2008 Lexus IS F inflation pressure

TABLE OF CONTENTSIndex
4
Power outlet .................................... 241
Seat heaters .................................... 242
Seat heaters and ventilators .... 244
Armrest ............................................ 246
Trunk storage extension............ 247
Coat hooks ..................................... 249
Floor mat......................................... 250
Trunk features................................. 251
Garage door opener .................. 254
Compass.......................................... 259
4-1. Maintenance and care............ 264 Cleaning and protecting the vehicle exterior................... 264
Cleaning and protecting the vehicle interior .................... 267
4-2. Maintenance ............................. 270 Maintenance requ irements ..... 270
General maintenance ................ 272
Emission inspection and maintenance (I/M)
programs ...................................... 275 4-3. Do-it-yourself
maintenance............................ 276
Do-it-yourself service precautions .................................. 276
Hood.................................................. 279
Positioning a floor jack.............. 280
Engine compartment.................. 282
Tires ................................................... 296
Tire inflation pressure................. 307
Wheels................................................. 311
Air conditioning filter................... 313
Electronic key battery ................. 316
Checking and replacing fuses ................................................. 318
Headlight aim................................. 332
Light bulbs ....................................... 334
5-1. Essential information .............. 340 If your vehicle needs to be towed ...................................... 340
If you think something is wrong ......................................... 346
Fuel pump shut off system ........ 347
Event data recorder ................... 348
4Maintenance and care
5When trouble arises

7
: If equipped
Tires
●Replacement
● Inflation pressure
● Information
P. 374
P. 407
P. 412
Tail lights P. 139
Side marker lights P. 139
Trunk P. 41
Rear window defogger P. 194
Doors P. 37
Fuel filler door P. 67
Rear turn signal lights
P. 126

Maintenance and care4
263
4-1. Maintenance and care ............................... 264
Cleaning and protecting the vehicle exterior............. 264
Cleaning and protecting the vehicle interior .............. 267
4-2. Maintenance .................. 270 Maintenance requirements ........................ 270
General maintenance .......... 272
Emission inspection and maintenance (I/M)
programs................................ 275 4-3. Do-it-yourself
maintenance ................ 276
Do-it-yourself service precautions ............................ 276
Hood ........................................... 279
Positioning a floor jack ......... 280
Engine compartment ........... 282
Tires............................................ 296
Tire inflation pressure........... 307
Wheels ........................................ 311
Air conditioning filter ............ 313
Electronic key battery........... 316
Checking and replacing fuses ......................................... 318
Headlight aim ......................... 332
Light bulbs ................................ 334

274
4-2. Maintenance
Vehicle exterior
ItemsCheck points
Steering wheel
• Moves smoothly?
• Has correct free play?
• No strange noises?
ItemsCheck points
Door/trunk• Operate smoothly?
Engine hood• The lock system works properly?
Fluid leaks• Is there any leakage after parking?
Ti r e
• Inflation pressure is correct?
• Tire surfaces not worn or dam-aged?
• Wheel nuts are not loose?
CAUTION
■If the engine is running
Turn the engine off and ensure that there is adequate ventilation before performing
maintenance checks.

277
4-3. Do-it-yourself maintenance
4
Maintenance and care
ItemsPa r t s a n d t o o l s
Engine oil level (P. 2 8 4 )
• “Toyota Genuine Motor Oil” or
equivalent
• Rag or paper towel, funnel (used only for adding engine oil)
Fuses ( P. 3 1 8 )• Fuse with same amperage rating as
original
Headlight aim ( P. 3 3 2 )• Phillips-head screwdriver
Radiator and condenser (P. 2 9 0 )
Tire inflation pressure ( P. 3 0 7 )• Tire pressure gauge
• Compressed air source
Wa s h e r f l u i d ( P. 2 9 5 )
• Water washer fluid containing anti-
freeze (for winter use)
•Funnel

296
4-3. Do-it-yourself maintenance
Tires
Installing tire inflation pressure warning valves and transmittersWhen replacing tires or wheels, tire pressure warning valves and trans-
mitters must also be installed.
When new tire pressure warning va lves and transmitters are installed,
new tire pressure warning valve and transmitter ID codes must be regis-
tered in the tire pressure warning co mputer and the tire pressure warning
system must be initialized. Have tire pressure warning valve and transmit-
ter ID codes registered by your Lexus dealer. ( P. 2 9 9 )
Replace tires in accordance with maintenance schedules and tread wear.
■Checking tires
New tread
Treadwear indicator
Worn tread
The location of treadwear indi-
cators is shown by the “TWI” or
“ ” marks, etc., molded on the
sidewall of each tire.
■The tire pressure warning system
Your Lexus is equipped with a tire pressure warning system that uses
tire pressure warning valves and tr ansmitters to detect low tire infla-
tion pressure before serious problems arise. ( P. 353, 362)

297
4-3. Do-it-yourself maintenance
4
Maintenance and care
Initializing the tire pressure warning system■ The tire pressure warning system must be initialized when the tire
inflation pressure is changed (such as when changing traveling
speed.)
When the tire pressure warning sy stem is initialized, the current tire
inflation pressure is set as the benchmark pressure.
■ How to initialize the tire pressure warning system
To initialize the system, use the satellite switch. ( P. 2 3 6 )
Park the vehicle in safe plac e and turn the “ENGINE START
STOP” switch to OFF.
While the vehicle is moving, initialization is not performed.
Adjust the tire inflation pressure to the specified cold tire inflation
pressure level. ( P. 4 0 7 )
Make sure to adjust the tire pressure to the specified cold tire inflation
pressure level. The tire pressure warning system will operate based on
this pressure level.
Turn the “ENGINE START STOP” switch to IGNITION ON
mode.
STEP1
STEP2
STEP3

298
4-3. Do-it-yourself maintenance
The tire inflation pressure initial-
ization setting display
Continue to press “” or “” until
the initialization setting display
appears.
It may take several minutes to com-
plete the setting. Wait for several
minutes before turning the
“ENGINE START STOP” switch to
OFF if necessary.
Recording tire inflation pressure
settings
Press and hold the “ON/OFF” but-
ton until the tire pressure warning
light blinks slowly 3 times and the
message “PRESSURE INITIAL”
showing that the initial setting is
complete is displayed on the multi-
information display.
Wait for a few minutes with the IGNITION ON mode, and then
turn the “ENGINE START STOP” switch to OFF.
STEP4
STEP5
