2008 Lexus IS250 filter

323
4-3. Do-it-yourself maintenance
4
Maintenance and care
■Checking interval
Inspect and replace the air conditioning filter according to the maintenance sched-
ule. In dusty areas or areas with heavy traffic flow, early replacement may be
required. (For scheduled maintenance information, please refer to the “Owner's
Manual Supplement/Scheduled Maintenance”.)
■If air flow from the vents decreases dramatically
The filter may be clogged. Check the filter and replace if necessary.
■Cleaning method
If the filter is dirty, clean by blow-
ing compressed air through the
filter from the downward side.
Hold the air gun 2 in. (5 cm)
from the filter and blow for
approximately 2 minutes at
72 psi (500 kPa, 5.0 kgf/cm
2
or bar).
If it is not available, have the
filter cleaned by your Lexus
dealer.
■ Replacement method
Remove the air conditioning fil-
ter from the filter case and
replace it with a new one.
The “UP” marks shown on the
filter and the filter case should
be pointing up.

324
4-3. Do-it-yourself maintenance
NOTICE
■To prevent damage to the system
●When using the air conditioning system, make sure that a filter is always installed.
●When cleaning the filter, do not clean the filter with water.

410
6-1. Specifications
Lubrication system
*: 5W-30 is an oil that provides optimal levels of fuel efficiency.
Oil viscosity
● The 5W portion of the oil viscosity rating indicates the characteristic of
the oil which allows cold startability . Oils with a lower value before the W
allow for easier starting of the engine in cold weather.
● The 30 in 5W-30 indicates the oil viscosity when the oil is at its operating
temperature. An oil with a higher viscosity may be better suited if the
vehicle is operated at high speeds, or under extreme load condition.
IS250IS350
Oil capacity
(drain and refill)
with filter
2WD models
AWD models
6.6 qt. (6.3 L, 5.5 lmp.qt.)
6.8 qt. (6.4 L, 5.7 lmp.qt.)6.6 qt. (6.3 L, 5.5 lmp.qt.)

without filter
2WD models
AWD models
6.2 qt. (5.9 L, 5.2 lmp.qt.)
6.3 qt. (6.0 L, 5.3 lmp.qt.)6.2 qt. (5.9 L, 5.2 lmp.qt.)
Oil gradeILSAC multi-grade engine oil
Recommended oil
viscosity
Use Lexus approved “Toyota Genuine Motor Oil” or
equivalent to satisfy the grade and viscosity shown
below.
Outside temperature

450
Alphabetical index
Alphabetical index
A/C ............................................................. 192
ABS.............................................................. 170
AFS .............................................................. 144
Adaptive front lighting system ......... 144
Air conditioning filter .......................... 322
Air conditioning systemAir conditioning filter ....................... 322
Automatic air conditioning system .................................................... 192
Airbags Airbag operating conditions.............81
Airbag precautions for your child.......................................................... 85
Airbag warning light ..........................361
Curtain shield airbag operating
conditions.............................................. 82
Curtain shield airbag precautions .......................................... 85
Front passenger occupant classification system......................... 90
General airbag precautions ........... 85
Locations of airbags............................ 79
Modification and disposal of airbags .................................................... 89
Proper driving po sture ............. 77, 85
Side airbag operating conditions.............................................. 82
Side airbag precautions .................... 85
SRS airbags ............................................. 79 Alarm .............................................................74
Antenna ....................................................208
Anti-lock brake system ........................170
Armrest .................................................... 255
Ashtrays.................................................... 248
Audio input.............................................. 228
Audio system
Antenna.................................................. 208
Audio input ........................................... 228
AUX adapter ...................................... 228
CD player/changer ............................. 211
MP3/WMA disc..................................217
Optimal use ..........................................225
Portable music player ..................... 228
Radio ....................................................... 204
Steering wheel audio switch.........229
Automatic air conditioning system ......................................................192
Automatic headlight leveling system ......................................................145
Automatic light control system.........143
Automatic transmission Automatic transmission ....................122
If the shift lever cannot be shifted from P....................................392
S mode ..................................................... 124
AUX adapter ......................................... 228A

456
Alphabetical index
Keyless entry.............................................. 34
KeysElectronic key ......................................... 20
Engine switch........................................... 117
If you lose your keys......................... 393
If the electronic key does not operate properly ............................ 394
Key number ............................................. 20
Keyless entry ........................................... 34
Keys ............................................................. 20
Mechanical key...................................... 20
Wireless remote control key .......... 34
Light bulbs Replacing ............................................... 342
Wattage.................................................. 420
Lights Door courtesy lights........................... 231
Fog light switch .....................................146
Headlights switch ................................ 143
Interior light switch ............................ 234
Outer foot lights ................................... 231
Overhead courtesy light.................. 231
Personal light switch ........................ 234
Replacing light bulbs........................ 342
Scuff lighting ........................................... 231
Shift lever lighting ................................ 231
Turn signal lever ...................................128
Vanity lights .......................................... 243
Wattage.................................................. 420
Load capacity .......................................... 182 Maintenance
Do-it-yourself maintenance......... 286
General maintenance..................... 282
Maintenance data ............................. 406
Maintenance requirements.......... 280
Manual transmission .............................126
Meter Instrument panel lig ht control ......... 131
Meters ....................................................... 130
Micro dust and pollen filter ................196
Mirrors Inside rear view mirror ...................... 60
Side mirror heater............................. 200
Side mirrors............................................... 61
Vanity mirrors ......................................243
Moon roof................................................... 66
MP3 disc .................................................... 217
Multi-information display ....................139
Odometer ................................................ 130
Oil Engine oil............................................... 295
Opener
Fuel filler door .........................................69
Hood ....................................................... 289
Trunk..............................................................41
Outer foot lights Outer foot lights................................... 231
Wattage ................................................. 420
Outside rear view mirrors Adjusting and folding ........................... 61
Mirror position memory ....................46
Outside temperature display ........... 140
Overhead console ............................... 238K
L
M
O

464
GAS STATION INFORMATION
Auxiliary catch leverP. 2 8 9Trunk openerP. 4 1Fuel filler door P. 6 9
Hood lock release lever P. 2 8 9Fuel filler door openerP. 6 9Tire inflation pressureP. 4 1 5
Fuel tank capacity17.2 gal. (65 L, 14.3 lmp.gal.)
Fuel typeUnleaded gasoline only P. 70, 409
Cold tire inflation
pressureP. 4 1 5
Engine oil capacity
(Drain and refill)
qt. (L, Imp.qt.)
IS250 IS250
(2WD models) (AWD models) IS350
With filter 6.6 (6.3, 5.5) 6.8 (6.4, 5.7) 6.6 (6.3, 5.5)
Without filter 6.2 (5.9
, 5.2)6.3 (6.0, 5.3) 6.2 (5.9, 5.2)
Engine oil type
Toyota Genuine Motor Oil or equivalent
Oil grade: ILSAC multigrade engine oil P. 410
Recommended oil viscosity: SAE 5W-30
