................250
idle speed control ...................243
lubrication specifications .......268
refill capacities ........................268
service points ..........................237
starting after a collision .........201
Engine block heater .................182
Engine oil ..................................239
change oil soon warning,
message center .......................239
checking and adding ..............239
dipstick ....................................239
filter, specifications ........242, 267
recommendations ...................242
refill capacities ........................268
specifications ..........................268
Event data recording ....................6
Exhaust fumes ..........................182
F
Fail safe cooling ........................250
2008 MKZ(378)
Owners Guide (post-2002-fmt)
USA(fus)
Index
276

locking and unlocking doors ....96
programming entry code .........95
Keys .......................................79, 98
positions of the ignition .........179
L
Lamps
autolamp system .......................37
bulb replacement
specifications chart ..................42
daytime running light ...............38
fog lamps ...................................38
headlamps .................................37
headlamps, flash to pass ..........39
instrument panel, dimming .....39
interior lamps ...........................41
replacing bulbs .........................43
Lane change indicator
(see Turn signal) ........................41
Lights, warning and indicator ....10
anti-lock brakes (ABS) ..........185
Load limits .................................172
Locks
autolock .....................................82
childproof ..................................86
doors ..........................................81
Lubricant specifications ...........268
Lug nuts ....................................213
Lumbar support, seats .............105
M
Message center .....................69–70
english/metric button ...............74
system check button ................74
warning messages .....................75
Mirrors ...................................58–59automatic dimming rearview
mirror ........................................58
heated ........................................60
programmable memory ............90
side view mirrors (power) .......59
Moon roof ..............................64, 89
Motorcraft parts ........233, 251, 267
N
Navigation system .......................30
O
Octane rating ............................255
Oil (see Engine oil) ..................239
P
Parking brake ............................185
Parts (see Motorcraft parts) ....267
Passenger Occupant
Classification Sensor .................113
Power distribution box
(see Fuses) ...............................205
Power door locks ........................81
Power mirrors .............................59
Power point .................................55
Power steering ..........................187
fluid, checking and adding ....262
fluid, refill capacity ................268
fluid, specifications .................268
Power Windows ...........................56
Power windows
opening using remote entry
system .......................................89
R
Radio ............................................16
2008 MKZ(378)
Owners Guide (post-2002-fmt)
USA(fus)
Index
278
